Jandy PRO Series JXI200 User manual

JXi™ Gas-Fired
Pool and Spa Heaters
Quick Reference Guide
Models JXI200, JXI260, JXI330, JXI400

2
WARNING If these instructions are not followed exactly, a fire or explosion may result,
causing property damage, personal injury, or death.
FOR YOUR SAFETY: This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the
product will be installed where such state or local requirements exists. In the event no such state or local requirement exists, the installer or maintainer must
be a professional with sufficient experience in pool equipment installation and maintenance so that all of the instructions in the manual can be followed exactly.
Before installing this product, read and follow all warning notices and instructions that accompany this product. Failure to follow warning notices and instructions
may result in property damage, personal injury, or death. Improper installation and/or operation can create carbon monoxide gas and flue gases which can cause
serious injury, property damage, or death. For indoor installations, as an additional measure of safety, Zodiac Pool Systems, Inc. strongly recommends installation
of suitable carbon monoxide detectors in the vicinity of this appliance and in any adjacent occupied spaces. Improper installation and/or operation will void the
warranty.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Immediately switch off main gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Information in this Quick Reference Guide is not intended to replace the instructions found in the complete Heater Installation and Owner’s manual.
Read the manual in its entirety before attempting any of the procedures found in this Quick Reference Guide.

WATER CHEMISTRY
• Proper chemical balances are necessary
for sanitary bathing conditions, as well
as ensuring your heater’s long life.
• For spas, it is necessary to perform
water changes, in addition to chemical
treatment. Change the spa water every
60 days for light usage and every 30
days if usage is heavy.
• Zodiac Pool Systems, Inc. does not
warrant heat exchangers damaged by
corrosive chemical levels or excess
dissolved solids in pool or spa water.
Refer to the recommended chemical
levels, see table right. CORROSIVE WATER
CHEMISTRY VOIDS ALL WARRANTIES.
*For calcium hypochlorite, lithium hypochlorite, or sodium hypochlorite.
** For sodium dichlor, trichlor, chlorine, gas, BCDMH.
***Start-up includes the TDS contribution of salt found in chlorine generating systems.
****Dictated by state or local codes. Typically 100 ppm (mg/L). Some codes are higher, some are lower.
Parameter Min. Ideal Max. Pool Type
Free Chlorine (ppm or mg/L) 1.0 2.0 - 4.0 5.0 Pools, Waterparks
2.0 3.0 - 5.0 10.0 Spas
Combined Chlorine (ppm or mg/L) 0 0 0.2 Pools, Waterparks
0 0 0.5 Spas
Total Bromine (ppm or mg/L) 2.0 4.0 - 6.0 10.0 All Types
PHMB (ppm or mg/L) 30 30 - 50 50 All Types
pH 7.2 7.4 - 7.6 7.8 All Types
Total Alkalinity as CaCO360 80 - 100*
100 - 120**
180 All Types
Total Dissolved Solids (ppm/ mg/L) NA NA 1500 over
start-up***
All Types
Calcium Hardness as CaCO3
(ppm or mg/L)
150 200-400 1000 Pools, Waterparks
100 150-250 800 Spas
Cyanuric Acid (ppm or mg/L) 0 30-50 **** All Types
3

MODEL & SERIAL NUMBER
Make sure you have the MODEL NUMBER
and SERIAL NUMBER available before calling
Zodiac Technical Support.
Model number and serial number on heater rating plate located on the front
of the combustion chamber. (Remove heater front panel.) Model number and
serial number on heater rating plate located on the front of the combustion
chamber. (Remove heater front panel.)
4For detailed information, refer to the complete installation and owner’s manual.

CLEARANCES General
Minimum Vertical Clearance:
36" (45 cm)
Minimum Clearance
to At Least One
Door Panel:
18" (22.5 cm) US
24" (30 cm) Canada
Minimum Service
Clearance
from Header:
12" (40.6 cm)
5
For detailed information, refer to the complete installation and owner’s manual.

Combustible Surfaces*
TOP: 6 inches (15 cm)
EXHAUST SIDE: 6 inches (15 cm) from surface of the exhaust vent
HEADER SIDE: 6 inches (15 cm)
SIDE PANELS: 6 inches (15 cm)
Service Access*
TOP: 36 inches (45 cm)
EXHAUST SIDE: 6 inches (15 cm) from surface of the exhaust vent
HEADER SIDE: 12 inches (30 cm)
SIDE PANELS
(at least one):
18 inches (22.5 cm) US
24 inches (60 cm) CAN
CLEARANCES
Combustible Surfaces & Service Access
* Clearances are manufacturer’s tested values. These are given as minimum values. Where
local and national codes apply, and if the clearance values specified in the applicable
codes are different that those listed in this manual, use the greater value to ensure safest
operation.
• Installation on a non-combustible
surface is recommended.
• Do not install on carpet.
• This unit can be installed on
combustible flooring.
6For detailed information, refer to the complete installation and owner’s manual.

OUTDOOR CLEARANCES
A
Distance: Heater to Door
USA - at least 4 feet (1.2m)
CAN - at least 10 feet (3.0m)
B
Distance: Top of Heater to
Vented Opening
(Forced Air Inlet)
If the top of the heater is less
than 3 feet (0.9m) above a vented
opening, the heater must be
installed at least 10 feet (3.0m)
away.
If the top of heater is more than
3 feet (0.9m) above, then any
distance is acceptable.
FORCED AIR INLET
A
B
7
For detailed information, refer to the complete installation and owner’s manual.

OUTDOOR INSTALLATIONS
5 ft (1.5 m)
Unless separated
by a solid wall, the
minimum distance to
the inside wall of the
pool must be at least
5 feet (1.5 m).
8For detailed information, refer to the complete installation and owner’s manual.

INDOOR INSTALLATIONS
Category I, Category III Venting
• Vent the heater in accordance with the
National Fuel Gas Code ANSI®Z223.1
(NFPA®54).
• Category I: Install a 4"double-wall
appliance adapter to meet vent size
requirements for the heater model.
• Category III: Install vent connector or
elbow to the flue collar according to
specific installation instructions from the
vent component manufacturer.
Model
Vent Size
(Category I)
Vent Size
(Category III)
JXI200 6" (15 cm) 4" (10 cm)
JXI260 7" (18 cm) 4" (10 cm)
JXI330 8" (20 cm) 4" (10 cm)
JXI400 8" (20 cm) 4" (10 cm)
9
For detailed information, refer to the complete installation and owner’s manual.

INDOOR CLEARANCES Venting for Category I (US) or Outdoor Shelter (CAN)
Required air supply to
room top and bottom
1/4 in. (6.35 mm) minimum
pitch per foot of horizontal pipe
LISTED
VENT CAP
STORM COLLAR
ROOF JACK AND FLASHING
• NOTE: Use approved roof jack
Vent terminated at least
2 ft (0.6 m) above any
object within 10 ft
10 ft
(3.5 m)
2 ft (0.6 m)
10 For detailed information, refer to the complete installation and owner’s manual.

• Side wall vent
terminals for
Category III (USA)
illustrated.
• For Canadian
installations,
refer to CSA
B149 for specific
requirements.
• Suggested Z-vent
part # 2SVSRTF.
VENT TERMINATION
FORCED AIR INLET
If less than 10 ft (3.0 m)
12 in (30 cm) min.
4 ft (1.2 m)
min.
3 ft (0.9 m)
min.
4 ft (1.2 m)
min.
INDOOR INSTALLATIONS
Side Wall Vent Termination
11
For detailed information, refer to the complete installation and owner’s manual.

INDOOR INSTALLATIONS
Combustion Air Supply
• All indoor installations must have
openings to outside air for combustion
and ventilation from the inside of the
building.
• As outlined in ANSI®standard Z223.1
(NFPA®54), the room in which the
heater is installed should have two
permanent air supply openings: (1)
within 12 inches (305 mm) of the
ceiling, and (2) within 12 inches (305
mm) of
the floor.
• All air from outdoors should have a net
free area, as shown in the table (right).
If using screens or metal louvers, add
additional area. Consult the specific
louver manufacturer for restriction
specifications as different louvers will
have varying restrictions.
* Area indicated is for one of two openings:
(1) 12ʺ from floor level, and (2) 12ʺ from ceiling level.
Minimum Required Area for Air Supply Openings
Model Direct from Outside* Duct from Outside*
JXI200 50 in2(323 cm2)100 in2(645 cm2)
JXI260 65 in2(419 cm2)130 in2(839 cm2)
JXI330 83 in2(535 cm2)165 in2(1065 cm2)
JXI400 100 in2(645 cm2)200 in2(1291 cm2)
12 For detailed information, refer to the complete installation and owner’s manual.

• Check supply pressure and local code
requirements before proceeding with
installation.
• Consider pipe fittings when
determining gas pipe sizing.
• Larger pipe size can be used if
required by local code.
• It is critical that the incoming gas
supply pressure at the heater is
within the maximum and minimum
pressure requirements. If the range
of acceptable supply pressure is not
provided, the gas supply system to
the heater must be modified to meet
pressure requirements.
• The gas shut off valve must be
installed in an accessible location
within six (6) feet of the heater.
• Do not use CSST or any flexible
gas piping.
GAS LINE SIZING
* Numbers are for natural gas (0.65 Sp. Gr.) based on 1/2 inch (3.45 kPa) water column pressure drop. Check
supply pressure with a manometer, and local code requirements for variations. For LP gas, reduce pipe
diameter by one size, but maintain a minimum 3/4 inch diameter.
For specific requirements:
(1) Natural gas heaters, refer to NFPA®54.
(2) Propane heaters, refer to NFPA 58.
Minimum Required Gas Pipe Sizing
Model
(BTU)
0-50 ft (0-15m) from
gas meter*
50-100 ft (15-30m)
from gas meter*
100-200 ft (30-60m)
from gas meter*
JXI200 1ʺ (25 mm) 1-1/4ʺ (32 mm) 1-1/4ʺ (32 mm)
JXI260 1-1/4ʺ (32 mm) 1-1/4ʺ (32 mm) 1-1/4ʺ (32 mm)
JXI330 1-1/4ʺ (32 mm) 1-1/4ʺ (32 mm) 1-1/2ʺ (38 mm)
JXI400 1-1/4ʺ (32 mm) 1-1/2ʺ (38 mm) 1-1/2ʺ (38 mm)
13
For detailed information, refer to the complete installation and owner’s manual.

GAS PRESSURE TEST
• Check the gas supply pressure while
the heater is operating.
• Any adjustments or readings made
while the heater is off will result in poor
performance and other problems.
• Connect a differential manometer
to the supply pressure port on the
gas valve.
• If the gas supply pressure does
not meet requirements (see table,
right), check for a restrictive fitting,
undersized gas meter, or undersized
pipe between the meter and the heater.
• Minimum inlet supply pressure must
be maintained during heater operation
while there is a full demand on the gas
delivery system.
Gas Supply Pressure NATURAL PROPANE
Max. Inlet 10.5" WC 14" WC
Min. Inlet 4" WC 4" WC
Gas Offset –0.2" WC –0.2" WC
14 For detailed information, refer to the complete installation and owner’s manual.

ON
OFF
UNITS
ZERO
ON
OFF
UNITS
ZERO
NEGATIVE
(Low Pressure Port)
_
POSITIVE
(High Pressure Port)
+
DIGITAL
DIFFERENTIAL
MANOMETER
FAN INLET PORT
“T” JOINER
GAS VALVE VENT PORT
GAS VALVE MANIFOLD PORT
Target Offset Pressure
-0.2 inch wc
DIGITAL MANOMETER
CONNECTION
15
For detailed information, refer to the complete installation and owner’s manual.

PRV SET-UP
• A pressure relief valve
(PRV) is recommended in all
installations.
• A PRV is required in any
installation in which the water
flow can be shut off between
the heater outlet and the pool/
spa. Check any applicable
installation codes in your
area to determine whether a
pressure relief valve is required.
• A pressure relief valve is not
supplied with the heater.
• Maximum working pressure of
this heater is 50 psi.
• Any PRV installed must comply
with provisions of the standard
described in ANSI®Z21.22 for
the United Sates or CSA 4.4 in
Canada.
3/8” NPT Nipple
3/8” NPT Elbow
3/4” NPT Pressure Relief Valve (PRV)
3/4” to 3/8” NPT Reducing Bushing
1
2
3
4
PRV R-KIT - R0336101
Using the dimple in the center
as a guide, drill a 1/4” hole in
the threaded boss at the outlet.
Ground Level
1
2
3
4
6” min
3/8” NPT Nipple
3/8” NPT Elbow
3/4” NPT Pressure Relief Valve (PRV)
3/4” to 3/8” NPT Reducing Bushing
1
2
3
4
PRV R-KIT - R0336101
Using the dimple in the center
as a guide, drill a 1/4” hole in
the threaded boss at the outlet.
Ground Level
1
2
3
4
6” min
MANUAL SHUT OFF VALVE
REMOVABLE CAP
T-FITTING
MINIMUM
3” (76 mm)
Incorrect
Correct
16 For detailed information, refer to the complete installation and owner’s manual.

MANUAL SHUT OFF VALVE
REMOVABLE CAP
T-FITTING
MINIMUM
3” (76 mm)
Incorrect
Correct
GAS LINE SEDIMENT TRAP
• Do not use flexible gas
piping, it will restrict the
gas flow to the heater.
• Do not use a restrictive
gas cock.
• Install a sediment trap
and union ahead of the
gas controls and outside
the heater panels.
• Sediment trap should be
installed as close to the
inlet as possible.
17
For detailed information, refer to the complete installation and owner’s manual.

POWER CONNECTIONS
• The heater comes factory-wired intended for use
with 240 Volt, 60 Hz AC field electrical supply.
• Do NOT use with 208 Volt.
• To use 120 Volt, 60 Hz AC, change the position
of the voltage selector board on the power
distribution board (see procedure below right).
• Electrical wiring must be done in accordance
with the latest edition of the National Electrical
Code®(NEC®) NFPA®70. In Canada, the Canadian
Electrical Code (CEC), CSA C22.1, must be
followed.
• Take care not to abrade or damage any wiring or
other components.
The voltage selector board is keyed so that it will
fit in only one (1) direction for the selected voltage
(either side of the board).
1. Cut the plastic wire tie fastening the voltage selector board in place
2. Unplug the voltage selector board from the receptacle.
3. Rotate the voltage selector board 180 degrees and reinsert it into the
receptacle so that the hole in the board is not visible.
4. Verify that the board is securely seated in the receptacle.
NOTE
POWER DISTRIBUTION BOARD
WIRE TIE
VOLTAGE SELECTOR BOARD
18 For detailed information, refer to the complete installation and owner’s manual.

WIRE TO 120V OR
240V/60 HZ
1. Remove the front panel of
the heater.
2. Connect the wires from the
power source to the leads
on the heater.
• Electrical wiring must be done in accordance with the
latest edition of the National Electrical Code®(NEC®)
NFPA®70. In Canada, the Canadian Electrical Code
(CEC), CSA C22.1, must be followed.
• Take care not to abrade or damage any wiring or other
components.
• The “hot” wire of the 120V power supply has to be
connected to the black wire (ACH1) on the power
distribution board and the “neutral” wire of the 120V
power supply has to be connected to the red wire
(ACN1).
WARNING
RISK OF ELECTRIC SHOCK WHICH CAN RESULT IN
SERIOUS INJURY OR DEATH.
Before attempting installation or service, ensure that all
power to the device is disconnected/turned off at the circuit
breaker. For detailed information to correctly and safely
complete the connection to the power source, refer to the
complete installation and owner’s manual.
Connect Power Source
to Heater Leads
Connect Conduit at
Port in Side Panel
Heater Interior
(access from front panel)
19
For detailed information, refer to the complete installation and owner’s manual.

ELECTRICAL SYSTEM SERVICE ACCESS
Use a screwdriver or other
tool to insert and release latch
Lift raceway until latch engages
to lock in raised position
Press to release latch
and lower raceway
Raceway will swing
outward and up
Remove front panel
(four screws)
1
2
3
4
5
4
1
2
3
5
20 For detailed information, refer to the complete installation and owner’s manual.
