Jaclyn Smith 0-05531020-5 User manual

Cora Dining Table with Lazy Susan
Product code: 0-05531020-5
UPC code: 769455 766595
Vendor Item: SC-160-1NT/2
Date of purchase: _____/ _____/ _____
1
USE AND CARE GUIDE

Thank you for your purchase
Thank you for your purchase
We are pleased that you have chosen Kmart for your outdoor furniture purchase.
We hope that you enjoy the unmatched quality, comfort, and style of your new patio
set. Every piece is meticulously considered all the way down to the smallest details,
exclusively for you, by our world class design team. We know you have a choice when
it comes to your patio furniture needs, so from our team to yours, thank you for letting us
be a part of your outdoors.
Table of Contents
Table of Contents.................................... 2
Safety Information................................... 3
Set Up your Furniture Properly.............3
Examine your furniture..........................3
Warranty................................................... 3
Care and Maintenance............................ 4
Pre-Assembly...........................................4
Planning Assembly.............................. 4
Observe weight Limits......................... 4
Hardware Included.............................. 4
Assembly Instructions
Package Contents................................. 5
Table....................................................... 6
Customer Service..................................7
2

Safety Information
SET UP YOUR FURNITURE PROPERLY
Ensure that all parts are assembled properly and fully tightened as per the instructions.
When placing in the desired location, ensure that all legs are resting on the same
surface. You may adjust the legs levelers as required to ensure that the item stands
in a rigid position.
EXAMINE YOUR FURNITURE
Examine occasionally to ensure that there are no loose parts. If loose parts are found,
they must be retightened fully before additional use.
Warranty
WARRANTY
We warrant our products to be free of manufacturing defects to the original purchaser for
the period listed below. We reserve the right to make substitutions with similar merchandise,
if the model in question is no longer in production.
EXCLUSIONS
This warranty does not cover: Furniture used for commercial or non-residential purposes;
failures caused by improper care; unreasonable or abusive use; freeze damage; acts of
nature. Steel products are not covered against rust. Tempered glass table tops are not
covered against breakage.
FINISH
Frame finish is warranted to be free of manufacturing defects for a period of one (1) year.
Discoloration or fading of the finish as a result of exposure to the elements, chemicals, or
spills is not covered.
FABRIC
Fabric is warranted to be free of manufacturing defects for a period of one (1) year.
Discoloration or fading of the finish as a result of exposure to the elements, chemicals, or
spills is not covered.
FRAMES
Frame is warranted to be free from defects in material or workmanship for a period of
one (1) year for steel frame.
FREIGHT & PACKAGING
Freight and packaging are the responsibility of the original purchaser.
CUSTOMER SERVICE
3
In case of a problem, call 1-800-457-4652 between 9:00 am to 5:00 pm Eastern standard
time Monday through Friday or contact us at www.numarkcustomerservice.com for
any question or problems you may have.

Care and Maintenance
Pre-Assembly
Read through all the instructions before beginning assembly. Unpack and identify all the parts.
Place them on a flat, non-abrasive surface. Assembly by two people is recommended.
PLANNING ASSEMBLY
HARDWARE INCLUDED
NOTED: Hardware not shown
to actual size.
4
Though its powder-coated finish is rust-resistant, steel is prone to rust over time with
exposure to the elements. In case of rust or scratches, lightly sand the affected area
and apply touch-up paint. To maintain the finish periodically apply wax with a soft cloth.
Wash frames with a mild solution of soap and water; rinse thoroughly. Do not use
bleach or solvents.
OBSERVE WEIGHT LIMITS
The recommended weight limits for the following products are listed below:
Table: 100 lbs
CAUTION: If you overload your
furniture, injuries can occur.
Always use anumbrella base tosecureumbrella. Do not store anything on
glass tabletop. Ensure the “o” ring is in place in the umbrellahole in the
glass top before inserting umbrella. Make sureumbrella is in the closed
position when not in use and during high winds. Use furniture covers or store
indoors during cold or inclement weather.
Fa (1 spare)
Short Bolt
Fb (1 spare)
Long Bolt
Fc (1)
Allen Wrench
Fd (1)
Umbrella
Insert Piece

Assembly Instructions
Package Contents
Safety Information
Do not completely tighten bolts until indicated in assembly step.
5
Pre-Assembly
A Tempered Glass Tabletop (8 Metal Washers and 8 Bolts attached)
B Leg (2 Metal Washers and 2 Bolts attached for each)
C Metal Center Ring
D Plastic Swivel Base
E Glass Lazy Susan Top
ITEM DESCRIPTION QUANTITY
1
4
1
1
A
E
D
B
B
B
BC
1

6
Assembly Instructions
1
Attaching the table legs to the tabletop
Fa
Fa
A
B
A
B
Fa x 8
Short Bolt
(remove from the tabletop)
Metal Washer x 8
(remove from the tabletop)
Repeat procedure for the remaining three legs.
2
Attaching the center ring to the table leg
C
B
Fa
Fb
Fa x 4
Short Bolt
(remove from the leg)
Fb x 4
Long Bolt
(remove from the leg)
Metal Washer x 8
(remove from the leg)
Note: the arrow faces downwards.
Repeat procedure for the remaining three legs.

Assembly Instructions
3
Placing the plastic swivel base and glass lazy susan on the tabletop
D
E
Note: the plastic bumper faces upwards.
4Inserting the umbrella insert piece into the umbrella hole on the table
Fd
Fd x 1
Umbrella
Insert Piece
Your table is now ready for use. Enjoy!
7
Tighten all bolts in a diagonal pattern.
D
Made in / Hecho en CHINA for Kmart Corporation, Hoffman Estates, IL 60179
For questions or comments about product:
Call toll-free: 1-800-457-4652
between 9:00 am to 5:00 pm Eastern standard time Monday through Friday
or contact us at www.numarkcustomerservice.com
Please refer to part numbers when reordering
See our extensive assortment of outdoor living products
on-line at www.sears.com and www.kmart.com
