Jacuzzi Fresco Y950 User manual

Like its namesake, the Fresco®is pure art.
features:
• Exclusive 360º Balanced Airflow™ system
• 800 watt variable speed heated air blower
• Thermal Lumbar Comfort (TLC)™
• Timed purge cycle
• Safely use salts and aromatic oils
• PrO
3
™
Cleansing System
fresco®pure air®ll bath
model number: Y950
exterior dimensions:
71½" long x 42" wide x 27¼" high
interior dimensions:
47" long x 25" wide
operating gallons:
60 gallons
Detail: The Fresco®Pure Air®ll bath’s high-backed
design cradles the neck and shoulders, while a
handrail adds safety.
fresco®pure air®ll bath
From the Italian phrase “buon fresco”—“really fresh”—comes the fresco®pure air®ll bath, a truly refreshing experience.

Fresco® Pure Air® II Bath
Model: Y950
Installation Notes
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Ordering Information
Product Code:
Y950 Fresco® Pure Air® II Bath
Right Hand
• Center Drain Location
• Accessories / Hardware:
Trim Kit Rotary: #BN21
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(845) – Oil Rubbed Bronze
Technical Specifications
Dimensions
71-1/2” L x 42” W x 27-1/4” H
(1816 mm) L x (1067 mm) W x (692 mm) H
Drain/Overflow
A: 20-1/8” (511 mm) B: 11-3/4” (299 mm)
Cutout
Template Provided: P/N P188000
Total Weight
921 lb (418kg) / 44 lb/sq. ft. (215 kg/m2)
Operating Gallonage
60 U.S. Gal. (227 Liters)
Product Weight
146 lb (66 kg)
Skirt Mounting
Not Available
Electrical Specifications
Requires a dedicated GFCI protected separate circuit.
Blower: 120 VAC, 15 AMP, 60 Hz.
Heater
No water heater is available on this unit. Blower has integral air heater.
71-1/2"
42"
36"
11-3/4"
2"
12" x 4"*
Blower
12" H x 18" L
Service Access
© Jacuzzi Whirlpool Bath • 14880 Monte Vista Avenue • Chino • CA • 91710 • www.jacuzzi.com
SIDE VIEW END VIEW
L
H
7-1/2"
W
2"
(51 mm) (Blower)
(19 cm)
#FR41 07/07
DRAIN/OVERFLOW
A
B
Product Shown: Fresco® Pure Air® II Bath Right Hand Shown Model: Y950
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
Minimum Service Access dimensions given.
