jbc TMS User manual

TMS / TMB
ESD Table Mat
INSTRUCTION MANUAL

Packing List
The following items are included:
ESD Table Mat .......................................... 1 unit*
* according to purchased reference
Manual ................................................. 1 unit
Ref. 0031825
This manual corresponds to the following references:
TMS-A (450 x 600 mm / 17.72 x 23.62in)
TMB-A (900 x 600 mm / 35.43 x 23.62in)
Application
To equip an EPA (Electrostatic Protected Area) workplace, it is necessary to place, among other items,
an ESD table mat on the workplace.
These components help to protect static-sensitive components from electrostatic discharge by
dissipating charge from objects placed on their surface. This prevents sensitive components from being
damaged by electrostatic discharges.
Features
The table mat is heat, solder, oil and chemical
resistant.
It comes with an anti-reflective grey surface, a
non-slipping bottom-side and rounded corners.
Each tabel mat is equipped with two ø10mm
press studs. One of them should be connected
to an earthing connection or a grounded
common point and the other one to the
wrist band of the person who works at this
workplace.
ø10mm Press Studs (2x)
2

* not included, sold separately
TMS or
TMB
ESD Table Mat
TM21
ESD Earthing Cable
TM20
ESD Spiral
Earthing Cable
TM50
ESD Earthing Wristband
ø10mm
Press Stud
Connection
ø3mm
Press Stud
Connection
Eyelet
Connection
ø10mm
Press Stud
Connection
Earth Connection or
Common Point
Ground System
TM10
ESD
Earting Plug
Alternative
Connection
JBC’s ESD table mat can be connected to other ESD components as shown in the picture below.
The following matching accessories are sold separately: An ESD spiral earthing cable, an ESD
earthing cable and an ESD earthing wristband and an ESD earting plug.
Work Place Connection Example
*
*
*
*
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
0031825-291123
TMS / TMB
ESD Table Mat
Ref.: TMS-A (450x600mm / 17.72 x 23.62in)
Ref.: TMB-A (900x600mm / 35.43 x 23.62in)
- Electrical resistance: 106- 108 Ω
- Resistant to: Abrasion, heat, solder, chemicals and oil
- Connections: ø10mm press stud (2x)
- Material: Permanently elastic
100% PVC-FREE and PHTHALATE-FREE
Two-layered: dissipative and conductive
RoHS compliant
- Surfaces: Top side: grey color, anti-reflective
Bottom side: black color, non-slipping
TMS TMB
- Total Net Weight: 0.76 kg / 1.68 lb 1.6 kg / 3.53 lb
- Package Dimensions/Weight: 620 x 136 x 135mm / 1.12 kg 620 x 136 x 135mm / 1.9 kg
(L x W x H) 24.41 x 5.35 x 5.31in / 2.47 lb 24.41 x 5.35 x 5.31in / 4.19 lb
Complies with CE standards.
ESD Safe.
Specifications
