JangleBox JBX User manual

GAIN ATTACK J-BOOST
GAIN
BASS TREBLE J-BOOST
BASS
J-BOOST
TREBLE
ON/OFF T-BOOST J-BOOST
GAIN ATTACK J-BOOST
GAIN
BASS TREBLE J-BOOST
BASS
J-BOOST
TREBLE
ON/OFF T-BOOST J-BOOST
REGULAR SIDE
J-BOOST SIDE
Copyright ©2019 JangleBox LLC
Unrivalled Power
and Flexibility
The key to maximizing the
eectiveness of the JBX
is to understand the basic
setup. The On/O switch
(red LED) controls the Bass,
Treble, Gain and Attack
functions. The J-Boost (blue
LED) controls the J-Boost
Gain and J-Boost Bass and
Treble. These are discrete
sides of the compressor.
The Attack knob and
T-Boost treble switch are
common to both sides of
the compressor. When the
J-Boost is activated, the
regular Bass, Treble and Gain
are inoperable.
Among many variations, the
J-Boost can work as a treble
or bass boost, or, by adjusting
the J-Boost Gain louder than
the regular Gain, can create a
“boost-on-boost” eect.

Congratulations on Your New
JangleBox JBX Compressor!
You’re probably a guitar player who won’t compromise on tone and
who demands pro-level compression. If so, your JangleBox JBX will
be your new, favorite pedal. The JBX will give you all the chime,
sustain and brilliance that JangleBox compressors are known for,
along with unrivaled tone-and-boost capabilities.
The JBX goes from the studio to the stage without missing a beat:
 Dual mono outputs.
 Separate, full EQ on both sides of the unit.
 Preset treble-boost switch.
 J-Boost gain switch for on-the-fly soloing or tonal variation.
 True bypass.
 Further refinements include moving the EQ circuit post-com-
pression for a quieter output, and eliminating microphonic
switch noise.
The advantages you’ll gain in power, flexibility and clarity will make
this one pedal in your rig that you’ll never turn o. The JBX is a com-
pression fan’s dream!
The JBX is Simple to Set Up
and Operate
As every guitar-and-amp combination is dierent for each guitarist, you’ll
want to experiment with the JBXsettings. We suggest first adjusting the
Bass and Treble to your desired tone, both on the regular side of the
compressor and the J-Boost side. Next, turn the Gain and Attack knobs to
the “12 o’clock” position, then tweak the volume and compression to your
satisfaction from there. Finally, adjust the J-Boost Gain to add (or lower)
volume and/or create a dierent tone.
 The Gain settings adjust volume. The Attack setting adjusts the
intensity of compression. The Attack knob is common to both the
regular side of the JBX and the J-Boost side.
 The T-Boost is a preset treble boost and is common to both sides of
the compressor. It will maintain the volume set either on the regular
side or J-Boost side.
 The J-Boost switch is the second stage of the JBX. It can be used
for dierent tonal variations and/or up to a 20-25dB volume boost.
Adjust the J-Boost Gain for soloing, if desired. You can also activate
the J-Boost so that it comes on when you hit the On/O switch.
 The J-Boost Gain, J-Boost Bass, and J-Boost Treble settings function
only when the J-Boost is switched on (blue light). See the back panel
for further explanation.
 When daisy-chaining a series of additional pedal eects, you should
place the JBX first in the sequence (plug your guitar into the JBX) to
take full advantage of its true bypass.
 Use any standard 9V pin-negative power source or the 9V battery
included with each unit. If you use a 9V battery to power your pedal,
compression will decrease as the battery wears. Remove the four
screws on the underside of the box to replace the battery.
11654 Plaza America Drive • Reston, VA 20190 • 1.866.352.6453 • www.janglebox.com
WARRANTY: JangleBox LLC warrants that the JangleBox JBX shall be free from defects. Consumer must notify
JangleBox LLC in writing, within one year of delivery of the JangleBox JBX, of any claim that there is a defect in
the pedal. If the JBX is found defective by JangleBox LLC, its sole obligation under this warranty is to remedy
such defect in a manner consistent with JangleBox’s regular business practices.
The above is a limited warranty and it is the only warranty made by JangleBox LLC. JangleBox LLC makes no
other warranty express or implied and expressly excludes all warranties of merchantability and fitness for a
particular purpose. JangleBox LLC shall have no liability for consequential, exemplary, or incidental damages
resulting from or arising out of the use of the JangleBox JBX.
