Jabra HHC ADAPTER - DATASHEET CISCO User manual

Headset HookswitcH control
for cisco Unified iP PHones.
JABRA HHC
ADAPTER
JABRA®IS A REGISTERED TRADEMARK OF GN NETCOM A/S
WWW.JABRA.COM
The Jabra 14201-16 HHC Adapter enables remote Headset
Hookswitch Control (HHC*) with Jabra wireless headsets and
the latest generation of Cisco Unified IP Phones.
This means that users can hear ring tones, answer and end
calls, adjust the volume or even mute the call up to 350 ft.
away from their desks. The integration of handset and headset
allows users to benefit from enhanced mobility and the ability
to multitask while on a call. The wireless freedom improves
work efficiency and ergonomics throughout the day.
HOW IT WORKS
The HHC Adapter is a plug-and-play solution that converts from
the HHC standard used in Cisco phones to the DHSG standard
used in Jabra headsets – and vice versa.
HANDSET
-HEADSET COMPATIBILITY
The HHC Adapter is compatible with the new suite of Cisco
Unified IP Phones released September 2007: 7942G, 7945G,
7962G, 7965G and 7975G. Cisco Unified IP Phone release 8.3(3)
will enable the HHC functionality.
For more details see www.jabra.com/cisco.
DATASHEET
The HHC Adapter can be used with the
following Jabra wireless office headsets:
JABRA GN9350/JABRA GN9350e
Wireless dual-function** headset that enables
users to switch between PC-based VoIP and a
desk phone. It offers conference call capability,
up to 350 ft range, three wearing styles, up
to 9 hours talk time plus optional battery for
‘around-the-clock’ talk time.
JABRA GN9120 EHS
Award-winning wireless headset offering
up to 300 ft range, three wearing styles,
conference call capability and up to 8 hours
talk time.
JABRA GN9120 DUO EHS
Dual speaker version of Jabra GN9120 EHS
optimized for noisy open office environments.
* HHC requires Cisco Unified Communications Manager 4.1(3) or
above plus the 8.3(3) phone firmware load.

tecHnical sPecifications
SPECIFICATIONS
JABRA EHS ADAPTER Enables Headset Hookswitch Control with Cisco Unified IP Phones* and Jabra headsets
Item number 14201-16
Length of cable 925 mm (36.4 inches)
Certification CE, FCC, IC, NOM, C-Tick, China, Taiwan, Korea, Japan, Australia
Warranty North America /APAC: One-year limited warranty. Europe: Two-year limited warranty
COMPATIBILITY
Cisco Unified IP Phones* 7942G, 7945G, 7962G, 7965G, 7975G
Jabra Headsets Jabra GN9120 EHS, Jabra GN9120 DUO EHS, Jabra GN9350/Jabra GN9350e**
HHC FEATURES
Answer call Yes
End call Yes
Ring tone in headset Yes
Volume control Yes
Mute control Yes
* HHC requires Cisco Unified Communications Manager 4.1(3) or above plus the 8.3(3) phone firmware load. Available from October 2007.
** When the USB link is active calls must be answered using the headset’s button or its base rather than the Cisco Unified IP Phone.
The Jabra 14201-16 HHC Adapter has tested compatible with the listed Cisco products. The Cisco Compatible logo signifies that GN Netcom product has
undergone interoperability testing by GN Netcom together with Cisco and a third-party test house based on testing criteria set by Cisco. GN Netcom is solely
responsible for the support and warrenty of this product. Cisco makes no warrenty, express or implied, with respect to GN Netcom product or its interoperation
with the listed Cisco products and disclaims any implied warrenties of merchantability, fitness for a particular use or against infringement.
For more information on Jabra solutions for Cisco phones go to www.jabra.com/cisco.
