Jayco 2005 Talon ZX User manual

Sport Utility Trailer &
Fifth-Wheel Sport Utility Trailer
Owner’s Manual
Model Year 2005

IWARNING: Read all instructions in this manual and component part
manufacturer supplied information before using your RV.
This manual has been provided by Jayco, Inc. for the sole purpose of providing instructions
concerning the operation and maintenance of this vehicle and its component parts. Nothing
in this manual creates any warranty, either expressed or implied. The only warranty
offered by Jayco, Inc. is the limited, express warranty applicable to this vehicle.
The owner’s failure to provide required service and/or maintenance results in the loss of
warranty. The owner should review Jayco’s limited, express warranty and the warranties
that apply to specific component parts that are offered with this vehicle.
Instructions are included in the manual for operating various component parts which are
optional on some vehicles. In addition, the owner should refer to individual
manufacturer’s operating instructions contained in the owner’s packet.
IWARNING:
VReview the compatibility of your tow vehicle with the trailer you will be
towing. You, as the owner, are responsible for the safety and
compatibility of your tow vehicle and trailer selections.
VYou must not exceed the gross vehicle weight rating (GVWR) of the
trailer. Include all additions, cargo and tank fluids when calculating
the weight of your trailer.
VDo not exceed the towing or cargo capacity of your tow vehicle. You
must clearly understand how your tow vehicle’s capacities are
calculated.
VDo not load your trailer so that it is unbalanced from front to rear or
from side to side.
VKnow your loaded hitch weight and select a hitch that is adequate for
that weight. Consult your hitch and tow vehicle manufacturers with
any questions before you tow your trailer.
VYou are responsible for the maintenance of your tow vehicle and trailer.
Make sure your tow vehicle is mechanically sound for your intended
usage. Pay particular attention to suspension components, tires and tire
pressure.
VWe recommend the use of sway control devices and weight distributing
hitches with all Jayco towable products (excluding fifth-wheels, which
use a different type of hitch).
VObey all traffic laws and use your seatbelts at all times. Many states
have lower speed limit requirements for tow vehicle/trailer
combinations. We recommend that you do not exceed 55 MPH when
towing a trailer.
Consult an expert for specific driver education when towing a trailer. There are private RV
driving schools, and some RV clubs, which offer driving seminars as part of their club
activities. Recreation vehicle publications and the Internet can be a source of information
regarding RV driver education, as well as many other topics to help you learn to safely use
your recreation vehicle.
© 2003 Jayco, Inc. LITHO USA 06/04***05-1 Part # 0181787

YOUR NEW JAYCO IS YOUR PASSPORT TO A WHOLE WORLD OF NEW FRIENDS,
CAMPING FUN AND TRAVEL ADVENTURE WHEN YOU JOIN THE THOUSANDS OF
JAYCO FAMILIES WHO MAKE UP THE . . .
JAYCO JAFARI INTERNATIONAL TRAVEL CLUB
You will find us enjoying the friendship and fellowship of JAFARI CAMPING as we join our
local area FLIGHTS at hundreds of weekend camp-outs all over North America each month . . .
WE’RE THE FAMILIES OF JAYCO!
There are special STATE, REGIONAL and INTERNATIONAL RALLIES where you can join
with your fellow JAFARIANS and their flights to enjoy a special kind of togetherness . . . fun,
games, and entertainment provide memories to last a lifetime.
And . . . how about the exotic surroundings of NEW ORLEANS, the sounds and color of
NASHVILLE and the GRAND OLE OPRY, the roar and rush of the INDIANAPOLIS 500, the
quiet surroundings of the CANADIAN ROCKIES, the color of the SMOKY MOUNTAINS in
the Fall. These and many other adventures can be yours when you join the. . .
JAYCO JAFARI INTERNATIONAL TRAVEL CLUB
Fill in the blanks on the reverse side, cut along dotted line and mail along with a check to:
JAYCO JAFARI INT’L TRAVEL CLUB
ATTN: Membership Coordinator
P.O. Box 192
Osceola, IN 46561-0192
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer 3

Yes, it’s for everyone with a JAYCO RV; young couples just starting out, families spending quality
time together, the young at heart expanding their life experiences. Whether you belong to another
camping club, have always traveled alone, or are just starting, don’t miss out on one of the most
priceless benefits of being an RV family ...meetnewfriends and spend a bit of your camping life
with some of the finest people you will ever have the opportunity to share a campfire or treasure a
moment of golden living with a . . FIFTH-WHEEL TRAVEL TRAILER. . .SPORT UTILITY
TRAILER . . . CONVENTIONAL TRAVEL TRAILER . . . TYPE C MOTORHOME . . .
FOLDING CAMPING TRAILER ...itdoesn’t matter. If you are a JAYCO RV FAMILY, then
you are eligible to become a Jayco Jafari Member.
YOU WILL NEVER BE SORRY YOU MADE THE DECISION!
Your membership entitles you to:
•Special international decals for your unit.
•The Hitch newsletter with schedules of upcoming events and activities.
•A membership roster - containing the names and addresses of current members of the club
will be sent bi-yearly.
•Discount Cards for several national theme parks including Six Flags and Busch Corp. Parks.
•A special price is available on Wheeler’s Campground Guides.
•Discounts with Hertz Rental Car.
•Discounts with Coach Net, an emergency roadside service.
•Farm & City Insurance has RV insurance available at discounted rates to current Jayco
Jafari International Club members.
• All of this, plus the joy of meeting new friends and enjoy Jafari adventures around the
country.
Start with the first phase of your camping life...just complete the following application and forward
it to the Jayco Jafari International Travel Club office. Your membership application may also be
completed online, by visiting our website at www.jaycorvclub.com. If you have further questions,
contact the club office direct at the website or by calling
800-262-5178. Local calls can be made to 574-258-0571.
WELCOME TO THE JAFARI FAMILY!
TO: Membership Coordinator for the Jayco Jafari International Travel Club
Please enroll us as members in the Jayco Travel Club. We are ready to roll to where the “friends we
just haven’t met yet” have the coffee on the fire and are waiting for us to arrive: We are ...
Name: Spouse:
Address: Phone:
City: State: Zip:
Email:
Ages of Children at Home:
Our JAYCO is a: Our Dealer
(type & size)
Membership Dues:
One year $25.00 Amount enclosed. $
Two years: $45.00 Check #:
Three years: $65.00
(signature) (date)

Table of Contents
Welcome............................................1
Warranty/Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .....3
Towable Limited Warranty . . . . . . . . . . . . . . . . .................4
Warranty Registration and Customer Delivery Form . . . . . ...............7
Limited Warranty Transfer Application . . . . ......................8
Service Procedures . . . . . . . . . . . . . . . . . . . . . . . . . ...........10
Basic Service Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Independent, Authorized Dealer . . . . . . . . . . . . . . . . ............11
Parts ..........................................11
Owner's Responsibility. . . . . . . . . . . . . . . . . . . . .............11
Manufacturer’s Customer Support Directory. . . . . . . . . .............12
Safety. ............................................13
Safety Considerations . . . . . . . . . . . . . . . . . . . . . . .............13
Reporting Safety Defects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Safety in Using LP Gas . . . . . . . . . . . . . . . . . . . . .............14
Checking for Leaks. . . . . . . . . . . . . . . . . . . . . . .............14
To Leak Test the LP Gas System: . . . . . . . ...................14
If a Leak is Detected: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Electrical System Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Water System Safety . . . . . . . . . . . . . . . . . . . . . .............15
Fuel Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . ............16
Fuel Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......16
Transportation of Cargo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Fire Extinguisher . . . . . . . . . . . . . . . . . . . . . . . . . ...........17
Inspection and Maintenance. . . . . . . . . . . . . . . . . . . . .........17
Carbon Monoxide Detector. . . . . . . . . . . . . ..................18
Smoke Detector . . . . . . . . . . . . . . . . . . . . . . . . . ...........18
Safety When Emergency Stopping . . . . . . . . . . . . . . . . ...........19
Changes, Modifications and Additions . . . . . . . ..................19
Additional Safety Considerations . . . . . . . . . . . . . . . . ...........20
Cold Weather/Extended Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Condensation . . . . . . . . . . . . . . . . . . . . . . . . . . . ............21
Insurance . ........................................21
Before you travel.... . . . . . . . . . . . . . . . . . . . . .................23
Weights and Cargo Capacity . . . . . . . . . . . . . ..................23
Loading Cargo. . . . . . . . . . . . . . . . . . . . . . . . . . . ............24
Cargo Ramp Door Operation . . . . . . . . . . . . . ..................26
To open the ramp door: . . . . . . . . . . . . . ..................26
To close the ramp door: . . . . . . . . . . . . . ..................26
Power Winch (Option). . . . . . . . . . . . . . . . . . . . . . .............27
Set up for Operation . . . . . . . . . . . . . . . . . . . . . .............27
Rear Bumper. . . . ....................................27
Holding Tank(s) and Trailer Weight. . . . . . . . . . . . . . . . ............27
Weighing Instructions . . . . . . . . . . . . . . . . . . . . . . .............28
To determine the wheel position weight: . . . . . . . . . .............28
Equipment . ........................................28
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer i

Tow Vehicle ......................................29
Sport Utility Trailer Only . . . . . . . . . . . . . . . . . . . . . . ...........30
Hitches . ........................................30
Weight Distributing System. . . . . . . . . . . . . . . . . . . ..........30
Sway Control ....................................30
Hitch Height ......................................31
The Hitching Procedure . . . . . . . . . . . . . . . . . . . . ............31
The Safety Chain ....................................32
Fifth-Wheel Sport Utility Trailers Only . . . . . . . . . . . . . . . . . .........33
Hitches . ........................................33
Hitch Height ......................................33
Hitching Procedures . . . ...............................33
Towing ..........................................34
Towing Behind Your Trailer . . . . . . . . . . . . . . . . . . . . . . . .......34
Tires . . ..........................................35
Wheel Lugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..........36
Brakes ...........................................37
Pre-Travel Checklist....................................38
Setting Up Camp.........................................41
Selecting your Campsite . . . ...............................41
Setting Up Your Trailer . . . ...............................42
Un-Hitching - Fifth-Wheel Sport Utility Trailer . . . . . . . . . . . . . . . . . . . . 42
Un-Hitching - Sport Utility Trailer . . . . . . . . . . . . . . . . . . . . . ......42
Leveling Your Trailer . . . . . . . . . . . . . . . . . . . . . . ...........42
Additional Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Stabilizer Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Slideout Room (Option on Some Models). . . . . . . . . . . . . . . . . . . . . . 43
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Extending Room . . . . . . . . . . . . . . . . . . . . . . ...........44
Retracting Room . . . . . . . . . . . . . . . . . . . . . . ...........44
Television ......................................44
Antenna .....................................44
Cable .......................................44
Rear Bed Operation (Fig. 12) . . . . . . . . . . . . . . . . . . . . . .......45
SetUp......................................45
Store Away....................................45
Couch/J-Steel Dinette Operation . . . . . . . . . . . . . . . . . .........45
Booth Dinette to Bed Conversion . . . . . . . . . . . . . . . . . .........46
Hide-a-Bed .....................................46
Awning Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Screen Wall (Option) . . . ...............................47
Patio Canopy and Screen Room (Option). . . . . . . . . . . . . ...........48
Utility Hookups ......................................53
Electricity .......................................53
Water ..........................................53
To utilize the city water connection:. . . . . . . . . . . . . . . . . . . ......53
To utilize the installed tank: . . . . . . . . . . . . . . . . . . . ..........54
ii Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer
Table of Contents

Gravity Fill Tank. . . . . . . . . . . . . . . . . . . . .............54
12-Volt DC Demand Pump . . . . . . . . . . . . . . . . . . . . .........54
Water Pressure Regulator . . . . . . . . . . . . . . . . . . ............54
LP Gas Connections and Start Up . . . . . . . . . . . . . . . . ...........55
Waste Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......55
To Connect the Trailer for Waste Disposal: . . . . . . . . . . . . . . .....56
At Camp... ..........................................57
Appliances. ........................................57
Kitchen . ........................................57
Range . . . . ....................................57
Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......57
Refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......57
Furnace . ........................................57
Water Heater . . . . . . . . . . . . . . . . . . . . . .................58
Bathroom . ........................................58
Toilet ..........................................58
Faucets ..........................................58
Exterior Water Hose . . . . . . . . . . . . . . . . . . . . . . . . . ...........59
Outside Shower (Option) . . . . . . . . . . . . . . . . . . . . .............59
Operation . . . . . . . . . . . . . . . . . . . . . .................59
Water Purification System. . . . . . . . . . . . . . . . . . . . .............59
To replace the filter: . . . . . . . . . . . . . . . . . . . . .............60
Entertainment . . . . . . . . . . . . . . . . . . . . . . . . . . . ............60
Radio Speaker Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Air Conditioner . . . . . . . . . . . . . . . . . . . . . .................60
Security Lights . . . . . . . . . . . . . . . . . . . . . .................61
Monitor Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . ............61
Operation . . . . . . . . . . . . . . . . . . . . . .................61
Fuel Tank(s) . . . . ....................................61
Fuel Gauge Operation . . . . . . . . . . . . . . . . . . . . . . .............62
Generator Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......62
Fuel Station Only . . . . . . . . . . . . . . . . . . . . . . . . . ...........62
Generator and Fuel Station . . . . . . . . . . . . . ..................62
Generator Prep / Generator (Option). . . . . . . . . . . . . . . . ............62
Generator Prep . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......62
Generator. . . . ....................................63
Fuel Station . . . . ....................................63
Operation. . . . ....................................64
To Dispense Fuel: . . . . . . . . . . . . . . . . . . . . . .............64
BBQ Grill Prep . . . . . . . . . . . . . . . . . . . . . .................65
BBQ Grill (Option). . . . . . . . . . . . . . . . . . . . . . .............66
Utilities/Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . ............67
Plumbing System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......67
Sanitizing the Potable Water System . . . . . . . ...................67
Drainage . . . . ....................................68
To Drain System: . . . . . . . . . . . . . . . . . . . . . .............68
Sanitation System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......68
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer iii
Table of Contents

Using Toilet and Tank System . . . . . . . . . . . . . . . . . . . ..........68
Vents ..........................................69
Holding Tanks .....................................69
Waste (Black) Tank Preparation . . . . . . . . . . . . . . . . . .........69
Gray Water Holding Tank. . . . . . . . . . . . . . . . . . . . . . . .......69
LP Gas System.......................................69
LP Gas Container .....................................71
Servicing and Filling LP Containers. . . . . . . . . . . . . . . . . . . ......72
OPD Overfill Protection . . . . . . . . . . . . . . . . . . . . ............73
Dual Cylinder Assembly with Bottle Rack on A-Frame or Front Trunk . . . . . . . 73
Two Cylinders - 20# or 30# (44 or 66 kilograms)
In a recessed compartment or housing (Fig. 57) . . . . . . . . . . . . . . . . . 74
Main Supply Hose - Low Pressure . . . . . . . . . . . . . . . . . . . . . ......74
Regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..........75
LP Gas Consumption . . . . . . . . . . . . . . . . . . . . ............75
LP Gas Detector ....................................75
Electrical System .....................................76
General . ........................................76
120-Volt AC System . . . ...............................76
Power Cord .....................................76
Ground Fault Current Interrupter (GFCI) . . . . . . . . . . . . . . . . . . . . . . 77
Testing Instructions . . . . . . . . . . . . . . . ................77
50-amp Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Consumption of 120-volt AC Power . . . . . . . . . . . . . ...........78
12-Volt DC System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Power Converter ....................................79
Auxiliary Battery (Independent, Authorized Dealer Installed Option) . . . . . . 79
Generator (Option) . . . . . . . . . . . . . . . . . . . . . . ...........80
Battery Disconnect Switch . . . . . . . . . . . . . . . . . . . ..........80
Battery Isolator (For Tow Vehicle) . . . . . . . . . . . . . . . . . . . ......80
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..........80
Exterior .....................................80
Porch .......................................81
Interior ......................................81
Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..........81
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..........81
DC Fuse Panel Layout. . . . . . . . . . . . . . . . . . . . ............82
Television Cable ....................................82
Brakes . ........................................82
Preparing to Travel Home... . . . . . . . . . . . . . . . . . . . . ............83
Departing Camp Checklist. . . . . . . . . . . . . . . . . . . . . . ...........83
Draining the Holding Tank(s) . . . . . . . . . . . . . . . ................85
To Empty Holding Tank: . . . . . . . . . . . . . . . . . . . . ............85
Maintaining Your Investment... . . . . . . . . . . . . . . . . . . . . . . . .......87
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..........87
Fifth-Wheel Sport Utility Trailer Only . . . . . . . . . . . . . . . . . .........87
Hitch ..........................................87
iv Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer
Table of Contents

Landing Gear . . . . . . . . . . . . . . . . . . . . . .................87
Sport utility Trailer Only . . . . . . . . . . . . . . . . . . . . .............87
Hitch ..........................................87
Coupler . ........................................87
Tongue Jack . . . . . . . . . . . . . . . . . . . . . .................88
Frame ...........................................88
E-Z Lube Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . ............88
Wheel Bearings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......88
Wheel Lugs. . . . . . . . . . . . . . . . . . . . . . . . . . . ............88
Brakes and Brake Linings . . . . . . . . . . . . . ..................89
Tires . . ..........................................89
Changing Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......89
Spare Tire Carrier (Option). . . . . . . . . . . . . ..................90
Clearance Lights. . . . . . . . . . . . . . . . . . . . . .................90
Exterior ..........................................91
Metal ..........................................91
Fiberglass Sidewalls . . . . . . . . . . . . . . . . . . . . . .............91
Roof Ladder (Option) . . . . . . . . . . . . . . . . . . . . .............91
(Fifth-Wheel Sport Utility Trailers Only). . . . . . . . . .............91
Rubber Roof . . . . . . . . . . . . . . . . . . . . . .................91
Sealing . ........................................92
Doors, Extrusions, Windows & Vents . . . . . . . . . . . . . . . . ...........93
Entrance Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......93
Cargo Bay Floor/Wall Coating . . . . . . . . . . . . . . . . . . ............94
Screen Wall and/or Patio Canopy/Screen Room. . . . . . . . . .............94
Screen Wall and/or Screen Room . . . . . . . ...................94
Fiberglass Screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Canopy . . . . . . . . . . . . . . . . . . . . . . . . . . . ............95
ABS Plastics . . . . ....................................95
For cleaning: . . . . . . . . . . . . . . . . . . . . . .................95
Bathroom Tub, Lavatory Sink . . . . . . . . . . . . . ..................95
Furniture..........................................96
Cloth Furniture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......96
Synthetic Leather. . . . . . . . . . . . . . . . . . . . . . . . . ...........96
Cushions..........................................96
Bedspreads . . . . ....................................96
Window Treatments . . . . . . . . . . . . . . . . . . . . . . . . . ...........96
Shower Curtain and Liner . . . . . . . . . . . . . . . . . . . . .............96
Paneling ..........................................97
Vinyl Floor . . . . ....................................97
Carpeting . ........................................97
Countertops . . . . ....................................97
High Pressure Laminate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Hardware and Sink or Shower Fixtures . . . . . . . ...................97
Slideout ..........................................98
Electric Slideout Override . . . . . . . . . . . . . ..................98
Fuel Station . . . . ....................................98
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer v
Table of Contents

Carbon Monoxide (CO) Detector . . . . . . . . . . . . . . . . . . . ..........98
LP Gas System.......................................99
LP Gas Bottles .....................................99
TV Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..........99
Furnace ..........................................99
Generator.........................................100
Periodic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . ........100
Air Conditioner......................................100
Toilet . . .........................................100
Maintenance Checklist . . . . . . . . . . . . . . . . . . . . . . . ...........101
Storing Your Trailer... . . . . . . . . . . . . . . .....................105
Winterizing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Method 1 .......................................105
Method 2 .......................................106
Storage Checklist.....................................107
During Storage Period. . . . . . . . . . . . . . . . . . . . . . . . . ........107
Index . ...........................................109
vi Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer
Table of Contents

WELCOME
Thank you for purchasing your Jayco Recreation Vehicle (RV) and welcome to the world
of recreation vehicle travel. Your purchase of a Jayco RV allows you to enter this unique
world of camping and leisure in a grand style. Your Jayco RV has been designed and
engineered to offer many comforts of home to make your camping experience as enjoyable
as possible. Jayco RVs are designed, constructed, warranted and intended to be used as
temporary living quarters for recreational, camping and travel uses, as defined in the
bylaws of the Recreation Vehicle Industry Association.
This owner’s manual will assist you in understanding the RV’s proper use and operation. If
you are a newcomer to RV travel, you will appreciate the suggestions and “shop talk”
information found throughout this manual.
Keep this manual in your recreation vehicle for handy reference. Get to know your new
vehicle and how it operates. The information in this manual reflects the most current
available to us at the time of publication. This manual is a supplement to various other
instructions supplied by the manufacturers of separately manufactured and warranted
component parts. Carefully read, understand and follow this owner’s manual and all
information supplied by manufacturers of components. This information contains
important operating, safety, and maintenance instructions. Direct questions that are not
answered by the owner’s manual or other booklets, to your independent, authorized dealer.
If they cannot satisfactorily answer your questions, they will call or refer you to the
component part manufacturer or Jayco.
Your vehicle was manufactured based on the applicable requirements of:
• Federal Motor Vehicle Safety Standards
• State Regulations
• Canadian Standards Associations (CSA) (where applicable)
•Requirements of ANSI Standard A119.2, the nationally recognized Standard For
Recreation Vehicles – Installation of Plumbing, Heating and Electrical Systems.
The Recreation Vehicle Industry Association (RVIA) and Canadian Standards Association
(CSA) periodically inspect our production line and assist us in maintaining strict
compliance with installation and safety standards for those systems.
Periodic safety inspections and a program of preventive maintenance are necessary for the
continuation of safe and trouble-free operation.
Camping is a great way to relax and enjoy the outdoors with your friends and family. Please
remember to tread lightly on our beautiful land and leave only your footprints so that others
may enjoy nature as much as you did.
The Jayco Family
Jayco, Inc.
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer 1

NOTES
2 Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer

WARRANTY/SERVICE
The following pages contain warranty information. It is our recommendation that you read
through Jayco’s warranty and all other warranties. If there is any part which you do not
understand, consult with your independent, authorized dealer, appropriate component part
manufacturer, or Jayco for further explanation. The warranty titles are defined as follows:
•Towable Limited Warranty - Also referred to as the 2+3 Warranty, this comes
direct from the manufacturer to the original purchaser. It provides limited coverage
for 2 years (24 months) against substantial defects in materials and workmanship, and
3 years (36 months) on structure. Beyond this, it can be transferred one time only
within the warranty period.
•Warranty Registration & Customer Delivery Form - This form is to be completed
by the independent, authorized dealer when you pick up your unit. Once it is
completed and signed, the independent, authorized dealer will forward the
information to us so we can register your trailer.
•Limited Warranty Transfer Application - This is the form required to transfer the
warranty as indicated above in the Towable Limited Warranty. This form must be
completed and filed as instructed for the transfer to occur. If you have questions,
consult with your independent, authorized dealer.
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer 3

TOWABLE LIMITED WARRANTY
WHAT AND WHO IS COVERED
The Jayco warranty covers this recreational vehicle (“RV”), when used only for its intended purpose of recreational travel
and camping, for two (2) years. In addition, it covers the structural integrity (defined as something essential to the manner
of construction during the assembly process) of the sidewalls, floor, roof and frame for one (1) additional year. The war-
ranty periods begin on the date that the RV is delivered to the first retail purchaser by an independent, authorized dealer of
Jayco, or, if the dealer places the vehicle in service prior to retail sale, on the date the RV is first placed in such service. In
the event that a substantial defect in material or workmanship, attributable to Jayco, is found to exist during the warranty
periods, it will be repaired or replaced, at Jayco’s option, without charge to the RV owner, in accordance with the terms,
conditions and limitations of this limited warranty.
This limited warranty applies to the first consumer purchaser, and the next subsequent owner, only. This limited, express
warranty may be transferred once during the warranty period. However, the subsequent owner must submit a warranty
transfer form to Jayco to make the warranty transfer effective. You may contact an independent, authorized dealer for de-
tails. All rights and limitations within this warranty are applicable to the original owner and the subsequent owner of the
RV. The subsequent owner’s warranty coverage periods are the remaining balance of the warranty coverage periods that
the prior owner was entitled to under this limited warranty.
Jayco’s obligation to repair or replace defective materials or workmanship is the sole obligation of Jayco under this lim-
ited warranty. Jayco reserves the right to use new or remanufactured parts of similar quality to complete any work, and to
make parts and design changes from time to time without notice to anyone. Jayco reserves the right to make changes in the
design or material of its products without incurring any obligation to incorporate such changes in any product previously
manufactured. Jayco makes no warranty as to the future performance of this RV, and this limited warranty is not intended
to extend to the future performance of this RV, or any of its materials, components or parts. In addition, the RV owner’s
obligation to notify Jayco, or one of its independent, authorized dealers, of a claimed defect does not modify any obliga-
tion placed on the RV owner to contact Jayco directly when attempting to pursue remedies under state or federal law.
LIMITATIONS, EXCLUSIONS AND DISCLAIMER OF IMPLIED WARRANTIES
ANY IMPLIED WARRANTY THAT IS FOUND TO ARISE BY WAY OF STATE OR FEDERAL LAW, IN-
CLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR ANY IMPLIED WARRANTY OF
FITNESS, IS LIMITED IN DURATION TO THE DURATIONS SET FORTH IN THIS LIMITED WARRANTY
AND IS LIMITED IN SCOPE OF COVERAGE TO THE SCOPE OF COVERAGE OF THIS LIMITED WAR-
RANTY. Jayco makes no warranty of any nature beyond that contained in this limited warranty. Jayco does not authorize
any person to create any other obligation or liability for it regarding this RV, and Jayco is not responsible for representa-
tion, promise or warranty made by any dealer or other person beyond what is expressly stated in this limited, express war-
ranty, and no one has the authority to enlarge, amend or modify this limited, express warranty. Any selling or servicing
dealer is not Jayco’s agent, but an independent entity.
JAYCO SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES THAT MAY
RESULT FROM BREACH OF THIS LIMITED WARRANTY OR ANY IMPLIED WARRANTY. THIS EX-
CLUSION OF CONSEQUENTIAL AND INCIDENTAL DAMAGES SHALL BE INDEPENDENT OF ANY
FAILURE OF THE ESSENTIAL PURPOSE OF ANY WARRANTY, AND THIS EXCLUSION SHALL SUR-
VIVE ANY DETERMINATION THAT THIS LIMITED WARRANTY OR ANY IMPLIED WARRANTY HAS
FAILED OF ITS ESSENTIAL PURPOSE.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you.
Towable Limited Warranty Page 1 of 3
4 Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer
Warranty/Service

HOW TO GET SERVICE
To obtain warranty service the owner must do all of the following:
1. Notify an independent, authorized dealer of Jayco, or Jayco, of the substantial defect in material or workmanship at-
tributable to Jayco, within the applicable warranty coverage period designated above that you are making a warranty
claim under;
2. Provide the notification mentioned in one (1), above, within ten (10) days of when the owner discovered, or should
have discovered, the substantial defect in material or workmanship attributable to Jayco; and
3. Promptly schedule an appointment with and take the RV to an independent, authorized dealer of Jayco, or Jayco, for
repairs; and
4. Pays any freight or transportation costs, import duties, fees and all incidental expenses associated with obtaining war-
ranty service.
For warranty service, simply contact one of Jayco’s independent, authorized service centers for an appointment and then
deliver your RV to the service center on the specified appointment date. If you need assistance you may contact Jayco, at
P.O. Box 460, Middlebury, Indiana 46540, Attn: Aftermarket Service, [phone], or http://www.jayco.com.
NOTE: Jayco does not control the scheduling of service work at the independent,
authorized dealerships. You may encounter some delay in scheduling or comple-
tion of work.
If two (2) or more service attempts have been made to correct any covered defect that you believe impairs the value, use or
safety of the RV, or if it has taken longer than thirty (30) days for those types of repairs to be completed, you must, to the
extent permitted by law, notify Jayco directly, in writing, at the above address, of the unsuccessful repair(s) of the alleged
defect(s) so that Jayco can become directly involved in making sure that you are provided service pursuant to the terms of
this limited warranty.
WHAT IS NOT COVERED
By way of example only, this Limited Warranty does not cover any of the following: defects in materials, components or
parts of the RV not attributable to Jayco, items that are added or changed after the RV leaves the possession of Jayco; addi-
tional equipment or accessories installed at any dealership, or other place of business, or by any other party, other than
Jayco; any RV used for rental or other commercial purposes (Note: It shall be concluded that the RV has been used for
commercial and/or business purposes if the RV owner or user files a tax form claiming any business or commercial tax
benefit related to the RV, or if the RV is purchased in a business name); normal wear, tear or usage, such as tears, punc-
tures, soiling, mildew, fading, or discoloration of exterior plastic or fiberglass, or soft goods, such as upholstery, drapes,
carpet, vinyl, screens, cushions, mattresses and fabrics; the effects of condensation or moisture from condensation inside
the RV; mold or any damage caused by mold to the inside or outside of the RV; imperfections that do not affect the suit-
ability of the RV for its intended purpose of recreational use or items that are working as designed but that you are unhappy
with; problems, including water leaks, related to misuse, mishandling, neglect or abuse, including failure to maintain the
RV in accordance with the owner’s manual, or other routine maintenance such as inspections, lubricating, adjustments,
tightening of screws, tightening of lug nuts, sealing, rotating tires; damage due to accident, whether or not foreseeable, in-
cluding any acts of weather or damage or corrosion due to the environment, theft, vandalism, fire, or other intervening acts
not attributable to Jayco; damage resulting from tire wear or tire failure; defacing, scratches, dents, chips on any surface or
fabric of the RV; damage caused by off road use, overloading the RV or alteration of the RV, or any of its components or
parts; wheel alignment or adjustments to axles when caused by improper maintenance, loading or damage from road haz-
ards, including off road travel, wheel damage or balancing or damage from tire failures.
In addition, this limited warranty does not cover any material, component or part of the RV that is warranted by another en-
tity, including, by way of example, handling, braking, wheel balance, muffler, tires, tubes, batteries, gauges, generator,
jacks, inverter, microwave, television, VCR, CD player, tape player, radio, speakers, television, refrigerator, range, water
heater, stove, carbon monoxide detector, smoke detector, furnace or any air conditioner. (Note: The written warranty pro-
vided by the manufacturer of the component part is the direct responsibility of that manufacturer).
Towable Limited Warranty Page 2 of 3
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer 5
Warranty/Service

EVENTS DISCHARGING JAYCO FROM OBLIGATION UNDER WARRANTY
Certain things completely discharge Jayco from any obligation under this warranty and void it. By way of example, the
following shall discharge Jayco from any express or implied warranty obligation to repair or replace any defect that results
from: any rental or other commercial use or purchase of the RV (as defined in this warranty), any defect in a separately
manufactured component part, owner neglect or failure to provide routine maintenance (See Owner’s Manual), unautho-
rized alteration, off road use, collision or accident, whether or not foreseeable, including any acts of weather or damage or
corrosion due to the environment, theft, vandalism, fire, explosions, overloading in excess of weight ratings, and tamper-
ing with any portion of the RV.
LEGAL REMEDIES
Any action to enforce any portion of this limited, express warranty, or any implied warranty, shall be commenced within
six (6) months after expiration of the warranty coverage period designated above that you are trying to enforce. Any per-
formance of repairs shall not suspend any limitation period from expiring. Any performance of repairs after the warranty
coverage periods have expired, or performance of repairs regarding any thing excluded from coverage under this limited
warranty shall be considered “good will” repairs, and they will not alter the express terms of this limited warranty, or ex-
tend the warranty coverage periods or this limitation period in this paragraph. In addition, this warranty is not intended to
extend to future performance, and nothing in this warranty, or any action of Jayco, or any agent of Jayco, shall be inter-
preted as an extension of the warranty or this limitation period. Some states do not allow a reduction in the statute of limita-
tions, so this reduction may not apply to you.
WARRANTY REGISTRATIONS:
Your warranty registration records should be completed and delivered to the manufacturers of component parts. The sell-
ing dealership will assist you in completing and filling out the Jayco product warranty registration form. That form must
be returned to Jayco within ten (10) days of your taking delivery of the RV. Your Jayco warranty will not be registered un-
less this warranty registration is completed and received by Jayco. Failure to file this warranty registration with Jayco will
not affect your rights under this limited, express warranty as long as you can present proof of purchase, but it can cause de-
lays in obtaining the benefits of this limited, express warranty, and it may inhibit any servicing facility’s ability to provide
proper repairs and/or part replacement.
CARE AND MAINTENANCE
It is the Purchaser’s responsibility to perform proper care and maintenance of the RV, and to assure correct load distribu-
tion. For details regarding this, please see your Jayco owner’s manual and the owner’s manuals of other component part
manufacturers. These outline various care and maintenance that is required to maintain your RV. Please review all manu-
als supplied with your RV, and contact your selling dealership or supplier of the component part if you have questions.
Note: Failure to maintain the RV as noted in those manuals voids this limited, express warranty, and any damage to the RV
as a result of your failure to perform such care, is not covered by this limited, express warranty.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
THAT VARY FROM STATE TO STATE.
JAYCO, INC.
903 South Main * P.O. Box 460 * Middlebury, IN 46540
Telephone: [phone]
Towable Limited Warranty Page 3 of 3
6 Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer
Warranty/Service

WARRANTY REGISTRATION AND CUSTOMER DELIVERY
FORM
Dealer is to assure that this form is properly completed and returned to Jayco within ten (10) working days after delivery.
OWNER’S NAME DEALER’S NAME
ADDRESS ADDRESS
CITY STATE ZIP CODE CITY STATE ZIP CODE
DELIVERY DATE PHONE NUMBER (DAYTIME) ODOMETER READING (MUST BE COMPLETED FOR MOTORHOMES)
JAYCO SERIAL NUMBER CHASSIS VIN (VEHICLE I.D. NUMBER) (SEVENTEEN DIGITS REQUIRED)
DEALER INSTALLED OPTIONS (Dealer installed options are not covered under Jayco’s limited warranties.)
OWNER/DEALER INSPECTION
I HAVE COMPLETED THE ABOVE INSPECTION ON THIS FAMILY CAMPING VEHICLE AND HAVE TAKEN A TEST DRIVE AT THE TIME OF
PURCHASE. I NOTED:
I RECEIVED A COPY OF THE JAYCO LIMITED WARRANTY BEFORE I PURCHASED THIS VEHICLE AND I UNDERSTAND THAT IT IS
DESIGNED TO BE USED ONLY FOR RECREATIONAL CAMPING AND TRAVEL.
THE PURCHASER HAS INSPECTED OR BEEN GIVEN THE OPPORTUNITY TO INSPECT THE VEHICLE AND TAKE THE TEST DRIVE,
SUPPLIED THE INFORMATION ABOUT HIS/HER NAME AND ADDRESS, BEEN GIVEN THE OPPORTUNITY TO MAKE NOTATIONS IN
THE SPACE PROVIDED AND OBSERVED OR RECEIVED SATISFACTORY EXPLANATIONS ABOUT ALL ITEMS LISTED ABOVE.
DATE PURCHASER’S SIGNATURE DEALER’S SIGNATURE
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer 7
Warranty/Service
Jayco, Inc.
P.O. Box 460
903 South Main Street
Middlebury, IN 46540
[phone]
ALL ITEMS MUST BE MARKED OFF BY THE DEALER IN THE CUSTOMER’S PRESENCE INDICATING
PERFORMANCE OR INSTRUCTION AS REQUIRED.
1. ELECTRICAL SYSTEM
¾120-Volt System
¾120-Volt Auxiliary Generator Operation
¾12-Volt System
¾Ground Fault Circuit Interrupter (GFCI)
¾All Interior Lights/Recepts/Switches
¾All Exterior Lights/Recepts/Switches
¾Battery System
¾Monitor Panel
¾Slideout Operation and Maintenance
¾Phone and Cable TV
¾Audio/Video Entertainment System
¾Converter Operation and Use
¾Solar Panel
¾Interior Fans - All
a. Motorized Only
¾Inverter Operation and Use
¾Driver Dash Controls/Switches
¾Hydraulic Leveling Jacks
¾Power Cord/Reel
¾Backup Camera and Monitor
2. LP GAS SYSTEM
¾Location and Maintenance of LP Lines and
Connections
¾Maintenance and Operation of Regulator
¾LP Gas Monometer Test (Check for leaks -
repair if needed and retest) Set Gas
Pressure at ________in. Water Column
¾Outside Grill Use and Operation
3. WATER/PLUMBING SYSTEM
¾Water Intake/Drain Lines
¾Demand Pump
¾Faucet(s)/Fixture(s)
¾Winterizing/Bypass
¾Outside Shower
¾Shower
3. WATER/PLUMBING SYSTEM CONT.
¾Black Holding Tank(s)
¾Grey Holding Tank(s)
¾Fresh Water Holding Tanks(s)
¾Toilet
4. APPLIANCES
¾Furnace and Thermostat
¾Range/Oven/Hotplate
¾Water Heater
¾Refrigerator
¾Air Conditioner
¾Microwave
¾Central Vacuum
¾Heat Pump
¾Washer/Dryer
5. INTERIOR
¾Curtain/Drapes/Valances/Blinds
¾Beds/Couches/Tables
¾Fire Extinguisher (Check CHARGE ONLY)
¾Interior Trim and Sealants
¾Windows - Crank Mechanisms/Slides/etc.
6. EXTERIOR
¾Doors and Locks - all keys
¾Screen Door
¾Entrance Step
¾Finish - spot paint, touch up and rub out if
necessary
¾TV and/or Satellite Antenna Mechanism
¾Vents - all
¾Compartment Doors
¾Trim and Sealants
¾Awnings
¾Bumper/A-Frame - touch up as needed
¾Window and Roof Sealants
7. CHASSIS - MOTORIZED ONLY
¾Check all Fluid Levels
¾Chassis Prep as Recommended by the
Manufacturer
¾Tires - Condition and Pressure
¾Wheel Lugs - as outlined in Chassis manual
8. RUNNING GEAR - TOWABLE ONLY
¾Brake Adjustment and Maintenance
¾Bearing Lubrication and Maintenance
¾Brake Wire Connections
¾Hydraulic Brake Fluid and Maintenance
¾A-Frame/Coupler Operation
¾Operate and Lube Jacks
¾Tires - Condition and Pressure Set
Tire Pressure ________ psi
¾Wheel Lugs - (Tighten to specs for ft. lb.
torque) Review Maintenance - tighten at
10,25,50 miles
9. FOLDING CAMPING TRAILER ONLY
¾Complete Set Up and Closing
Demonstration, Proper Leveling
10. GENERAL
¾Wash Vehicle
¾Be certain that all required literature is in the
vehicle
¾Be certain that all accessories including
remotes are in the vehicle
¾Be certain that all Owner’s Manuals are in
the vehicle
¾Be certain that the Warranty Forms are
completed
1. Exterior and interior finish.
2. Operate all appliances, optional equipment and accessories and discuss
maintenance.
3. Review operation, maintenance and safety of LP Gas System.
4. Explain weight ratings, limitations and proper load distribution and
maintenance.
5. Operate all fresh water and plumbing components including faucets, shower,
toilet and drain locations.
6. Review tow vehicle, hitch and sway control set-up - test drive. (towables only)
7. Complete review of owner’s manuals and highlight safety issues.

LIMITED WARRANTY TRANSFER APPLICATION
The warranty on your unit is transferable one time only within the warranty period. This
form as shown here and on the next page must be completed and sent to Jayco, Attention:
After Market Services. If you have questions, consult with your independent, authorized
dealer for assistance.
8 Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer
Warranty/Service
Limited Warranty Transfer Application
Mail original copy of Jayco, Inc. Limited Warranty Transfer
Application, along with a transfer fee to $100.00 payable to:
Jayco, Inc.
Warranty Dept.
P.O. Box 460
Middlebury, IN 46540
REQUIRED
FIELD Vehicle Identification Number
A
B
C
D
NEW
OWNER
INFORMATION
PRIOR
OWNER
INFORMATION
SELLING
DEALER
INFORMATION
(IF APPLICABLE)
ALL TITLED
OWNER
SIGNATURES
Transfer Coverage To:
Transfer Coverage From:
PLEASE READ TERMS AND REPRESENTATIONS PRIOR TO SIGNING
THE BASIC2+3JAYCO, INC. LIMITED WARRANTIES MAY BE TRANSFERRED ONE (1) TIME DURING THE
WARRANTY PERIOD WITH THIS APPLICATION AND A $100.00 PROCESSING FEE.
Last Name
Dealer Name
New Owner’s Signature New Owner’s Signature
New Owner’s Signature Selling Dealer’s Signature
Last Name
First Name
First Name
Owner Address 1
Dealer Address 1
Owner Address 2
Dealer Address 2
City
City
State
State
Zip
Zip
Date of Transfer Odometer Reading at Transfer MUST BE COMPLETED ON ALL MOTORIZED VEHICLES
I HAVE READ AND AGREE TO THE TERMS AND CONDITIONS ON THE BACK OF THIS FORM.
Phone
Phone
____/____/________ __ __ __ __ __ __ __ __ __

TERMS AND REPRESENTATIONS
By my signature(s) on the face side of this form, and in order to induce Jayco, Inc. to transfer its
Limited Warranty, I represent the following:
1. That I have received and read a copy of the Jayco Limited Warranty and Owner’s Manual.
2. I understand that the unit is to be used only for recreational camping and travel.
3. That all information provided by me on the face side of this form is true and correct.
4. I understand that I am purchasing a pre-owned recreational vehicle and Jayco, Inc. does not
make any representation as to is present condition.
5. I understand and agree that all my claims against Jayco must be arbitrated and that a court
will enforce the arbitration award. The terms of arbitration are set forth below:
Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer 9
Warranty/Service

SERVICE PROCEDURES
Basic Service Procedures
We are interested in your satisfaction. Only by having your complete confidence and
satisfaction with our product and its service can we assure our continued success as
manufacturers of recreation vehicles. We have found that continuing a pleasant and
effective relationship through our independent, authorized dealers is equally as important
as maintaining the technical excellence of our product. Your independent, authorized
dealer will cordially assist you in providing service, maintenance, selection of options and
instructions concerning the operation of your vehicle.
If you have a problem with your trailer that requires service, please follow these
instructions in sequence.
Contact your selling independent, authorized dealer's service department for an
appointment. Describe to the best of your knowledge the nature of the problem.
Contact the owner or General Manager of the independent, authorized dealership if
the initial attempt fails with the service department.
If further assistance is needed, contact:
After Market Services
Jayco Incorporated
P.O. Box 460
Middlebury, IN 46540
Email: service @jayco.com
Business Hours: Monday - Friday 8:00 - 5:00 EST
Give all the above information as requested along with the serial number of the unit in
question and we will make every attempt to help you resolve your repair needs. It is
important that you contact your selling independent, authorized dealer before calling
Jayco. In most cases, the independent, authorized dealer can provide the service you
require.
If you are traveling and are unable to locate an independent, authorized Jayco dealer, or an
independent, authorized dealer for the component needing service, contact your selling
independent, authorized dealer for assistance.
.NOTE: Service at a non-authorized Jayco dealer should have prior authorization.
You will be asked to return any mechanical parts replaced before reimbursement
consideration is made. Unauthorized or improper repairs may void Jayco’s
warranty and the warranty on the component part.
Please keep your owner's manual, your copy of your warranty registration form and
any other related papers in your RV.
Please bear in mind that most problems arise from misunderstandings concerning warranty
coverage and service. In most instances, you will be referred to the dealer and your repair
needs will be resolved at the dealer's facilities.
10 Talon Sport Utility Trailer and Fifth-Wheel Sport Utility Trailer
Warranty/Service
