Jai Gox-5105m-5ge User manual

Thank you for purchasing this product.

Be sure to read this documentation before use.

This documentation includes important safety precautions and instructions on how to operate the unit. Be sure to read this documentation to ensure

proper operation.

The contents of this documentation are subject to change without notice for the purpose of improvement.

User Manual

GOX-5105M-5GE GOX-5105C-5GE

GOX-8105M-5GE GOX-8105C-5GE

GOX-12405M-5GE GOX-12405C-5GE

GOX-16205M-5GE GOX-16205C-5GE

GOX-20405M-5GE GOX-20405C-5GE

GOX-24505M-5GE GOX-24505C-5GE

CMOS Digital Progressive Scan

Monochrome and Color Camera with GigE Interface

Document Version: 1.0

Go-X_Series_5GE_Manual_Ver.1.0_2023-03-07

User Manual (Ver. 1.0) - Table of Contents

- 2 -

Table of Contents

Table of Contents 2

About Technical Note 8

Notice/Warranty/Certifications 9

Notice 9

Warranty 9

Certifications 9

CE Compliance 9

FCC 9

Warning 10

KC 10

Supplement 11

Supplement 12

Package Contents, Accessories 13

Usage Precautions 14

Notes on Supplying Power via PoE 14

Notes on Cable Configurations 15

Notes on Attaching the Lens 16

Notes on LAN Cable Connection 16

Phenomena Specific to CMOS Image Sensors 17

Notes on Exportation 17

Features 18

Feature Overview 18

Parts Identification 20

①Lens Mount (C-Mount) 20

②RJ-45 Connector 21

③LINKLED 21

④ACTLED 21

⑤POWER/TRIG LED 22

⑥DC IN/TRIG Connector (6-Pin Round) 22

⑦ ⑧ Mounting Holes 23

User Manual (Ver. 1.0) - Table of Contents

- 3 -

Recommended Circuit Diagram (Reference Examples) 23

Recommended External Input Circuit Diagram 23

Recommended External Output Circuit Diagram 23

Characteristics of the Recommended Circuits for Opto OUT 24

Preparation 25

Step 1: Install the Software (First Time Only) 26

Step 2: Connect Devices 26

①Lens 27

②Heatsink Set (When Supplying Power via PoE) 28

How to Attach/Mount 28

③Mounting (or Use MP-46 Tripod AdapterPlate) 29

④LAN Cable 29

⑤Network Card 30

⑥DC IN / Trigger IN Connection Cable 30

⑦AC Adapter (Power Supply) (If Necessary) 30

Step 3: Verify Camera Operation 30

Step 4: Verify the Connection between the Camera and PC 31

Step 5: Change the Camera Settings 33

Step 6: Adjust the Image Quality 34

Adjust the Gain 35

Adjust the White Balance 36

Adjust the Black Level 37

Step 7: Save the Settings 38

To Save User Settings 39

To Load User Settings 40

Main Functions 41

Acquisition Control 41

Changing the Frame Rate 42

Exposure Mode 43

Actual Exposure Time 44

RCT Mode 44

Trigger Control 45

User Manual (Ver. 1.0) - Table of Contents

- 4 -

When Using the FrameStart Trigger 46

Pixel Format 48

SensorDigitizationBits 49

Image Flip Function 49

GPIO (Digital Input/Output Settings) 50

VideoProcessBypassMode 51

Calculate the Maximum Frame or Trigger Rate (Approximate) 52

1. Calculate the H Period 52

2. Calculate the Minimum Frame Period 55

3. Calculate the Maximum Frame Rate or Maximum Trigger Rate 56

Timing Chart 58

Exposure Mode = Timed (Overlap Readout) 59

GOX-5105M-5GE, GOX-5105C-5GE 60

GOX-8105M-5GE, GOX-8105C-5GE 61

GOX-12405M-5GE, GOX-12405C-5GE 62

GOX-16205M-5GE, GOX-16205C-5GE 63

GOX-20405M-5GE, GOX-20405C-5GE 64

GOX-24505M-5GE, GOX-24505C-5GE 65

Exposure Mode = TriggerWidth (Overlap Readout) 66

GOX-5105M-5GE, GOX-5105C-5GE 67

GOX-8105M-5GE, GOX-8105C-5GE 68

GOX-12405M-5GE, GOX-12405C-5GE 69

GOX-16205M-5GE, GOX-16205C-5GE 70

GOX-20405M-5GE, GOX-20405C-5GE 71

GOX-24505M-5GE, GOX-24505C-5GE 72

Exposure Mode = Timed (RCTMode) 73

GOX-5105M-5GE, GOX-5105C-5GE 74

GOX-8105M-5GE, GOX-8105C-5GE 75

GOX-12405M-5GE, GOX-12405C-5GE 76

GOX-16205M-5GE, GOX-16205C-5GE 77

GOX-20405M-5GE, GOX-20405C-5GE 78

GOX-24505M-5GE, GOX-24505C-5GE 79

User Manual (Ver. 1.0) - Table of Contents

- 5 -

Gain Control 80

Automatic Gain Level Control 80

White Balance 81

Color Temperature 81

ALC (Automatic Level Control) Function 82

To Use the ALC Function 82

Gamma Function 83

To Use the Gamma Function 83

LUT (Lookup Table) 84

To Use the LUT Function 84

LUT Value 84

BlemishCompensation 85

Automatic Detection 85

Manual Configuration 86

Shading Correction 87

To Use the Shading Correction Function 88

Binning Function 89

Image Scaling Mode (Xscale) 90

Specifying the Scaling Ratio 91

Decimation Mode 93

Gradation Compression Mode 94

Examples 95

Overlay Mode 97

ROIFunction (Single ROI) 98

Single ROI - Example 99

ROIFunction (Multi ROI) 100

Configuration Example 102

Color Space Conversion (ColorTransformationControl) 103

Edge Enhancer, Color Enhancer 104

Sequencer Function 105

TriggerSequencer Mode 105

Sample TriggerSequencer Mode Operation 106

User Manual (Ver. 1.0) - Table of Contents

- 6 -

CommandSequencer Mode 107

Pulse Generator 108

Counter and Timer Control Function 109

Counter Occurrence Diagram 109

Internal Camera Blocks 110

To Use the Counter Function 110

Action Control Function 111

Action Control Example 112

Chunk Data Function 112

Event Control Function 113

PTP (Precision Time Protocol) 114

Non-Volatile Flash Memory 115

Functions That Cannot Be Used Together 116

Setting List 117

Selector 117

Feature Properties 118

DeviceControl 118

TransportLayerControl 121

ImageFormatControl 125

MultiROIControl 131

AcquisitionControl 133

DigitalIOControl 135

PulseGenerator 138

AnalogControl 140

LUTControl 142

AutoLevelControl 143

ColorTransformationControl 145

ImagingControl 146

ShadingControl 147

BlemishControl 148

SequencerControl 149

CounterAndTimerControl 152

User Manual (Ver. 1.0) - Table of Contents

- 7 -

ActionControl 153

EventControl 154

ChunkDataControl 156

TestControl 157

UserSetControl 157

Miscellaneous 158

Troubleshooting 158

Power Supply and Connections 158

Image Display 158

Settings and Operations 158

Specifications 159

Spectral Response (GOX-5105M-5GE/GOX-5105C-5GE) 166

Spectral Response (GOX-8105M-5GE/GOX-8105C-5GE) 167

Spectral Response (GOX-12405M-5GE/GOX-12405C-5GE) 168

Spectral Response (GOX-16205M-5GE/GOX-16205C-5GE) 169

Spectral Response (GOX-20405M-5GE/GOX-20405C-5GE) 170

Spectral Response (GOX-24505M-5GE/GOX-24505C-5GE) 171

Dimensions 172

Camera 172

Heatsink Set (HS-02) 173

Heatsink Set (HS-02) with the Camera 174

Comparison of the Decibel Display and Multiplier Display 175

User's Record 176

Appendix 177

Revision History 178

User Manual (Ver. 1.0) - Table of Contents

- 8 -

About Technical Note

Some additional technical information is provided on the JAI website as Technical Notes. In this

manual, if a technical note is available for a particular topic, the above icon is shown. Please refer to

the following URL for Technical notes.

https://www.jai.com/support-software/technical-notes

User Manual (Ver. 1.0) - Notice/Warranty/Certifications

- 9 -

Notice/Warranty/Certifications

Notice

The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan, and

may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of

its product and assumes no responsibility for any errors which may appear or for damages resulting

from the use of the information contained herein. JAI Ltd., Japan reserves the right to make changes

without notice.

Company and product names mentioned in this manual are trademarks or registered trademarks of

their respective owners.

Warranty

For information about the warranty, please contact your factory representative.

Certifications

CE Compliance

As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC

(Electromagnetic compatibility), JAI Ltd., Japan declares that GOX-5105M-5GE, GOX-5105C-5GE,

GOX-8105M-5GE, GOX-8105C-5GE, GOX-12405M-5GE, GOX-12405C-5GE, GOX-16205M-5GE,

GOX-16205C-5GE, GOX-20405M-5GE, GOX-20405C-5GE, GOX-24505M-5GE, and GOX-24505C-

5GE comply with the following provisions applying to their standards.

EN 55032:2015(CISPR32:2015)

EN 55035:2017(CISPR35:2016)

FCC

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

lReorient or relocate the receiving antenna.

lIncrease the separation between the equipment and receiver.

User Manual (Ver. 1.0) - Notice/Warranty/Certifications

- 10 -

lConnect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

lConsult the dealer or an experienced radio/TV technician for help.

Warning

Changes or modifications to this unit not expressly approved by the party responsible for FCC

compliance could void the user’s authority to operate the equipment.

제조년월은 제품상자의 라벨을 참조하십시오.

User Manual (Ver. 1.0) - Notice/Warranty/Certifications

- 11 -

Supplement

The following statement is related to the regulation on “Measures for the Administration of the Control

of Pollution by Electronic Information Products “, known as “China RoHS“. The table shows contained

Hazardous Substances in this camera.

mark shows that the environment-friendly use period of contained Hazardous Substances is 15

years.

Applicable models: GOX-5105M-5GE, GOX-8105M-5GE, GOX-12405M-5GE, GOX-16205M-

5GE, GOX-20405M-5GE, GOX-24505M-5GE

重要注意事项

有毒，有害物质或元素名称及含量表

根据中华人民共和国信息产业部『电子信息产品污染控制管理办法』，本产品《有毒，有害物质或

元素名称及含量表》如下．

部件名称

有毒有害物质或元素

铅

(Pb)

汞

(Hg)

镉

(Cd)

六价铬

(Cr (VI)) 多溴联苯

(PBB) 多溴二苯醚

(PBDE)

电路板 × 〇〇〇〇〇

螺丝 × 〇〇〇〇〇

插座 × 〇〇〇〇〇

..... ..... ..... ..... ..... ..... .....

〇:表示该有毒有害物质在该部件所有均质材料中的含量均在GB/T 26572-2011规定的限量要求以下。

×:表示该有毒有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572-2011规定的限量要求。

环保使用期限

电子信息产品中含有的有毒有害物质或元素在正常使用的条件下不会发生外泄或突变、

电子信息产品用户使用该电子信息产品不会对环境造成严重污染或对其人身、财产造成

严重损害的期限。

数字「15」为期限15年。

User Manual (Ver. 1.0) - Notice/Warranty/Certifications

- 12 -

Supplement

The following statement is related to the regulation on “Measures for the Administration of the Control

of Pollution by Electronic Information Products “, known as “China RoHS“. The table shows contained

Hazardous Substances in this camera.

mark shows that the environment-friendly use period of contained Hazardous Substances is 15

years.

Applicable models: GOX-5105C-5GE, GOX-8105C-5GE, GOX-12405C-5GE, GOX-16205C-

5GE, GOX-20405C-5GE, GOX-24505C-5GE

重要注意事项

有毒，有害物质或元素名称及含量表

根据中华人民共和国信息产业部『电子信息产品污染控制管理办法』，本产品《有毒，有害物质或

元素名称及含量表》如下．

部件名称

有毒有害物质或元素

铅

(Pb)

汞

(Hg)

镉

(Cd)

六价铬

(Cr (VI)) 多溴联苯

(PBB) 多溴二苯醚

(PBDE)

电路板 × 〇〇〇〇〇

螺丝 × 〇〇〇〇〇

插座 × 〇〇〇〇〇

光学滤镜 × 〇 × 〇〇〇

..... ..... ..... ..... ..... ..... .....

〇:表示该有毒有害物质在该部件所有均质材料中的含量均在GB/T 26572-2011规定的限量要求以下。

×:表示该有毒有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572-2011规定的限量要求。

环保使用期限

电子信息产品中含有的有毒有害物质或元素在正常使用的条件下不会发生外泄或突变、

电子信息产品用户使用该电子信息产品不会对环境造成严重污染或对其人身、财产造成

严重损害的期限。

数字「15」为期限15年。

User Manual (Ver. 1.0) - Package Contents, Accessories

- 13 -

Package Contents, Accessories

Camera (1)

Sensor protection cap (1)

Dear customer (sheet) (1)

Optional Accessories (Sold Separately)

Note: The tripod adapter plate and the heatsink set cannot be used together. When using a tripod

with the heatsink set attached to the camera, use the tripod screw hole on the bottom of the

heatsink.

MP-46 Tripod Adapter Plate

HS-02 Heatsink Set

Related Topic: ②Heatsink Set (When Supplying Power via PoE)

User Manual (Ver. 1.0) - Usage Precautions

- 14 -

Usage Precautions

Notes on Supplying Power via PoE

The use of the PoE function results in higher power consumption and more heat generation than when

power is supplied via the 6-pin connector. Therefore, the PoE function should only be used if steps are

taken to ensure that excess heat does not create a safety hazard or cause damage to the camera.

Specifically, PoE should only be used when one of the two following operating conditions is met:

lThe camera is outfitted with the JAI Heatsink set (sold separately).

lThe camera is operated with a limited LAN cable length and frame rate as specified below.

Cautions:

lThe camera warranty does not cover the use of the PoE function unless one of the two

specified operating conditions is met.

lEven under specified operating conditions, the camera housing and heatsink surface

temperatures can reach 76°C at room temperature. Please take sufficient safety measures

to guard against serious injuries (burns).

Operating Condition Option 1: Attach the Heatsink Set

When operating this camera using PoE, attach the heatsink set (sold separately) to the camera.

When the heatsink set is properly attached, there are no limitations on the LAN cable length and/or the

frame rate.

Notes:

lFor details on how to attach the heatsink set, see ②Heatsink Set (When Supplying Power

via PoE) in the Preparation chapter.

lRegarding the heatsink set's performance, see Appendix.

User Manual (Ver. 1.0) - Usage Precautions

- 15 -

Operating Condition Option 2: Limit the LAN Cable Length and Frame Rate (without

Heatsink set)

When operating this camera using PoE without attaching the heatsink set, the following conditions

must be strictly observed.

1. LAN Cable Length: Less than 10m

2. Frame Rate: Do not exceed the frame rate shown below (50% of the camera’s maximum frame

rate)

Camera Model Recommended Max Frame Rate

GOX-5105MC-5GE 51 fps

GOX-8105MC-5GE 33 fps

GOX-12405MC-5GE 21 fps

GOX-16205MC-5GE 16 fps

GOX-20405MC-5GE 13 fps

GOX-24505MC-5GE 11 fps

If operating the camera for a long period of time, make sure that the camera's internal temperature will

not exceed the following maximum temperature. You can monitor the camera's internal temperature

by DeviceTemperature (DeviceControl).

Measurement Area Maximum Temperature Allowed

FPGA 95°C

Sensor 100°C

PHY 100°C

Notes on Cable Configurations

The presence of lighting equipment and television receivers nearby may result in video noise. In such

cases, change the cable configurations or placement.

User Manual (Ver. 1.0) - Usage Precautions

- 16 -

Notes on Attaching the Lens

How to Clean a Sensor

Avoiding Dust Particles

When attaching the lens to the camera, stray dust and other particles may adhere to the sensor

surface and rear surface of the lens. Be careful of the following when attaching the lens.

lWork in a clean environment.

lDo not remove the caps from the camera and lens until immediately before you attach the lens.

lTo prevent dust from adhering to surfaces, point the camera and lens downward and do not

allow the lens surface to come into contact with your hands or other objects.

lAlways use a blower brush to remove any dust that adheres.

lNever use your hands or cloth, blow with your mouth, or use other methods to remove dust.

Notes on LAN Cable Connection

Secure the locking screws on the connector manually, and do not use

a driver. Do not secure the screws too tightly. Doing so may wear

down the screw threads on the camera. (Tightening torque: 0.147 Nm

or less)

Caution: Secure manually. Do not secure too tightly.

User Manual (Ver. 1.0) - Usage Precautions

- 17 -

Phenomena Specific to CMOS Image Sensors

The following phenomena are known to occur on cameras equipped with CMOS image sensors.

These do not indicate malfunctions.

lAliasing: When shooting straight lines, stripes, and similar patterns, vertical aliasing (zigzag

distortion) may appear on the monitor.

lBlooming: When strong light enters the camera, some pixels on the CMOS image sensor may

receive much more light than they are designed to hold, causing the accumulated signal charge

to overflow into surrounding pixels. This “blooming” phenomenon can be seen in the image but

does not affect the operation of the camera.

lFixed pattern noise: When shooting dark objects in high-temperature conditions, fixed pattern

noise may occur throughout the entire video monitor screen.

lDefective pixels: Defective pixels (white and black pixels) of the CMOS image sensor are

minimized at the factory according to shipping standards. However, as this phenomenon can be

affected by the ambient temperature, camera settings (e.g., high sensitivity and long exposure),

and other factors, be sure to operate within the camera’s specified operating environment.

lVertical stripes: Due to the design characteristics of the sensor used, vertical stripes may

appear in the image when using the camera under the following condition(s), especially a

combination of these circumstances:

lA shallow incident angle, a large aperture, a short exposure time, and/or the use of long-

waveband lighting (especially infrared)

You may be able to improve the vertical stripes in the image by changing the above condition(s)

(e.g., smaller aperture, longer shutter speed).

Notes on Exportation

When exporting this product, please follow the export regulations of your country or region.

User Manual (Ver. 1.0) - Features

- 18 -

Features

These camera models are industrial progressive scan cameras equipped with a global shutter CMOS

image sensor. These small-size cameras (approx. 29mm x 29mm x 68mm) are also lightweight (95g),

which makes them easy to install and mount. In addition, these provide an attractive combination of

high resolution, high speed, and high image quality for machine vision applications.

Model Name Image Sensor Active Pixels Pixel Size Max Frame Rate*

(6-pin Power Supply)

GOX-5105M-5GE Mono

Type 1/1.8 2472 x 2064 2.74 μm x 2.74 μm 112 fps

GOX-5105C-5GE Color

GOX-8105M-5GE Mono

Type 2/3 2856 x 2848 2.74 μm x 2.74 μm 71 fps

GOX-8105C-5GE Color

GOX-12405M-5GE Mono

Type 1/1.1 4128 x 3008 2.74 μm x 2.74 μm 47 fps

GOX-12405C-5GE Color

GOX-16205M-5GE Mono

Type 1.1 5328 x 3040 2.74 μm x 2.74 μm 36 fps

GOX-16205C-5GE Color

GOX-20405M-5GE Mono

Type 1.1 4512 x 4512 2.74 μm x 2.74 μm 29 fps

GOX-20405C-5GE Color

GOX-24505M-5GE Mono

Type 1.2 5328 x 4608 2.74 μm x 2.74 μm 24 fps

GOX-24505C-5GE Color

*When Pixel Format =Mono8/BayerRG8,SensorDigitizationBits =10 Bits, NetworkThroughputSafetyMargin = 100,

Packet Size = 12036, ExtendedIDMode = Off.

Caution: Refer to Notes on Supplying Power via PoE for the frame rate limitation when supplying

power via PoE.

Feature Overview

lGlobal shutter CMOS image sensor with backside illuminated pixel technology

l8/10/12-bit output in choice of monochrome or raw Bayer color models

lFlexible ROI; rescaling function (monochrome and color); traditional 1x2, 2x1, 2x2 binning

(monochrome models); horizontal/vertical image flip function; blemish correction; shading

compensation; sequencer function; and Automatic Level Control (ALC). (See the Main Functions

chapter for details).

User Manual (Ver. 1.0) - Features

- 19 -

lCompact size with excellent shock and vibration resistance

lPoE or via separate 6-pin connector

Caution: See Notes on Supplying Power via PoEwhen the camera is operating with aPoE

power supply.

lLens mount: C-mount

User Manual (Ver. 1.0) - Parts Identification

- 20 -

Parts Identification

①Lens Mount (C-Mount) ②RJ-45 Connector

③LINKLED ④ACTLED

⑤POWER/TRIG LED ⑥DC IN/TRIG Connector (6-Pin Round)

⑦ ⑧ Mounting Holes

①Lens Mount (C-Mount)

Mount a C-mount lens, microscope adapter, etc. here.

Note: Before mounting a lens, be sure to refer to ①Lens and confirm the precautions for attaching

a lens and the supported lens types.

This manual suits for next models

Table of contents

Popular Security Camera manuals by other brands

urmet domus

urmet domus DS1092-244 quick guide

Honeywell

Honeywell HDZ30A user manual

Ikegami

Ikegami ISD-A30 instruction manual

Samsung

Samsung SNF-7010 user manual

Hanwha Vision

Hanwha Vision QNE-C9013RL user manual

Nuvico

Nuvico MP-OV22N installation manual

NDI

NDI BirdDog P110 user guide

Wisenet

Wisenet ANE-L6012R quick guide

Stealth Cam

Stealth Cam Titan STC-Z3IR instruction manual

Velleman

Velleman CAMCLOPIR user manual

BlueEyes

BlueEyes iCam PRO Operation manual

Riva

Riva RC8102HD-6111T installation guide

Ezviz

Ezviz C2C-FHD manual

Bosch

Bosch FLEXIDOME HD VR Quick install

Link Interactive

Link Interactive HD 100 installation guide

Bosch

Bosch MIC Series 550 user manual

JVC

JVC LoLux TK-T2101RU instructions

Nexvoo

Nexvoo N450-AI user manual

JAI GOX-5105M-5GE User manual

Popular Security Camera manuals by other brands
