Jandy FHPM FloPro Series User manual

Installation and Operating Data
Installation and
Operation Manual
FloPro
Series Pumps
Model FHPM
WARNING
FOR YOUR SAFETY: This product must be installed and serviced by a professional service
technician, qualified in pool/spa installation. The procedures in this manual must be followed
exactly. Improper installation and/or operation can create dangerous electrical hazards, which
can cause high voltages to run through the electrical system, possibly causing death, serious
injury or property damage. Improper installation and/or operation will void the warranty.
ATTENTION INSTALLER: This manual contains important information about
the installation, operation and safe use of this product. This information
should be given to the owner/operator of this equipment.
H0315300B

Page 3
FloPro Series Pumps Installation and Operation Manual
Table of Contents
Section 1. Important Safety Instructions........... 4
1.1 Safety Instructions .......................... 4
1.2 Pool Pump Suction Entrapment
Prevention Guidelines..................... 6
Section 2. General Description.......................... 8
2.1 Introduction..................................... 8
2.2 Description...................................... 8
Section 3. Installation........................................ 8
3.1 Plumbing......................................... 8
3.1.1 Preparation...................................... 8
3.1.2 Pump Location................................ 8
3.1.3 Replacement of Existing Pump....... 8
3.1.4 Pipe Sizing ...................................... 9
3.2 Electrical Installation ...................... 10
3.2.1 Voltage Checks................................ 10
3.2.2 Bonding and Grounding.................. 10
3.2.3 Electrical Wiring ............................. 11
3.3 Pressure Testing .............................. 11
Section 4. Operation.......................................... 12
4.1 Start-up............................................ 12
Section 5. Service and Maintenance ................. 13
5.1 Routine Maintenance ...................... 13
5.2 Winterizing the Pump ..................... 13
Section 6. Troubleshooting and Repair ............. 14
6.1 Troubleshooting .............................. 14
6.2 Service Technician Maintenance .... 15
6.2.1 Blocked Impeller............................. 15
6.2.2 Impeller Removal ........................... 15
6.2.3 Impeller Replacement..................... 16
6.2.4 Mechanical Seal Replacement........ 17
6.2.5 Motor Replacement......................... 18
Section 7. Product Specifications and
Technical Data.................................. 19
7.1 Replacement Parts List ................... 19
7.2 Exploded View................................ 20
7.3 FHPM Pump Curves....................... 21
7.4 Physical and Operational
Specifications.................................. 22
7.5 Replacement Motor Guide.............. 23
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER)
PUMP MODEL HORSEPOWER
NOTES:
EQUIPMENT INFORMATION RECORD

Page 4 FloPro Series Pumps Installation and Operation Manual
Section 1. Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS
1.1 Safety Instructions
All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes.
When installing and using this electrical equipment, basic safety precautions should always be followed, including the
following:
WARNING
To reduce the risk of injury, do not permit children to use this product.
WARNING
RISK OF SUCTION ENTRAPMENT HAZARD, WHICH, IF NOT AVOIDED, CAN RESULT IN SERIOUS
INJURY AND/OR DEATH. Do not block pump suction, as this can cause severe injury and/or death. Do
not use this pump for wading pools, shallow pools, or spas containing bottom drains, unless the pump
is connected to at least two (2) functioning suction outlets. Drain covers must be certified to the latest
published version of ANSI/ASME A112.19.8.
WARNING
To reduce the risk of property damage and/or injury, do not attempt to change the backwash (multiport,
slide, or full flow) valve position with the pump running.
WARNING
Jandy Pumps are powered by a high voltage electric motor and must be installed by a licensed or certified
electrician or a qualified swimming pool service technician.
WARNING
Due to the potential risk of fire, electric shock, or injuries to persons, Jandy Pumps must be installed
in accordance with the National Electrical Code (NEC), all local electrical and safety codes, and the
Occupational Safety and Health Act (OSHA). Copies of the NEC may be ordered from the National
Fire Protection Association, 470 Atlantic Ave., Boston, MA 02210, or received by contacting your local
government inspection agency.
WARNING
Incorrectly installed equipment may fail, causing severe injury and/or property damage.
WARNING
• Do not connect the system to an unregulated city water system or other external source of pressurized
water producing pressures greater than 35 PSI.
• Trapped air in the system can cause the pump and/or filter lid to be blown off. This can result in death,
serious personal injury, and/or property damage. Be sure all air is out of the system before operating.

Page 5
FloPro Series Pumps Installation and Operation Manual
CAUTION
This pump is for use with permanently installed pools and may also be used with hot tubs and spas, if so
marked. Do not use with storable pools. A permanently installed pool is constructed in or on the ground
or in a building such that it cannot be readily disassembled for storage. A storable pool is constructed so
that it may be readily disassembled for storage and reassembled to its original integrity.
CAUTION
Do not install within an outdoor enclosure or beneath the skirt of a hot tub or portable spa. The
pump requires adequate ventilation to maintain air temperature at less than the maximum ambient
temperature rating listed on the motor rating plate.
SAVE THESE INSTRUCTIONS
WARNING
Chemical spills and fumes can weaken pool/spa equipment. Corrosion can cause filters and other
equipment to fail, resulting in severe personal injury or property damage. Do not store pool chemicals
near your equipment.
CAUTION
Do not start pump dry! Running the pump dry for any length of time will cause severe damage and will
void the warranty.
WARNING
To minimize the risk of severe injury or death, the filter and/or pump should not be subjected to the
piping system pressurization test.
Local codes may require the pool piping system to be subjected to a pressure test. These requirements
are generally not intended to apply to the pool equipment, such as filters or pumps.
Jandy pool equipment is pressure tested at the factory.
However, if the WARNING cannot be followed and pressure testing of the piping system must include
the filter and/or pump, BE SURE TO COMPLY WITH THE FOLLOWING SAFETY INSTRUCTIONS:
• Check all clamps, bolts, lids, lock rings, and system accessories to make sure they are properly
installed and secured before testing.
• RELEASE ALL AIR in the system before testing.
• Water pressure for test must NOT EXCEED 35 PSI.
• Water temperature for test must NOT EXCEED 100°F (38°C).
• Limit test to 24 hours. After test, visually check the system to make sure it is ready for operation.
Notice: These parameters apply to Jandy equipment only. For non-Jandy equipment, consult the
equipment manufacturer.

Page 6 FloPro Series Pumps Installation and Operation Manual
1.2 Pool Pump Suction Entrapment Prevention Guidelines
WARNING
Pump suction is hazardous and can trap and drown or disembowel bathers. Do not use or
operate swimming pools, spas, or hot tubs if a suction outlet cover is missing, broken, or loose.
The following guidelines provide information for pump installation that minimizes the risk of injury to
users of pools, spas, and hot tubs:
Entrapment Protection - The pump suction system must provide protection against the hazards of
suction entrapment.
Suction Outlet Covers - All suction outlets must have correctly installed, screw-fastened covers in
place. All suction outlet (drain) covers must be maintained. Drain covers must be listed/certified to the
latest version of ANSI/ASME A112.19.8. They must be replaced if cracked, broken, or missing.
Number of Suction Outlets Per Pump - Provide at least two (2) main drains, with covers, as suction
outlets for each circulating pump suction line. The centers of the main drains (suction outlets) on any
one (1) suction line must be at least 3 feet apart, center to center. See Figure 1 on page 7. For additional
details and guidelines, refer to ANSI/APSP 7, the standard for Suction Entrapment Avoidance in
Swimming Pools, Wading Pools, Spas, Hot Tubs, and Catch Basins.
The system must be built to include at least two (2) suction outlets (drains) connected to the pump
whenever the pump is running. However, if two (2) main drains run into a single suction line, the single
suction line may be equipped with a valve that will shut off both main drains from the pump. The system
shall be constructed such that it shall not allow for separate or independent shutoff or isolation of each
drain. See Figure 1 on page 7.
More than one (1) pump can be connected to a single suction line as long as the requirements above
are met.
Water Velocity - The maximum water velocity through the suction fitting or cover for any suction outlet
must be 1.5 feet per second, unless the outlet complies with the latest published version of ANSI/ASME
A112.19.8, the standard for Suction Fittings For Use in Swimming and Wading Pools, Spas, Hot Tubs,
and Whirlpool Bathtub Applications. In any case, do not exceed the suction fitting’s maximum designed
flow rate.
If 100% of the pump’s flow comes from the main drain system, the maximum water velocity in the pump
suction hydraulic system must be 6 feet per second or less, even if one (1) main drain (suction outlet) is
completely blocked. The flow through the remaining main drain(s) must comply with the latest published
version of ANSI/ASME A112.19.8, the standard for Suction Fittings For Use in Swimming and Wading
Pools, Spas, Hot Tubs, and Whirlpool Bathtub Applications.
Testing and Certification - Suction outlet covers must have been tested by a nationally recognized
testing laboratory and found to comply with the latest published version of ANSI/ASME A112.19.8, the
standard for Suction Fittings For Use in Swimming and Wading Pools, Spas, Hot Tubs, and Whirlpool
Bathtub Applications.
Fittings - Fittings restrict flow; for best efficiency use the fewest possible fittings (but at least two (2)
suction outlets).
Avoid fittings that could cause an air trap.
Pool cleaner suction fittings must conform to applicable International Association of Plumbing and
Mechanical Officials (IAPMO) standards.
WARNING
SUCTION HAZARD. Can cause serious injury or death. Do not use this pump
for wading pools, shallow pools, or spas containing bottom drains, unless the
pump is connected to at least two (2) functioning suction outlets.

Page 7
FloPro Series Pumps Installation and Operation Manual
Figure 1. Number of Suction Outlets Per Pump
At Least
3 Feet
Suction Outlet
(Main Drain)
Suction Outlet
(Main Drain)
No valves between
Tee and Main Drains
Listed/certified to the latest
published version of
ANSI/ASME A112.19.8
Anti-entrapment
Cover/Grate or Suction
Fitting, screw-fastened to
Main Drain Sump
Listed/certified to the latest
published version of
ANSI/ASME A112.19.8
Anti-entrapment
Cover/Grate or Suction
Fitting, screw-fastened to
Main Drain Sump
Valves OK between
pump and Tee
Pump

Page 8 FloPro Series Pumps Installation and Operation Manual
Section 2. General Description
2.1 Introduction
This manual contains information for the proper
installation, operation, and maintenance of Jandy FloPro
(FHP) Series Pumps, Model FHPM. Procedures in this
manual must be followed exactly. To obtain additional
copies of this manual, contact Jandy Customer Service
at 1.800.822.7933. For address information, see the
back cover of this manual.
2.2 Description
Jandy FHP Pumps are designed to meet the
needs of today’s more hydraulically demanding pool
equipment. The pump housing, backplate, diffuser,
impeller, and hair-and-lint pot (pump debris filter
basket) are all made from high quality thermoplastic
materials. These materials were chosen for their strength
and corrosion resistance.
The pump is driven by an electric motor directly
attached to the pump impeller. As the electric motor
turns, it causes the impeller to turn, which forces water
to flow through the pump. The water flows through the
pump inlet and then into the filter basket. The basket
assembly pre-strains/traps large particles. The water
then enters the center of the pump housing, flows
through the impeller into the diffuser, and then flows
out the pump discharge port.
Section 3. Installation
3.1 Plumbing
3.1.1 Preparation
1. Upon receipt of the pump, check the carton for
damage. Open the carton and check the pump for
concealed damage, such as cracks, dents, or a bent
base. If you find damage, contact the shipper or
the distributor where the pump was purchased.
2. Inspect the contents of the carton and verify
that all parts are included. See Section 7.1,
Replacement Parts List.
3.1.2 Pump Location
1. Zodiac Pool Systems, Inc. recommends installing
the pump within 1 foot above water level. The
pump should not be elevated more than a few feet
above the water level of the pool. A check valve is
recommended on the suction line to the pump.
NOTE Better self-priming will be achieved if the pump
is installed as close as possible to the water
level of the pool.
2. If the pump is located below water level, isolation
valves must be installed on both the suction and
return lines to prevent the back flow of pool water
during any routine or required servicing.
3. Zodiac Pool Systems, Inc. recommends that the
pump and other circulation equipment be located
more than 5 feet from the water. Choose a location
that will minimize turns in the piping.
NOTE In Canada, the pump must be located a
minimum of 3 meters (approximately 10 feet)
from the water (CSA C22.1).
4. The pump must be placed on a solid foundation
that will not vibrate. To further reduce the
possibility of vibration noise, bolt the pump to the
foundation, or place it on a rubber mat.
NOTE Zodiac Pool Systems, Inc. recommends bolting
the pump directly to the foundation.
5. The pump foundation must have adequate drainage
to prevent the motor from getting wet. Protect the
pump from the rain and sun.
6. Proper ventilation is required for the pump to
operate normally. All motors generate heat that
must be removed by providing proper ventilation.
7. Provide access for future service by leaving a
clear area around the pump. Allow plenty of space
above the pump to remove the lid and basket for
cleaning.
8. If the equipment is under cover, provide adequate
lighting.
WARNING
Some Safety Vacuum Release System (SVRS)
devices are not compatible with installation of check
valves. If the pool has an SVRS device, be sure to
confirm that that it will continue to safely operate when
any check valves are installed.

Page 9
FloPro Series Pumps Installation and Operation Manual
3.1.3 Replacement of Existing Pump
Jandy FHP pumps can easily replace several
other pumps: the Hayward®Super Pump®, Pentair®
SuperFlo®, Pentair®WhisperFlo®, Jandy PlusHP (PHP),
and Jandy MaxHP (MHP).
To replace the Pentair®WhisperFlo®, Jandy PHP,
or Jandy MHP, use the FHP’s adjustable base. The FHP
base (and its spacers) increase the total height of the
pump and the height of the suction side of the pump.
See Table 1.
Table 1. FHP Dimensions
Base Configuration Suction Side
Height
Pump
Height
Pump without Base 7 ¾" 12¾"
Pump with Base 8⅞"13⅞"
Pump with Base and Spacers 9⅛"14⅛"
3.1.3.1 Hayward®Super Pump® and
Pentair®SuperFlo®
The Jandy FHP can replace a Hayward®Super
Pump®or a Pentair®SuperFlo®without using the FHP
base. See Figure 2.
7 3/4"
12 3/4"
Figure 2. Place FHP Directly on Equipment Pad
8 7/8"
13 7/8"
Figure 3. Place FHP with Base on Equipment Pad
X
X
Cut
spacers
at X.
Figure 4. Cut Sets of Spacers Out of Base
Figure 5. Snap Spacers into Place
9 1/8"
14 1/8"
Figure 6. Place FHP with Base and Spacers on
Equipment Pad
3.1.3.2 Pentair® WhisperFlo® Pump
To replace a Pentair®WhisperFlo®pump with a
Jandy FHP, place the FHP base on the equipment pad
and place the FHP on the base, as shown in Figure 3.
3.1.3.3 Jandy PlusHP (PHP) and
Jandy MaxHP (MHP)
To replace a Jandy PHP or Jandy MHP pump with a
Jandy FHP, use the FHP base with spacers.
1. Using a hand cutter tool, cut the plastic bars
connecting the top and bottom sets of spacers, as
shown in Figure 4.
2. Push the two (2) top spacers and two (2) bottom
spacers out of the base.
3. Align the pins in the four (4) spacers with the
holes in the base and snap the spacers into place,
as shown in Figure 5.
4. Place the FHP on the base assembly. See Figure 6.
Hayward and Super Pump are registered trademarks of Hayward
Industries, Inc.
Pentair is a registered trademark of Pentair, Inc.
SuperFlo and WhisperFlo are registered trademarks of Pentair Water
Pool and Spa, Inc.

Page 10 FloPro Series Pumps Installation and Operation Manual
3.1.4 Pipe Sizing
3.1.3.1 Suction Pipe
When the pump is located up to 50 feet from the
pool, the recommended Schedule 40 minimum pipe size
for the suction side of the pump is 1½" for .75 HP and
2" for 1to 2 HP. For 2.5 HP pumps, the recommended
pipe size is 2½".
3.1.3.2 Discharge Pipe
When the pump is located up to 50 feet from the
pool, the recommended Schedule 40 minimum pipe size
for the discharge side of the pump is 1½" for .75 HP and
2" for 1to 2 HP. For 2.5 HP pumps, the recommended
pipe size is 2½".
NOTE All pipe sizes (Schedule 40) are able to
withstand the pressures the pump will deliver,
but not necessarily the flow. If the pipe is too
small for the pump, or if the pump is elevated
above water, the maximum gallons per minute
(GPM) may not be delivered. If this happens,
the pump will develop an air pocket (cavitation)
that will make noise, and the life of the pump
may be shortened.
3.1.3.3 Installation Recommendations
1. If the pump is located below water level, isolation
valves must be installed on both sides of the pump
to prevent the back flow of pool water during any
routine or required servicing.
2. To help prevent difficulty in priming, install the
suction pipe without high points, which can trap
air. (High points are inverted ‘U’s above the inlet
of a pump. In plumbing, they are commonly
referred to as airlocks.) For installations of
equipment up to 100 feet from the water, refer to
the pipe sizing chart in Table 2. For installations of
equipment more than 100 feet from the water, the
recommended pipe size must be increased to the
next size.
Table 2. Pipe Sizing Chart for Schedule 40 PVC
Pipe
Size
Maximum Flow
Suction
(8 feet per second)
Maximum Flow
Discharge
(10 feet per second)
1½" 50 GPM (189 LPM) 65 GPM (246 LPM)
2" 85 GPM (322 LPM) 105 GPM (397 LPM)
2½" 120 GPM (454 LPM) 149 GPM (564 LPM)
3. FHP Pumps come equipped with unions on
both the suction and discharge ports. This
feature simplifies installation and service, and
it eliminates the possibility of leaks at threaded
adapters.
4. The FHP Pump must be connected to at least two
(2) main drains (suction outlets) for each pool
pump suction line. Each drain must be provided
with covers that are listed or certified to the latest
published version of ANSI/ASME A112.19.8.
The suction outlets of the main drains must be at
least 3 feet apart or at different planes. The suction
outlets can be a drain and skimmer, two (2) drains,
two (2) skimmers, or a skimmer with an equalizer
line installed. For additional details and guidelines,
refer to ANSI/APSP 7, the standard for Suction
Entrapment Avoidance in Swimming Pools,
Wading Pools, Spas, Hot Tubs, and Catch Basins.
Check the local codes for proper installation
requirements. Applicable local codes will take
precedence over other codes.
NOTE To prevent entrapment, the system must be
built so that it cannot operate with the pump
drawing water from only one (1) main drain. At
least two (2) main drains must be connected
to the pump when it is in operation. However,
if two (2) main drains run into a single suction
line, the single suction line may be equipped
with a valve that will shut off both main drains
from the pump.
5. The piping must be well supported and not forced
together in places where constant stress will be
experienced.
6. Always use properly sized valves. Jandy Diverter
Valves and Jandy Ball Valves typically have the
best flow capabilities.
7. Use the fewest fittings possible. Every additional
fitting has the effect of moving the equipment
farther away from the water.
NOTE If more than 10 suction fittings are needed, the
pipe size must be increased.
8. Every new installation must be pressure tested
according to local codes. See Section 3.3, Pressure
Testing.
3.2 Electrical Installation
3.2.1 Voltage Checks
The correct voltage, as specified on the pump data
plate, is necessary for proper performance and long
motor life. The incorrect voltage will decrease the
pump’s ability to perform and can cause overheating,
reduce the motor life, and result in higher electric bills.
It is the responsibility of the electrical installer
to provide data plate operating voltage to the pump
by ensuring proper circuit sizes and wire sizes for the
specific application.

Page 11
FloPro Series Pumps Installation and Operation Manual
CAUTION
The pump must be permanently connected to a
dedicated electrical circuit. No other equipment,
lights, appliances, or outlets may be connected to
the pump circuit, with the exception of devices that
may be required to operate simultaneously with the
pump, such as a chlorinating device or heater.
3.2.3 Electrical Wiring
WARNING
To avoid risk of property damage, severe personal
injury, or death, always ground before connecting to
an electrical power suppy.
1. The pump motor must be securely and adequately
grounded using the green screw provided. Ground
before attempting to connect to an electrical power
supply. Do not ground to a gas supply line.
2. Wire size must be adequate to minimize a voltage
drop during the start-up and operation of the
pump. See Table 3 for suggested wire sizes.
3. Insulate all connections carefully to prevent
grounding or short-circuits. Provide extra
protection for sharp edges on terminals. To
prevent wire nuts from loosening, tape them
using a suitable, listed (UL, ETL, CSA) electrical
insulating tape. For safety, and to prevent entry
of contaminants, reinstall all conduit and terminal
box covers. Do not force connections into the
conduit box.
4. To configure the internal wiring of the pump motor
for the correct voltage, refer to the diagram on the
motor data plate.
CAUTION
Failure to provide data plate voltage (within 10%)
during operation will cause the motor to overheat
and will void the warranty.
3.2.2 Bonding and Grounding
1. The motor frame must be grounded to a reliable
grounding point using a solid copper conductor,
No. 8 AWG or larger. In Canada, No. 6 AWG or
larger must be used. If the pump is installed within
5 feet of the inside walls of the swimming pool,
spa, or hot tub, the motor frame must be bonded to
all metal parts of the swimming pool, spa, or hot
tub structure and to all electrical equipment, metal
conduit, and metal piping within 5 feet of the
inside walls of the swimming pool, spa, or hot tub.
2. Bond the motor using the provided external lug.
WARNING
To avoid the risk of property damage, severe
personal injury, and/or death, always disconnect
the power source before working on a motor or its
connected load.
WARNING
To avoid the risk of property damage, severe
personal injury, and/or death, make sure that the
control switch or time clock is installed in an easily
accessible location, so that in the event of an
equipment failure or a loose plumbing fitting, the
equipment can be easily turned off.
RECOMMENDED MINIMUM WIRE SIZE (AWG) FOR FHP PUMPS*
Distance from Sub-Panel 0-50 Feet 50-100 Feet 100-150 Feet 150 Feet-200 Feet
Model
Branch Fuse AMPS
Class: CC, G, H, J, K,
RK, or T
Voltage Voltage Voltage Voltage
230 VAC 115 VAC 230 VAC 115 VAC 230 VAC 115 VAC 230 VAC 115 VAC 230 VAC 115 VAC
FHPM 0.75HP 15A 15A 14 12 12 8 10 6 8 6
FHPM 1.0HP 15A 20A 14 10 10 8 8 6 8 4
FHPM 1.5HP 15A 20A 12 10 10 6 8 6 6 4
FHPM 2.0HP 15A 20A 12 8 8 6 6 4 6 3
FHPM 2.5HP 15A N/A 12 N/A 8 N/A 6 N/A 6 N/A
FHPM 1.0HP-2-Speed 15A N/A 14 N/A 10 N/A 8 N/A 8 N/A
FHPM 1.5HP-2-Speed 15A N/A 12 N/A 10 N/A 8 N/A 6 N/A
FHPM 2.0HP-2-Speed 15A N/A 12 N/A 8 N/A 6 N/A 6 N/A
*Assumes three (3) copper conductors in a buried conduit and 3% maximum voltage loss in branch circuit. All National Electrical Code (NEC) and
local codes must be followed. Table shows minimum wire size and branch fuse recommendations for a typical installation per NEC.
Table 3. Recommended Minimum Wire Size for FHP Pumps

Page 12 FloPro Series Pumps Installation and Operation Manual
3.3 Pressure Testing
WARNING
When pressure testing a system with water, air
is often trapped in the system during the filling
process. This air will compress when the system
is pressurized. Should the system fail, this trapped
air can propel debris at a high speed and cause
property damage, severe injury, or death. Every
effort to remove trapped air must be taken,
including opening the bleed valve on the filter
and loosening the pump basket lid while filling the
pump.
WARNING
Trapped air in system can cause the filter lid to
be blown off, which can result in death, serious
personal injury, or property damage. Be sure all air
is properly out of system before operating. DO NOT
USE COMPRESSED AIR TO PRESSURE TEST OR
CHECK FOR LEAKS.
WARNING
Do not pressure test above 35 PSI. Pressure
testing must be done by a trained pool professional.
Circulation equipment that is not tested properly may
fail. This could result in severe personal injury or
property damage.
WARNING
When pressure testing the system with water, it is
very important to make sure that the pump basket
lid is completely secure.
1. Fill the system with water, being careful to
eliminate trapped air.
2. Pressurize the system with water to no more than
35 PSI.
3. Close the valve to trap pressurized water in the
system.
4. Carefully observe the system for leaks and/or
pressure decay.
Section 4. Operation
4.1 Start-up
CAUTION
Never run the pump without water. Running the
pump "dry" for any length of time can cause severe
damage to both the pump and motor and will void
the warranty.
If this is a new pool installation, make sure all
piping is clear of construction debris and has been
properly pressure tested. Check the filter for proper
installation, verifying that all connections and
clamps are secure according to the manufacturer’s
recommendations.
WARNING
To avoid risk of property damage, severe personal
injury, or death, verify that all power is turned off
before starting this procedure.
1. Release all pressure from the system and open the
filter pressure release valve.
2. Take one of the following actions:
– If the pump is located below the water level
of the pool, open the filter pressure release
valve to prime the pump with water.
– If the pump is located above the water level,
remove the lid and fill the basket with water
before starting the pump.
3. Prior to replacing the lid, check for debris around
the lid o-ring seat. Debris around the lid o-ring
seat will cause air to leak into the system, and
make it difficult to prime the pump.
4. Hand-tighten the lid to make an air tight seal. Do
not use any tools to tighten the lid: hand-tighten
only. Ensure that the lid is secure. Make sure all
valves are open and the unions are tight.
5. Restore power to the pump and then turn it on.
6. Once all the air has left the filter, close the filter
pressure release valve.
7. The pump should prime. The time it takes to prime
will depend on the elevation and length of pipe
used on the suction supply pipe. See
Section 3.1.3.3, Installation Recommendations for
proper elevation and pipe size.
8. If the pump does not prime and all the instructions
to this point have been followed, check for a
suction leak. If there is no leak, repeat Steps 2
through 7.
9. For technical assistance, call Jandy Technical
Support at 1.800.822.7933.

Page 13
FloPro Series Pumps Installation and Operation Manual
Section 5. Service and Maintenance
5.1 Routine Maintenance
WARNING
To avoid the risk of property damage, severe personal
injury, and/or death, turn off the pump and switch off
the circuit breaker to the pump motor before servicing
the pump.
Inspect the pump basket for debris by looking
through the clear pump lid. Remove any debris, because
as debris accumulates, it will begin to block the flow
of water through the pump. Keep the basket clean to
improve the performance of the pump.
1. Turn off the power to the pump. If the pump is
located below the water level, close the isolation
valves on the suction and discharge sides of the
pump to prevent backflow of water.
2. Turn the lid’s locking ring counter-clockwise until
‘START’ aligns with the ports. Carefully remove
the lid.
CAUTION
A misaligned basket will cause the lid to be
improperly seated, allowing an air leak, which could
result in pump damage.
3. Lift the basket out of the pump. Dispose of all
debris and thoroughly clean the basket, making
sure all the holes are open. Using a garden hose,
spray the basket from the outside to help clear the
holes. Remove any remaining debris by hand.
4. Replace the basket in the pump by aligning the
open section of the basket with the inlet pipe. If
aligned properly, the basket will drop easily into
place. Do not force it into place.
5. Remove the lid o-ring and remove debris around
the lid o-ring seat, as this will cause air leaks into
the system. Clean the lid o-ring and replace it.
6. Replace the lid with locking ring on the pump
housing. Align ‘START’ with the ports and turn
the lid’s locking ring clockwise until ‘LOCKED’
aligns with the ports. Hand-tighten the lid to make
an air tight seal. Do not use any tools to tighten
the lid.
7. Verify that all valves have been returned to the
proper position for normal operation.
8. Open the pressure release valve on the filter, and
make sure it is clean and ready for operation.
9. Turn on the power to the pump. Once all the air
has been evacuated from the filter, close the filter
pressure release valve.
5.2 Winterizing the Pump
CAUTION
The pump must be protected when freezing
temperatures are expected. Allowing the pump
to freeze will cause severe damage and void the
warranty.
CAUTION
Do not use antifreeze solutions in the pool,
spa, or hot tub systems! Antifreeze is highly toxic
and may damage the circulation system. The only
exception to this is Propylene Glycol. For more
information, see your local pool/spa supply store or
contact a qualified swimming pool service company.
1. Drain all water from the pump, system equipment,
and piping.
2. Remove the two (2) drain plugs. Store the drain
plugs in a safe location and reinstall them when
the cold weather season is over. Do not lose the
o-rings.
3. Keep the motor covered and dry. Do not cover it
with plastic, as this will create condensation and
this moisture will damage the pump.
NOTE To protect your pump, Zodiac Pool Systems,
Inc. recommends having a qualified service
technician or electrician properly disconnect
the electrical wiring at the switch or junction
box. Once the power is removed, the two (2)
unions can be loosened and the pump stored
indoors. For safety, and to prevent entry of
contaminants, reinstall all conduit and terminal
box covers.
4. When the system is reopened for operation, make
sure all piping, valves, wiring, and equipment
are in accordance with the manufacturer’s
recommendations. Pay close attention to the filter
and electrical connections.
5. The pump must be primed prior to starting; refer
to Section 4.1, Start-up.

Page 14 FloPro Series Pumps Installation and Operation Manual
Section 6. Troubleshooting and Repair
Zodiac Pool Systems, Inc. strongly recommends that you call a qualified service technician to perform any repairs
on the filter/pump system. To locate a qualified technician, check your local yellow pages or visit www.jandy.com and
click on “Product Support.”
6.1 Troubleshooting
Symptom Possible Problem/Solution
The cleaning/circulating system is
not operating correctly.
Verify that skimmer baskets, pump basket and other screens are clean. Clean as
necessary.
Check filter and clean as necessary.
Check valve positions. Adjust as necessary.
NOTE Multiple pieces of equipment operating at one time (for example, waterfalls, spa
jets, and surface returns) may affect the cleaning system and prevent it from working
properly.
Check the cleaning system manual to ensure that the system is adjusted according to the
manufacturer's recommendations.
Bubbles present in the pump
basket.
Air in system. Check the pool or spa water level to ensure that it is at the proper level and
that air is not being drawn into the suction piping. If the water is at the normal level, turn off
the pump. Turn the lid’s locking ring counter-clockwise until ‘START’ aligns with the ports.
Carefully remove the lid and check for debris around the lid o-ring seat, as debris will cause
air to leak into the system. Clean the lid o-ring and place on the lid. Replace the lid with
locking ring on the pump housing. Align ‘START’ with the ports and turn the lid’s locking
ring clockwise until ‘LOCKED’ aligns with the ports. Hand-tighten the lid to make an air
tight seal. Do not use any tools to tighten the lid. Turn the pump back on.
Air leaks are still present. Check the suction side piping union. While the pump is running, try to tighten the union. If
this does not stop the air leak, turn off the pump. Loosen both unions and slide the pump
out of the way. Remove, clean and re-install both union o-rings.
Reposition the pump next to the piping and secure the union nuts to the pump. With clean
union o-rings, hand-tightening of the unions should create a seal. If the unions still do not
seal, gently tighten with a large pair of tongue-and-groove pliers.
Do not over-tighten.
There is no air in the system, but
the pressure is still low.
It is possible that debris is caught in the pump impeller. The pump impeller moves the
water, and the vanes in the impeller can become blocked with debris. See Section 6.2,
Service Technician Maintenance, 6.2.1, Blocked Impeller, for more information.
There is no debris blocking the
impeller and the pressure is still
low.
The pump impeller and diffuser are showing signs of normal wear. Have a qualified service
technician check the impeller and diffuser and replace as necessary.
If the pump is part of a relatively new installation, it could be an electrical problem. Contact
a qualified service technician. Have the technician check for loose electrical connections
and check the voltage at the pump motor while it is in operation. The voltage must be within
10% of the motor’s data plate rating. If the voltage is not within 10%, contact a qualified
electrician and/or the local power service provider.
The pump seal is leaking air. Have a qualified service technician replace the seal.
The pump is leaking water between
the motor and pump body.
This is caused by a damaged or failed mechanical seal. Replace the seal. See Section 6.2,
Service Technician Maintenance, 6.2.4, Mechanical Seal Replacement.
The pump gets hot and shuts off
periodically.
Ensure that there is adequate room around the motor to circulate air and keep the motor
cool. Have a qualified electrician check for loose connections and check the voltage at the
pump motor while it is in operation. The voltage must be within 10% of the motor's data
plate rating. If the voltage is not within 10%, contact a qualified electrician and/or the local
power service provider.

Page 15
FloPro Series Pumps Installation and Operation Manual
4. Pull the motor and backplate out of the pump
body. Remove the pump body o-ring. The impeller
is connected to the motor shaft.
5. Using a No. 1 Phillips screwdriver, remove the
two (2) screws holding the diffuser. (The diffuser
is the cover over the impeller). Then remove the
diffuser. (See Figure 8.)
6.2 Service Technician Maintenance
WARNING
This pump must be serviced by a professional
service technician, qualified in pool/spa installation.
The following procedures must be followed exactly.
Improper installation and/or operation can create
dangerous electrical hazards, which can cause high
voltages to run through the electrical system. This
can cause property damage, serious injury, and/
or death. Improper installation and/or operation will
void the warranty.
6.2.1 Blocked Impeller
WARNING
Before servicing the pump, turn off the pump and
switch off the circuit breaker to the pump motor.
Severe personal injury, death, or property damage
may occur if the pump starts while your hand is
inside the pump.
1. Turn off the pump. Switch off the circuit breaker
to the pump motor.
2. Remove the lid and basket.
3. Look inside the pump for any debris. Remove any
debris found inside.
4. Replace the basket and lid.
5. Switch on the circuit breaker to the pump motor.
6. Turn on the pump, and see if the problem is
solved.
7. If the impeller is still blocked with debris and it
is not possible to remove the debris using Steps 2
through 4, the pump will need to be disassembled
in order to access the inlet and outlet of the
impeller.
6.2.2 Impeller Removal
WARNING
Before servicing the pump, turn off the pump and
switch off the circuit breaker to the pump motor.
Severe personal injury, death, or property damage
may occur if the pump starts while your hand is
inside the pump.
1. Turn off the pump. Switch off the circuit breaker
to the pump motor. If you are not replacing the
motor, do not disconnect the electrical wiring.
NOTE If you are replacing the motor, Zodiac Pool
Systems, Inc. strongly recommends that a
qualified service technician or electrician
properly disconnect the electrical wiring at the
pump motor.
2. Turn off any valves to prevent pool water from
reaching the pump. Drain the water from the pump
by loosening the unions or removing the
drain plugs.
3. Using a 9/16" wrench, loosen the bolts connecting
the pump body to the motor backplate. See
Figure 7.
Figure 7. Remove the Pump Housing
Pump
Body
Motor Backplate
Bolts (6)
Motor Shaft Cover
Figure 8. Remove the Diffuser
Motor
Backplate Screws (2)
Diffuser
Diffuser O-ring

Page 16 FloPro Series Pumps Installation and Operation Manual
Backplate
Screws (2)
Diffuser
Impeller
Mechanical Seal
Diffuser O-Ring
Backplate O-ring
Self Sealing Left Hand Screw
Figure 10. Diffuser and Impeller Exploded View
Figure 9. Remove the Impeller
Impeller
Self Sealing Left Hand Screw
Backplate
Mechanical
Seal
6. If necessary, remove any debris in the inlet and
outlet of the impeller.
7. Remove the motor shaft cover on the back of the
motor by twisting the hex-head screw with a 90°
crescent wrench. (See Figure 7.) The motor shaft
will be exposed.
8. Hold the exposed motor shaft with a ½" wrench
and remove the impeller center screw using a No.
2 Phillips screwdriver. Turn the left-hand-threaded
screw clockwise to loosen it. See Figure 9.
CAUTION
VERY IMPORTANT! Grasp the lower portion of
the seal (opposite the carbon face) when installing
the seal or it will be damaged.
NOTE To assist assembly, only use water or a soap
solution as a lubricant. Any other lubricant will
destroy the seal after a short period of time.
NOTE Excercise great care to keep the seal and
mating parts clean.
2. While holding the motor shaft with a ½" wrench,
thread the impeller onto the motor shaft. Hand-
tighten the impeller until it is secure. Install
the impeller center screw into the center of the
impeller and tighten, using a No. 2 Phillips
screwdriver. Do not overtighten. Turn the left-
hand-threaded impeller screw counter-clockwise
to tighten it.
3. Replace the motor shaft cover by inserting the
cover tabs into the slots and rotating the cover 90º
clockwise.
4. Replace the diffuser over the impeller, using care
to insert alignment pins into the correct holes. The
alignment pins in the diffuser allow the diffuser to
be inserted only one (1) way.
Figure 11. Mechanical Seal
Carbon Seal Surface
•
C
eramic Face
S
eal
• Backplate Seal
•
C
arbon Face
/
S
pring
Side of Seal
• Impeller Side of the
Mechanical Seal
9. Hold the motor shaft with a ½" wrench while
unscrewing the impeller from the motor shaft with
your hand. Turn the right-hand-threaded impeller
counter-clockwise to unscrew it.
10. Inspect the impeller and diffuser for signs of
rubbing and/or damage. See Figure 10.
6.2.3 Impeller Replacement
WARNING
To avoid the risk of property damage, severe personal
injury, or death, turn off the pump and switch off the
circuit breaker to the pump motor before beginning
this procedure.
1. Press the carbon face seal half (see
Figure 11) on the motor shaft using a twisting
motion. Make sure the carbon surface is facing
toward the ceramic ring in the backplate.

Page 17
FloPro Series Pumps Installation and Operation Manual
5. Replace the two (2) small Phillips-head screws.
Tighten the screws to draw the diffuser against the
motor backplate.
6. Make sure the diffuser o-ring, o-ring groove, and
o-ring seal area are clean and free of debris, which
could cause a leak. If you removed the diffuser
o-ring during disassembly, re-install it on the
diffuser, as shown in Figure 12. If grease is used
to retain the diffuser o-ring, it must be silicone
based. Do not use petroleum-based grease. It will
destroy the o-ring.
12. Open the pressure release valve on the filter and
make sure it is clean and ready for operation.
13. Switch on the circuit breaker to the pump motor.
13. Turn on the pump and check the system for normal
operation.
14. Once all the air has left the filter, close the filter
pressure release valve.
6.2.4 Mechanical Seal Replacement
NOTE Refer to Figure 13 for an illustration of the
location of the mechanical seal and impeller.
Pump Body
Diffuser
Diffuser
O-ring
O-ring Mounting Location
Figure 12. Pump Body and Diffuser Exploded View
7. Slide the diffuser into the mating hole in the pump
body. While supporting the motor, start two (2)
screws on opposite sides. (This will hold the motor
in position while you start the other screws.) Start
the other four (4) screws.
8. Tighten all six (6) screws lightly in a crossing “X”
pattern using a 9/16" wrench. Start with the inner
(middle) two (2), then tighten the outer (top and
bottom) four (4) to draw the backplate to the body
in a even manner. Once all the screws are snug,
torque in the same order to 10 foot-pounds.
9. If the pump is located above the water level of the
pool, remove the lid and fill the basket with water
before starting the pump.
10. Prior to replacing the lid, remove any debris
around the lid o-ring seat, as debris will allow air
to leak into the system.
11. Place the lid with locking ring on the pump
housing. Align ‘START’ with the ports and turn
the lid’s locking ring clockwise until ‘LOCKED’
aligns with the ports. Hand-tighten the lid to make
an air tight seal. Do not use any tools to tighten
the lid.
NOTE This is a two-part replacement process. The
mechanical seal must be replaced as a set.
WARNING
Do not damage the ceramic or carbon surfaces of
the seals. If surfaces are damaged, leaks will occur.
1. To access the mechanical seal, comply with the
warning and follow steps 1 through 8 of Section
6.2.2, Impeller Removal.
2. Remove the carbon face seal half from the motor
shaft. (See Figure 11.) This is a spring-loaded seal.
Grasp the portion of the seal closest to the impeller
body and pull the seal off using a twisting motion.
3. Remove the motor from the backplate following
steps 1 through 3 in Section 6.2.5, Motor
Replacement.
4. Place the backplate o-ring side down and force the
ceramic seal out using a screwdriver or drift.
Figure 13. Backplate, Impeller, Diffuser, and
Mechanical Seal Exploded View
Screws (2)
Diffuser O-ring
Diffuser
Self Sealing Left Hand Screw
Impeller
Mechanical Seal
Backplate
Backplate O-ring

Page 18 FloPro Series Pumps Installation and Operation Manual
5. Turn the backplate o-ring side up and insert the
new ceramic seal side into the backplate. Use
great care to press the seal in squarely with your
fingers. The ceramic is easily damaged and must
be pressed in using only your fingers or soft tools.
Do not use any lubricant other than water and soap
solution.
6. Install the backplate following the steps in
Section 6.2.3, Impeller Replacement.
7. Install the motor following the steps in Section
6.2.5, Motor Replacement.
6.2.5 Motor Replacement
CAUTION
To ensure continued safety and reliable operation,
Zodiac Pool Systems, Inc. requires that you replace
the motor with a motor that has the identical HP
rating and service factor (Zodiac Pool Systems, Inc.
approved only).
WARNING
To avoid the risk of property damage, severe personal
injury, or death, turn off the pump and switch off the
circuit breaker to the pump motor before beginning
this procedure.
1. To disassemble the pump housing from the motor,
follow steps 1 through 8 in Section 6.2.2, Impeller
Removal.
2. Remove the four (4) screws on the main cover and
remove the main cover.
3. Place the backplate motor assembly o-ring side
down and unscrew the four (4) 9/16" screws and
remove the motor.
NOTE Before removing the backplate, note the
alignment of the backplate to the motor. See
Figure 14.
4. If installing a new motor, remove the protective
plastic cap from the motor shaft. Place the motor
on the backplate so that the opening in the motor
faces the bottom of the backplate. The starting
capacitor on the motor should be at the
12 o’clock position.
5. Replace the four (4) bolts and washers holding the
backplate to the motor.
6. To reassemble the pump after replacing the
motor, follow steps 1 through 13 of Section 6.2.3,
Impeller Replacement.
NOTE Zodiac Pool Systems, Inc. recommends
replacing the mechanical seal at the same time
that you replace the motor. See Section 6.2.4,
Mechanical Seal Replacement, for details.
Bolts and
Washers (4)
Backplate
Motor
Starting
Capacitor
Figure 14. Backplate Assembly

Page 19
FloPro Series Pumps Installation and Operation Manual
Section 7. Product Specifications and Technical Data
7.1 Replacement Parts List
To order or purchase parts for Jandy pumps, contact your nearest Jandy dealer. If
the Jandy dealer cannot supply you with what you need, contact Jandy customer service
at 1.800.822.7933, or send an e-mail message to [e-mail].
Key
No. Description Model No. (HP) Order Part No.
1 Single-speed Motor & Hardware, FHP 0.75 R0479310
1 Single-speed Motor & Hardware, FHP 1.0 R0479311
1 Single-speed Motor & Hardware, FHP 1.5 R0479312
1 Single-speed Motor & Hardware, FHP 2.0 R0479313
1 Single-speed Motor & Hardware, FHP 2.5 R0479314
1 2-Speed Motor & Hardware, FHP 1.0 R0479306
1 2-Speed Motor & Hardware, FHP 2.0 R0479307
1 2-Speed Motor & Hardware, FHP 2.5 R0479308
2 Backplate, FHP (Backplate w/Hardware, Backplate O-ring & Mechanical Seal) All R0479500
3Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring) 0.75 R0479601
3Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring) 1.0, 1.0-2 R0479602
3Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring) 1.5, 1.5-2 R0479603
3Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring) 2.0, 2.0-2 R0479604
3Impeller, FHP (Impeller, Screw w/O-ring & Backplate O-ring) 2.5 R0479505
4 Diffuser, FHP (Diffuser w/O-ring, Hardware & Backplate O-ring) 0.75, 1.0, 1.0-2 R0479702
4 Diffuser, FHP (Diffuser w/O-ring, Hardware & Backplate O-ring) 1.5, 1.5-2, 2.0, 2.0-2, 2.5 R0479701
5 Mechanical Seal, Carbon and Ceramic (1 Set) All R0479400
6 Pump Body, FHP (Body and Backplate O-ring) All R0479800
7 Motor Mounting Foot, FHP All R0479900
8 Lid w/Locking Ring, FHP (Lid w/Locking Ring & Lid O-ring) All R0480000
9 Pump Debris Filter Basket, FHP All R0480100
10 Drain Plug w/ O-ring (Set of 2) All R0446000
11 Tail Piece, O-ring & Union Nut (Set of 2) All R0327301
12 Lid O-ring, FHP All R0480200
13 Backplate O-ring, FHP All R0480300
14 Diffuser/Impeller Hardware (Diffuser O-ring, Screws (2), Screw w/O-ring & Backplate
O-ring)
All R0480400
15 Backplate Hardware, FHP (Backplate Hardware & Backplate O-ring) All R0480500
16 Motor Hardware Kit All R0446700
17 Tailpiece O-ring (Set of 2) All R0337601
18 Pump Base Kit All R0486700

Page 20 FloPro Series Pumps Installation and Operation Manual
Figure 15. FHP Exploded View
7.2 Exploded View
1
1 (qty 4)
16 (qty 4)
2 (qty 6)
15 (qty 6)
2
2, 5
3
4
6
11 (qty 2)
11
2, 3, 4, 6, 13, 14, 15
4,14
3,14
10 (qty 2)
8
12
7
4, 14 (qty 2)
9
18
17 (qty 2)
