J-Tech Digital JTD-BT-Plug1x1 User manual

Operating Instructions
Website: www.jtechdigital.com
Toll Free: 1-888-610-2818
Email: [e-mail]
USER MANUAL
J-Tech Digital® Wireless Remote Controlled Electrical Outlet Switch
Model: JTD-BT-Plug1x1
JTD-ID: 142

Thank you for purchasing the JTD-BT-Plug1x1. J-Tech Digital products offer cost effective AV solutions to any
scenario, including security, home, commercial and live applications.
The J-Tech Digital Wireless Remote Controlled Electrical Outlet Switch is a new product based on the RF433
wireless technology. The JTD-BT-Plug1x1 can wirelessly control most devices connected to the outlet from the convenience
of your remote. Suitable for many different applications and environments, the JTD-BT-Plug1x1 will allow you to streamline
your life and enjoy the benefits of wireless control.
Please read all instructions before attempting to un-pack, install or operate this equipment. Please read all instructions
prior to connecting the power supply. Please keep the following in mind as you install this equipment.
Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to people.
To prevent fire or shock hazards, do not expose this unit to rain/moisture or install this product near water.
Never spill liquid of any kind on or into the JTD-BT-Plug1x1.
Never push an object of any kind into this product through any openings or empty slots in the unit, as you may
damage internal components.
Do not allow step on or allow any excessive weight to be placed up on this unit.
Do not connect more than rated current load device.
1 x Wall Outlet Switch
1 x Remote Control
1 x Operation Manual
Introduction
Safety Precautions
Package Contents

Easy Installation
Attractive appearance
Ease of use
RF433 radio frequency technology
Receiver Working Voltage………………………………………………………………………………………AC 110~240V-50/60Hz
Working Temperature………………………………………….……………………………….………..………………-10°C to +55°C
Relative Humidity…………………………………………….…………………………………………………………….…..10% - 93%
Remote Control Frequency………………………………………………………………………….……………………...433.92MHz
Remote Control Transmission Distance (Indoor/Outdoor)……………………………………………………10 Meters / 30 Meters
Total Power………………………………………………………………………………………………….…………………...120V/10A
Battery Life………………………………………………………………………………..……...Normal Operation More Than 1 Year
Dimensions (LxWxH)…………………….……..……………………………………………………………….………..100x55x63mm
Weight………………………………………………………………………………………………………………………...…………98g
Model…………...………………………………………………………………………………………………………...JTD-BT-Plug1x1
Single Outlet ON/OFF Pairing:
1. Plug in the remote controlled outlet into an available electrical outlet.
2. While the LED indicator is off, press and hold the “learn” button for 3 seconds until the LED indicator turns red.
3. Once the LED indicator turns red, push the “On” button on the remote. (The LED indicator on the remote controlled
outlet will flash on and off 4 times indicating that the pairing was successful.)
Clear Pairing Codes:
1. While the red LED indicator is off, hold the “learn” button on the remote controlled outlet for 7 seconds until the LED
indicator flashes four times. (This indicates that the pairing has been cleared)
Operation
Specifications
Features

Have more questions? Scan this QR code using
your smartphone to contact us!
Scan this QR code using your smartphone to
view the full J-Tech Digital Product Lineup!
www.jtechdigital.com
J-Tech Digital®
12803 Park One Drive
Sugarland, TX 77478
Product pictures are for reference only.
Specifications, pictures & software described herein are subject to change without prior notification.
Only use the provided power supply when operating this unit. J-Tech Digital® is not responsible for any damage due to customer neglect.
All trademarks are the sole property of their respective companies.
Copyright ©J-Tech Digital, Inc. All rights reserved.
