Jabra Pro 9450 Duo
How to connect my Jabra PRO 9450 with Nortel IP 1120E,
1140E, 1150E, 1165E
Prerequisite:
Jabra PRO 9450 + Jabra LINK 14201-32
In combination with one of the following phones:
Nortel IP 1120E
Nortel IP 1140E
Nortel IP 1150E
Nortel IP 1165E
from firmware release 3.1 for IP phones.
Connection:
1. Connect the 1-sided end (USB plug) of the EHS adapter with the USB
socket on your phone.
2. Insert the RJ9 plug into the socket marked with a "phone" symbol and
the RJ45 plug into the socket marked with "AUX" on the base.
You now have the option of setting up the headset on your phone via the
automatic or manual configuration.
Automatic configuration:
To start the automatic configuration, ask someone to call you on this
phone and wait at least 10 seconds before taking the call. The appropriate
EHS mode should now be installed.
19/01/2023 18:32
https://www.apac.jabra.com/supportpages/jabra-pro-9450/9450-29-707-
103/faq/990d213f-23b1-4173-877c-de7230746d09
Page 1 of 3

If the automatic configuration has not worked, please select DHSG mode
manually.
Base setup:
Set the phone set-up switch to position "A".
Microphone level setup:
Remove the cover from the base of the Jabra PRO 9450 and make a call
with the headset, to a colleague for example. If you are too loud or too
quiet to the person you are calling, please use the volume adjuster until
you achieve the optimum volume level.
Phone setup:
Press the "service" button twice > Default settings > Headsets > USB
In the menu, you must also activate the "Enable HID Commands" option.
See below.
