Jadak Photo Research SpectraScan PR-7 Series User manual

PR-7XX SpectraScan®
User’s Manual
PHOTO RESEARCH
7279 William Barry Blvd.
North Syracuse, NY 13212-3349
Phone: [phone]
Fax: [phone]
Email: [e-mail]
URL: www.photoresearch.com

Notice
The information contained in this document is subject to change without notice. If there are any
questions pertaining to the use of this system, contact JADAK.
Jadak and Novanta shall not be liable for errors contained herein or for incidental consequential
damages in connection with the furnishing, performance, or use of this system.
This document contains proprietary information that is protected by copyright. All rights are
reserved worldwide. No part of this document may be reproduced photographically, electronically
or by any other means without the express written permission from Novanta.
© 2019 Novanta. All rights reserved worldwide.
PR is a registered trademark of JADAK
PHOTO RESEARCH, Inc. is a registered trademark of Novanta
Pritchard is a registered trademark of Novanta.
Automatic Adaptive Sensitivity is a registered trademark of Novanta
Windows is a registered trademark of Microsoft.

Customer Support
PHOTO RESEARCH, Inc. has support services available to users in case of problems using the
PR-7XX.
PHOTO RESEARCH, Inc. personnel are available from 8:00 AM to 4:30 PM (Eastern Time)
Monday through Friday, except legal holidays, to aid in technical support.
Call [phone], FAX: [phone] or e-mail:
[e-mail] for instrument repair or calibration
[e-mail] for technical support.
If calling, please have the following information ready:
•Instrument Model
•Instrument Serial Number
•This manual
•Any printed data you feel might aid in resolving the problem - such as test data.

PR-7XX User’s Manual
i
Table of Contents
Chapter - 1 Introduction............................................................................................................ 10
Standard Equipment......................................................................................................... 10
Chapter - 2 System overview.................................................................................................... 11
LCD screen................................................................................................................................ 13
Graphical User Interface (GUI)......................................................................................... 13
Title Bar ............................................................................................................................ 16
System Status Icons......................................................................................................... 16
Command Bar................................................................................................................... 17
Back Button ...................................................................................................................... 17
Making Measurements ..................................................................................................... 17
Viewing Measurements .................................................................................................... 17
System Information.................................................................................................................... 18
I/O ports ..................................................................................................................................... 18
External Trigger Connector .............................................................................................. 19
(#1 in Figure 10) ............................................................................................................... 19
RS-232 Connector - optional............................................................................................ 21
(#2 in Figure 10) ............................................................................................................... 21
Mini USB 1.1 Connector................................................................................................... 22
(#3 in Figure 10) ............................................................................................................... 22
Power Connector.............................................................................................................. 22
(#4 in Figure 10) ............................................................................................................... 22
Connecting the AC Adapter....................................................................................................... 22
MS-75 Standard Objective Lens................................................................................................ 22
Installing and / Removing the Standard Lens................................................................... 23
Removing the Objective Lens........................................................................................... 24
Installing the Objective Lens............................................................................................. 24
Software..................................................................................................................................... 24
SpectraWin™ 2 Software ................................................................................................. 24
SpectraWin 2 Lite .............................................................................................................. 24
SpectraWin 2 Pro............................................................................................................... 24
Optical Accessories ................................................................................................................... 25
Variable Focus Lenses .............................................................................................................. 27
Fixed Focus Lenses................................................................................................................... 27
Chapter - 3 Theory of Operation............................................................................................... 29
Chapter - 4 Basic Setup Procedures ........................................................................................ 33

PR-7XX User’s Manual
ii
Introduction ................................................................................................................................ 33
Before you Begin Using the Instrument..................................................................................... 33
Calibrating the Touch Screen Display.............................................................................. 33
Setting Instrument Preferences ................................................................................................. 34
How to Adjust Power Savings Settings ............................................................................ 35
How to Enable and Disable Instrument Sounds and Alerts ............................................. 36
USB Hub Type Connectivity Options ............................................................................... 37
To change the USB Hub Type........................................................................................... 38
Setting the Date and Time................................................................................................ 39
Changing Units................................................................................................................. 39
RS-232 Connectivity......................................................................................................... 41
Reset to Default................................................................................................................ 42
Hard Reset........................................................................................................................ 42
Chapter - 5 Setup Menu ........................................................................................................... 43
Instrument Setup Instructions.................................................................................................... 43
How to Select the Bandwidth............................................................................................ 43
how to Select an Aperture................................................................................................ 44
How to Select A Primary Accessory................................................................................. 44
How to Select an Add-on Accessory................................................................................ 44
How to Set the Number of Measurements to Average..................................................... 44
How to Set the Adaptive Exposure Time.......................................................................... 45
How to Set a Fixed Exposure Time.................................................................................. 45
How to Set the Instrument Sensitivity Range................................................................... 45
How to Set the Measurement Speed ............................................................................... 46
How to Set the SYNC Mode............................................................................................. 46
How to Set Smart Dark Mode........................................................................................... 47
Measurement Modes..................................................................................................................... 48
Standard Mode .......................................................................................................................... 48
L*u*v* / L*a*b* Modes................................................................................................................ 48
How to Make L*u*v* or L*a*b* Measurements ................................................................. 49
RGB Display Cal........................................................................................................................ 52
Setting up RGB DisplayCal Measurements ...................................................................... 52
Mode Field........................................................................................................................ 53
Selecting a Phosphor......................................................................................................... 53
Setting the White Point...................................................................................................... 54
Match Sample Procedure.................................................................................................. 55

PR-7XX User’s Manual
iii
Y x,y (or x,y) Data Entry Procedure................................................................................... 56
Y x,y Procedure ................................................................................................................. 56
Making an RGB Display Cal Measurement....................................................................... 57
Color Rendering Index (CRI) –Optional for PR-7XX. ............................................................... 58
Setting up CRI Measurements ......................................................................................... 59
Reference Source.............................................................................................................. 59
How To Select the Reference source............................................................................ 59
Auto Create Source Option ........................................................................................... 61
CCT Tolerance .............................................................................................................. 61
Chromaticity Tolerance (CIE 1960 uv) .......................................................................... 62
CRI Measurement Results ............................................................................................ 62
Standard Illuminants...................................................................................................................... 63
Timed Measurements.................................................................................................................... 64
How to Set Timed Measurements Parameters.......................................................................... 64
Continuous Measurements............................................................................................... 65
Advanced Setup ............................................................................................................................ 66
Custom Spectral Calibration ...................................................................................................... 66
Accessing the Custom Spectral Calibration Menu........................................................... 66
Importing Data.................................................................................................................. 67
As a .MEA File................................................................................................................... 67
As a .TXT File.................................................................................................................... 68
CIE Pass / Fail (Optional) .......................................................................................................... 69
Using CIE Pass / Fail........................................................................................................ 69
Accessing the Pass / Fail Menu: ....................................................................................... 69
Defining Pass / Fail Regions ............................................................................................. 70
Rectangles (or Squares)................................................................................................ 70
Ellipses (or Circles)........................................................................................................ 71
Polygons........................................................................................................................ 73
User Profiles.................................................................................................................................. 75
How to Save a User Profile........................................................................................................ 75
How to Rename a Profile........................................................................................................... 75
How to Recall a Profile............................................................................................................... 75
Reset to Default............................................................................................................................. 76
How to Reset to Default............................................................................................................. 76
Chapter - 6 Utilities Functions................................................................................................... 77
How to Restore Calibration/Illuminant files.................................................................................... 77
Requirements:............................................................................................................................ 77
Restore Procedure..................................................................................................................... 77

PR-7XX User’s Manual
iv
How to Update the Firmware......................................................................................................... 78
Requirements............................................................................................................................. 78
Secure Digital (SD) card. ........................................................................................................... 78
Update Procedure...................................................................................................................... 78
Chapter - 7 File Settings........................................................................................................... 81
How to Access the File Setting Screen ............................................................................ 81
Auto Save.......................................................................................................................... 81
SD File Field..................................................................................................................... 81
How to Create a New Measurement File........................................................................... 82
How to Delete a Measurement File ................................................................................... 83
How to Rename a Measurement File............................................................................... 83
How to Set Auto Save on Shutdown ................................................................................ 84
Explorer Settings........................................................................................................................ 85
Accessing the Explorer Settings Screen .......................................................................... 85
Current View..................................................................................................................... 85
SD File.............................................................................................................................. 85
How to Recall measurements stored on the SD card................................................................ 86
Measurement Types .................................................................................................................. 86
Luminance / Radiance ............................................................................................................... 86
Chapter - 8 How to Make a Luminance / Radiance Measurement........................................... 89
Using an Objective Lenses................................................................................................ 89
Using the FP-730............................................................................................................... 91
Using the LA-730 Luminance Adaptor............................................................................... 92
Chapter - 9 How to Make an Illuminance / Irradiance Measurement ....................................... 93
Illuminance / Irradiance.............................................................................................................. 93
Using the CR-730.............................................................................................................. 94
Using the RS-3 or SRS-3 Reflectance Standard............................................................... 95
Measuring Procedure ........................................................................................................ 95
Cleaning and Handling Instructions for the RS-3 (and SRS-3)..................................... 96
Using the ICC-730 Integrating Sphere .............................................................................. 97
Measuring Procedure .................................................................................................... 97
Chapter - 10 Luminous / Radiant Intensity ............................................................................. 99
How to Make Luminous Intensity / Radiant Intensity Measurements...................................... 100
Description....................................................................................................................... 100
Geometrical Considerations ........................................................................................ 100
Procedure - LED Adapter Cap Replacement .............................................................. 100
Making Measurements ................................................................................................ 100

PR-7XX User’s Manual
v
Chapter - 11 Luminous / Radiant Flux.................................................................................. 101
Overview......................................................................................................................... 101
Installing the IS-730..................................................................................................... 102
Mounting the LED........................................................................................................ 102
Adjusting the Mounting Tube Height ........................................................................... 102
Making a Measurement............................................................................................... 103
Chapter - 12 Connectivity ..................................................................................................... 105
USB.......................................................................................................................................... 105
Installing the USB Driver ................................................................................................ 105
USB Hub Type................................................................................................................ 107
Determining USB Hub Power (Windows 7 Only) ........................................................... 107
Setting USB Hub Type on the PR-7XX.......................................................................... 108
RS-232 (optional)..................................................................................................................... 110
Hardware Protocol.......................................................................................................... 110
Bluetooth (optional).................................................................................................................. 111
Pairing the PR-7XX ........................................................................................................ 111
Appendix - 1 Remote Control Mode...................................................................................... 115
Installing the USB Driver.......................................................................................................... 115
Using Remote Control Commands.......................................................................................... 115
Entering Remote Mode............................................................................................................ 116
Remote Control Command Summary...................................................................................... 118
Remote Control Command Detail................................................................................................ 119
Setup Commands........................................................................................................................ 121
Measurement and Data Send Codes............................................................................. 126
Data Code Summary...................................................................................................... 127
Data Code Details .......................................................................................................... 128
Remote Control Error Codes ................................................................................................... 134
Remote Control Measurement Errors ............................................................................ 134
Remote Control Parsing Errors ...................................................................................... 134
Routine Maintenance................................................................................................................... 136
Cleaning Lenses / Optical Accessories ................................................................................... 136
Cleaning Exterior Surfaces ...................................................................................................... 136
Recalibration............................................................................................................................ 136
Factory Repair ......................................................................................................................... 136
In-Warranty Repair ......................................................................................................... 136
Out-of-Warranty Repair ................................................................................................... 137
Appendix 3 –PR-7XX Lens Chart.................................................................................. 138

PR-7XX User’s Manual
vi

PR-7XX User’s Manual
vii
Table of Figures
FIGURE 1-PR-7XX SPECTRASCAN SIDE VIEW................................................................................. 11
FIGURE 2-I/O PANEL ENLARGEMENT ............................................................................................... 11
FIGURE 3-PR-7XX REAR VIEW ....................................................................................................... 12
FIGURE 4-5WAY FUNCTION SWITCH .............................................................................................. 13
FIGURE 5-PR-7XX SYSTEM MENU.................................................................................................. 13
FIGURE 6-PR-7XX TITLE BAR......................................................................................................... 16
FIGURE 7:PR-7XX MEASUREMENT COMMAND BAR.......................................................................... 17
FIGURE 8-PR-7XX MEASUREMENT VIEW COMMAND BAR.................................................................. 17
FIGURE 9-PR-7XX STARTUP /SYSTEM INFORMATION SCREEN. ........................................................ 18
FIGURE 10 -PR-7XX I/O CONNECTOR PANEL. .................................................................................. 18
FIGURE 11 -EXTERNAL TRIGGER PIN-OUT......................................................................................... 19
FIGURE 12 -SAMPLE EXTERNAL TRIGGER INPUT CIRCUIT DRIVERS...................................................... 20
FIGURE 13 -SAMPLE EXTERNAL TRIGGER OUTPUT CIRCUIT................................................................ 21
FIGURE 14 -PR-7XX RS-232 OPTION.............................................................................................. 21
FIGURE 15 -MINI-B USB CONNECTOR. ............................................................................................ 22
FIGURE 16 -MS-75 OBJECTIVE LENS. .............................................................................................. 23
FIGURE 17 –SPECTRUM MEASURED BY THE AND PR-7XX................................................................ 29
FIGURE 18 –PR-7XX SPECTROMETER............................................................................................ 30
FIGURE 19 -PR-7XX SIMPLIFIED BLOCK DIAGRAM........................................................................... 30
FIGURE 20 -CIE 1931 TRISTIMULUS FUNCTIONS .............................................................................. 31
FIGURE 21 -INITIAL SCREEN............................................................................................................. 33
FIGURE 22 -SYSTEM MENU............................................................................................................... 34
FIGURE 23 -CALIBRATE TOUCH SCREEN............................................................................................ 34
FIGURE 24 -SYSTEM MENU FIGURE 25 -PREFERENCES MENU ...................................................... 35
FIGURE 26 -POWER SAVING MENU .................................................................................................. 35
FIGURE 27 -BRIGHTNESS AND CONTRAST SCREEN........................................................................... 36
FIGURE 28 -SOUNDS AND ALERTS SCREEN...................................................................................... 37
FIGURE 29 -CONNECTIVITY MENU .................................................................................................... 38
FIGURE 30 -DATE AND TIME SCREEN............................................................................................... 39
FIGURE 31 -UNITS MENU ................................................................................................................. 40
FIGURE 32 -RS-232 CONNECTIVITY .................................................................................................. 41
FIGURE 33 -MAIN SCREEN FIGURE 34 -SYSTEM MENU.................................................................. 43
FIGURE 35 -SETUP MENU FIGURE 36 -PR-7XX INSTRUMENT SETUP.............................. 43

PR-7XX User’s Manual
viii
FIGURE 37 –MEASUREMENT AVERAGE ENTRY SCREEN.................................................................... 44
FIGURE 38 –EXPOSURE TIME ENTRY SCREEN.................................................................................. 45
FIGURE 39 -SYNC PERIOD DATA ENTRY SCREEN............................................................................ 47
FIGURE 40 -L*U*V*SETUP SCREEN FIGURE 41 -FILE RECALL SCREEN.......................................... 49
FIGURE 42 -STANDARD ILLUMINANTS SCREEN.................................................................................. 49
FIGURE 43 -L*U*V*SETUP SCREEN.................................................................................................. 50
FIGURE 44 -L*U*V*RESULT SCREEN ............................................................................................... 51
FIGURE 45 -RGB DISPLAY CAL SETUP SCREEN............................................................................... 52
FIGURE 46 -RGB PHOSPHOR SELECT SCREEN ................................................................................ 53
FIGURE 47 -SELECT RGB ILLUMINANT SCREEN................................................................................ 54
FIGURE 48 -RGB DISPLAY CAL SETUP SCREEN............................................................................... 55
FIGURE 49 -YXY DATA ENTRY SCREEN ........................................................................................... 56
FIGURE 50 -RGB DATA ENTRY........................................................................................................ 57
FIGURE 51 -RGB MEASUREMENT SCREEN....................................................................................... 58
FIGURE 52 -COLORS USED TO DETERMINE AVERAGE CRI.................................................................. 58
FIGURE 53 -CRI SETUP SCREEN...................................................................................................... 59
FIGURE 54 -CRI SOURCE SELECT SCREEN...................................................................................... 60
FIGURE 55 -CRI SETUP SCREEN WITH SELECTED SOURCE DATA ......................................................... 61
FIGURE 56 -CCT FOR PLANKIAN OR DAYLIGHT SOURCE ENTRY SCREEN........................................... 61
FIGURE 57 -CCT TOLERANCE ENTRY SCREEN................................................................................. 62
FIGURE 58 -CRI RESULT SCREEN.................................................................................................... 62
FIGURE 59 -STANDARD ILLUMINANTS SCREEN ................................................................................. 63
FIGURE 60 -TIMED MEASUREMENTS SCREEN................................................................................... 64
FIGURE 61 -MEASUREMENT INTERVAL ENTRY FIELD......................................................................... 65
FIGURE 62 -UTILITIES MENU............................................................................................................ 77
FIGURE 63. PR-7XX UTILITIES MENU................................................................................................ 78
FIGURE 64 -PR-7XX FIRMWARE UPDATE PROMPT. ........................................................................... 79
FIGURE 65 -SECURE DIGITAL CARD FILE SETTINGS........................................................................... 81
FIGURE 66 -MEASUREMENT FILE DOES NOT EXIST ON SD CARD........................................................ 82
FIGURE 67 -SD CARD NEW MEASUREMENT FILE NAME ENTRY............................................................ 82
FIGURE 68 -SECOND CHARACTERS SET............................................................................................ 83
FIGURE 69 -MEASUREMENT FILE RENAME......................................................................................... 83
FIGURE 70 -AUTO SAVE ON SHUTDOWN PROMPT............................................................................... 84
FIGURE 71 -EXPLORER SETTINGS.................................................................................................... 85

PR-7XX User’s Manual
ix
FIGURE 72. FILE EXPLORER.............................................................................................................. 85
FIGURE 73 -ILLUMINANCE /LUMINANCE CONCEPT............................................................................. 87
FIGURE 74 -MS-75 LENS ................................................................................................................ 89
FIGURE 75 -APERTURE ALIGNMENT ................................................................................................. 90
FIGURE 76 -INSTRUMENT SETUP MENU............................................................................................ 90
FIGURE 77 -FP-655 /FP-670 ......................................................................................................... 91
FIGURE 78 -LA-730 LUMINANCE ADAPTOR....................................................................................... 92
FIGURE 79 -ILLUSTRATION OF ILLUMINANCE...................................................................................... 93
FIGURE 80 -CR-730 ....................................................................................................................... 94
FIGURE 81 -ICC-730 INTEGRATING SPHERE .................................................................................... 97
FIGURE 82 -ILLUSTRATION OF LUMINOUS INTENSITY ......................................................................... 99
FIGURE 83 -LR-730 LED RECEPTOR............................................................................................... 99
FIGURE 85 -IS-730 OUTER VIEW................................................................................................... 101
FIGURE 86 –IS-730 INTERNAL VIEW ........................................................................................... 102
FIGURE 87 –IS-730 HEIGHT ADJUSTMENT............................................................................... 103
FIGURE 88 -NEW HARDWARE WIZARD............................................................................................. 105
FIGURE 89 -PR-7XX USB DRIVER INSTALL.................................................................................... 106
FIGURE 90 -WINDOWS COMPATIBILITY WARNING FOR PR-7XX USB DRIVER................................... 106
FIGURE 91 -PR-7XX USB DRIVER INSTALL COMPLETE. .................................................................. 107
FIGURE 93 -USB POWER SCREEN................................................................................................. 108
FIGURE 94 -USB CONNECTIVITY MENU........................................................................................... 108
FIGURE 95 -PR-7XX RS-232 OPTION............................................................................................ 110
FIGURE 96 –RS-232 CONNECTIVITY,BAUD RATE SETUP............................................................... 111
FIGURE 98. -WINDOWS DEVICE MANAGER ...................................................................................... 115

Chapter 1 - Introduction
10
Chapter - 1 INTRODUCTION
The PR-7XX SpectraScans are the newest additions to the already world renowned SpectraScan
colorimeter series of instruments. These laboratory grade spectroradiometers utilize a cooled, fast-
scanning photo diode array, a 3.5” color touch screen display, and AutoSync®for automatically
synchronizing the exposure time to the source refresh rate ensuring the utmost accuracy. Other features
include an external trigger port allowing remote measurement activation from a push button or peripheral
device, a USB Interface and a Secure Digital (SD) card for measurement storage. The spectral range of
the PR-730, PR-740, and PR-788 is visible (380 nm to 780 nm) while the PR-735 and PR-745 extends
the spectral range into the near infrared (380 nm to 1080 nm).
For wireless control, the PR-7XX can be supplied with a Class 1 Bluetooth®interface for operation of up
to 100 meters (330 feet) from the controller.
For the ultimate in portability, a Li-ion battery is available providing over 8 hours of operation on a single
charge.
STANDARD EQUIPMENT
The standard PR-7XX includes:
oSpectraScan (PR-7XX).
oMS-75 Lens.
oUSB 1.1 Port.
oSecure Digital (SD) Card.
oAC-740-6 –6’ Universal input AC Adapter.
oUSB-10 –10 ft (3.05 m) USB Interconnecting Cable.
oCD with drivers, Instruction Manual and demo version of SpectraWin software.
oNIST Traceable Calibration - (certified for one year).
oRemote Mode Software

Chapter 2 –System Overview
11
Chapter - 2 SYSTEM OVERVIEW
FIGURE 1 - PR-7XX SPECTRASCAN SIDE VIEW
FIGURE 2 - I/O PANEL ENLARGEMENT
1
2
3
11
10
12
13
14

Chapter 2 –System Overview
12
FIGURE 3 - PR-7XX REAR VIEW
Reference
Description
Function
Reference
Description
Function
1
Objective Lens
Focusing on
target
8
3.5 in. Color
Touch Screen
Display
System Menus /
Measurement
Results
2
View Finder
Shutter Control
Open/Close view
finder
9
SD Card Slot
Data Storage
3
View Finder
View target /
measuring
aperture / focus
on aperture
10
Bluetooth
Antenna
Wireless
Communication
4
Measure
Switch
Execute
measurement
11
I/O Connector
Panel
Interface / Power
connection
5
Power Switch
Turn On (I) / Off
(O) unit
12
RS232
Connector
(Optional)
Serial
Communication
6
Status
Indicators
Instrument
status indicators
13
USB Connector
USB
Communication
P-Power
C- Charge
F- Fault
7
5 way function
switch
Menu navigation
14
DC Power
connector
Power in
TABLE 1 - PR-7XX FUNCTIONAL OVERVIEW.
3
4
5
6
7
8
9

Chapter 2 –System Overview
13
LCD SCREEN
The PR-7XX features an on-board, 3.5” high resolution, full color touch screen LCD display. The area visible to
the user is called the active area. The active area of the LCD display contains the graphical user interface of the
PR-7XX. All setup options and measurements including spectral and CIE graphs are controlled and viewed
directly on the vivid color display.
GRAPHICAL USER INTERFACE (GUI)
The Graphical User Interface (GUI) is what is displayed on the active area of the display. The GUI allows the
user to navigate through the PR-7XX menu system. Menu items can be selected simply by touching the screen
on the item of choice, or by using the 5 Way Function Switch. To use the 5 Way Switch, press the arrow keys to
highlight the selection, then press the Enter (center) key to select the highlighted choice.
FIGURE 4 - 5 WAY FUNCTION SWITCH
FIGURE 5 - PR-7XX SYSTEM MENU.
1
2
3
Enter Key

Chapter 2 –System Overview
14
The Graphical User Interface consists of three major panes:
Item
Description
1
Title bar
2
Active pane
3
Command bar
TABLE 2 - GUI PANE DESCRIPTION.
The flow of the menu navigation on the PR-7XX is similar to that of a tree structure. In a tree structure there are
roots and extending from the roots are branches (sub menus), indicated by the following icon ( ) which have
more branches or end nodes (leafs). Traversing back to the root is as simple as touching the back ( ) icon,
located at the bottom left corner of the GUI.
The following example depicts the tree structure mentioned, by navigating to the Date & Time setup screen from
System Menu.
Navigation Steps:
Preferences → Date & Time
Root
From System Menu navigate to and select
Preferences.
Branch
From Preferences navigate to and select Date &
Time.
End Node (Leaf)

Chapter 2 –System Overview
15
To traverse back to the System Menu simply touch the Back button twice.

Chapter 2 –System Overview
16
TITLE BAR
The title bar displays the current active menu location (1) and critical system status information (2). A detailed
list of system status icons can be found in the system status section of this manual.
Figure 6 - PR-7XX Title bar.
SYSTEM STATUS ICONS
The system status icons display current instrument state and status. They are triggered either by a selection
made in the instrument setup section or by the instrument. Below are all system status icons and their
corresponding indication.
Battery Charge %
(Optional for
PR-7XX)
ICON
DESCRIPTION
AC Adaptor Active
Green w / 2½ bars
100% Charge
Green w / 1½ bars
66% Charge
Yellow w / ½ bar
33% Charge
Orange w / ½ bar blinking
Low Battery (<= 5%)
SYNC
No Icon
Manual Sync Mode (20 –400 Hz)
Sync Disabled
Automatic Sync
Auto Save
No Icon
Auto Save to SD card disabled.
Auto Save On & SD Card Detected.
Auto Save on & No SD card detected.
Bluetooth
No Icon
Bluetooth Off
Bluetooth On
Timed
Measurements
No Icon
Timed measurements disabled
Timed measurements enabled
Table 3 - PR-7XX Status Icon List
Detailed information pertaining to the system status icons can be found in their respective sections of the
manual.
1
2
