janitza UMG 801 Instruction manual

www.janitza.com
Modular Power Analyzer
UMG801
User manual and technical data
Doc. no.: 2.053.021.3.b Date: 07/2023
Janitza electronics GmbH
Vor dem Polstück 6
D-35633 Lahnau
Support tel. [phone]
Email: [email protected]
www.janitza.com

UMG801 www.janitza.com
2
UMG 801
Modular multifunctional meter for
recording energy quantities
Doc. no.: 2.053.021.3.b
Date: 07/2023
The German version is the original edition of the documentation

www.janitza.com UMG801
3
Subject to technical alterations.
The contents of our documentation have been compiled with great care and reflect the current state of the
information available to us. Nonetheless, we wish to point out that updates of this document are not always
possible at the same time as technical refinements are implemented in our products. Please see our website
under www.janitza.de for the current version.
Please see our website under www.janitza.com for the current version.

UMG801 www.janitza.com
4
TABLE OF CONTENTS
1. Information on the device and the user manual 12
1.1 Disclaimer 12
1.2 Copyright notice 12
1.3 Technical changes 12
1.4 About this user manual 12
1.5 Defective device/disposal 13
2. Safety 14
2.1 Display of warning notices and safety information 14
2.2 Hazard levels 14
2.3 Product safety 14
2.4 Dangers when handling the device 15
2.5 Electrically qualified personnel 16
2.6 Warranty in the event of damage 16
2.7 Safety information for handling current transformers 16
2.8 Safety information for handling measurement devices with residual current measurement 17
2.9 Handling batteries/accumulators 17
3. Product description 18
3.1 Device description 18
3.2 Incoming goods inspection 19
3.3 Intended use 19
3.4 Performance characteristics 20
3.5 EU/UKCA Declaration of Conformity 20
3.6 FCC Declaration of Conformity 20
3.7 Scope of delivery 21
3.8 Accessories 21
3.9 Measuring method 22
3.10 Transformers 22
3.11 Operating concept 22
3.12 Web server with device homepage 23
3.13 GridVis®network analysis software 23
3.14 Overview of the range of functions 23
3.14.1 Configuration on the device (via 6 buttons) 23
3.14.2 Communication 23
3.14.3 Measured values (with voltage component) 24
3.14.4 Measured values (with current component) 24

www.janitza.com UMG801
5
4. Structure of the device 26
4.1 Front panel and display 26
4.2 Side views 28
4.3 Bottom view 28
4.4 Identification of the device (rating plate) 29
5. Mounting 30
5.1 Installation location 30
5.2 Bus connector 31
5.3 DIN rail mounting of the device 31
6. Grid systems 33
7. Installation 34
7.1 Nominal voltages 34
7.2 Circuit breaker 35
7.3 Supply voltage 35
7.4 Voltage measurement 36
7.4.1 Overvoltage 36
7.4.2 Mains frequency 36
7.4.3 Connection variants for voltage measurement 37
7.5 Current measurement 38
7.5.1 Connection variants for current measurement 39
7.5.2 Summation current measurement 40
7.5.3 Ammeter 40
7.6 Multifunction channels 40
7.7 Residual current measurement (RCM) 41
7.7.1 Current direction of the residual current transformers 42
7.7.2 Residual current transformer example 42
7.7.3 Important information about the residual current measurement inputs 42
7.7.4 Connection examples - Residual current measurement 43
7.7.5 Connection example - Residual current monitoring 44

UMG801 www.janitza.com
6
7.8 Residual current measurement - limit value calculation 45
7.8.1 Static limit value calculation 45
7.8.2 Dynamic limit value calculation 46
7.8.3 Stepwise limit value calculation 47
7.8.4 Example: Residual current limit value exceeded 48
7.8.5 Activating cable break detection (failure monitoring) RCM for the
multifunction channels. 49
7.9 Temperature measurement 50
8. Communication via the Ethernet interfaces 52
8.1 Functions of the Ethernet interfaces 52
8.2 "Switched mode" connection option 53
8.3 "Dedicated mode" connection option 53
8.4 Meaning of the Ethernet interface LEDs: 53
9. PC connections and other interfaces 54
9.1 PC connections 54
9.2 RS-485 interface (serial interface) 56
9.2.1 Shielding 57
9.2.2 Termination resistors/Termination 57
9.2.3 Bus structure (bus segment) 58
9.3 JanBus interface 58
9.4 Digital inputs 59
9.5 Digital outputs 60
9.6 Analog outputs 61
10. Operation and button functions 62
10.1 Controls 62
10.2 Function buttons 62
10.3 Measuring display 62
10.4 Menu 62
10.5 PIN (password) 63
10.6 Overview of menu displays 64

www.janitza.com UMG801
7
11. Configuration 66
11.1 The Configuration window 66
11.2 Configuring Ethernet (TCP/IP) 66
11.2.1 Communication via TCP/IP 67
11.2.2 Communication via OPC UA 67
11.3 Configuring the fieldbus (RS-485 interface) 68
11.3.1 Communication settings 68
11.4 Configuring current transformers 69
11.5 Configuring voltage transformers 70
11.6 Temperature measurement configuration 71
11.6.1 Temperature sensor types 71
11.6.2 "Temperature offset" item 71
11.7 Configuring the display 72
11.7.1 Language 72
11.7.2 Standby (after) 72
11.7.3 Brightness 73
11.8 Configuring the system 73
11.8.1 PIN 73
11.8.2 Restart (reboot) 74
11.8.3 Time 74
11.8.4 Date 74
11.9 Reset 75
11.9.1 Standard factory settings 75
11.9.2 Reset configuration 75
11.9.3 Reset minimum, maximum and average values 76
11.9.4 Reset energy values 76
11.9.5 Reset historical data 77
11.10 Module identification / diagnostics 77
11.11 Events and transients 78
11.11.1 Events 78
11.11.2 Transients 78
11.11.3 Event and transient recording 79
11.11.4 Configuration of the waveform for events and transients 80
11.11.5 Half-wave RMS values for events 80
11.11.6 Update time for transients 81
11.11.7 Configuration in the GridVis software 81

UMG801 www.janitza.com
8
12. Digital inputs and outputs 82
12.1 4 digital inputs 82
12.2 4 digital outputs 84
13. Analog outputs 86
14. Commissioning 88
14.1 Supply voltage 88
14.2 Measured voltage 88
14.3 Measured current 89
14.4 Frequency measurement 89
14.5 Direction of rotary field 90
14.6 Fundamentals on the phasor diagram 90
14.7 Checking of voltage and current inputs by means of phasor diagram 91
14.8 Checking the phase assignment 91
14.9 Checking the power measurement 91
14.10 Checking measurement 92
14.11 Checking individual power 92
14.12 Checking summation power 92
14.13 Drag indicator function 93
14.13.1 Configuring the drag indicator synchronization 93
14.13.2 Drag indicator - measurement device display 95
14.13.3 Resetting the drag indicator 96
14.14 Average value - gridded and moving 96
14.14.1 Gridded average value 96
14.14.2 Moving average value 97
14.14.3 Gridded and moving average in the GridVis®software 97
15. Overview of measured value and meter displays 98
16. Connection example 112

www.janitza.com UMG801
9
17. Dismounting 113
18. Device homepage 114
18.1 "Home" start page 114
18.1.1 Login 115
18.1.2 Change password 116
18.2 "Measured values" menu bar item 117
18.2.1 Details 117
18.2.2 Events and transients 118
18.3 "Settings" menu bar item 119
18.3.1 Firmware update 120
18.3.2 Whitelist (Modbus port 502) 121
18.4 "Information" menu bar item 122
18.4.1 Device information 122
18.4.2 Modbus address list 123
18.4.3 Imprint 123
19. Service and maintenance 124
19.1 Repair and calibration 124
19.2 Front panel foil and display 124
19.3 Service 124
19.4 Device adjustment 125
19.5 Firmware update via the device homepage 125
19.6 Firmware update via the GridVis®software 125
19.7 Clock/Battery 125
19.8 Battery replacement 125
20. Error messages 126
20.1 Overrange 126
20.2 Procedure in the event of a malfunction 127

UMG801 www.janitza.com
10
21. Technical specifications 128
21.1 Technical data 128
21.2 Performance characteristics of functions 134
21.3 Parameter and Modbus address list 135
21.4 Information on saving measured values and configuration data 135
22. Dimensional drawings 136
22.1 Basic device UMG801 136
22.2 Bus connector 137

www.janitza.com UMG801
11

UMG801 www.janitza.com
12
1. Information on the device and the user manual
1.1 Disclaimer
Compliance with the informational products for
the device is a prerequisite for safe operation and
attaining the stated performance characteristics and
product features.
Janitza electronics GmbH assumes no liability for
bodily injury, material damage or financial losses
which result from disregard of the informational prod-
ucts.
Ensure that your informational products are readily
accessible in a legible form.
1.2 Copyright notice
© 2023 - Janitza electronics GmbH - Lahnau. All
rights reserved.
Any reproduction, processing, distribution or other
use of this informational product, in whole or in part,
is prohibited.
All trademarks and the rights arising from them are
the property of the respective owners of these rights.
1.3 Technical changes
· Make sure that your device (modules/components)
matches the user manual.
· This user manual applies to the UMG801. Separate
validities and distinctions are marked.
· First make sure you have read and understood the
usage information accompanying the product.
· Keep the usage information associated with the
product available for the entire service life and pass
it on to any possible subsequent users.
· Find out about device revisions and the associated
modifications of the usage information associated
with your product at www.janitza.com.
1.4 About this user manual
If you have questions, suggestions or ideas for im-
provement of the user manual, please let us know via
email at: [email protected].
INFORMATION
This user manual describes the UMG801 and pro-
vides information on the operation of the device.
Also consult the additional documentation relevant for
this user manual, such as:
· the installation manual.
· the data sheet.
· the "Safety information" supplement.
· if applicable, the usage information of the integrat-
ed modules and components of your meter and
module topology (e.g. current transformers).
Moreover, the GridVis®software has an “online
help” feature.
INFORMATION
Our usage information uses the grammatical mascu-
line form in a gender-neutral sense! This form always
refers equally to women, men and diverse. In order
to make the texts more readable, distinctions are not
made. We ask for your understanding for these simpli-
fications.

www.janitza.com UMG801
13
1.5 Defective device/disposal
Before sending defective devices, modules or
components back to the manufacturer for testing:
· Contact the manufacturer's Support department.
· Send devices, modules or components complete
with all accessories.
· When doing so, please bear the terms for transpor-
tation in mind.
INFORMATION
Please return defective or damaged devices, modules
or components to Janitza electronics GmbH in ac-
cordance with the shipping instructions for air or road
freight (complete with accessories).
Observe special regulations for devices with built-in
batteries or rechargeable batteries!
Do not attempt to open or repair the device (the
module, the component) on your own because oth-
erwise all warranty claims become invalid!
For the disposal of the device (the module, the
component), please observe national regulations!
Dispose of individual parts, as applicable, depending
on their composition and existing country-specific
regulations, for example, as
· Electronic waste,
· Batteries and rechargeable batteries,
· Plastics,
· Metals.
Engage a certified disposal company to handle
scrapping as needed.
Information on service and maintenance of your
device can be found in chapter „19. Service and
maintenance“ on page 124.

UMG801 www.janitza.com
14
2. Safety
The chapter on Safety contains information which
must be observed to ensure your personal safety
and avoid material damage.
2.1 Display of warning notices and safety
information
The warning notices shown below
· are found throughout all of the documentation,
· can be found on the devices themselves.
· indicate potential risks and hazards,
· underscore aspects of the information provided that
clarifies or simplifies procedures.
The additional symbol onthedevice itself indicates
anelectrical danger that can result in serious injuries
or death.
This general warning symbol draws attention to a
possible risk of injury. Be certain to observe all of the
information listed under this symbol in order to avoid
possible injury or even death.
2.2 Hazard levels
Warning and safety information is marked by a
warning symbol, and the hazard levels are shown as
follows, depending on the degree of hazard:
DANGER
Warns of an imminent danger which, if not avoided,
results in serious or fatal injury.
WARNING
Warns of a potentially hazardous situation which, if
not avoided, could result in serious injury or death.
CAUTION
Warns of an immediately hazardous situation which,
if not avoided, can result in minor or moderate injury.
ATTENTION
Warns of an immediately hazardous situation which,
if not avoided, can result in material or environmental
damage.
2.3 Product safety
The devices, components and modules reflect
current engineering practice and accepted safety
standards, but hazards can arise nonetheless.
Observe the safety regulations and warning notices.
If notices are disregarded, this can lead to personal
injury and/or damage to the product.
Every type of tampering with or use of this device,
· which goes beyond the mechanical, electrical or
other operating limits can lead to personal injury
and/or damage to the product;
· constitutes “misuse” and/or “negligence” under the
product’s warranty and thus voids the warranty for
any possible resulting damage.
Before installing, operating, maintaining and using
the device, read and understand the user manual
and the device usage information. As applicable,
also observe all further usage information on the
components and modules of your system.
Only operate the device when it is in perfect condi-
tion and in compliance with this user manual and the
enclosed usage information. Send defective devices
back to the manufacturer in compliance with proper
transport conditions.
Retain the user manual throughout the service life of
the device and keep it at hand for consultation.
When using the device, also observe the legal and
safety regulations for your system that are applicable
for the respective use case.
INFORMATION
Indicates procedures in which there is no hazard of
personal injury or material damage.

www.janitza.com UMG801
15
2.4 Dangers when handling the device
When operating electric devices, components or
modules, it is unavoidable for certain parts of these
devices to conduct hazardous voltage. Consequent-
ly, severe bodily injury or material damage can occur
if they are not handled properly.
Therefore, when handling our devices, components,
or modules, always observe the following:
· Do not exceed the limit values specified in the user
manual and on the rating plate! This must also be
observed during testing and commissioning!
· Take note of the safety and warning notices in all
usage information that belongs to the device, com-
ponents or modules!
WARNING
Disregarding the connection conditions of the
Janitza measurement devices, modules or com-
ponents can lead to injuries or even death or to
material damage!
· Do not use Janitza meters, modules or compo-
nents for critical switching, control or protection
applications where the safety of persons and
property depends on this function.
· Do not carry out switching operations with the
Janitza measurement devices, modules or com-
ponents without prior inspection by your system
manager with specialist knowledge! In particular,
the safety of persons, material assets and the ap-
plicable standards must be taken into account!
WARNING
Risk of injury due to electrical currents and voltag-
es!
Severe bodily injury or death can result! Therefore
please abide by the following:
· Switch off your installation before commenc-
ing work! Secure it against being switched on!
Check to be sure it is de-energized! Ground and
short circuit! Cover or block off adjacent live
parts!
· During operation and troubleshooting (especial-
ly with DIN rail devices), check the environment
for dangerous voltages and switch these off if
necessary!
· Wear protective clothing and protective equip-
ment in accordance with applicable guidelines
when working on electrical systems!
· Before making connections, ground the device
/ component / module by means of the ground
wire connection, if present!
· Do not touch bare, stripped wires or device in-
puts that are dangerous to touch on the devic-
es, components and modules. Equip stranded
conductors with wire ferrules!
· Hazardous voltages can be present in all cir-
cuitry parts that are connected to the power
supply.
· Protect wires, cables and devices with a suit-
able line circuit breaker/fuse!
· Never switch off, remove or tamper with safety
devices!
· There can still be hazardous voltages present in
the device or in the component (module) even
after it has been disconnected from the supply
voltage (capacitor storage).
· Do not operate equipment with current trans-
former circuits with ../5A(1A) current trans-
formers with exposed connections.
· Only connect screw terminals with the same
number of poles and design!
· Do not exceed the limit values specified in the
user manual and on the rating plate! This must
also be observed during testing and commis-
sioning.
· Take note of the safety and warning notices
in the usage information that belongs to the
device, components or modules!

UMG801 www.janitza.com
16
2.5 Electrically qualified personnel
To avoid bodily injury and material damage, only
electrically qualified personnel are permitted to work
on the devices and their components, modules,
assemblies, systems and current circuits who have
knowledge of:
· The national and international accident prevention
regulations.
· Safety technology standards.
· Installation, commissioning, operation, disconnec-
tion, grounding and marking of electrical equip-
ment.
· The requirements concerning personal protective
equipment.
Electrically qualified persons within the scope of the
technical safety information of all usage informa-
tion associated with the device and its components
(modules) are persons who can furnish proof of
qualification as an electrically skilled person.
WARNING
Warning against unauthorized manipulation or
improper use of the device or its components
(modules)!
Opening, dismantling or unauthorized manipulation of
the device and its components which goes beyond
the mechanical, electrical or other operating limits
indicated can lead to material damage or injury, up to
and including death.
· Only electrically qualified personnel are per-
mitted to work on the devices and their com-
ponents (modules), assemblies, systems and
current circuits.
· Always use your devices or components
(modules) only in the manner described in the
associated usage information.
· If there is discernible damage, send the device
or the component (module) back to the manu-
facturer!
2.6 Warranty in the event of damage
Any unauthorized tampering with or use of the
device, component or module constitutes “misuse”
and/or “negligence” under the product’s warranty
and thus voids the warranty for any possible re-
sulting damage. In this regard, please take note of
section „3.3 Intended use“ on page 19.
2.7 Safety information for handling current
transformers
The field of transformer technology groups the
totality of all devices that perform the function of a
current, voltage or measuring transformer togeth-
er as sensors.
In the usage information for our devices, modules
and components, the terms current transformer,
voltage transformer or transformer all refer to
sensors.
A further distinction is made by the terms CT (cur-
rent transformer) and LP-CT (low-power current
transformer):
The term "current transformer" is used for special
transformers for the primary-proportional conversion
of currents of large magnitudes to directly measur-
able, smaller current values. In contrast, the term
"LP current transformer" is used for special trans-
formers for the primary-proportional conversion of
currents of large magnitudes to directly measurable
voltage values (low power).
Current transformers and LP current transform-
ers provide safe galvanic isolation between the
primary circuit and the measurement circuit due to
their design and their physical operating principle.
For Janitza measurement devices, modules and
components, use only "transformers for measur-
ing purposes" which are suitable for the energy
monitoring of your system! Please note Sect. “3.10
Transformers” on p.22 and Sect. “7. Installation”
on p.34 in this regard!
The UMG801 basic device uses the term "current
transformer" only in the display for the configura-
tion of both current transformers and LP current
transformers.

www.janitza.com UMG801
17
CAUTION
Risk of injury or damage to the meter due to high
measurement currents at the connections of the
current transformers!
High measurement currents can cause temperatures
of up to 80°C (176°F) on the connections of the
current transformers
· Use wiring that is designed for an operating
temperature of at least 80°C (176°F)!
· The current transformers can be hot even after
the power supply has been switched off. Allow
the connections of the current transformers
and the connecting cables to cool down before
touching them!
CAUTION
Risk of injury or damage to the basic device (mod-
ule) and/or your system due to a short circuit!
Inadequate insulation at the current measurement in-
puts of the modules with respect to the supply circuits
of the basic device can cause dangerous voltages
at the measurement input or damage to your device
(module)/system.
· Ensure reinforced or double insulation with
respect tothe supply circuits!
WARNING
Risk of injury due to large currents and high elec-
trical voltage on the current transformers!
Current transformers operated while open on the
secondary side (high voltage peaks pose a hazard
when touched) can result in severe bodily injury or
death.
· Avoid operating the current transformers while
open; short circuit the unloaded transformers!
· Before interrupting the current supply, short
circuit the secondary connections of the cur-
rent transformers. Switch any test switches
that automatically short circuit the secondary
lines of the current transformers to the “Test”
status (Check the test switch/short circuiting
connection beforehand)!
· Only use current transformers with basic insu-
lation to IEC61010-1:2010!
· Caution, even current transformers rated as
safe for open operation can pose a hazard
when touched during operation while open!
· Make sure that screw terminals for the current
transformer connection on the device are ade-
quately tightened!
· Comply with the information and provisions in
the documentation of your current transform-
ers!
2.8 Safety information for handling measure-
ment devices with residual current mea-
surement
WARNING
Risk of injury or damage to the meter due to im-
proper use!
Meters with residual current measurement can trigger
warning pulses if limit values are exceeded, and these
are used exclusively for monitoring residual currents
or failure monitoring. Use of the warning pulses as a
stand-alone protective device against electrical shock
can lead to injury and even death!
· Do not use devices with residual current mea-
surement as a stand-alone protective device.
Employ suitable protective devices for your
system!
CAUTION
Risk of injury or damage to the meter/your system
due to short circuit!
Inadequate insulation of the operating equipment at
the residual current measurement input with respect
to the supply circuits can cause voltages at the
measurement input which represent a hazard when
touched or damage to your device or system.
· Ensure reinforced or double insulation with
respect tothe supply circuits!
· Ensure galvanic isolation of the residual current
measurement inputs from each other!
2.9 Handling batteries/accumulators
The following apply for the battery used in the de-
vice:
CAUTION
Risk of injury due to fire or burns!
The battery used in the device may cause fire or
burns if used improperly.
· Only replace the battery with the same type or
types recommended by Janitza!
· Observe the polarity when installing the bat-
tery!
· Remove batteries only with non-conductive
tools (e.g. plastic tweezers)!
· Do not recharge, disassemble, burn or heat
batteries above 100°C (212°F)!
· Do not dispose of batteries with household
waste! Follow the disposal instructions in the
respective device documentation!
· Keep batteries away from children and ani-
mals!
· In case of damage, return devices with a sol-
dered battery to the manufacturer, observing
proper transport conditions!

UMG801 www.janitza.com
18
3. Product description
3.1 Device description CAUTION
Malfunction and damage of the device or risk of
injury due to improper connection.
Improperly connected devices can deliver incorrect
measured values, damage the device or pose a risk of
injury to persons.
Observe the following:
· That measured voltages and currents come
from the same network.
· Do not use the device for measuring direct
current!
· Ground current-conducting switchboards!
The measurement device is a multifunctional network
analyzer and is suitable for:
· Measurements and calculations of electrical
quantities such as voltage, current, power, energy,
harmonics current in building installations, on distri-
bution boards, circuit breakers and busbar trunking
systems.
· An expansion of the range of functions using mod-
ules.
· The connection of remote measurement points in
the switchboard cabinet or small installation distrib-
utors via transfer modules.
· Measurements of voltages and currents from the
same network.
· Measurements in low-voltage networks (3-phase
4-conductor systems) in which nominal voltages of
up to 480 V from conductors to ground and surge
voltages of overvoltage category III occur.
· Measurements in medium and high voltage net-
works via current and voltage transformers.
· Current measurement via
- external ../1A or ../5A current transformers.
- the multifunction channels (mA current inputs).
· Installation in stationary switch cabinets or small
distribution boards, in any mounting orientation.
· The measurement of residual currents (Residual
Current Monitoring, RCM) of an electrical system.
The measurement device is not a protective device
against electric shock!
· Use in industrial areas.
Measurement results are displayed by the measure-
ment device and can be read and processed via
interfaces.
Fig.: UMG801 measurement device

www.janitza.com UMG801
19
3.2 Incoming goods inspection
Safe and trouble-free operation of this measurement
device (with its modules and components) presup-
poses proper transport, storage, setup and assembly
as well as operation and maintenance in addition to
compliance with the safety information and warning
notices.
Exercise due caution when unpacking and packing
the device, do not use force and only use suitable
tools. Check the following:
· The measurement device by visually checking that
it is in perfect mechanical condition.
· the scope of delivery for completeness before be-
ginning with assembly and installation.
If it can be assumed that safe operation of your
measurement device is not possible, disconnect the
measurement device immediately. To avoid electrical
accidents, follow the 5 safety rules as follows:
1. Disconnect the system (devices, as applicable
modules and components also)!
2. Secure it against being switched on!
3. Check to be sure it is de-energized!
4. Earth and short circuit the system (devices, as
applicable modules and components also)!
5. Cover or block off adjacent live parts!
Safe operation isimpossible, if the measurement
device:
· has visible damage,
· no longer functions despite an intact power supply,
· was subjected to extended periods of unfavorable
conditions (e.g. storage outside of the permissible
climate conditions without adaptation to the room
climate, condensation, etc.) or transport stress
(e.g. falling from an elevated position, even without
visible external damage, etc.).
3.3 Intended use
The measurement device is
· Only for use in the industrial sector.
· Intended for installation in switchboard cabinets
and small distribution boards.
· Designed as an indoor meter.
The measurement device is not for installation
· in vehicles! Use of the device in non-stationary
equipment constitutes an exceptional environmen-
tal condition and is only permissible by special
agreement.
· In environments with harmful oils, acids, gases,
vapors, dusts, radiation, etc.
Safe and trouble-free operation of the measurement
device requires proper transport, storage, assembly,
installation, operation and maintenance.
ATTENTION
Improper handling can damage the measurement
device (possibly also modules and components)
and lead to material damage!
The contacts of JanBus interfaces can bend or break
off and destroy the interface.
·Never touch or manipulate the contacts of Jan-
Bus interfaces!
·Never use force to mount bus connectors,
modules and components! Please refer to the
chapters "Mounting" and "Dismounting" here in
the user manual and, if applicable, in the usage
information of the modules and components
that are used!
·Protect the contacts of the interfaces when
handling, transporting and storing the measure-
ment device (as applicable, the modules and
components as well)!

UMG801 www.janitza.com
20
3.5 EU/UKCA Declaration of Conformity
Please see the EU/UKCA declarations of conformity
posted at www.janitza.com for the laws, standards
and directives applied by Janitza electronics GmbH
for the devices. The EU/UKCA conformity of the
device permits the marking CE/UKCA.
3.6 FCC Declaration of Conformity
The device
· complies with Part 15 of the FCC Rules for Class
B digital devices (limits to protect against harmful
interference in a residential installation).
· generates, uses and can radiate high-frequency
energy
· can cause harmful interference to radio communi-
cations if not installed and used properly. There is
no guarantee that interference will not occur in a
particular installation.
If there is radio or television reception interference,
which can be determined by turning the device on
and off, proceed as follows:
· Align or reposition the receiving antenna.
· Increase the distance between the device and the
radio/television receiver.
· Connect the device and the radio/television receiv-
er in different circuits.
· if necessary, contact Janitza support or a radio/
television technician.
Code of Federal Regulations, Title 47, Part 15, Sub-
part B - Unintentional Radiators.
3.4 Performance characteristics
General
· DIN rail measurement device with the dimensions
W:144mmxH:90mmxD:76mm.
· Mounting on 35mm DIN rail (for types see chap.
"Technical data").
· TFT display.
· Operation via 6 buttons.
· Password protection.
· Connection via screw terminals.
· 4 voltage measurement inputs (1000V, CATIII).
· 2x 4 current measurement inputs (via current trans-
former).
· RS-485 interface (Modbus RTU, with DIP switch for
termination).
· 2x Ethernet interface (RJ45).
· 4 digital inputs.
· 4 digital outputs.
· 1 analog output (galvanically isolated).
· 4 multifunction channels for use as residual current
or temperature measurement inputs and additional
current measurement channels (mA).
· Clock and battery.
· Optional remote display (RD96) for convenient
meter operation.
· Expandable with current measuring modules and
digital input modules via transfer modules (see
usage information for the respective modules).
Measurement uncertainty
· Active energy, measurement uncertainty class 0.2 S
for ../5A transformers.
· Active energy, measurement uncertainty class 0.5 S
for ../1A transformers.
· Active energy, measurement uncertainty class 0.5 S
for ../50mA transformers.
· Reactive energy, class 1.
Measurement
· Measurement in TN, TT and IT networks.
· Measurement in networks with nominal voltages up
to L-L 830V and L-N 480V.
· Measuring range, voltage 720Veff L-N;
1000Veff L-L; 100V N-PE.
· Measuring range, current 0.005 .. 6Aeff.
· True effective value measurement (TRMS).
· Continuous sampling of the voltage and current
measurement inputs.
· Frequency range of the fundamental oscillation
40Hz ..70Hz.
· Voltage: 1..127 harmonics and interharmonics.
· Current: 1..63 harmonics.
· Residual current acc. to IEC/TR 60755 (2008-01),
type A + type B and B+.
