Jabra Pro 9470 Mono User manual

How do I connect my Jabra wireless headset with the Jabra
Link 14201-10 to my Aastra desk phone so I have remote call
control using my headset?
Jabra Pro 9470 Mono
Prerequisites
Jabra Link 14201-10
DHSG connection cable from Aastra
Connection:
1. Connect the AC adapter that is supplied with the headset to the
headset base, and connect the other end to an electrical outlet.
2. Connect the Jabra Link 14201-10 EHS cable with the red band to the
AUX interface on the headset base, and connect the end with the blue
band to the headset base socket that is marked with a phone icon.
3. Connect the Jabra Link 14201-10 EHS cable single end to the RJ45
adapter that is supplied with your Aastra DHSG cable kit.
4. Connect the Aastra DHSG cable kit cord with the blue band to the
RJ45 adapter. Connect the Aastra DHSG cable kit cord with the green
band to the headset interface on the Aastra desk phone, and connect
the end with the yellow band to the socket for the Aastra phone
expansion module.
24/04/2021 11:17
/supportpages/jabra-pro-9470/9470-26-904-102/faq/4428a7d3-b71c-4803-9020-
b38c440a375b
Page 1 of 2

Configuration:
1. Ensure the audio mode is set to “Headset/Speaker”, and the DHSG
mode is enabled on your desk phone. Refer to your phone or IT support
for assistance.
2. Follow the setup instructions for your Jabra wireless headset. If the
headset base requires manual configuration, set the electronic hook
switch setting to “DHSG” and set the dial tone switch to position “A”.
3. Make a call to the headset. If the volume of your voice is too loud or
quiet to the person you are calling, adjust the headset microphone
volume until you achieve the optimum level.
