JADO Wynd 816/989 Series User manual

3/4" Thermostatic Mixing
3/4" Thermostatic Mixing
Valve Trim Kit
Valve Trim Kit
Installation Instructions
To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.
©JADO USA 2005
Products Luxury Faucets and Accessories
JADO USA
6615 West Boston
Chandler, AZ 85226
Phone:(8OO) 227-2734
Fax: (8OO) 552-JADO (5236)
www.jadousa.com
Product Number
816/989/...
Wynd
100
COLD
HOT
H965211B

3/4" Thermostatic Mixing
Valve Trim Kit
Plumbers' Putty or Caulking
Adjustable Wrench
Teflon Tape
Phillips Screwdriver
Channel Locks
RECOMMENDED TOOLS
Tubing Cutter Regular Screwdriver
TEMPERATURE CALIBRATION
1
Unscrew PLASTER GUARD SCREWS and remove PLASTER GUARD.
Check that arrow marking B points vertically upwards. If not, push
the BLACK CLAMP on the SECURING RING to the right, pull off KNOB
MOUNT and reinstall KNOB MOUNT with arrow "B" pointing upwards.
For 100˚ F adjustment, turn the water supply on. Turn KNOB
MOUNT until the spout temperature is 100˚ F. Check that arrow
marking A on the KNOB MOUNT still points upward after adjusting
the thermostat to 100˚ F. If not, pull out the RED LOCKING DEVICE.
Remove KNOB MOUNT by pulling it towards you while standing directly
in front of the valve.
Reinstall the KNOB MOUNT so that the arrow marking A points upwards.
The maximum mixed water temperature is set at 109˚ F at the
factory. This setting can be changed if desired.
Remove the TEMPERATURE LIMIT STOP (H shaped Black Plastic
part). Re-install it at the desired notch as indicated in the diagram
to limit the maximum mixed water temperature to 104˚F or 112˚F.
Reinstall RED LOCKING DEVICE.
KNOB
MOUNT
ARROW
"A"
BLACK
CLAMP
ARROW
"B"
RED LOCKING
DEVICE
SECURING
RING
104˚
109˚
112˚
TEMPERATURE
LIMIT STOP
ROUGHING-IN DIMENSIONS
FINISHED
FLOOR FINISHED
WALL
1-11/16"
to
2-1/2"
3/4" NPT OUTLETS
3/4" NPT INLETS
5-7/8"
C
L
48" TO 54"
FOR SHOWER ONLY
(OPTIONAL)
32" TO 42"
FOR BATH/SHOWER
AND BATH FILLER
(OPTIONAL)
3-3/8"
For reference
H965211B
7-1/8" D.

3/4" Thermostatic Mixing
Valve Trim Kit
CHECK STOP
(RED TO BLUE)
CHECK STOP
(BLUE TO RED)
Should the hot and cold water supply pipes have been
transposed making adjustment impossible, proceed as
follows:
Important note: RED CHECK STOP is now on the right of the
mixer body and the BLUE CHECK STOP is now on the left.
2
COLD
HOT
1
TRANSPOSED SUPPLY PIPING
4
OPERATING THE VALVE
5
2
3
Push CAP (1) over the O-RING SEAL (2).
TRIM INSTALLATION
HANDLE INSTALLATION
Slide COVER PLATE (5) onto CAP (1) flush against
ESCUTCHEON (3).
34
Remove check stops and re-install them transposed.
Shut off water supply.
Remove handle and rim
Turn the water supply back on and perform the temperature
adjustment in step 1.
GREASE
ESCUTCHEON
O-RING SEAL
Push ESCUTCHEON (3) with lightly greased O-ring
seal over CAP (1) and secure with long (60mm) SCREWS (4).
If a temperature over 100˚ F is desired, push the STOP
BUTTON (1) down and turn the TEMPERATURE KNOB (2).
This will increase the mixed water temperature up to the
maximum limit previously selected in step 1.
5
ROLL
PIN
Push TEMPERATURE-CONTROL KNOB (1) onto KNOB
MOUNT (2). Attach TEMPERATURE-CONTROL KNOB (1)
to valve with ATTACHMENT SCREW (3). Push HANDLE
BASE (4) onto TEMPERATURE-CONTROL KNOB (1).
Tighten set screw with HEX WRENCH (5) to secure
HANDLE BASE (4). Align HANDLE (6) with roll pin and
install onto HANDLE BASE (4). Tighten HANDLE SCREW (7)
to secure handle. Push HANDLE CAP (8) into HANDLE (6).
100
2
1
34
6
78
5
2
1
100
COLD
HOT
COLD
HOT
H965211B

3/4" Thermostatic Mixing
Valve Trim Kit
