Jackco SHARP ALIGN User manual

SA-1000
user's manual
Ver. 1.0

Overview:
On/O Switch
Micro USB
Charging Port
LED Power
Indicator
LED Bluetooth
Indicator

Features
Technical Specication:
Displays steering angle in real time
Interactive on-screen instructions
guide you through the process
Get measurements in minutes
Bluetooth automatically connects
when Sharp Align app is open
Detailed reports saved
Easy to compare data in list view
Add photos and notes to each report
Live camber reading screen
Steering Angle (S.A.)
Minimum Steering ±18°
Accuracy ±1.5° , S.A. <45°
Camber
Range ±25°
Resolution 0.1°
Accuracy ±0.2° , S.A. <15°
±0.3° , S.A. <25°
Caster
Range ±25°
Resolution 0.1°
Accuracy ±1.5°
Temperature
Operation 0°C~50°C
Storage -10°C~60°C
Battery
Battery Type AAA x2 Chargeable
or Primary
Consumption 123mW, (operation)
Communication
Bluetooth LE V4.0
Range 10M / 30ft.
Dimensions
Sensor Dimensions 4.33” x 2.48” x .78”

Operation
2.1 Connecting the sensor to your smart device
2.2 Fixture Assembly
1. Download App
4
0
°
3
0
°
2
0
°
1
0
°
0
°
1
0
°
2
0
°
3
0
°
4
0
°
race version
Look for and download the Sharp Align Angle Sensor App on
your smart device
If your Bluetooth is turned on, search for the Sharp Align sensor and connect. When the yellow light on
the sensor is steady on, your device has connected.

Operation
3.1 New Measurement 3.1.2 Allow Sharp Align to calibrate.
Once calibrated, a Camber reading
will show.
Follow the interactive on-screen instruction
to obtain your camber caster reading.
3. Open Sharp Align App / Main Menu
New Measurement: Starts the measurement process to get a caster and
camber on the left and right wheel.
Live Camber Angle: Reads a real-time camber angle for fast viewing.
Report: View a list of previously saved reports
Settings: Allows you to select a device and calibrate the sensor.
3.1
3.2
3.3
3.4

Operation
3.1.3 3.1.4
Follow the on-screen instructions.
Turn wheel to the left (>18°) and HOLD
When instructed, turn the wheel to the
right (>18°) and HOLD.
When measurement is complete, a Caster
reading will show.
Repeat the process on the Right by
selecting the “Right Wheel” tab at the top

Operation
3.1.5
3.1.6
Add photo to report
Current Location Weather
Delete Report
Save Report
Date/Time
of Measurement
View Report
Measurement Complete. You can let your steering
wheel go back to 0°.
Select the “Report” tab to view the report
Select the “Restart” button to restart the measurement

Operation
3.2 Live Camber Angle
Reads a real-time camber angle for fast viewing.

Operation
3.4 Settings
3.4.1 Select Device
3.4.2 Calibration
3.3 Reports
View a list of previously saved reports.
Select a report to see more details.

Sharp Align Universal Fixture Parts List
5
1
2
2
2
3
3
3
4
5
6
7
8
6
1 Center Base 11
2 Center Base Extension Rod 12
3 Spacer 13
4 Tire Holding Bracket 14
5 Tire Holding Arm 15
6 Holding Arm Adjusting Knob 16
7 Knob 17
8 Sharp Align Sensor 18
9 19
10 20
Sharp Align Universal Fixture

Environmental Protection
Warranty
Limited One (1) Year Warranty
Jackco Transnational Inc. warrants “Sharp Align” branded products to the original purchaser against any manufacturing
defect in material or worksmanship for a period of one (1) year from the original date of purchase. If the defective
product is determined to be covered under this warranty, it shall be repaired or replaced at manufacturer’s discretion
without charge. Provided that the product must be returned with proof of purchase and freight prepaid when returned
to the manufacturer. This warranty shall not apply to damage due to accident, negligent use, lack of maintenance,
abuse or applications other than the specic function the product is designed for.
No other warranties, expressed or implied, including those of merchantability or tness for particular purpose shall be
applicable to Jackco except as specically stated herein. In no event shall Jackco be liable to any party for any special,
direct, indirect, consequential, punitive damage of any nature caused by the sale or use of the equipment, tool, or
product.
Note: This warranty gives the original purchaser specic legal rights which may vary from state to state.
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and
packaging should be sorted, taken to a recycling centre and disposed of in a manner which is
compatible with the environment.
Environmental Protection
This product is manufactured for
Jackco Transnational Inc.
Made in Taiwan
For Technical Assistance, Contact us at
[phone]
www.sharpalign.com
