JabloCom EYE-02 User manual
GSM Security Camera
EYE-02
Security Camera
Camera EYE-02:
Package content:
II.
B
A
12
4
3
EYE-02 camera
1Camera lens
2PIR motion sensor
3Green light 4Red light
5Infra red illumination
6GSM Antenna
7Power button
8AC adaptor socket
9USB connector
10 Battery cover
Battery
Instalation CD
Remote control
6
8
9
7
10
5
Screwdriver
User manual
AC adapter
Wall mounting screws
Connecting cable
USB cable
JR_EYE-02.ENG.MAN.Manual.16.A - 1 -
EYE-02 is a security and monitoring camera that communicates wirelessly via the GSM network.
EYE-02 integrates the following built-in detectors that allows to detect an intruder:
Detects movement by sensive detecon of human body temperature.
Recognizes the specic sound of breaking window glass
Recognizes any unwanted change in the camera‘s posion and angle
Detects changes in a scene by taking snapshots regularly and comparing them
• EYE-02 is simple to install and congure (suitable for DIY installaons)
• EYE-02 sends an alarm record using MMS, e-mail, SMS or voice call. Copies of pictures and videos can be
stored on the memory card or can be stored at a web server. Alarm Receiving Centers are also suppor-
ted.
• EYE-02 allows 24 hour monitoring via its night view mode.
• EYE-02 is compable with a wide range of external wireless devices (refer to the table on the inside back
cover of this manual).
Please refer to the picture A on the inside front cover of this manual.
1Camera lens 6GSM antenna
2PIR moon sensor 7Power buon
3Green light (LED) 8AC adaptor socket
4Red light (LED) 9USB connector
5Infra red illuminaon (LEDs) 10 Baery cover
1.1 Basic Features ........................................................... 1
1.2 EYE-02 Camera Descripon ..................................... 1
1.3 EYE-02 Camera Internal Parts ................................. 2
2.1 Package Contents ..................................................... 2
2.2 Installaon ................................................................ 3
3.1 Working Modes ........................................................ 4
3.2 Remote Control ........................................................ 4
3.3 CONFIG Mode ........................................................... 5
3.4 Proles ...................................................................... 5
3.5 Detectors .................................................................. 6
3.6 Reports & Contacts .................................................. 7
3.7 SECURITY SETTINGS ................................................. 8
4.1 Set-Up and Conguraon via PC ............................. 8
4.2 SMS Commands ....................................................... 9
4.3 Event Reports ......................................................... 10
4.4 Video Record Seng (Available through JabloTool
only) ....................................................................... 11
4.5 GSM Network Seng ...........................................12
5.1 Call Control ............................................................. 13
5.2 Night View .............................................................. 13
5.3 Monitoring ............................................................. 13
5.4 Switching OFF and ON ............................................ 14
5.5 Baery .................................................................... 14
5.6 Micro SD card ......................................................... 14
5.7 Reset to Factory Defaults ...................................... 15
5.8 External Wireless Devices .....................................15
8.1 Baery Informaon ............................................... 18
8.2 Warranty................................................................. 18
JR_EYE-02.ENG.MAN.Manual.16.A - 2 -
Please refer to the EYE-02 camera picture D on the back cover of this manual.
1Dual band GMS antenna 7Microphone + digital signal processing
• Glass-break detecon
2
EDGE/GSM module
- Picture transfer to mobile phones via MMS
or e-mail
- Data connecon to monitoring servers
and ARC
8
Short range radio
• Free band 868 MHz
• Allows cooperaon with remote controls
• Possible extension with JABLOTRON professional
wireless security system
3Buzzer
• Built-in acousc indicator 9
Tilt and vibraon detector
• Protects against intruder manipulaon with the
camera
4
Li-Ion baery
• Provides back-up energy during electricity
failure
10
Infrared reector
• Illuminates the scene by non-visible beams for
camera night vision
5SD memory card
• Extends memory capacity up to 32 GB 11 PIR infrared detector
• Excellent sensivity for human body detecon
6SIM holder
• For a standard GSM SIM card 12 VGA camera
• CMOS chip with 2.9 mm lens
Before installing the camera, ensure you have a SIM card provided by your GSM operator with an
acvate EDGE/GPRS internet connecon and MMS service.
Some SIM cards are protected by PIN code. It is necessary to disable the PIN code protecon of
the SIM card. To do this, insert the SIM into your mobile phone and disable the PIN security code.
If this is not observed, the EYE-02 camera may not operate correctly.
Unpack the camera and check the package contents. Please refer to the picture B on inside front cover of this
manual.
1 EYE-02 camera 6 Screwdriver
2 Baery 7 Wall mounng screws
3 Remote control 8 User manual
4 Installaon CD 9 AC adapter
5 USB cable 10 Connecng cable
Use only baeries, chargers and accessories approved by JABLOCOM for use with this parcular
model. The use of any unapproved device may invalidate any approval or warranty, and may be
dangerous.
JR_EYE-02.ENG.MAN.Manual.16.A - 3 -
For an extended graphic version of the installaon procedure, see the Quick Guide manual.
Before inserng SIM card into camera make sure that:
- PIN protecon is disabled
- MMS service is enabled
- Internet data access is enabled
• Insert SIM card and baery into camera
Unscrew and open the baery cover. Insert the SIM card. Insert baery and screw cover back.
• Install the camera to the selected posion
Mark and drill-out xing holes on a wall.
Mount the camera holder rmly.
Adjust the camera posion. Remove the lens protecon.
• Connect camera to power source
Plug the power cable to the camera. Plug the power adaptor to a wall socket. The camera will automacally turn on. Wait 30 seconds
and check the EYE-02 camera LED lights on the front panel.
• Enroll your mobile phone and remote control to the camera
Call the camera number from
your mobile phone. On the remote control, press the buon .
JR_EYE-02.ENG.MAN.Manual.16.A - 4 -
The EYE-02 camera has three main working modes:
,
and
.
Mode Descrip on Bu on on
the Remote Control
SLEEP
SLEEP mode is a stand-by mode of the camera. The camera doesn’t
detect any movement in the targeted area and the major detectors
are disabled. The only ac ve detectors are those that protect camera
itself against an unwanted manipula on by an intruder.
WATCH In WATCH mode camera guards fully the targeted area, all detectors
are ac ve.
CONFIG CONFIG mode allows user to change camera se ngs and switch the
camera to other special modes (ENROLL, TEST, USB). and
together
The chosen camera mode is terminated by switching to a di erent camera mode.
The package contains a wireless remote control (RC-86 type), which can be used to
switch between camera modes.
Changing a mode by using the remote control is signaled both by the LED lights on
the camera front panel, and by an acous c signal. Meaning of the LEDs and acous c
signals is as follows:
Remote control
Remote control naviga on
Lights are O .
Green light is permanently On.
Red and Green lights blink
slowly together.
Red and Green lights swap
blinks slowly.
Red light is permanently On.
The progress of the camera startup and shutdown and also the USB mode is indicated by fast green light
ashing. Entering USB mode is signalized by four long beeps.
JR_EYE-02.ENG.MAN.Manual.16.A - 5 -
CONFIG mode allows the user to change camera’s sengs.
To enter the CONFIG mode by the remote control, press and buons simultaneously – red and green
LED lights on the front panel will start to blink slowly at once.
From the CONFIG mode is possible to switch to other special modes (ENROLL, TEST, REPORT, USB).
In the ENROLL mode, the camera allows to enroll new external wireless
devices such as remote controls, detectors, sirens, etc. Also a new contact
– phone number can be enrolled in this mode by just a simple call to the
camera. ENROLL mode is terminated automacally aer one new items has
been enrolled.
TEST mode is a special mode for tesng funconality of all detectors
without causing number of unwanted alarm reports. Camera beeps
and blinks aer acvaon of any sensor.
In the REPORT mode, the camera sends a special report to all contacts
(call, MMS etc.) according to the camera sengs.
Example of an SMS from the camera: Camera EYE-02 reports:
User originated camera test External wireless device RC-80(1),
Time:13/11/2008 11:33:49.
press and buons
simultaneously for about
4 sec
In this special mode camera behaves as a standard USB ash disk. It
allows to access les on the SD memory card without installaon of
a special camera driver to PC.
Shortly power buon
on camera back panel with
connected power or USB
cable
To protect the camera’s safety, special modes will be closed automacally aer a 5 minutes meout
and the camera returns to CONFIG mode.
The EYE-02 camera allows fast and simple seng of all necessary detector parameters by selecng one of
the pre-dened PROFILEs. These proles are suitable for most camera applicaons. If necessary, the prole
may be further adjusted by the user.
HOME prole has been designed for camera installaon inside
a building (house, at, oce). During the WATCH mode, there are
no movements of people, no wind dras, no signicant temperatu-
re changes, or loud noises etc. expected.
The TILT detector is acve also in the SLEEP mode to protect the
camera against an unwanted manipulaon.
OUTDOOR prole ts best camera installaon outside your home.
The camera signicantly reduces its detectors’ sensivity in the
OUTDOOR proe as there are many possible sources that could
cause a false alarm triggering (sunshine, animals, street noise,
wind, etc.).
For outdoor installaon see chapter 5.9.
JR_EYE-02.ENG.MAN.Manual.16.A - 6 -
This prole is suitable for installaon inside your garage. It is simi-
lar to the HOME prole. Addionally, the GARAGE prole provides
a 30-second entrance delay. It allows you to open the garage or
home entrance door rst and switch the camera to the SLEEP
mode during this delay.
Prole CARE has been especially designed for monitoring small
children and elderly or disabled people.
The camera used in the CARE prole allows
the user to leave its home, stay in a short
distance away from the home and watch its
sleeping baby or ill grandmother etc.
at the same me.The camera is acvated
by any movement or by a PANIC alarm
(triggered by a personal wrist buon)
The internal acousc camera signals are disabled in the CARE prole. Also the TILT detector is bloc-
ked to allow the camera manipulaon.
The most powerful prole is SHOP. In this prole, all detectors are
acve, including the permanent process of “Moon in Picture” dete-
con. This prole oers the highest quality of permanent monitoring;
consequently it is the highest energy consumpon prole.
This prole perfectly ts places requiring a whole day monitoring and
a full protecon during the night me, such as shops, oce corridors
and recepon areas, etc.
The default prole is HOME. For switching the prole use SMS command PROFILE (For details see chapter
4.2). You can switch mode and make some addional sensor customizaon also in JabloTool soware.
The EYE-02 camera integrates a wide range of detectors. This sophiscated soluon of combining various
types of detectors enables the user to protect the desired area from a wide range of threats. This chapter
briey describes individual detector principles necessary for a correct seng of detecon.
PIR detector (Passive InfraRed sensor) or a Human Body Detector is the most common type of professional secu-
rity systems detectors. PIR can detect even very small changes of temperature dierences in front of the camera.
The key principle of this detector is derived from a professional surveillance camera system. It analyzes the
scene and detects any change in the picture permanently.
A sophiscated digital algorithm provides an excellent resistance to false alarms caused by non-essenal
changes in pictures (geng dark, switching on the street lamps, etc).
The user can simply mask-out (hide) a part of a picture in order not to detect changes in this part (mask of
the street trac, etc.) and set the sensivity according to the size and speed of change in the picture.
As the DSP method is energy demanding, MIP is usually acvated aer some alert from the PIR detector.
Glass-break detector uses a digital signal analysis from the microphone and is able to detect a characterisc
sound of the window breaking up to 9 meters away.
The Door-Opening-Detecon is a special type of the detecon that uses the acousc signal ltering. It allows
detecon of the infrasonic wave (pressure wave) caused by a door or window opening.
GBS sensor can be used for indoor installaons only.
JR_EYE-02.ENG.MAN.Manual.16.A - 7 -
Built-in lt and vibraon detector can detect a tampering or an unwanted manipulaon of the camera.
Example: Stealing the camera body or changing camera posion.
As vibraon detectors are very sensive, it should not be use for outdoor installaon to prevent
the false alarms caused by the wind gusts. The vibraon detector sensivity reducon may be
necessary also for indoor installaon with usual vibraons in some cases.
The detectors are opmized for applicaon in rooms with a maximum distance up-to 10 meters.
Each detector can be congured to 3 sensivity levels and 3 levels of analysis.
Higher sensivity sengs mean that detector si acvated more easily.
Example: Smaller movement or smaller vibraon will be interpreted as acvaon.
Higher analysis level means that for acvaon more analysis has to be made before it is rated as acvaon.
Example: The movement or sound have to last longer or object (person) has to cross more detecon zones etc..
The EYE-02 camera can report events to mobile phones (via voice call , text message , MMS ) or to
e-mail addresses. Up to 10 dierent phone numbers and 10 e-mail addresses can be saved to the camera list.
Each stored contact can have its own report level set. Three levels (Normal, Extended, All Details) indicate
how many events are reported to the contact. Normal level reported contacts will receive ALARMS only,
Extended will get also some troubleshoong informaon (power failure, at baery...) and All Details level
contacts will receive all addional events (mode changes, startup/shut down...)
By default sengs, camera sends alarm report as MMS and makes a call to all enrolled contacts. All other
reports come as SMS to the user.
The extended level of reporng is assigned only to the rst enrolled contact, all addional contacts get
normal level.
To add a new contact by calling, you can call the EYE-02 camera directly from a new phone number while the
camera is in the ENROLL mode.
New contacts may also be added via an SMS command (see chapter 4.2, CONFIG commands).
The most comfortable way of eding contacts is JabloTool soware. You may simply edit the numbers or
e-mail adresses and completely customise what events will be reported at which reporng level.
Jablotool DESKTOP - contacts conguraon
JR_EYE-02.ENG.MAN.Manual.16.A - 8 -
If there are no phones saved in the contact list (a er installing a new EYE-02 camera or a er using the
factory reset func on), the camera switches automa cally to ENROLL mode (a er power on) and waits for an
incoming call.
Camera sends e-mails with the reply address noreply@jablocom.com. Please check your e-mail
client SPAM lter to accept e-mails from this address.
Camera is not protected by any password in the factory se ngs.
Without se ng a password the camera processes incomming SMS messages or receives calls only from
phone numbers stored in Contacts. It is possible to setup two passwords. For password se ng or changing
use JabloTool or con gura on SMS commands (chapter 4.2).
This password protects any access to your camera (SMS, JabloTool).
If it is used, camera process SMS messages that begins with the password from any phone number.
This password protects camera con gura on. (The contacts are not part of con gura on.)
Password can contain 4-31 characters, allowed symbols are 0..9, a..z, A..Z. Password is not case
sensi ve.
Protect your camera by se ng the Remote Access Password.
The most convenient way to set-up the EYE-02 camera and con gure its parameters is by using PC and the
JabloTool so ware.
JabloTool is available as a so ware on the installa on CD included in the camera package.
JabloTool works remotely with the camera from www.jablotool.com.
Func on of both JabloTool versions are the same, the only di erence is in the method of connec on to the
camera - requires a connec on to the internet and establishes a cable-free connec on with
the camera, interconnects the camera with the PC by a USB cable. The advantage of the
USB connec on is a faster data transfer from the camera.
Load the installa on CD to your computer, start
the and follow the program
instruc ons.
EYE-02 connec on wit JabloTool DESKTOP
Do not connect the EYE-02 camera to the USB on your computer un l you have nished installing
the JabloTool so ware from the CD!
The latest version of the installa on so ware can be downloaded from
www.jablotool.com/download.
Turn the camera On and connect it to the computer by the USB cable. Wait un l the
opera ng system recognizes the camera. Click on the JabloTool icon on the desktop than
to load the program and follow instruc ons on the screen. JabloTool
The maximum length of a USB cable is usually 5 meters. If your EYE-02 camera is too far, you may
need to remove it temporarily from its loca on or bring your PC nearer.
JR_EYE-02.ENG.MAN.Manual.16.A - 9 -
JabloTool WEB is a service at www.jablotool.com.
User accessing its EYE-02 camera trough the Jablo-
Tool WEB will be guided to establish the connec on
to the camera. If the user is not registered or if the
EYE-02 camera is not protected by a Remote Access
Password, the user will have to send a special SMS
authoriza on command from his mobile phone
rst to ini ate the EYE-02 camera connec on to
JabloTool.
EYE-02 connec on wit JabloTool WEB
Basic EYE-02 camera func ons can be operated by text message (SMS) commands sent to the camera. Com-
mands are accepted only when sent from a mobile phone number stored in the contact list.
If the EYE-02 camera is protected by the or the , each
SMS must be introduced with the appropriate password. Using the password the camera can be operated
from phone.
Please note passwords and commands are case insensi ve.
Control commands report or change the camera state.
Switches EYE-02 camera to the
mode.
Example: <Remote Access Password> WATCH
If the camera remote access is protected by the password MIKE, the command must be
send as: MIKE WATCH
Camera will con rm the message with a status SMS.
Switches EYE-02 camera to the
mode.
EYE-02 camera will return an SMS indica ng the current camera status.
Example of a response: Camera EYE-02 status: SLEEP mode, Time: 12/11/2009 13:56:31,
SwitchX : O , SwitchY: On
Camera EYE-02 Name of your camera
SLEEP mode Current camera status
Time:12/11/2009 13:56:31 Time (date) of status report
SwitchX: O Indica on that SwitchX is curretnly o .
SwitchY: On Indicates that SwitchY is currently on.
The name SwitchX (SwitchY) can be changed to whatever you want need - see the table below.
The EYE-02 camera returns a mul media message with a picture of the current scene in
front of the camera. The message also contains current camera status.
The EYE-02 camera sends a report of the 10 latest events . Camera sends up to 5 SMS.
EYE-02 camera sends an MMS with the last alarm event recorded in the camera history.
This command has been designed especially for the prepaid SIM cards. The EYE-02 camera
will return a text message with informa on about the current credit on your SIM card.
This func on is provided by your network operator and might not work correctly on some
networks.
A er the rst using of this command camera keeps the USSD part. It’s possible to send
CREDIT command only since then.
Camera returns a text message with a list of the SMS commands.
Command is for connec ng the camera to the JabloTool server. The server describes detai-
led syntax for the command.
JR_EYE-02.ENG.MAN.Manual.16.A - 10 -
If the camera is enrolled to a wireless relay, this command switches its programmable out-
put. Parameters are ON or OFF. If you would like to make a pulse on the output, send the
command ON <me in seconds>.
Please see chapter OASiS wireless devices.
Example: SwitchX ON Switches on the PGX output of the wireless relay.
Example: <Conguraon Password> SwitchY OFF
Example: SwitchX ON 30 Switches on the PGX output for 30 seconds
CONFIG commands change the EYE-02 camera sengs. Camera conrms conguraon commands with an
SMS.
Prole seng, <prole> is
,
,
,
or
Example: CONFIG PROFILE SHOP Camera switches to the prole
Example: <Conguraon Password> CONFIG PROFILE HOME
Camera will switches to the prole
Add a new contact.
Example: CONFIG CONTACT MyEmail@domain.com
The e-mail address myemail@domain.com will be added to the EYE-02 camera
contact list, ALARM reports will be sent to this e-mail address including the video
records.
Example: <Conguraon Password> CONFIG CONTACT +555 888 770 551
The phone number +555 888 770 551 will be added to the EYE-02 camera contact
list. ALARMs will be reported to this phone number in accordance with default set-
ngs via a voice call and anMMS.
Changes the EYE-02 camera language sengs.
Camera sets the language according to the inserted SIM card automacally. If the
SIM card language is not installed in the camera, English texts remains.
Example: CONFIG LANG GER changes the default language to German.
Possible languages: ENG, GER, SPA, FRE, FIN, SWE, NOR, SQI, ARA, CZE, DAN, GRE,
HRV, HUN, ITA, DUT, POL, POR, RUM, RUS, SLK, SWE, TUR.
For the list of currently installed languages in your camera send an SMS: HELP LANG
Example of an answer from the camera:
Camera EYE-02 help: LANG ENG, CZE, GER, SPA, FRE
Changes the Exit delay mer seng, <me> is me in seconds.
Example: CONFIG DELAY 25 sets the exit delay to 25 seconds
Changes the power mode, <mode> can be NORMAL or BATTERY.
Example: CONFIG POWER BATTERY changes power mode to BATTERY mode
Sets date and me in format YYYY-MM-DD HH:MM:SS.
Example: CONFIG DATE 2009-10-24 08:34:02
Sets or changes the Remote Access Password.
Example: CONFIG ACCESS 1234 for seng the password
Example: 1234 CONFIG ACCESS 5555 for changing the password
Sets or changes the Conguraon Password.
Example: CONFIG PASSWORD 5555 for seng the password
Example: 5678 CONFIG PASSWORD 8888 for changing the password
When the camera is switched to other language than English, it sll accepts English commands as
well.
Every event detected by the EYE-02 camera is recorded into the camera’s memory.
The event record consists of the date and me mark, detail descripon of the event including its source and
a video record.
JR_EYE-02.ENG.MAN.Manual.16.A - 11 -
Example of Events history viewed by the JabloTool soware:
Jablotool Desktop - events list
There are many types of event records. The most important are ALARM reports, which are reported
to the contacts from the contact list immediately. Other types of records are the ALERT records
(similar to ALARM, but ALERTs are not reported to the contacts) or some technical reports (Example:
informaon about the AC power failure).
The EYE-02 camera allows a detail seng of all important parameters for collecng video records under
many condions.
from 20 frames per sec, to 1 frame
per 5 sec
The frequency of snapshots. Higher fre-
quency increases the video record le size.
(0 sec, 5sec, 10sec ,... 2 min, 5 min,
10 min)
Default value is 20 seconds
Camera keeps video recording for some
me period aer an ALARM.
Next snapshot (frame) will be saved to the video record le only if a change there
has been detected a changing to the previous snapshot. If the pictures are almost
the same, it will not be stored. This seng SIGNIFICANTLY reduces the video le size.
160x120, 320x240, 640x480 pixels
Default value is 320x240 pixels
Image resoluon in pixels. Higher resoluon
increases the quality of recorded pictures
but it also increases the size of video les
and lengthens the me for transfer it via
GSM network.
5 levels of JPEG compression Level of JPEG compression. Higher compres-
sion reduces the le size and slightly decrea-
ses the detail resoluon in the picture.
(OFF, 50Hz, 60Hz), default OFF If the scene is illuminated by standard
uorescent lamps, this will lter undesirable
lamp blinks. Set the standard AC power
frequency in your country.
JR_EYE-02.ENG.MAN.Manual.16.A - 12 -
+/- 2EV, with step 0.5EV, default 0 A camera calculates the best brightness of
pictures automacally. This seng allows
changing the pre-set level of brightness.
(fast, normal, slow), default normal Default seng is NORMAL. Set of FAST
in case there may be some fast moving
objects in front of the camera (cars, running
persons, etc.), SLOW is suitable mainly for
door control and dark rooms.
An internal IR lamp is automacally switched on when the lightness of the scene is
too low for normal camera funcon. This opon disables this automac funcon
and it is mostly used if the illuminaon is done by an external lamp.
A small mestamp will be inserted into the le top corner of the picture. This helps
to determinate exactly the me of the snapshot.
The video recording connues also in SLEEP mode if there is some acvity detected
in front of the camera. This is well usable for shops, petrol staons and other places
where permanent watching is required.
5 JPEG pictures will be sent by e-mail instead of AVI video les.
Please consider that even though the size of MMS and email is limited to 300 kB and 1 MB respec-
vely, sending such MMS or e-mail may take up to several minutes according to your local network
condions. To reduce the le size and fasten sending you can choose a lower image resoluon,
snapshot interval or recording duraon.
Jablotool DESKTOP - video recording conguraon
The EYE-02 camera needs correct sengs of some GSM network parameters. These parameters depend on
the country you live in and on the GSM network you use.
The EYE-02 camera can automacally adjust the correct seng for most of GSM networks. In case there are
some specic sengs of your GSM network, which you got from you GSM network operator, you can con-
gure it manually in JabloTool, Device conguraon, GSM network folder.
Please contact your GSM service provider for detail parameters seng.
JR_EYE-02.ENG.MAN.Manual.16.A - 13 -
Jablotool DESKTOP - GSM network conguraon
The EYE-02 camera provides a basic control funcon when it is called from a user’s phone. When a phone
saved in the contacts calls the EYE-02 camera, the camera answers the call and plays the basic navigaon
menu:
To listen to the sound from the camera microphone ................................ press 1,
to receive an MMS with a current picture ................................................. press 2,
to receive an MMS with the last alarm record ......................................... press 3,
to receive the latest events history in a text message .............................. press 4,
to switch the camera to the WATCH mode ............................................... press 7,
to switch the camera to the SLEEP mode .................................................. press 9.
a
The user can select a requested acon by pushing the appropriate number key on his mobile phone.
The EYE-02 camera is equipped with a Night View funcon, which allows taking the infra-red spectrum
photos.
The EYE-02 camera has a built-in infrared LED lamp, which can illuminate the scene by non-visible
infrared light. Thought the human eye can’t see such light, the camera chip can collect a picture in this
spectrum.
The infra lamp illuminaon is acvated automacally when taking a picture is requested and the level of
ambient light is too low.
The night scene may be overexposed by IR lamp reecon from close located objects. In such case
the internal IR lamp should be disabled in the camera conguraon and an external IR lamp should
be used instead. For more informaon about IR illuminaon see applicaon notes on www.jablo-
com.com .
The EYE-02 camera can report all events from the system to the professional Alarm Receiving Centre - ARC
(also known as Central Monitoring Staon).
Refer to the picture “
on the back cover page of this manual for understanding of the EYE-02 communica-
on with a commercial security agency ARC.
Reports are done in accordance with internaonal standard communicaon protocols. Protocol sengs will
be done by authorized ARC service provider once you subscribe to their service. For supported protocols see
applicaon notes on www.jablocom.com .
JR_EYE-02.ENG.MAN.Manual.16.A - 14 -
, switch it to the
mode (see chapter 3.3). Disconnect the power
and USB cables from the camera and press and hold the power buon on the back panel for .
When the green light on the front panel switches o, the camera shuts down.
, press and hold the power buon on the back panel of the camera. Keep
holding the buon unl the green light on the front panel switches on. The start-up process has started and
you can release the buon.
The camera also starts up automacally aer it is connected to the AC adaptor or to PC by a USB cable.
Whenever the camera is expected to be switched o for a longer period of me or for transporta-
on, it is strictly recommended to remove the backup baery from the EYE-02 camera.
The camera starts in the same mode it was before switching o with the following excepon: In
case you do not have enrolled any remote control and contact (phone number) camera starts in
ENROL mode in place of CONFIG or SLEEP mode. For normal operaon there must be minimum 1
remote control and 1 number enrolled in the camera.
The EYE-02 camera has an internal backup Li-Ion baery, which allows operang in case of the loss of AC
power. If used in any of the predened proles, the backup baery allows the camera to operate for approxi-
mately 24hours. Any individual sensor conguraon may shorten this period accordingly.
In case of acve MIP sensor, the backup me may be as short as 40 % of the original value. In case of simulta-
neous use of IR illuminator working during AC failure, the backup me may drop to 20 %.
Please, note that each item of network communicaon will shorten the backup me rapidly, especially if the
camera is operated in a poor network coverage area.
In certain cases, for example when used in locaons where AC power isn’t available, it may be desired to
extend the baery operaon duraon. In such case you may use the special
mode.
When in the
mode, the EYE-02 camera reduces dramacally its power consumpon in WATCH. It
logs out from the GSM network, switches o the short range radio receiver and switches on the moon-in-
picture detector only aer ALERT. It means that the EYE-02 camera, while in the
mode, can not be
reached by calls or by SMS commands. Addionally, the external detectors and remote controls cannot be
used for the BATTERY mode, too.
The EYE-02 camera keeps all the internal detectors working and reports all events as in the
mode.
Aer an ALARM, the EYE-02 camera switches on the radio and logs onto the GSM network for 2 minutes. It
reacts to calls, SMS commands and remote controls during these 2 minutes only.
A fully charged baery in the BATTERY mode can operate the EYE-02 camera for up to 30 days.
The EYE-02 camera is equipped with an SDmicro memory card slot allowing further extension of the internal
storage capacity. The EYE-02 Camera comes with an inserted 1 or 2GB memory card.
JabloTool DESKTOP soware allows you to switch the EYE-02 camera into the USB mode in which you can ac-
cess the SD card as a standard ash disc from an aached PC. To switch to the USB mode, display the device
state screen, switch it into the Advanced user mode, choose CONFIG and USB mode.
Other EYE-02 camera funcons are blocked during the PC direct access to the SD card.
When exploring the SD card, you will nd the following folder structure:
HISTORY This folder contains les with complete (all details) log of event history. Files are stored
sequenally in the “ev00001.txt” format.
PICTURE Archive of stac JPEG les recorded at ALARMs (For example: )
VIDEO Archive of AVI video les recorded during ALARMs (For example: )
cong.txt A le with the current conguraon of EYE-02 – can be used for backup or restore of
conguraon.
JR_EYE-02.ENG.MAN.Manual.16.A - 15 -
Camera keeps more than 10% of free space on the memory card. Automacally deletes old les.
The SDmicro memory card also contains some esenal data for camera. In case you replace your
card with another one always use Jablotool to restore data structures.
If necessary, the EYE-02 camera can be RESET to the factory default sengs following this guide:
Warning: All user sengs, contacts and events will be deleted! Memory card will be formated.
Events an les downloaded into the JabloTool DESKTOP soware remain in PC.
• Switch o the camera, remove the baery
• Wait at least 10 seconds
• Press the power buon and while holding it, do the following steps.
• Insert the baery
• Within 10 seconds connect the AC power adaptor
• Camera starts producing fast beeps
• Wait unl the camera makes 3 longer beeps and both LEDs (R+G) start ashing. Release the power
buon.
• Camera resets and restarts into the ENROLL mode.
The EYE-02 camera has a built-in short range radio transceiver, which allows communicaon with a wide
range of professional security wireless devices from OASiS system produced by JABLOTRON ALARMS (see
www.jablotron.com).
This is a very simple way to extend your camera funcon to provide addional services such as:
• heang control by a mobile phone
• PANIC buon funcon for elderly or disabled people.
Refer to the table on the inside back cover page of this manual for a brief review of available types of wire-
less devices.
For enrolling a new device use JabloTool soware (EYE-02/Conguraon/External devices/Add new device)
or switch the camera to the
For installing all wireless components follow their manual.
• Remote controls / panic buons: switch the camera to the , press any buon on the
remote control.
• Detectors: switch the camera to the , insert the baery in to the detector.
• JA-80L Siren: switch the camera to the , plug the siren to the wall socket.
• JA-80A Siren: switch the camera to the , connect the baery in the siren socket.
• AC-82 Wireless relay: switch the camera to the , follow the manual of AC-82. For acvang
the transmier of EYE-02 press the power buon on the camera shortly.
Once the camera is enrolled into the wireless relay, you can choose funcon of the relay outputs. Outputs
can be managed by an SMS, can signal the mode of camera, etc. For sengs go to JabloTool EYE-02/Congu-
raon/External devices/ Programmable outputs.
For more informaon about wireless devices see applicaon notes on www.jablocom.com
JR_EYE-02.ENG.MAN.Manual.16.A - 16 -
Although the EYE-02 camera housing provides a basic humidity resistance, it is required to use an addional
plasc housing when mounted outdoors to protect the camera against rain and snow. If an external housing
with a front glass is used, the internal IR illuminaon must be switched o and an external IR lamp must be
used.
Please visit the www.jablocom.com web page to see the detail applicaon notes about outdoor installaon
or usage with a solar power panel.
The EYE-02 camera doesn’t require any special maintenance.
• Check the event reporng funcon by the at least once a month.
• Regularly test the basic funcon of all detectors by the
• Regularly test the baery of the remote control by pressing any buon. If the light on your remote does
not switch on, the baery is discharged and should be replaced. Replace the baery with a new one of
same or equivalent type.
2
1
1
2
Remote control - baery replace procedure
• Once a year, check the camera‘s baery capacity – see chapter 8.1 Baery informaon.
JABLOCOM will periodically release new versions of the EYE-02 camera soware as well as the JabloTool so-
ware. Visit www.jablocom.com to nd the latest version of the EYE-02 camera rmware, supporng soware
and detailed guide to troubleshoong.
• Your SIM card is out-of-service or blocked by a PIN code – remove the SIM card the camera,
put it into your GSM phone and try to make a call and send an SMS. If PIN protected, please
remove the PIN or set it to default network value.
• Your SIM card isn’t placed in the SIM holder correctly, or the camera doesn’t support your
SIM card type. Check if the SIM card is placed in the holder correctly or contact your GSM
service provider.
• Camera locaon is not covered by GSM network signal - check the quality of GSM network
signal directly at the place of the camera installaon: place your mobile phone close to the
camera, wait a few seconds and read the signal strength from your phone display. If the
signal is too low you might try to replace original camera GSM antenna by another approved
type of GSM antenna with a higher gain.
• Flat baery in your remote control – press a buon and check if the light on your control
goes on. If not, replace the remote control internal baery.
• The remote control has been accidently deleted from the EYE-02 camera conguraon. Use
PC with JabloTool soware, open the ENROLL mode and press any buon of your remote
control to enroll it in to the EYE-02 camera.
If you discover abnormal EYE-02 camera behavior, please try to update EYE-02 camera rmware to the latest
version. To do this, use JabloTool, Conguraon, Control panel, Firmware upgrade.
JR_EYE-02.ENG.MAN.Manual.16.A - 17 -
Camera dimension 155x75x55 mm, 300 g
Package dimensions 300x215x75 mm, 950 g
Extended memory capacity SD micro card slot, maximum capacity 32 GB
Standard Package includes 1GB SD memory card
Image resoluon VGA (640x480), QVGA (320x240), QQVGA (160x120)
Picture format JPEG, EXIF 2.2
Video format MJPEG
Lens AB29, view angle 95°
Infra reector 6x Infra LED, 6x 100mW, wavelength 850nm, eming angle 80°
PIR moon detector detecon range 10m / 140°
MMS support MMS version 1.2 over WAP 2.0
Events history min 100 records in an internal memory + extension to SD card
Operang temperature -20°C to +55°C; 25 to 75 % humidity
AC power adaptor 100 - 240 V AC, 50 to 60 Hz, 5 V / 2 A DC
Input power (range) 5.0 - 6.7 V / 1 A DC
Back-up baery Li-Ion baery, 1300 mAh
GSM system Quad band 850/900/1800/1900 MHz
GSM antenna External GSM antenna +2.5 dBi, SMA connector
Data connecvity EDGE class 10; GPRS class 10: max. 85.6 kbps, CS1, CS2, CS3 and CS4,
Audio parameters AGC and Noise reducon system, HR, FR, EFR and AMR audio codec
Audio monitoring Built-in high sensivity omni-direconal microphone with DSP processing
PC connecvity USB port 2.0
Internal alarm detectors Moon-in-Picture detector
PIR moon detector
Glass break detector
Tilt and vibraon detector
Short range radio 868 MHz, Operated according to ERC REC 70-03
Remote control type RC-86
Alkaline baery type L1016 (6.0 V), Typical baery lifeme approx. 3 years
Complies with ETSI EN 300220,EN 55022, EN 50134-2,EN50130-4, EN60950-1
JR_EYE-02.ENG.MAN.Manual.16.A - 18 -
The camera is powered by an AC adaptor and has a backup rechargeable baery. The baery provides power to the camera when the
AC power fails. The baery may wear out aer some me period. The capacity of the baery should be tested at least once a year:
disconnect the AC power adaptor and measure the me unl camera announces the baery low state. Replace the baery if the me
is shorter than 10 hours for predened proles. See chapter 5.5 if you use customised prole. Always switch o the camera before
replacing baery!
Do not short-circuit the baery. Accidental short-circuing can occur when a metallic object such as a coin, clip or pen connects the
baery contacts. Short-circuing may damage the baery or the connecng object; it may even cause a re.
Exposing the baery to extremely cold or hot temperature will reduce the baery capacity and lifeme. Opmally, try to keep the
baery at temperature between 5°C and 35°C. Device with extremely hot or cold baery may not work temporarily, even if the baery
is fully charged. Baery performance is parcularly limited in temperatures well below freezing.
Do not dispose the baeries into re as they may explode. Baeries may also explode if damaged. Dispose the baeries according to
local regulaons – please recycle when possible and do not dispose them as household waste.
Do not dismantle or shred cells or baeries. In case of baery leak, do not allow the liquid to come in contact with the skin or eyes. In
case of being contacted by such leak, ush aected place with a lot of water and seek the medical help.
Hereby, JABLOCOM s.r.o., declares that this EYE-02 GSM Camera is in compliance with the essenal requirements
and other relevant provisions of Direcve 1999/5/EC.
The original conformity assessment document can be found at the web site
www.jablocom.com.
This product is designed not to exceed the limits for exposure to radio waves recommended by internaonal guidelines developed by
the independent scienc organizaon ICNIRP and include safety margins designed to assure the protecon of all persons, regardless
of age and health. The guidelines use a unit of measurement known as the Specic Absorpon Rate, or SAR. The SAR limit for wireless
devices is 2 W/kg and the highest SAR value for this camera when tested complied with this limit.
This product is in compliance with the basic restricons as specied in the European Council Recommendaon [1999 519 EC] for the
measured GSM 900, GSM 1800 and GSM 1900 standards.
This camera is only intended for use in the country which it was sold in.
Subject to the condions of this Limited warranty JABLOCOM s.r.o. warrants this product to be free from defects in design, material
and workmanship at the me of its original purchase by a customer and for a subsequent minimal warranty period under the naonal
legislaon in force. Should your product need warranty service, please return it to the dealer from whom it was purchased. The defects
will be eliminated free of charge by repairing or, at our discreon, replacing it.
If you wish to make a claim under the warranty, please return the Product with all accessories in the original packaging to your dealer.
The warranty is valid only if the original receipt issued to the original purchaser by the dealer, specifying the date of purchase and the
IMEI corresponding with the Product, is presented with the Product to be repaired or replaced. Plasc parts, cables or accessories of
the Product must not be visibly damaged, the Product must not show marks of the contact with liquid, the warranty seal must not be
broken and the fault must be described.
This warranty doesn’t cover any failure of the Product due to misuse, including but not limited to use in other than the normal and
customary manner, in accordance with instrucons for use and maintenance of the Product. Nor does this warranty cover any failure of
the product due to accident, modicaon, adjustment, improper repair or acts of God.
This warranty doesn’t apply to limited-life consumable components, such as baeries or accessories. It also doesn’t apply to modules
of other suppliers, such as SIM cards from the GSM provider.
The warranty provided doesn’t aect the consumer’s statutory rights under applicable naonal legislaon in force, or the consu-
mer’s rights against the dealer arising from their sales/purchase contract.
Under no circumstances shall JABLOCOM be responsible for any loss of data or income or any special, incidental, consequenal or
indirect damages howsoever caused.
As the product is under connuous development, JABLOCOM reserves the right to make changes and improvements to any of the
products described in this document without prior noce.
Operaons and some features are SIM card and/or network dependent.
Other manuals for EYE-02
8
Table of contents
Other JabloCom Security Camera manuals
JabloCom
JabloCom EYE-02 User manual
JabloCom
JabloCom EyeSee User manual
JabloCom
JabloCom EYE-02 User manual
JabloCom
JabloCom EYE-02 Installation and operating instructions
JabloCom
JabloCom EYE-02 User manual
JabloCom
JabloCom EYE-02 User manual
JabloCom
JabloCom EYE-02 User manual
JabloCom
JabloCom EYE-02 User manual
JabloCom
JabloCom EYE-02 Installation and operating instructions
