Jade TITAN JTKC-24 Operating and safety instructions

WWW.JADERANGE.COM JADE RANGE, LLC., A MIDDLEBY COMPANY • 2650 Orbiter Street • Brea, CA 92821 • PHONE: [phone] FAX: [phone]
Note: In line with their policy to continually improve products, Jade reserves the right to change materials and specifications without notice. printed in usa
CHITWOOD “SMOKE” BROILER
TITAN CHITWOOD “SMOKE” BROILER
MODEL NO. DESCRIPTION
o
jtkc-24 24" charbroiler
o jtkc-36 36" charbroiler
o jtkc-48 48" charbroiler
o jtkc-60 60" charbroiler
STANDARD FEATURES
• 14 gauge stainless steel all welded body construction
• Stainless steel front, top rim, stub back and sides
• Heavy duty cast iron grates
• Ceramic briquettes to provide even heat
• Cast iron bottom grates for briquette support
• Cast iron 30,000 BTU/hr. burners with stainless steel radiants
• Variable size multi-point gas connection—see utility information for details
• Infinite control manual gas valves at each burner for precise heat control
• 12 gauge all welded firebox construction
• Exclusive CHITWOOD Smoke-Ejector system to provide maximum
smoke to the grill surface. The smoke box is independent of main burner
heat for COLD SMOKING
• Two separate 14 gauge steel drip pans to control flare ups
• Stainless steel 6" plate shelf
• Stainless steel cabinet interior and exterior
• Stainless steel gas tubing throughout
• Stainless steel adjustable 6" legs
• 3/4" gas regulator (shipped loose, must be installed for proper operation)
AVAILABLE OPTIONS
oStainless steel high riser
oStainless steel double high riser
oStainless steel tubular high shelf
oStainless steel tubular double high shelf
oFish grate (round bars)
oStainless steel sides
oCommon plate shelf with Item(s) Model(s)
oCap and cover manifold. Left oRight o
ACCESSORIES
o6" casters, front two locking (5" diameter wheel)
o36" flex hose with quick disconnect (3/4" connection)
o48" flex hose with quick disconnect (3/4" connection)
o1" gas pressure regulator (specify gas type)
o1-1/4" gas pressure regulator (specify gas type)
form #jt0538 ©2008 jade range, llc
TM
TITAN™
JTKC-36 shown with optional high riser

WWW.JADERANGE.COM JADE RANGE, LLC., A MIDDLEBY COMPANY • 2650 Orbiter Street • Brea, CA 92821 • PHONE: [phone] FAX: [phone]
Note: In line with their policy to continually improve products, Jade reserves the right to change materials and specifications without notice. printed in usa
CHITWOOD “SMOKE” BROILER
TITAN CHITWOOD “SMOKE” BROILER
form #jt0538 ©2008 jade range, llc
TM
TITAN™
model main burners smoke ejectors width depth btus appx. shp. wt.
jtkc-24 2 1 24" 38" 60,000 300 lbs.
jtkc-36 3 1 36" 38" 90,000 350 lbs.
jtkc-48 4 2 48" 38" 120,000 400 lbs.
jtkc-60 5 2 60" 38" 150,000 500 lbs.
NOTE: SPECIFY TYPE OF GAS WHEN ORDERING.
UTILITY INFORMATION:
• Ranges are supplied with 1-1/4" front manifold connection
and a 1" or 3/4" capped rear manifold connection. For rear
manifold connection, remove cap. Ranges are supplied
with 3/4" gas pressure regulator. For 1-1/4" or 1" gas
pressure regulator, see accessories. (Specify required
front manifold cap and cover when ordering.)
• Required operating pressure:
Natural Gas 5" W.C. minimum
Propane Gas 10" W.C. minimum
14" W.C. maximum
Note: This unit must be connected with the gas appliance
regulator supplied.
DESCRIPTION:
CHITWOOD range match “Smoke” charbroiler. To be model
#JTKC manufactured by Jade Range. Furnished
with 14 gauge all welded body construction and stainless steel
front, sides, top rim, stub back and bottom. Provide with heavy
duty cast iron grates. One cast iron burner with stainless steel
radiants each 12" of broiler. Provide ceramic briquettes for
even heat and 12 gauge firebox with all welded construction.
Include exclusive Smoke Ejector system, heavy gauge smoke
drawer with independent control for cold smoke applications.
Furnish two separate 14 gauge drip pans. To have 6" stainless
steel adjustable legs.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 ft.
CURB
[ ] = MILLIMETERS
RISER TO MATCH
SINGLE DECK SHELF
WIDTH
DOUBLE DECK SHELF
RISER TO MATCH
30 1/2" [775]
6" [152]
1 1/4"[32] MANIFOLD
38" [965]
STUB BACK
6" [152]
3" [76]
34" [864]
34 3/4" [883]
55" [1397]
66 1/2" [1689]
1 1/2" [38]
REAR GAS CONNECTION
REAR GAS
CONNECTION
2 1/2" [64]
24 3/8" [619]
