jbc GSF Series User manual
Allen Screws* ......................................... 2 units
Headless Screws* ................................ 3 units
Manual ....................................................... 1 unit
Ref. 0028099
Packing List
The following items are included:
Without Solder Wire Perforation:
GSF04D-B for wire Ø 0.4 mm / Ø 0.016 in
GSF05D-B for wire Ø 0.5 mm / Ø 0.020 in
GSF06D-B for wire Ø 0.6 mm / Ø 0.025 in
GSF08D-B for wire Ø 0.7 - 0.8 mm / Ø 0.028 - 0.032 in
GSF10D-B for wire Ø 0.9 - 1.0 mm / Ø 0.035 - 0.040 in
GSF12D-B for wire Ø 1.1 - 1.2 mm / Ø 0.043 - 0.047 in
GSF15D-B for wire Ø 1.3 - 1.5 mm / Ø 0.051 - 0.059 in
GSF16D-B for wire Ø 1.6 mm / Ø 0.063 in
This manual corresponds to the following references:
With Solder Wire Perforation:
GSF08V-B for wire Ø 0.8 mm / Ø 0.032 in
GSF10V-B for wire Ø 1.0 mm / Ø 0.040 in
GSF12V-B for wire Ø 1.2 mm / Ø 0.047 in
GSF15V-B for wire Ø 1.5 mm / Ø 0.059 in
GSF16V-B for wire Ø 1.6 mm / Ø 0.063 in
GSF Guide Kit for SF280 with Solder Wire Perforation
Intermediate Nozzle
Guide Tube* ............................................. 1 unit
Inlet Nozzle* ............................................. 1 unit
Guide Wheel* ........................................... 1 unit
Counter Wheel* ....................................... 1 unit
Blade Clamp* ........................................... 1 unit
Blade* ......................................................... 1 unit
Intermediate Nozzle* ............................. 1 unit
Outlet Nozzle* .......................................... 1 unit
*references see table on page 4
Guide Tube
Inlet Nozzle Guide Wheel
Outlet Nozzle
Blade Clamp
Blade
Counter Wheel
Headless Screws
Allen Screws
2
The following items are included:
Packing List
Guide Tube* ............................................. 1 unit
Inlet Nozzle* ............................................. 1 unit
Traction Wheel* ....................................... 1 unit
Support Wheel* ....................................... 1 unit
Counter Wheel* ....................................... 1 unit
Intermediate Nozzle* ............................. 1 unit
Outlet Nozzle* .......................................... 1 unit
*references see table on page 5
GSF Guide Kit for SF280 without Solder Wire Perforation
Intermediate Nozzle
Traction Wheel
Outlet Nozzle
Counter Wheel
Support Wheel
Headless Screws
Guide Tube
Inlet Nozzle
Allen Screws
Allen Screws*......................................... 2 units
Headless Screws*................................ 3 units
Manual ....................................................... 1 unit
Ref. 0028099
3
GSF Guide Kit for SF280
with Solder Wire Perforation
4
GSF Guide Kit for SF280
without Solder Wire Perforation
5
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 0 mm
Discon�nuous
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Speed
Con�nuous
Supplied: 12 mm
Speed
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
日本語
한국어
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 0 mm
Discon�nuous
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Speed
Con�nuous
Supplied: 12 mm
Speed
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
日本語
한국어
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
Con�nuous
Supplied: 12 mm
325
º
C
Con�nuous
Supplied: 12 mm
Changing Guide Kits
Assemble the counter wheel (1).
Insert the intermediate nozzle (2) until its collar
rests against the housing and tighten the screw.
Assemble the inlet nozzle (3).
Assemble the guide wheel (4) and tighten the
screw.
Assemble the blade first, then mount the
blade clamp (5) onto the same axis and tighten
the screw. Caution: handle the blade carefully
to avoid injury.
Insert the guide set (6).
Assembly with Solder Wire Perforation: Assembly without Solder Wire Perforation:
Changing Wheels and Blade
For this operation, disconnect the device from the mains. Disconnect the tool from the control unit
and open its cover.
First disassemble the guide tube (6), the nozzles (2)+(3), then the wheels, blade and clamp (4)+(5).
Disassemble the counter wheel (1). Use the allen key and the spanner, provided with the station.
Assemble the counter wheel (1).
Insert the intermediate nozzle (2) until its collar
rests against the housing and tighten the screw.
Assemble the inlet nozzle (3).
Assemble the traction wheel (4) onto the axis
and tighten the screw.
Assemble the support wheel (5) and tighten
the screw.
Insert the guide set (6).
Traction
Wheel Support
Wheel
Interm.
Nozzle
Inlet
Nozzle
Counter
Wheel 1
23
4
5
Inlet
Nozzle
Interm.
Nozzle
Blade
Blade
Clamp
Guide
Wheel
Guide
Set
Guide
Set
Counter
Wheel 1
2
3
4
5
66
Blade
Blade Clamp
Inlet
Nozzle
Guide
Wheel
Intermediate
Nozzle
Traction
Wheel
Support
Wheel
Intermediate
Nozzle
Inlet
Nozzle
Counter
Wheel
Counter
Wheel
1
4
1
2
3
4
5
5
4
2
3
6
6
Guide
Set
Guide
Set
6
Main MenuMain Menu
1 Reset settings
2
Station settings
3
Tool settings
4 Programs Settings
3
4
SF with no Guide Tube assembled
Replacing the Guide Tube
Once the tool is disconnected from the control unit follow the instructions below:
Disassemble the outlet nozzle (1) from the guide tube.
Open the guide clamp (2), take off the guide tube (3) and insert the new one.
Note: The guide tube length can be easily adjusted (4) when the guide clamp knob (2) is open.
Once the guide tube length is adjusted close the guide clamp knob (2).
Assemble the outlet nozzle (1) onto the guide tube tip.
Enter en “Tool Settings” at the SF control unit main menu and select the proper wire diameter.
Guide Clamp
Knob
Guide
Tube
Outlet
Nozzle
SF with Guide Tube assembled
1
Guide
Tube
2
7
Main MenuMain Menu
5 Tin Reload Process
6 Counters
7 Software Version
1 Reset settings
2
Station settings
3
Tool settings
4 Programs Settings
ExitExit
Ba
ckward Forward
Reload ProcessReload Process
Press enter when finished
OK
Tool Assembly
Connect the tool to the control unit following
this steps:
Insert and push the guide nozzle until the end
(1) and tighten the screw (2).
Connect the jack (3).
Solder Wire Loading
Put the solder reel into its support (1).
Introduce the solder wire into the inlet nozzle (2)
until it reaches the wheels (3).
Use the Tin Reload Process in the Main Menu (4).
The Relaod Procees screen opens.
Press to start the process.
Make sure the wire passes through the Interme-
diate Nozzle and enters into the Guide Tube (5).
1
3
Inlet
Nozzle
1
2
Insert to the end
4
Intermediate
Nozzle
To Guide Tube
2
3
5
8
Notes
9
Notes
10
GSF
Guide Kits for SF280
With Perforation:
Ref.: GSF08V-B wire Ø 0.8 mm / Ø 0.032 in
Ref.: GSF10V-B wire Ø 1.0 mm / Ø 0.040 in
Ref.: GSF12V-B wire Ø 1.2 mm / Ø 0.047 in
Ref.: GSF15V-B wire Ø 1.5 mm / Ø 0.059 in
Ref.: GSF16V-B wire Ø 1.6 mm / Ø 0.063 in
Without Perforation:
Ref.: GSF04D-B wire Ø 0.4 mm / Ø 0.016 in
Ref.: GSF05D-B wire Ø 0.5 mm / Ø 0.020 in
Ref.: GSF08D-B wire Ø 0.7 - 0.8 mm / Ø 0.028 - 0.032 in
Ref.: GSF10D-B wire Ø 0.9 - 1.0 mm / Ø 0.035 . 0.040 in
Ref.: GSF12D-B wire Ø 1.1 - 1.2 mm / Ø 0.043 - 0.047 in
Ref.: GSF15D-B wire Ø 1.3 - 1.5 mm / Ø 0.051 - 0.059 in
Ref.: GSF16D-B wire Ø 1.6 mm / Ø 0.063 in
- Guide Tube Length: 126 cm / 49.6 in
- Package Dimensions: 245 x 185 x 45 mm
(L x W x H) 9.65 x 7.28 x 1.77 in
Complies with CE standards.
ESD safe
Specifications
Total Net Weight: Package Weight:
108 g / 0.24 lb 200 g / 0.44 lb
108 g / 0.24 lb 200 g / 0.44 lb
94 g / 0.21 lb 186 g / 0.41 lb
94 g / 0.21 lb 186 g / 0.41 lb
94 g / 0.21 lb 186 g / 0.41 lb
104 g / 0.23 lb 196 g / 0.43 lb
104 g / 0.23 lb 196 g / 0.43 lb
104 g / 0.23 lb 196 g / 0.43 lb
104 g / 0.23 lb 196 g / 0.43 lb
90 g / 0.20 lb 182 g /0.40 lb
90 g / 0.20 lb 182 g /0.40 lb
90 g / 0.20 lb 182 g /0.40 lb
11
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
Get 1 extra year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
0028099-310522
