Janglebox Jb2 byrds le User manual

Unrivalled Versatility

The key to maximizing the eectiveness of the JB2 Byrds LE is to understand the basic setup.

The On/O switch (red LED) controls the Bass, Treble, Gain and Attack functions. The

JangleBoost (blue LED) controls the J-Boost Gain and J-Boost Tone. The Attack is common to

both sides of the compressor. When the JangleBoost is activated, the Bass, Treble and Gain are

inoperable.

Among many variations, the JangleBoost can work as a treble or bass boost, or, by adjusting the

J-Boost Gain louder than the regular Gain, can create a “boost-on-boost” eect.

“The Byrds” is a registered trademark of David Crosby, and is unaliated in any way with JangleBox LLC or its products.

HANDMADE IN THE USA

On/Off JangleBoost

COMPRESSION

SUSTAINER

JangleBox

TREBLEBASS

GAIN J-BOOST GAINATTACK

INPUT π

π OUTPUT

THE BYRDS

LIMITED EDITION TRIBUTE

J-BOOST

TONE

HANDMADE IN THE USA

On/Off JangleBoost

COMPRESSION

SUSTAINER

JangleBox

TREBLEBASS

GAIN J-BOOST GAINATTACK

INPUT π

π OUTPUT

THE BYRDS

LIMITED EDITION TRIBUTE

J-BOOST

TONE

“EQ Side” “JangleBoost Side”

Congratulations on Your New

JangleBox JB2 Byrds LE Compressor!

This limited edition compression pedal pays homage to

The Byrds, the great ’60s band whose guitarist, Roger

McGuinn, helped inspire the JangleBox sound. A fantastic

update, the new JB2 Byrds LE is the complete realization

of the original JB2.

With the new J-Boost tone control, the clean, striking

graphics and all the great features of the original JB2, this

is the only true boost-and-tone, two-stage compressor on

the market today. Handmade in the USA, the JangleBox

JB2 Byrds LE delivers the distinctive compression edge for

demanding pros and aspiring artists alike.

Getting started with your JangleBox JB2 Byrds LE

As every guitar-and-amp combination is dierent for each guitarist, you’ll want to experiment

with the JB2 Byrds LE settings. We suggest ﬁrst adjusting the Bass and Treble to your desired

tone. Next, turn the Gain and Attack knobs to the “2 o’clock” position, then tweak the compres-

sion to your satisfaction from there.

nThe Gain setting adjusts volume and amount of compression. The Attack setting adjusts

the intensity of compression.

nThe JangleBoost is the second stage of the JB2 Byrds LE that can be used to create a dif-

ferent tonal variation and up to a 25-30 dB boost. Adjust the J-Boost Gain for soloing, or

the J-Boost Tone for sounds ranging from warm bass to ultra-bright treble. You can acti-

vate the JangleBoost so that it comes on when you hit the main On/O switch.

nThe J-Boost Gain and J-Boost Tone settings function only when the JangleBoost is

switched on (blue light). See the back panel for further explanation.

nWhen daisy-chaining a series of additional pedal eects, you should place the JB2 Byrds

LE ﬁrst in the sequence (plug your guitar into the JB2 Byrds LE) to take full advantage of

its true bypass.

nUse any standard 9V pin negative power source or the 9V battery included with each unit. If

you use a 9V battery to power your pedal, compression will decrease as the battery wears.

Remove the six screws on the underside of the box to replace the battery.

WARRANTY: JangleBox LLC warrants that the JangleBox product shall be free from defects. Consumer must notify JangleBox LLC in writing, within one year of delivery of the JangleBox compressor, of any

claim that there is a defect in the compressor. If the JangleBox is found defective by JangleBox LLC, its sole obligation under this warranty is to remedy such defect in a manner consistent with JangleBox’s

regular business practices.

The above is a limited warranty and it is the only warranty made by JangleBox LLC. JangleBox LLC makes no other warranty express or implied and expressly excludes all warranties of merchantability and

ﬁtness for a particular purpose. JangleBox LLC shall have no liability for consequential, exemplary, or incidental damages resulting from or arising out of the use of the JangleBox compressor.
