JTECH-NS24 (JTD-793) and JTECH-EX-120M-UN-T/R(JTD-791 and
JTD-792) Quick Start Guide and J-Tech Digital App Setup
This guide will show you how to properly setup the JTECH-NS24 (ZT-IPS24) 24 Port AV over IP Switch
with the JTECH-EX-120M-UN-T(Transmitter) and R(Receiver). We will also show you how to connect
your Switch to the J-Tech Digital App.
JTD-791 Package Contents
••1x HDMI Extender Transmitter
••1x 5V DC Power Adapter
••1x IR Cable Receiver
••1x User Manual
JTD-792 Package Contents
••1x HDMI Extender Receiver
••1x 5V DC Power Adapter
••1x IR Cable Transmitter
••1x User Manual
JTD-793 Package Contents
•1x User manual
•1x Warranty Card
•1x JTECH-NS24
•2x Rackmount Ears
•1x Power Cable
FRONT SIDE
BACK SIDE

2
Diagram: Completed JTD-791, JTD-792 and JTD-793 Setup
Default Switch Settings
JTD-793 Default IP:192.168.168.254
JTD-793 Default Username:admin Default Password:admin
JTD-793 Default Input Ports:1-11 Default Output Ports:12-22 Default Management Ports:23,24
HOW TO CONNECT THE TRANSMITTER (JTD-791) AND RECEIVER (JTD-792) TO THE SWITCH (JTD-793)
1)Connect the Transmitters to the Input Ports (1-11) via CAT 5E/CAT 6cable and the Receivers to the
Output Ports (12-22) via CAT 5E/ CAT 6. You can change this later.
2) Connect the source device via HDMI to the Transmitter (JTD-791) and the display device via HDMI
to the Receiver (JTD-792)

3
HOW TO CONNECT YOUR SWITCH TO YOUR NETWORK
3) Connect your Computer via CAT5E/ CAT6 to your Wireless Router.
4) Check the Wireless Router’sNetwork Configuration by running Command Prompt on Windows or
Terminal on MAC OS, enter “ipconfig” for Windows to get the Network Configuration. Enter “ifconfig”
on the Terminal on MAC OS for the Network Configuration.
Note: Network Information on your setup will be different than displayed.
5) Connect your Computer via CAT5E/CAT 6to Port 23 or 24 to the Switch.
6) Change your Computer’sStatic IP Address to the Switch’sIP Address Scheme (192.168.168.XXX)
temporarily.
IP Changing Process:Open Control Panel > Network and Internet > Network Connections > Right
Click Ethernet > Ethernet Status > Properties > Internet Protocol Version 4> Use the following IP
Address

4
Note: Network Information on your setup will be different than displayed.
7) Set your Computer back to DHCP (obtain an IP address automatically) and connect your Computer
back to your router.
8)Connect your J-Tech Switch directly to your router on port 23 or 24 in order to log back in to the
web interface using the new IP. You will also be able to login wirelessly to your network with a
laptop or desktop that is connected to the same Wireless Router.
9)Login to the switch by entering 192.168.168.254 into your web browser
Username:admin
Password:admin
10) Once logged in, go to network settings on the switch and change the scheme to match the
router, and the Subnet Mask and Default Gateway to match the router.
JTD-793 Default IP:192.168.168.254

5
Note: Network Information on your setup will be different than displayed.
HOW TO CONNECT YOUR SWITCH TO THE J-TECH DIGITAL APP
11) Download the J-Tech Digital App from the Google Play Store (Android) or from the App Store
(iOS).
12) Connect your phone or tablet to the same Wireless Router the Switch is on.
13) Locate and select the JTD-793 selection on the app homepage. Enter the IP Address you assigned
to the Switch then under “Username”: admin and “Password”: admin and tap “Save”

6
Note: Network Information on your setup will be different than displayed.
HOW TO CHANGE PORT ASSIGNMENTS AND ROUTE PORTS ON THE SWITCH
14) Logging in you will see the “Port Routing” page settings. You can change the output ports the
input ports are being directed to by selecting the boxes with the desired output port and desired
input port. You can also save these “Port Routing” selections as their own “Modes”
15) You can perform “Port Routing” and “Mode” creation and “Mode” selection on the J-Tech Digital
App.
App Port Routing App Mode Selection

7
16) You can also change the port functions on the Switch by going to “Port Setting” in the Web
Interface. By default, Ports P1-P11 are Input ports, P12-P22 are Output ports and P23 and P24 are
Management Ports.
17) You can also save these as different “Modes” we have “Mode 1-4” so you can have presets for
different uses.
18) You can also change the port settings from the J-Tech Digital App as well.
