Jantex GD847-A User manual

Hand Dryer
Instruction Manual
Model:
GD847-A

2 | P a g e
Index
Safety Tips ........................................................................................................ 3
Product Description ........................................................................................ 3
Pack Contents .................................................................................................. 3
Installation ....................................................................................................... 4
Operation ......................................................................................................... 4
Adjsuting the Automatic Sensor .................................................................... 4
Cleaning Care and Maintenance..................................................................... 5
Trouble Shooting............................................................................................... 5
Technical Specifications ................................................................................... 5
Electrical Wiring............................................................................................... 5
Compliance ........................................................................................................ 6
Declaration of Conformity ............................................................................... 7

3 | P a g e
Safety Tips
Position on a flat, stable surface.
A service agent/qualified technician should carry out installation and any repairs if required.
Do not remove any components or service panels on this product.
Consult Local and National Standards to comply with the following:
oHealth and Safety at Work Legislation
oBS EN Codes of Practice
oFire Precautions
oIEE Wiring Regulations
oBuilding Regulations
DO NOT use jet/pressure washers to clean the appliance.
DO NOT use the appliance outside.
DO NOT store products on top of the appliance
Always switch off and disconnect the power supply to the unit before cleaning.
Keep all packaging away from children. Dispose of the packaging in accordance with the
regulations of local authorities.
If the power cord is damaged, it must be replaced by a Jantex agent or a recommended qualified
technician in order to avoid a hazard.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the appliance by a person responsible
for their safety
Children should be supervised to ensure that they do not play with the appliance.
This appliance must NOT be installed where persons bathing could reach
This appliance must NOT be installed within 1.8M of a wet zone (bath, sink, shower etc)
This appliance must NOT be installed where persons could reach when taking a shower
DO NOT cover the air inlet
Product Description
GD847-A - Jantex Automatic Hand Dryer - Stainless Steel
Pack Contents
Jantex Automatic Hand Dryer
Instruction Manual

4 | P a g e
Installation
Remove all packaging and dispose of it safely.
Installation work must be carried out by a qualified electrician
Incorrect wiring of this electrical device may lead to electrocution or damage to property.
The dryer must be located at least 1.8m from wet area (Zone 0).
A switch with two poles should be applied between this appliance and the power supply cable.
The appliance must be properly grounded / earthed.
Install a residual current circuit breaker (RCD)
NOTE:
This appliance must not be located where it may accidently be splashed with water. ric
Electric Shock may result
Operation
1. Place hands under nozzle. The hand dryer will automatically start.
2. Hand dryer will stop when hands are removed from under nozzle or time exceeds 1 minute.
Adjusting the Automatic Sensor
The Jantex Hand Dryer automatically detects when hands are placed under the air nozzle and will
then start automatically. The sensitivity (distance from the unit hands need to be to start Hand
Dryer) can be adjusted to suit. Adjustment of the Automatic Sensor should only be carried out by a
qualified engineer. The adjusting screw can be found by removing the front cover.

5 | P a g e
Cleaning, Care and Maintenance
Switch off the Power at the mains prior to cleaning.
Do not use abrasive cleaning agents. These can leave harmful residues.
Always wipe dry after cleaning
A Jantex agent or qualified technician must carry out repairs if required.
Trouble Shooting
Problem Diagnosis Remedy
Unit does not
operate
Power off Check power
Sensing distance too short Call Jantex agent or qualified engineer
Sensing device damaged Call Jantex agent or qualified engineer
No hot air Heater faulty Call Jantex agent or qualified engineer
Motor damaged Call Jantex agent or qualified engineer
Technical Specifications
Model
Voltage
Power
Current
Dimensions
H X W X D (mm)
Weight (Kg)
GD847-A
230v 50hz
2500w
11.5A
200 x 275 x 230
6
Electrical Wiring
This appliance is wired as follows:
Live wire (coloured brown) to terminal marked L
Neutral wire (coloured blue) to terminal marked N
Earth wire (coloured green/yellow to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.

6 | P a g e
Compliance
The product must not be disposed of as household waste. To help prevent possible harm
to human health and/or the environment, the product must be disposed of in an
approved and environmentally safe recycling process. For further information on
how to dispose of this product correctly, contact the product supplier, or the
local authority responsible for waste disposal in your area.
JANTEX parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and
federal authorities.
JANTEX products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by
any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written
permission of JANTEX.
Every effort is made to ensure all details are correct at the time of going to press, however, JANTEX
reserve the right to change specifications without notice.

7 | P a g e
DECLARATION OF CONFORMITY
Equipment Type
Hand Dryer
Model
GD847-A
Legislation
C-Tick
SAA-150987-EA
AS/NZ 3820 Essential Safety Requirements for Low Voltage Electrical
Equipment
Standards
AS/NZS CISPR 15
IEC 60335-1:2010
AS/NZ 60335-2-23:2012
Producer Name
Jantex
Producer Address
15 Badgally Road,
Campbelltown,
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and
Standard(s).
Date
29/05/15
Signature
Full Name
Richard Cromwell
Position
Commercial Director

GD847-A_A5_v2_20190621
