jbc DPM-A User manual

INSTRUCTION MANUAL
www.jbctools.com
Solder Paste Hand Dispenser
Ref. DPM-A

2
Packing List
The following items are included:
Solder Paste Hand Dispenser .................................................................................... 1 unit
Ref. DPM-A

Solder Paste Hand Dispenser
Ref. DPM-A
INSTRUCTION MANUAL
www.jbctools.com
www.jbctools.com
3
Manual ............................................................................................................................... 1 unit
Ref. 0023415
3cc Syringe Barrel .......................................................................................................... 2 units
Ref. SB03CC

4
How to use
4. Replace the cap with the needle in
the plunger housing.
1. Fill in the plunger housing with
solder past.
2. Place the piston into the plunger
housing.
3. Insert the plunger rod in the plunger
housing.

www.jbctools.com
5
5. Lift the toggle
7. Lower the toggle
6. Insert the plunger with the syringe
in the housing, fit the syringe fins in
8. Operate the lever until the paste
comes out

6.5
32
STYLE Ref. COLOR GAUGE ØID
(mm) ØID (in) ØOD (mm) ØOD (in) LENGTH (mm)
LENGTH
(in)
TOTAL
LENGHT
(mm)
TOTAL
LENGHT
(in)
QTY
Stainless
Steel
Needles
ND18S6 Green 18 0.84 0.050 1.27 0.033 6.5 0.25 24 0.25 10
ND20S6 Pink 20 0.61 0.036 0.90 0.024 6.5 0.25 24 0.25 10
ND21S6 Purple 21 0.51 0.032 0.82 0.020 6.5 0.25 24 0.25 10
ND22S6 Blue 22 0.41 0.028 0.72 0.016 6.5 0.25 24 0.25 10
ND23S6 Orange 23 0.31 0.025 0.63 0.013 6.5 0.25 24 0.25 10
ND25S6 Plan Red 25 0.25 0.020 0.50 0.010 6.5 0.25 24 0.25 10
ND27S6 Clear 27 0.2 0.016 0.40 0.008 6.5 0.25 24 0.25 10
ND30S6 Lavender 30 0.15 0.012 0.31 0.006 6.5 0.25 24 0.25 10
ND32S6 Yellow 32 0 .1 0.009 0.24 0.004 6.5 0.25 24 0.25 10
ND34S6 Grass Green 34 0.06 0.008 0.20 0.002 6.5 0.25 24 0.25 10
STYLE Ref. COLOR GAUGE ØID
(mm) ØID (in) ØOD (mm) ØOD (in) LENGHT (mm)
LENGTH
(in)
TOTAL
LENGHT
(mm)
TOTAL
LENGHT
(in)
QTY
Tapered
Tips
ND18P Green 18 0.84 0.033 1.27 0.050 - - 32 1.26 10
ND20P Pink 20 0.64 0.024 1.20 0.048 - - 32 1.26 10
ND22P Blue 22 0.41 0.016 0.72 0.028 - - 32 1.26 10
ND25P Red 25 0.25 0.010 0.50 0.020 - - 32 1.26 10
ND27P Orange 27 0.2 0.008 0.40 0.016 - - 32 1.26 10
6
Nozzles Range
STAINLESS STEEL NEEDLES
TAPERED TIPS
More Info at www.jbctools.com

STYLE Ref. COLOR GAUGE ØID
(mm) ØID (in) ØOD (mm) ØOD (in) LENGTH (mm)
LENGTH
(in)
TOTAL
LENGHT
(mm)
TOTAL
LENGHT
(in)
QTY
Stainless
Steel
Needles
ND18S6 Green 18 0.84 0.050 1.27 0.033 6.5 0.25 24 0.25 10
ND20S6 Pink 20 0.61 0.036 0.90 0.024 6.5 0.25 24 0.25 10
ND21S6 Purple 21 0.51 0.032 0.82 0.020 6.5 0.25 24 0.25 10
ND22S6 Blue 22 0.41 0.028 0.72 0.016 6.5 0.25 24 0.25 10
ND23S6 Orange 23 0.31 0.025 0.63 0.013 6.5 0.25 24 0.25 10
ND25S6 Plan Red 25 0.25 0.020 0.50 0.010 6.5 0.25 24 0.25 10
ND27S6 Clear 27 0.2 0.016 0.40 0.008 6.5 0.25 24 0.25 10
ND30S6 Lavender 30 0.15 0.012 0.31 0.006 6.5 0.25 24 0.25 10
ND32S6 Yellow 32 0 .1 0.009 0.24 0.004 6.5 0.25 24 0.25 10
ND34S6 Grass Green 34 0.06 0.008 0.20 0.002 6.5 0.25 24 0.25 10
STYLE Ref. COLOR GAUGE ØID
(mm) ØID (in) ØOD (mm) ØOD (in) LENGHT (mm)
LENGTH
(in)
TOTAL
LENGHT
(mm)
TOTAL
LENGHT
(in)
QTY
Tapered
Tips
ND18P Green 18 0.84 0.033 1.27 0.050 - - 32 1.26 10
ND20P Pink 20 0.64 0.024 1.20 0.048 - - 32 1.26 10
ND22P Blue 22 0.41 0.016 0.72 0.028 - - 32 1.26 10
ND25P Red 25 0.25 0.010 0.50 0.020 - - 32 1.26 10
ND27P Orange 27 0.2 0.008 0.40 0.016 - - 32 1.26 10
www.jbctools.com
7

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
Get 1 extra year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
www.jbctools.com
Specifications
0023415-0719
- Dimensions: 130x66x16mm / 0.05kg
5.12 x 2.6 0 x 0 .63in / 0.11lb
- Package Dimensions: 155x55x45mm / 0.007kg
6 .10 x 2.17 x1.7 7i n / 0.16 l b
Complies with CE standards
ESD Safe
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
