jablotron CA-2103 Athos User manual

CA-2103 Athos
GSM / GPS car alarm
User
Manual
ProtectionControl Options

2/ FOREWORD
Dear User,
Thank you for purchasing the CA-2103 Athos
car alarm. It is a modern security device.
You can control it with the original car remote
controls, JABLOTRON remote controls, using
the voice menu, SMS commands or through
the user-friendly MyJABLOTRON application.
The car alarm protects the car body (generally the
doors, boot, bonnet), detects handling the ignition
key and it can be supplemented with an array
of wired and wireless detectors.
This makes the product suitable for a wide range
of applications from a common family car, through
to trucks, caravans and the protection of the car’s
surroundings such as e.g. a garage.
This manual will suggest how to control your
car alarm and what you can expect from it.
To get more information about the characteristics
of the car alarm and the exact scope of the
installation (detectors used), contact your installation
company or JABLOTRON support directly
on [email protected]
We wish you to always find your car
in order whereever you have parked it.
Your JABLOTRON

Control
Using a remote control to control the car alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Control and administration through the MyJABLOTRON application . . . . . . . . . . . . . . . . . . . . . . . 5
SMS command control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Voice menu control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Protection
Alarm – attack on the car . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Acoustic and optical indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Other functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Geofence, blocking, control of appliances, SINFO, GSM interference monitoring, vehicle voltage check
Options
Forwarding of unknown SMSes, roaming, driver’s logbook, credit balance, Locator . . . . . . . . . . . . . . . 13
Warranty terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2/ FOREWORD 3/ CONTENTS

The car alarm can be either controlled with the original car remote control,
or with a JABLOTRON remote control, or a combination of these methods.
Follow the respective paragraph that corresponds to the installation type in your car.
Setting – press the key on the remote control
to set the car alarm. If the car alarm is interconnected
with the central locking, the vehicle is locked
at the same time.
Partial setting – repeatedly press the
key (within 15 s of setting) to partially set the car
alarm. In this mode, some wired and wireless
detectors are not active. E.g. the car can be loaded
onto a train or ferry without triggering a tilt alarm,
or you can move inside a caravan. At the same time,
the sensor of vehicle voltage dips is not active.
Unsetting – use the key on the remote control to
unset the car alarm. If the car alarm is interconnected
with the central locking, the vehicle is unlocked
at the same time.
Setting – the car alarm is set together with locking
the vehicle.
Partial setting – repeatedly press the lock key
to partially set the car. In this mode, some wired
and wireless detectors are not active. E.g. the car
can be loaded onto a train or ferry without triggering
a tilt alarm, or you can move inside a caravan.
At the same time, the sensor of a vehicle voltage drop
is not active. Caution! This function is not available
in all vehicle types through the car remote control.
In such a case it can be replaced by phone control
(a smartphone app, ringing or SMS).
Unsetting – the car alarm is unset together
with unlocking the vehicle.
a) Using the original car remote control b) Using a JABLOTRON remote control
Using a remote control
4/ CONTROL

4/ CONTROL 5/ CONTROL
Control and administration
through the MyJABLOTRON
application
The MyJABLOTRON application represents a very
user-friendly and simple control method It is accessible
for all customers that are registered in MyJABLOTRON.
It is available both as a web and smartphone version.
After the login to the application the main menu
is opened, displaying the current status of the car
alarm and allowing you to control the system.
The MyJABLOTRON application also allows you
to display the position of the car on a map, the history
of events and to control optional appliances.
The application can also contain an easy-to-use
driver’s logbook with vehicle monitoring.

SMS control is available from pre-registered phone numbers.
If the user code and a space are inserted before the command,
the car alarm can be controlled from any phone.
The user code can consist of 4 to 10 characters
(A to Z and 0 to 9), the default setting is 1111
(change after installation).
To change the code, you must enter the original
code and the new code twice with a space.
An example of setting the new user code petr73 is:
1111 UC petr73 petr73
An example of the SMS command to check
the car alarm status:
– from a pre-registered phone number: STATUS
– from a non-registered phone number: 1111 STATUS
SMS control and administration
6/ CONTROL

7/ CONTROL
SMS command Alarm functions
AM Car alarm setting (with JABLOTRON remote control – car locking as well) 1)
AM EXT Partial setting (with JABLOTRON remote control – car locking as well) 1)
DM Car alarm unsetting (with JABLOTRON remote control – car unlocking as well) 1)
IMO Car blocking (permanent immobilization)
UNIMO Car unblocking
STATUS Requesting an SMS about the current status of the car alarm
GPS Requesting the last established GPS position
LOCATOR Requesting an SMS about the approximate position of the vehicle 1) 2)
HELP Requesting an SMS with help
SIREN Starting the siren for 30 sec.
CREDIT Checking the credit (with the use of a prepaid SIM card) 1)
GEOFENCE ON/OFF The unit sends / does not send SMSes to specified numbers about leaving and returning
to the preset zone. 1) 3)
Command SMS for car alarm control
In SMS messages, small and capital letters are not distinguished, diacritic (accented) marks are not allowed.
Request customized settings for the texts of command SMSes or texts of alarm messages from your service centre.
1) The function must be set by a service technician.
2) The service must be supported by the operator.
3) If you use the MyJABLOTRON application, set the Geofence function directly in the application.
Frequently crossing the zone edge influences the card’s operational costs.

8/ CONTROL
Voice menu control
The menu is accessible from the registered phone numbers that are saved
in the car alarm. It can also be allowed from phone numbers that are not saved
in the alarm, but before entering the menu the caller has to enter a password.
When the call is answered by the car alarm, the caller is informed
about the system status. Then, options to use it are offered.
Main Menu
Voice menu structure
More options
1 – Setting
2– Partial setting
3 – Unsetting
4– Blocking (see below)
5– Unblocking
0– More options
1– Sending an SMS with GPS coordinates
2– Sending a status SMS
3– Activation of the AUX A output
0– Back to Main Menu

8/ CONTROL 9/ PROTECTION
Alarm – attack on the car
In the case of a car attack - by activation of one of the inputs or detectors,
the car alarm triggers an alarm. It is indicated acoustically by the siren for 30 seconds
(optional). At the same time, the car alarm communicates via the GSM network.
The car alarm sends an SMS with the exact cause of the alarm to the registered
phone number and it also informs these users with a phone call.
The alarm can be stopped with a remote control
or SMS. During an ongoing alarm, control by the
voice menu or from the application may be restricted
due to outgoing communication.
A correct termination of an alarm is reported
to registered users by means of an SMS.
The number of alarms triggered by an individual
input is limited to a max. of three in one security
cycle in the case of an input fault.
The car alarm is able to communicate with an Alarm
Receiving Centre. In such a case the vehicle is under
supervision for 24 hours a day / 7 days a week thanks
to regular communication of the car alarm with the Alarm
Receiving Centre. In the case of an alarm (but also another
technological event, e.g. disconnection of the car battery),
it is not only the user that is informed, but also the Alarm
Receiving Centre, which organizes intervention immediately.
You will get more detailed information about Monitoring
by an Alarm Receiving Centre from our regional distributor
in your country.
Protection by an Alarm Centre

10 / PROTECTION
Acoustic and optical indication
The car alarm informs the user about changes to the status or system problems
(e.g. unavailability of the GSM network) acoustically by sounding the siren.
The acoustic signal confirming unsetting and setting is optional.
Indication of partial setting and error indication cannot be disabled.
Sounding Description
1 sound setting the car alarm (optional)
2 continuous sounds partial setting
2 separated sounds unsetting (optional)
3 separated sounds unsetting after an alarm
4 separated sounds an active input on setting (optional)
6 continuous sounds unavailability of the GSM network
LED lamp Description
flashes
more quickly
logging into the GSM network is occur-
ring or the GPS signal has been lost
flashes indicating the set condition
flashes slowly the unit indicates AUTOIMO
flashes SOS (...---...) unit failure
lights permanently drive detection indication (if activated)
lights for 20 sec.
after setting the exit delay is occurring
off idle condition of the car alarm
Acoustic indication by the siren
The car alarm also indicates its status by the siren.
Optical indication by the LED
The car alarm indicates its status with an LED indicator.
Caution! If unavailability of the GSM network is indicated, the car alarm cannot communicate with the Alarm Receiving Centre
or with the registered users!

10 / PROTECTION 11 / PROTECTION
Command Status
AUXA or AUXB The relay will close for 1 second
AUXA (B) ON ON – permanent closing of the relay
(1 can be used instead of ON)
AUXA (B) OFF OFF – opening the relay
(0 can be used instead of OFF)
AUXA (B) xxM xxM – is the number of minutes for
which the output relay should be closed
AUXA (B) xxS xxS – is the number of seconds for
which the output relay should be closed
Control of appliances in the vehicle
The AUX text can be e.g. changed to HEATING text.
The maximum closing time is 60 minutes for all
command types, including ON.
Other functions
Geofence – in the car alarm you can set the
GEOFENCE function for the monitoring of leaving /
entering a defined zone. We recommend you to
entrust an installation company with setting up the
service, or use the MyJABLOTRON application.
Blocking / unblocking – the car alarm supports
blocking a functional circuit of the vehicle, preventing
its use (the function may not be supported in all
vehicle types). This happens automatically after
every setting or in the case of an alarm. You can
also activate permanent blocking with an SMS,
from the voice menu, or from the MyJABLOTRON
application to prevent use of the vehicle even after
proper unlocking. You can use this function e.g.
after your car keys get stolen.
Control of appliances in the vehicle – through
an additional module the car alarm supports
switching various appliances in the vehicle,
e.g. supplementary heating. Appliances can
be controlled by SMS, from the voice menu,
or by the MyJABLOTRON application.

12 / PROTECTION
Other functions
SINFO – this function gives registered users the option
to be informed by SMS or voice calls about every start
(setting in motion) of the vehicle.
GSM interference monitoring – to protect the communication
of the system the car alarm continuously checks
the availability of the GSM network and its quality.
If it detects interference with the network for more than
30 seconds in the set status, it will trigger an alarm.
In the unset status it only informs about this event
with an SMS. In both cases the information is transmitted
to the registered phone numbers and possibly to the
Alarm Receiving Centre.
Vehicle voltage checking – in the set status the car alarm
checks for dips in the car battery voltage (optional function).
In the case of a dip an alarm is triggered. The alarm also
checks slow decreasing of the voltage (e.g. due to lights
being on) and voltage drops below the limit endangering
protection of the vehicle, sending an SMS if needed.
The car alarm also checks for and informs about complete
disconnection of the car battery. In this case, the car alarm
is supplied from its own backup power supply.

12 / PROTECTION 13 / OPTIONS
Supplementary information
Forwarding unknown SMSes – the car alarm
can forward unknown SMSes to registered users.
Thus, they will receive messages that are delivered
to the number of the SIM card in the car alarm,
e.g. info from the operator.
Roaming – during travels abroad the car alarm
is fully functional if the SIM card has active roaming
for voice calls and SMS enabled. To check
the current status of the service, contact your
mobile operator or service provider. The services
of the MyJABLOTRON application are only active
abroad with an enabled data roaming service.
Driver’s logbook – the car alarm can send
on-line GPS positions. This allows you to check
the movement of the vehicle in real time in the
MyJABLOTRON application on a map background.
Then, an easy-to-read driver’s logbook is compiled
from these data. For activation of the service and
more detailed information, contact the installation
company.
Credit balance – if a prepaid
card is used in the car
alarm, at preset intervals
the credit balance can be
checked and you can get
informed about a decrease
under a set limit.
Locator – some mobile
operators support location
within the GSM network.
Thus, the car alarm can
offer a backup location
method in the case
of GPS unavailability.

14 / OPTIONS
Warranty terms
The installation company is responsible
for the installation.
The warranty does not cover batteries
and devices supplied by other suppliers.
The manufacturer is not liable for damage caused
by incorrect or unsuitable use of the product
or for defects caused deliberately or by force
majeure (fire, lightning strike, etc.).
The manufacturer recommends regular annual
inspections for 100% functionality of the product.
They can be ordered from the installation
company.
The CA-2103 car alarm is exclusively designed for professional installation
by a trained company. The manufacturer’s warranty covers the entire product,
not its installation.
Recommended inspection date Inspection performed on

14 / OPTIONS 15 / SUPPORT
In case of problems
Contact the company that installed the alarm.
It is generally able to give you the best advice.
Installed by
Date
Phone
Valid certificate number
Or you can directly contact the regional
distributor of JABLOTRON ALARMS
in your country.

ATHOS UZ 062016-EN MHF24500
Manufacturer:
JABLOTRON ALARMS a.s.
Pod Skalkou 33
46601 Jablonec nad Nisou
Czech Republic
[email protected]
www.jablotron.com
