Jamba Juice Smoothie & Ice Pop Maker Service manual
2
Welcome!
A long time ago, a few friends from a California beach
town had a pretty fruitful idea: to throw their favorite
fruits into a blender and whip up something tasty,
nutritious, and fun. Tada, the Jamba Juice smoothie
was born!
Today, Jamba Juice is still making delicious smoothies
from the best stuff in nature, like scrumptious straw-
berries with Vitamin C and belly-filling bananas with
potassium. Sometimes it can be hard to find food that
tastes good and is good for you, but Jamba smoothies
make it easy. And now you can make them yourself, at
home, any time you want!
With the Jamba Juice™ Smoothie & Ice Pop Maker,
it’s easy to whirl up your own smoothies and frozen
pops – just pick a recipe, add the ingredients, and get
blending! It’s fun, delicious, and nutritious—just like
Jamba Juice!
Product Overview
3
Contents:
• SmoothieMaker
with safety switch & lid lock
• Smoothiemixingjug
• Icepopmoldwith4compartments
• 4Icepopsticks
• Stirrer
• Instruction&recipebooklet
Safety isolation switch
on/off button
lid
cleaning brush
stirrer
ice pop sticks
upright for ice pop molds
hinge tabs
smoothiemixingjug
with non-removable safety grille ice pop mold
Product Overview
4
Safety Features
Your EZ-2 Make™ Jamba Juice™ Smoothie & Ice Pop Maker is fitted with 3 safety
features:
1. ThesmoothiemixingjugfortheSmoothieMakerhasanon-removable
safety grille which prevents fingers from accessing the cutting blades
(as shown in Diagram A). Simply cut the fruits into small segments and
put through the grille as described in the recipe pages.
2. Thesmoothiemixingjugwillseparatefromthebase,(pleasesee
Diagrams A-C) for cleaning purposes. The motor has a safety isolation
switch and cannot be switched on when the 2 parts
are separated.
3. Lid must be slid completely in place to activate the unit (Diagram D).
For your safety
• Donotre-freezeicecreamorsorbettomakeicepops.
• Askanadulttohelpremovethepopsfromthemold.
• Ensureyourhandsaredryoruseadryclothtohandlethepopmold,
• Whenremovingfromthefreezer,keepmoldsupright.
Your Hygiene
• AlwayswashyourhandsthoroughlybeforeusingtheSmoothieMaker.
• Alwaysaskanadulttowashanddrythesmoothiemixingjug,ice
pop molds, ice pop sticks, etc. in warm soapy water before using (see
Cleaning & Maintenance section).
• Alwaysusefreshingredients.
• Keeppetsawayfromfoodandfoodpreparationareas.
• Keepworksurfacescleanandtidytoavoidgerms.
• Allpartsaremadefromfoodgradematerials.
Diagram A
Diagram C
Diagram B
Diagram D
• Ifaddingicecreamorsorbettothemix:DONOTRE-FREEZE!
CAUTION!Containsfunctionalsharpedge.Adultsupervisionrequired.
Product Overview
5
Unpack and check the contents against the contents list on page 3 of
this booklet. Ensure the smoothie mixing jug, stirrer, ice pop molds &
ice pop sticks are thoroughly washed before use.
1. To install the batteries, loosen the battery cover screw on the base by
turningcounterclockwiseandremovebatterycover.Insert4xCsize
batteries inside the battery compartment, ensuring the correct polarity
(+/-) is followed (see diagram 1).
2. Lift the two hinge tabs upwards (see diagram 2).
3. Placethesmoothiemixingjughingesintothecradles.Pushthebase
of the jug (downwards & sideways) until it clicks into the base (see
diagram 3).
4. Closethehingetabs(seediagram4).
5. Make sure that the upright piece (that holds the ice pop mold into
place) is pushed fully inwards, towards the jug (see diagram 5).
6. Place the ice pop molds onto the upright piece (see diagram 6). Wash
and prepare the fruit (always ask an adult to cut the fruit for you). You
can place the fruit in the fridge to create a cooler smoothie. Carefully
followthemixingdetailsandmeasuresdescribedintheRecipeSection
andplacetheingredientsintothesmoothiemixingjugasinstructed.
7. Align&placethelidontothesmoothiemixingjug(seediagram7).
8. Pressthestartbuttononthesideofthebaseandmixuntiltheingre-
dientsaremixedaccordingtotherecipe(seediagram8).
9. Pourthemixtureintoaglassoricepopmoldsasspecifiedinthe
individual recipes (see diagram 9).
10. To fill the ice pop molds, line one mold up with the jug spout, remove
lid,tiltthejugtoonesideandfillnearlytothetop(leaveapprox.a
2mmgap).NOTE:liquidexpandswhenfrozen,sodonotoverfill.
11.Rotatetheicepopmoldandrepeatuntilallofthemoldsarefull(see
diagram 10). Place the ice pop sticks into the ice pop molds (see dia-
gram 11) and remove from the upright. Ask an adult to put this in the
freezingcompartment.NOTE:KEEPTHEICEPOPMOLDUPRIGHTFOR
STORAGE/FREEZING!Leavetheicepopmixtofreezeovernightoruntil
frozen(freezingtakesapprox.6-8hours,dependingonfreezersettings
& recipe contents).
Diagram 1
Diagram4
Diagram 7
Diagram 10
Diagram 2
Diagram 5
Diagram 8
Diagram 11
Diagram 3
Diagram 6
Diagram 9
6
Troubleshooting & Questions
Cleaning & Maintenance
Have an adult only do the following:
• DonotimmersethewholeSmoothieMakerintowater!
• Removethesmoothiemixingjugfromthebase(asshowninthedia-
grams on page 3).
• Washthejug,lid,icepopmold,yellowupright&icepopsticks
thoroughly in warm soapy water using the cleaning brush provided.
• Abottlebrushisincludedtocleantheinsideofthejug.
• Rinseunderthetaptoremoveanysoapsuds.Keepingthebattery
compartment cover on, surface wipe the remaining parts of the
Smoothie Maker with a damp, soapy cloth.
• Donotattempttocompletelysubmergeinwater.
• Allmaterialsmustbeproperlycleanedtoprevent
unsafe bacteria from growing.
Tips for a smoother smoothie:
• Chopthefruitsintosmallchunks(approx.1/4"x1/4")toputintothe
mixingjug.
• Seeindividualrecipesincludedforbestresults.
Do’s & Don’ts
• DonotattempttocrushiceintheSmoothieMaker.
• Alwayscrushtheicebeforeplacinginthemix.
• Alwaysusefresh,ripefruit.
• Alwaysaskanadulttocutthefruitforyou.
• DonotsubmergetheSmoothieMakerinwaterwhencleaning.
• Donotaddingredienttypesthatarenotincludedintherecipebook(as
this may damage the blade).
• Doensurethattheaccessoriesarecleananddrybeforepackingaway.
• Protectsurfacesintheplayarea.
• KeeptheSmoothieMakeroutofreachofchildrenunder5yearsold.
• DonotplacetheSmoothieMakeroneasilymarked,delicatesurfaces.
Tips
7
Symptom Problem Solution
You have not mixed the contents for
a long enough period.
The batteries are dead. OR
My Drink recipe has not mixed very
well.
The Smoothie Maker will not
switch on.
The Smoothie Maker has stopped
mixing.
The ice pops are difficult to remove
from the molds.
Pour the contents back into the smoothie mixing jug and mix
again.
Replace the 4 x C batteries.
The lid is not slid into place. Slide the lid along its track, into closed position.
The lid may be partially open. Slide the lid along its track, into closed position.
The batteries are not connected
properly. OR
Open the battery compartment and check that the batteries are
connected using the correct polarities (+/-).
The jug and motorized unit are not
properly connected together. OR
Ensure that the hinges are sitting in the cradle correctly and
the jug is clicked into the base correctly.
May be jammed.
OR
Use only soft, ripe ingredients. Switch the Smoothie Maker
off first, before removing jammed food items.
The ice pops sticks come away from
the pops and the ice pop is stuck in
the molds.
The ice pops have not completely
frozen. OR
Place back in the freezer for a few more hours.
The mix has not frozen well to the
ice pop stick.
Ta ke the sticks out and pour a small amount of cold water into
the slit made by the ice pop sticks. Replace the ice pop sticks &
place back in the freezer for a few more hours. When removing,
ask an adult to run warm water over the sides of the ice pop
mold for a few moments. NOTE: NEVER USE HOT OR BOILED
WATER! Also, try to make the mix a chunkier consistency.
Isolation switch has been
activated. OR
Ensure that the hinges are sitting in the cradle correctly and
the jug is clicked into the base correctly.
The ice pops are frozen hard & stuck
in the mold.
Leave to stand for a few minutes or ask an adult to run warm
water over the sides of the mold for a few moments.
NOTE: NEVER USE HOT OR BOILED WATER!
8
Recipes
Very Berry Banana:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.orangejuice
• 4strawberries,diced
• ½banana,diced
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the orange juice
and blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
If you would like a more smooth drink, blend for additional 2
minutesthenpourintoaglass&decoratewiththeextrachopped
strawberries.
If you would like to make ice pops, blend to a rough consistency,
thenpourthemixtureintotheicepopmolds,readyforfreezing.
Ask an adult to place the ice pop mold in the freezer and leave
until completely frozen.
Strawberry Apple Sensation:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.applejuice
• 4strawberries,diced
• ½banana,diced
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the apple juice and
blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
If you would like a more smooth drink, blend for additional 2
minutesthenpourintoaglass&decoratewiththeextrachopped
strawberries.
If you would like to make ice pops, blend to a rough consistency,
thenpourthemixtureintotheicepopmolds,readyforfreezing.
Ask an adult to place the ice pop mold in the freezer and leave
until completely frozen.
9
Recipes
Mango Strawberry Madness:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.lemonade
• 2strawberries,diced
• ½cupdicedmango
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the lemonade and
blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
If you would like a more smooth drink, blend for additional 2
minutesthenpourintoaglass&decoratewiththeextrachopped
fruit.
If you would like to make ice pops, blend to a rough consistency,
thenpourthemixtureintotheicepopmolds,readyforfreezing.
Ask an adult to place the ice pop mold in the freezer and leave
until completely frozen.
Peachy Mango Dream:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.applejuice
• 2strawberries,diced
• ½cupdicedmango
• ½peach,diced
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the apple juice and
blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
If you would like a more smooth drink, blend for additional 2
minutesthenpourintoaglass&decoratewiththeextrachopped
fruit.
If you would like to make ice pops, blend to a rough consistency,
thenpourthemixtureintotheicepopmolds,readyforfreezing.
Ask an adult to place the ice pop mold in the freezer and leave
until completely frozen.
10
Recipes
Orange Berry Bliss:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.orangejuice
• 3strawberries,diced
• ½cupblueberries
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the orange juice
and blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
Peach Banana Paradiso:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.orangejuice
• ½banana,diced
• 1peach,diced
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the orange juice
and blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
If you would like a more smooth drink, blend for additional 2
minutesthenpourintoaglass&decoratewiththeextrachopped
fruit.
If you would like to make ice pops, blend to a rough consistency,
thenpourthemixtureintotheicepopmolds,readyforfreezing.
Ask an adult to place the ice pop mold in the freezer and leave
until completely frozen.
Berries Aloha:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.pineapplejuice
• 4strawberries,diced
• ½cupraspberries
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the pineapple juice
and blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
If you would like a more smooth drink, blend for additional 2
minutesthenpourintoaglass&decoratewiththeextrachopped
strawberries.
If you would like to make ice pops, blend to a rough consistency,
thenpourthemixtureintotheicepopmolds,readyforfreezing.
Ask an adult to place the ice pop mold in the freezer and leave
until completely frozen.
11
Recipes
Berry Banana Delight:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.pineapplejuice
• 4strawberries,diced
• ½banana,diced
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the pineapple juice
and blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for 2 to 3 minutes.
Creamy Strawberry Blueberry Fusion:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.applejuice
• 2tbsp.strawberryyogurt
• 3strawberries,diced
• ½cupblueberries
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the apple juice and
yogurt and blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
If you would like a more smooth drink, blend for additional 2
minutesthenpourintoaglass&decoratewiththeextrachopped
strawberries.
If you would like to make ice pops, blend to a rough consistency,
thenpourthemixtureintotheicepopmolds,readyforfreezing.
Ask an adult to place the ice pop mold in the freezer and leave
until completely frozen.
Creamy Banana Berry Jumble:
Makestwo4oz.servings.Whatyouwillneed:
• 4floz.orangejuice
• 2tbsp.vanillayogurt
• 3strawberries,diced
• ½banana,diced
1. Dice fruit into small (¼ inch) cubes and refrigerate for 10 minutes.
2. When fruit is chilled, place in Smoothie Maker, add the orange juice
and yogurt and blend it for 5 minutes.
3. Add ¼ cup of crushed ice (for best results use small pieces of crushed
ice) after blending juice and fruits and blend for an additional 2 to 3
minutes.
If you would like a more smooth drink, blend for additional 2
minutesthenpourintoaglass&decoratewiththeextrachopped
strawberries.
If you would like to make ice pops, blend to a rough consistency,
thenpourthemixtureintotheicepopmolds,readyforfreezing.
Ask an adult to place the ice pop mold in the freezer and leave
until completely frozen.
Questions or Comments?
In North America please call
1-866-984-3121
Think Wow Toys, a division of WowWee USA, Inc.
TM & © 2009 Think Wow Toys
133 West 25th Street,
NewYork,NY10001
AllRightsReserved.
Jamba Juice and all Jamba Juice-based trademarks, product
names, slogans and logos that are referred to or displayed
herein are trademarks or registered trademarks of the
Jamba Juice Company in the US and other countries.
Requires4“C”Batteries.(BatteriesNotIncluded).
Please retain all information for future reference.
To replace batteries, unscrew battery compartment
coverwithaPhillipsheadscrewdriver.Removecover
andinsert4“C”batteriesobservingpolarity.
BATTERYSAFETYINFORMATION:
1. An adult should replace the batteries.
2. Non-rechargeablebatteriesarenottoberecharged.
3. Rechargeablebatteriesaretoberemovedfromthe
toy before being charged.
4. Rechargeablebatteriesareonlytobechargedunder
adult supervision.
5. Donotmixalkaline,standard(carbon-zinc),or
rechargeable (nickel-cadmium) batteries.
6. Donotmixoldandnewbatteries.
7. Onlybatteriesofthesameorequivalenttypeas
recommended are to be used.
8. Batteries are to be inserted with the correct polarity.
9. Exhaustedbatteriesaretoberemovedfromthetoy.
10. The supply terminals are not to be short-circuited.
11. Dispose of batteries safely. Do not dispose of batter-
iesinfire,astheymayleakorexplode.
Printed in China.
ProductmeetsorexceedallU.S.safetystandards.
ConformstoASTMF-963.
Contents may vary in style, color, shape and decoration from images
shownonpackage.Adultsupervisionrequired.
Warning! NotSuitableforChildrenunder5YearsofAge.
To be used only under the direct supervision of an adult.
Caution! SmoothieMixingJugcontainsfunctionalsharpedges.
Handlewithcare.AdultSupervisionRequired.
Table of contents
