Jason.L Flyby Echo User manual

ASSEMBLY INSTRUCTIONS
Flyby Echo screen
with L-brackets
Page 2 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Echo Plate x 1
L Bracket x2
Clamps cover x2
Screws x4
Wood screws x 4
A
B
C
D
E
COMPONENTS
D
B
C
Experienced assembly is required. User will need to drill wood screws into underside of desk. No pre-drilled holes are provided for this system.
Power Drill tool is required.2 Persons required for installation *
A

ASSEMBLY INSTRUCTIONS
Flyby Echo screen
with L-brackets
Page 3 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
STEP 01
Please drill two holes using 8mm drill bit having a 32.5 mm
gap between screw holes.
Assembe Aplate with B bracket and tighten using 4 x screws provided
(D) and apply the bracket cover C
STEP 02
D
A
B
C
250 mm
285 mm
317.5 mm

ASSEMBLY INSTRUCTIONS
Flyby Echo screen
with L-brackets
Page 4 of 4
Need help!
Call us on
1300 527 665
www.jasonl.com.au
STEP 03
Please assemble Echo panel with desktop using L brackets. Please drill 4 x wood screws (E) into the underneath desk and tighten
the L brackets on the desk.
STEP 04
