Jade CHITWOOD SMOKE BROILER KC-24 Operating and safety instructions

WWW.JADERANGE.COM JADE RANGE, LLC., A MIDDLEBY COMPANY • 2650 Orbiter Street • Brea, CA 92821 • PHONE: [phone] FAX: [phone]
Note: In line with their policy to continually improve products, Jade reserves the right to change materials and specifications without notice. printed in usa
CHITWOOD SMOKE BROILER
TITAN CHITWOOD SMOKE BROILER
MODEL NO. DESCRIPTION
o
kc-24 24" wide broiler
o kc-36 36" wide broiler
o kc-48 48" wide broiler
o kc-60 60" wide broiler
STANDARD FEATURES
• 14 gauge stainless steel all welded body construction
• Heavy duty cast iron 9-bar grill grates
• Stainless steel front, sides and top rim
• Ceramic briquettes to provide even heat
• Cast iron bottom grates for briquette support
• One 30,000 BTU/hr. burner every 12" broiler
• Exclusive CHITWOOD Smoke-Ejector system to provide maximum smoke
to the grill surface. Independent of main burner heat for COLD SMOKING
• Infinite control manual gas valves at each burner for precise heat control
• 12 gauge all welded firebox construction
• 3/4" gas regulator
• Stainless steel gas tubing throughout
• Stainless steel tray bed
AVAILABLE OPTIONS
oStainless steel smoke hood with stay cool handle. Left oRight o
oStainless steel 8" extended plate shelf with drop down hinges
oStainless steel enclosed stand with drawers and doors for storage –
models ESKC*
oStainless steel open stand with round tube legs and shelf – models OSKC*
oStainless steel 8" solid plate shelf
* ESKC: Enclosed Stand Series; OSKC: Open Stand Series
ACCESSORIES
o6" casters, front two locking (5" diameter wheel)
o36" flex hose with quick disconnect (3/4" connection)
o48" flex hose with quick disconnect (3/4" connection)
oStainless steel adjustable 6" legs
form #jt0548 ©2008 jade range, llc
KC-36 shown with optional smoke hood
TM
TITAN™
KC-48 shown with optional smoke hood,
stainless steel enclosed stand and casters

WWW.JADERANGE.COM JADE RANGE, LLC., A MIDDLEBY COMPANY • 2650 Orbiter Street • Brea, CA 92821 • PHONE: [phone] FAX: [phone]
Note: In line with their policy to continually improve products, Jade reserves the right to change materials and specifications without notice. printed in usa
CHITWOOD SMOKE BROILER
TITAN CHITWOOD SMOKE BROILER
form #jt0548 ©2008 jade range, llc
TM
TITAN™
model main burners smoke ejectors width btus appx. shp. wt. width–a
(optional hood)
kc-24 2 1 24" 65,000 300 lbs. 22"
kc-36 3 1 36" 95,000 350 lbs. 16"
kc-48 4 2 48" 130,000 400 lbs. 22"
kc-60 5 2 60" 160,000 500 lbs. 22"
NOTE: SPECIFY TYPE OF GAS WHEN ORDERING.
UTILITY INFORMATION:
• Ranges are supplied with a 3/4" rear gas connection.
Ranges are supplied with 3/4" gas pressure regulator.
• Required operating pressure:
Natural Gas 5" W.C. minimum
Propane Gas 10" W.C. minimum
14" W.C. maximum
Note: This unit must be connected with the gas appliance
regulator supplied.
DESCRIPTION:
CHITWOOD SMOKE BROILER. To be model #KC
manufactured by Jade Range. Furnished with 14 gauge all welded
body construction and stainless steel front, sides and top rim.
Provide with heavy duty cast iron grates. One cast iron burner
with stainless steel radiants each 12" of broiler. Provide ceramic
briquettes for even heat and 12 gauge firebox with all welded
construction. Include exclusive Smoke Ejector system, heavy gauge
smoke drawer with independent control for cold smoke
applications. Furnish 14 gauge drip pan and 3/4" regulator. To have
6" stainless steel adjustable legs.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
JADE RANGE
WIDTH
CASTERS
ARE OPTIONAL
OPTIONAL STAINLESS
CHITWOOD
OPTIONAL SMOKE
HOOD
[ ] MILLIMETERS
STEEL ENCLOSED STAND
(MODEL ESKC)
3/4" GAS INLET
6" [152]
A
6" [152]
24 7/16" [621]
18 1/2" [470]
12" [305]
5" [127]
6" [152]
17 1/2" [444]
26 1/2" [673]
2" [51]
26 1/4" [667]
