JBL Synthesis S7150 User manual

SYNTHESIS
S7150
POWER
AMPLIFIER
USER’S
MANUAL
JBL Synthesis
8500 Balboa Boulevard
Northridge, CA 91329
250 Crossways Park Drive
Woodbury, NY 11797
800-336-4JBL
A Harman International Company
Part No. S7150-OM6/00
Printed in USA on recycled paper

TABLE
OF
CONTENTS
SECTION ______________________________________________________PAGE
1.0 Precautions _______________________________________________________4
1.1 Important Safeguards for Audio Products ______________________________4-7
2.0 Introduction and Features of the S7150 ________________________________8-9
3.0 Operation and Controls______________________________________________10
3.1 S7150 ________________________________________________________10-12
4.0 Connecting Your Synthesis System ____________________________________13
4.1 JBL Synthesis Two & Three – Suggested Rack Mounting Order ______________14
4.2 JBL Synthesis Two & Three – Control Wiring Diagram _____________________15
4.3 JBL Synthesis Two & Three – Interconnection Diagram ____________________16
5.0 Installing the S7150 ________________________________________________17
6.0 Troubleshooting ___________________________________________________18
7.0 Specifications _____________________________________________________19
8.0 Synthesis Limited Warranty __________________________________________20
JBL Synthesis S7150 Power Amplifier
User's Manual
©2000 JBL
JBL and Synthesis are registered trademarks of JBL Incorporated.
All Rights Reserved
JBL Synthesis
8500 Balboa Boulevard, Northridge, CA 91329
250 Crossways Park Drive, Woodbury, NY 11797
800-336-4JBL
Printed on Recycled Paper
Part Number: S7150OM6/00
A Harman International Company
3

1.1 Important Safeguards
For Audio Products
PLEASE READ CAREFULLY ALL THE
FOLLOWING IMPORTANT SAFEGUARDS
THAT ARE APPLICABLE TO YOUR EQUIPMENT
1. Read instructions – All the safety and operating
instructions should be read before the product is
operated.
2. Retain instructions – The safety and operating
instructions should be retained for future reference.
3. Heed Warnings – All warnings on the product
and in the operating instructions should be
adhered to.
4. Follow Instructions – All operating and use
instructions should be followed.
5. Water and Moisture – The product should not
be used near water – for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, and the like.
6. Carts and Stands – The product should be used
only if a cart or stand is recommended by the
manufacturer.
6a. A product and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination
to overturn.
7. Wall or Ceiling Mounting – The product should
be mounted on a wall or ceiling only when and as
recommended by the manufacturer.
8. Ventilation – The product should be situated so
that its location or position does not interfere with
its proper ventilation. For example, the product
should not be situated on a bed, sofa, rug, or
similar surface that may block the ventilation
openings; or, placed in a built-in installation,
such as a bookcase or cabinet that may impede
the flow of air through the ventilation openings.
9. Heat – The product should be situated away from
heat sources such as radiators, heat registers, stoves,
or other products that produce heat. If placed near
an amplifier, check with the manufac-turer for
applicability.
10. Power Sources – The product should be connected
to a power supply only of the type described in the
operating instructions or as marked on the product.
11. Grounding or Polarization – Precautions should
be taken so that the grounding or polarization means
of a product is not defeated.
12. Power-Cord Protection – Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where
they exit from the product.
13. Cleaning – The product should be cleaned only as
recommended by the manufacturer.
14. Power Lines – An outdoor antenna should be
located away from power lines.
15. Nonuse Periods – The power cord of the product
should be unplugged from the outlet when left
unused for a long period of time.
16. Object and Liquid Entry – Care should be taken
so that the objects do not fall and liquids are not
spilled into the enclosure through the openings.
The lighting flash with arrowhead
symbol, within an equilateral trian-
gle, is intended to alert the user to
the presence of uninsulated ”dan-
gerous voltage” within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and mainte-
nance (servicing) instructions in
the literature accompanying the unit..
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT
TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS (POLAR-
IZED) PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUT-
LET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT
BLADE EXPOSURE.
ATTENTION: POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS
UTILISER AVEC UN PROLONGATEUR. UNE PRISE DE COURANT OUUNE
AUTRE SORTIE DE COURANT SAUF SI LES LAMES PEUVENT ETRE
INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.
4
1.0
PRECAUTIONS 1.0
PRECAUTIONS

1.0
5
PRECAUTIONS
17. Outdoor Antenna Grounding – If an outside
antenna is connected to the receiver, be sure
the antenna system is grounded so as to
provide some protection against voltage
surges and built-up static charges. Article
810 of the National Electrical Code,
ANSI/NFPA 70, provides information with
regard to proper grounding of the mast
and supporting structure, grounding of the
lead-in wire to an antenna-discharge unit,
size of grounding conductors, location of
antenna-discharge unit, connection to
grounding electrodes, and requirements for
the grounding electrode (See Figure 1).
18. Damage Requiring Service – The product
should be serviced by qualified service
personnel when:
a. The power supply or the plug has been
damaged; or
b. Objects have fallen on, or liquid has
been spilled into, the product; or
c. The product has been exposed to rain; or
d. The product does not appear to operate
normally or exhibits a marked change
in performance; or
e. The product has been dropped, or
the enclosure damaged.
19. Servicing – The user should not attempt to
service the product beyond that described
in the operating instructions. All other
servicing should be referred to qualified
service personnel.
Note to CATV system installer:
This reminder is provided to call the CATV
system installer’s attention to Article 820-22
of the NEC that provides guidelines for proper
grounding and, in particular, specifies that
the cable ground shall be connected to the
grounding system of the building, as close
to the point of cable entry as practical.
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
Figure-1
Example of Antenna Grounding
as per National Electrical Code

Français
Instructions de Sûreté Importantes
Gardex ces instructions pour réference future.
Observez toutes les instructions et tous les avertissements marqués sur l’appareil.
Branchez uniguements sur un réseau de tension indiquée. Consultez le manuel
d’instruction du fabriquant pour les spécifications de courant. N’oubliez pas que
différentes tensions peuvent nécessiter l’utilisation de cables et/ou de fiches
deconnexion différents.
N’installez pas l’appareil en un compartiment non-aéré ou directement au-dessus
d’équipements générateurs de chaleur, tels qu’amplificateurs de courants, etc. Ne
dépassez pas la température ambiante maximale de fonctionnement indiquée
dans les spécifications du produit.
Des fentes et ouvertures sont prévues dans le boîtier pour l’aération; Pour assur-
er le bon fonctionnement et pour prévenir l’échauffement, ces ouvertures ne
doivent pas être couvertes ou bloquées. N’insérez pas d’objets dans les fentes
d’aération. Empêchez tout liquide de se répandre sur l’appareil.
Ce produit est muni d’une fiche à trois fils pour la mise à terreee. Ceci est une
mesure de sécurité et ne doit pas être contrariée.
Ne connectez jamais d’amplificateurs audio directement aux connecteurs de l’appareil.
Pour empêcher les chocs électriques et le danger d’incendie, évitez d’exposer
l’appareil à la pluie ou à l’humidté, et ne le mettez pas en marche en un endroit
où il serait exposé aux éclaboussures d’eau.
N’essayez pas de faire fonctionner l’appareil s’il est tombé à terre, a été endom-
mangé, exposé à un liquide, ou si vous observez des différences nettes dans son
fonctionnement, indiquant la nécessité de réparations.
Cet appareil ne doit être ouvert que par un personnel de service qualifié. En enl-
evant les couvercles vous vous exposez àdes tensions électriques dangereuses.
Ce triangle, sur votre appaeil vous avertit de la présence de ten-
sion dangereuse, non-isolée à l’intérieur du boîtier…une tension
suffisante pour représenter un danger d’electrocution.
Ce triangle sur sur votre appareil vous invite de suivre d’impor-
tantes instructions d’utillisation et d’entretien dans la documen-
tation livrée avec le produit.
Español
Instrucciones importantes de sequirdad
Guarde esta instrucciones para uso posterior.
Utilice siempre el voltaje correcto. Diríjase a las instrucciones de operación del
fabricante para obtener las especificaciones de potencia. Esté al tanto de que
voltajes de operación distintos requieren el uso de cable y/o enchufes distintos.
No instale esta unidad en un estante sin vntilación, ni tampoco directamente
encima de equipose que generen calor tales como amplificadores de potencia.
Fíjese en las temperaturas ambientales máximas de operación que se mencionan
en las especificaciones del producto.
Las aperturas y ranuras del chasis sirven para proveer la ventilación necesaria para
operar la unidad con sequridad y para prevenir sobrecalentamiento, y por lo tanto
no pueden ser obstruidas o cubiertas. No introcuzca objetos de ningún tip a través
de las ranuras de ventilación, y nunca deje caer ningún líquido sobre la unidad.
Este producto está equipado con un enchufe de 3 clavijas con conexión a ierra.
Este es un elemento de seguridad que no debe ser eliminado.
Nunca conecte ningùn tipo de salida de amplificadores de sonido directamente a
los conectores de la unidad.
Para prevenir descargas eléctricas o incendios, mantenga la unidad alejada de la
lluvia, humedad o cualquier lugar en el que pueda entrar en contacto con ague.
No trate de hacer funcionar la unidad si se ha caído, está dañada, ha entrado en
contacto con lítuidos, o si nota cualquir cambio brusco en su funcionamiento
que indique la necesidad de hacerle un servicio de mantenimiento.
Esta unidad deberá ser abierta únicamente por personal calificado. Si usted quita
las coberturas se expondrá a voltajes peligrosos.
Este triángulo que apaece en su componente le advierte sobre la
existencia dentro del chasis de voltajes peligrosos sin ais-
lantes…voltajes que son lo suficientemente grandes como para
causar electrocución.
Este triángulo que aparece en su componente lo alerta sobre las
instrucciones de operación y mantenimiento importantes que
están en los materiales de lectura que se incluyen.
Italiano
Importanti norme di sicurezza
Conservare le presenti norme per l’utilizzo futuro.
Osservare tutte le istruzioni e le avvertenze apposte sull’unita.
Utilizzare esclusivamente con la tensione di rete corretta. Consultare le istruzioni
operative fornite dal fabbricante per i dati riguardanti la tensione e l’assorbimento
di corrente. Potrebbe essere necessario l’uso di cavi di rete e/o di spine diverse a
seconda della tensione utilizzata.
Non installare l’unità in uno scaffale privo di ventilazione oppure direttamente sopra
una fonte di calore, come, ad esempio, un amplificatore. Non superare la temper-
atura ambientale massima di funzionamento riportata nei dati tecnici del prodotto.
Le fessure e le altre aperture nella scatola servono alla ventilazione. Per un fun-
zionamento affidabile, e per evitare un eventuale surriscaldamento, queste aper-
ture non vanno ostruite o coperte in nessun modo. Evitare in tutti i casi di inserire
oggetti di qualsiasi genere attraverso le fessure di ventilazione. Non versare mai
del liquido di nessun tipo sull’unità.
QUesto pordotto viene fornito con una spina a 3 fili con massa. Tale dispositivo
di sicurezza non va leiminato.
Evitare sempre di collegare le uscite dell’amplificatore auio direttamente ai con-
nettori dell’unità.
Per prevenire il pericolo di folgorazione e di incendio non esporre l’unità alla
pioggia o ad un’umidtà eccessiva; evitare di adoperare l’unità dove potrebbe
entrare in contatto con acqua.
Evitare di adoperare l’unità se la stessa è stata urtata violentemente, se ha subito
un danno, se è stata esposta ad un liquido o in caso di un evidente cambiamento
dell prestazioni che indichi la necessità di un intervento di assistenza tecnica.
Ogni intervnto sull’unità va esqguito esclusivamente da personale qualificato. La
rimozione della copertura comporta l’esposizione al pericolo di folgorazione.
ll present triangolo impresso sul componente avverte della pre-
senza di tensioni pericolose non isolate all’interno della copertu-
ra…tali tensioni rappresentano un pericolo di folgorazione
ll presente triangolo imprsso sul componente avverte l’utente
della presenza nella documentazione allegata di importanti
istruzioni relative al funzionament ed alla manutenzione.
Deutsch
Wichtige Sicherheitsanweisungen
Heben Sie sich diese Sicherheitsanweisungen auch für später auf.
Befolgen Sie alle auf der Vorrichtung stehenden Anweisungen und Warnungen.
Immer nur mit der richtigen Spannung verwenden! Die Gebrauchsanweisungen
des Herstellers informieren Sie über die elektrischen Anforderungen. Vergessen
Sie nicht daß bei vershiedenen Betrievsspannungen ggf. auch verschiedene
Leitungskabel und/oder Verbindungsstacker zu verwenden sind.
Stellen Sie die Vorrightung nicht in ein unbelüftetes Getell oder unmittelbar über
wärmeerzeugende Geräte wie z.B. Tonverstärker. Halten Sie die in den Produkt-
spezifikationen angegebene maximale Umgebungstemperatur bei Betrieb ein.
Schlitze und Öffnungen im GehUause dienen der Belüfung; um verläßlichen
Betrieb sicherzustellen und Überheizen zu vermeiden dürfen diese Öffnungen
nich verstopft oder abgedeckt werden. Stecken Sie nie irgend einen Gegenstand
durch die Belüftungsschlitze. Vergießen Sie keine Flüssigkeiten auf den Apparat.
Dieses Produkt is mit einem 3-drahtigen Erdungsstecher ausgerüstet. Diese
Sicherheitsmaßnahme darf nicht unwirksam gemacht werden.
Schließen Sie nie Tonverstärker unmittelbar an einen Anschluß des Apparates an.
Um elektrischen Schlag oder Feuer zu vermeiden, setaen Sie den Apparat weder Regen
noch Feuchtigkeit aus und betreiben Sie ihn nicht dort wo Wasser eindringen könnte.
Versuchen Sie nicht den Apparat zu betreiben falls er fallen gelassen, beschädigt,
oder Flüssigkeiten ausgesetzt wurde, oder falls sich seine Arbeitsweise derart
ändert daß daraus ein Bedarf nach Raparatur zu schließen ist.
Dieser Apparat sollte nur von qualifizierten Fachleuten geöffnet
werden. Das Abnehmen von Abdeckungen setzt Sie
gefährlichen Spannungen aus.
Dieses Dreick auf ihrem Apparat warnt Sie voe nicht-isolierter,
gefährlicher Spannung im Gehäuse…stark genug um eine
Berührungsgefahr darzustellen.
Diese Dreick auf ihram Apparat bedeutet daß wichtige Betriebsund
Wartungsanweisungen in der mitgelieferten Dokumentation zu
finden sind.
6

7
Dansk
Vigtig information om sikkerhed
Gem denne vejledning til senere brug.
Følg all anvisninger og advaresler på apparatet.
Apparatet skal altid tilslttes den korrekte spænding. Der henvises til brugsanvis-
ningen, der indeholder specifikationer for strømforsyning. Der gøres opmærk-
som på, at ved varierende driftsspændinger kan det blive nødvendigt at bruge
andre lednings- og/eller stiktyper.
Apparated må ikke monteres i et kabinet uden ventilation eller lige over andet
udstyr, der udvikler varme, f.eks. forstærkere. Den maksimale omgivelsestemper-
atur ved drift, der står opført i specifikationerne, skal overholdes.
Der er ventilationsåbninger i kainettet. For at sikre apparatets drift og hindre
overophidning må disse åbninger ikke blokeres elle tildækkes. Stik aldrig noget
ind igennem ventilationsåbningerne, og pas på aldrig at spilde nogen form for
væske på apparatet.
Dette apparat er forsynet med et stik med jordforbindelse. Denne sikkerheds-
foranstaltning må aldrig omgås.
Udgangsstik fra audioforstærkere må aldrig sættes direkte i apparartet.
Apparatet må ikke udsættes for regn eller fugt og må ikke bruges i nærheden af
vand for at undgå risiko for elektrisk stød og brand.
Apparatet må aldrig bruges, hvis det er blevet stødt, beskadiget eller vadt, eller
hvis ændringer i ydelsen typer på, at det trænger til eftersyn.
Fette apparat må kun åbnes af fagfolk, Hvis dækslet tages af, udsættes man for
livsfarlig højspænding.
Denne mærkat på komponenten advarer om uisoleret, farlig
spænding i apparatet… høj nok til at give elektrisk stød.
Denne mærkat på komponenten advarer om vigtig driftsog
vedligeholdsinformation i den tilhørende litteratur.
Suomi
Tärkeitä varten
Säilytä nämä ohjeet tulevaa käyttoöä varten.
Seuraa kaikkia yksikköön merkittyjä ohjeita ja varoituksia.
Käytä aina oikeaa verkkojännitettä. Tehovaatimukset selviävät valmista-
jan käyttöohjjeista. Huomaa, että eri käyttöjännitteet saattavat vaatia
toisenlaisen verkkojohdon ja/tai- pistokkeen käytön.
Älä asenna yksikköä telineeseen jossa ei ole tuulet usta, tai välittömästi
lämpöä tuottavien laitteiden, esim. tehovahvistimien, yläpuolelle.
Ympäristön Iämpötila käytössä ei saa ylittää twotespesifikaation mak-
similämpötilaa.
Kotelo on varustettu tuuletusreiillä ja -aukiooa. Luotettavan toiminnan
varmistamisksi ja ylilämiseksi näitä aukkoja ei saa sulkea tai peittää.
Mitään esineitä ei saa työntää tuuletusaukkoihin. Mitään nestritä ei saa
kaataa yksikköön.
Tuote on varustettu 3-jjohtimisella maadoitetulla verkkipistokkeella.
Tämä on turvallisuustoiminne eikä sitä saa poistaa.
Älä kytke audiotehovahvistimen lähtöjä suoraan mihinkään yksikön liit-
timeen.
Sähköiskun ja palovaaran välttämiseksi yksikkö ei saa olla sateessa tai
kosteassa, eikä sitä saa käyttää märässä ympäristössa.
Älä käytä yksikköä jos se on pudonnut, vaurioitunut, kostunut, tai jos
sen suorituskkyky on huomattavasti muuttunut, maikä vaatii huoltoa.
Yksikön saa avata vain laitteeseen perehtynyt huoltohenkilö. Kansien
poisto altistaa sinut vaarallisille jännittelille.
Tämä kolmio, joka esiintyy homponentissasi, varoittaa
siua eristämättömän vaarallisen jännitteen esiintymisestä
yksikön sisällä. Tämä jännite saattaa olla riittävä korkea
aiheuttamaan sähköiskuvaaran.
Tämä koimio, joka esiintyy komponentissasi, kertoo sin-
ulle, että tässä tuotedokumentoinnissa esiintyy tärkeitä
käyttö-ja ylläpite-ohjeita.
Norsk
Viktig informasjon om sikkerhet
Ta vare pådenne veiledningen for senere bruk.
Følg alle anvisningene og advarslene som er angitt på apparatet.
Apparatet skal alltid anvendes med korrekt spenning.
Produktbeskrivelsen inneholder spesifikasjoner for strømkraav. Vær oppmerksom
på at det ved ulike driftsspenninger kan være nødvendig å bruke en annen led-
ningog/eller støpseltype.
Apparatet skai ikke monteres i skap uten ventilasjon, eller direkte over varmepro-
duserende utstyr, som for eksempel kraftforsterkere. Den maksimale romtempera-
turen som står oppgitt i produktbeskrivelsen, skal overholdes.
Apparatet er utstyrt med ventilasjonsåpninger. For at apparatet skal være pålitelig
i bruk og ikke overopphetes, må disse åpningene ikke blikkeres eller tildekkes.
Stikk aldri noe inn i ventilasjonsåpningene, og pass på at det aldri søles noen
form for væske på apparatet.
Dette apparatet er utstyrt med et jordet støpsel. Dette er en sikkerhetsforanstalt-
ning som ikke må forandres.
Utgangsplugger fra audioforsterkere skai aldri koples direkte til apparatet.
Unngå brannfare og elektrisk støt ved å sørge for at apparatet ikke utsettes for
regn eller fuktighet og ikke anvendes i næheten an vann.
Apparatet skal ikke brukes hvis det har blitt utsatt for støt, er skadet eller blitt vått,
eller hvis endringer i ytelsen tyder på at det trenger service.
Dette apparatet skal kun åpnes av fagfolk. Hvis dekselet fjernes, utsettes man for
livsfarlig høyspenning.
Komponenten er merket med denne trekanten, som er en
advarsel om at det finnes uisolert, farlig spenning inne i kabi-
nettet…høy nok til å utgjøre en fare for elektrisk støt.
Komponenten er merket med denne trkanten, som betyr at den
tilhørende litteraturen inneholder viktige opplysninger om drift
og vedikehold.
Svenska
Viktiga säkerhetsföreskrifter
Spara dess föreskrifter för framtida bruk.
Följ alla anvisningar och varningar som anges på engeten.
Använd alltid rätt nätspänning. Se tillverkarens bruksanvisningar för informa-
tion om effektkrav. Märkväl, att andra matningsspänningar eventuellt kräver att
en annan typs nätsladd och/eller kontakt anänds.
Installera inte enheten i ett oventilerat stativ, eller direkt ovanför utrustningar
som avger värme, t ex effektförstärkare. Se till att omgivningens temperatur
vid drift inte överskrider det angivna värdet i produktspecifikationen.
Behållaren är försedd med hål och öppningar för ventilering. För att garantera
tillförlitlig funktion och förhindra överhettning får dessa oppningar inte block-
eras eller täckas. Inga föremål får skuffas in genom ventilationshålen. Inga
vätskor får spillas på enheten.
Produkten är försedd med en jordad 3-trådskontakt. Detta ä en säkerhetsfunk-
tion som inte får tas ur bruk.
Anslut aldrig audioeffektförstärkarutgångar direkt till någon av enhetens
kontakter.
För att undvika elstöt eller brandfara får eenheten inte utsättas för reegn eller
fukt, eller användas på ställen där den blir våt.
Använd inte enheten om den far fallit i golbet, skadats, blivit våt, eller om dess
prestanda förändrats märkbart, vilket kräver service.
Enheten får öppnas endast av behörig servicepersonal. Farliga spänningar blir
tillgängliga när locken tas bort.
Denna triangel, som visas på din komponent, varnar dig om
en oisolerad farlig spänning inne i engeten. Denna spänning
är eventuellt så hög att fara för elstöt föreligger.
Denna triangel, som visas på din komponent, anger att viktiga
bruksanvisningar och servideanvisningar ingår i dokumenta-
tionen i fråga.

Introduction
Congratulations on your purchase of this JBL
Synthesis S7150 power amplifier! You have purchased
a product that embodies the best of what JBL has
learned about the emotional power of audio
reproduction in over fifty years of preeminence in the
field. This amplifier has been designed and crafted to
provide the user with a high level of sonic perform-
ance; special attention has been paid to minimize the
number of components in the audio signal path,
resulting in extremely low distortion, excellent transient
response, and wide dynamic range. Synthesis products
set new benchmarks in audio technology, and, when
used as part of a complete JBL Synthesis System, will
bring the ambience and acoustics of some of the world’s
greatest concert halls and theaters into your home.
To obtain the best performance from this amplifier, please
be sure to completely read this user’s manual and use
the S7150 only in accordance with its instructions.
Features
The JBL Synthesis S7150 power amplifier features the
following:
THX ®Ultra Specifications
This amplifier meets or exceeds the stringent specifications set
by the Lucasfilm THX Audio division in their specifications for
"Ultra"-class certification, including power handling, total
harmonic distortion, frequency response, signal to noise ratio,
slew rate, and crosstalk. When incorporated into a complete
THX system, you will hear in your home what the director and
sound engineer heard in the recording studio.
Full Seven Channel Operation
The S7150 has been designed to integrate well into
the world of multi-channel audio. It is one of the first
amplifiers designed to reproduce the latest development
in home theater audio; rear channels, in addition to
side channels, to produce a truly enveloping sound
field. When coupled with a high quality subwoofer
amplifier, such as the Synthesis S800, it is a solid
foundation on which to build a high-performance
home cinema system that will astound the listener
with its power and realism.
High Power Capability
The S7150 provides a satisfying 160 watts per channel
of distortion-free audio (<0.03% THD) into eight ohms.
Because of their power capabilities, all Synthesis
amplifiers have an extremely wide dynamic range, an
element critical to realistic home cinema. Sound levels
equal to those at original performances are easily recreated
in even the largest of home listening environments.
Auto Turn-On and Power Sequencing Circuitry
When used in a JBL Synthesis System, the S7150 can
be turned on automatically whenever the surround
processor is activated. No longer do you have to get
out of that chair to turn on the various pieces of
equipment in your entertainment system; just one
touch on the remote control of the surround processor,
and you’re a few seconds away from a truly impressive
audio presentation!
Modern amplifiers produce more power per channel
(and frequently have more channels) than those of the
traditional two-channel stereo era. Due to the high
current demands of power amplifiers at the instant of
turn-on, the S7150, S650A, and S800 amplifiers and
the SDEC digital equalizer are equipped with power
sequencing circuits which turn on each unit in
sequence, avoiding the large instantaneous current
demand (and possible house circuit breaker tripping)
that would occur should they all turn on at the
same instant.
8
2.0
INTRODUCTION
AND FEATURES
2.0
INTRODUCTION
AND FEATURES

Quiet Cooling
The S7150 utilizes a fan to cool the amplifier channels,
ensuring long-term reliability. To reduce fan noise to an
absolute minimum, a thermal sensing and control
circuit has been incorporated in the Synthesis S7150
that senses increases in temperature within the
amplifier and powers a fan at a speed proportional to
that temperature increase. When the S7150 is
"loafing", the fan turns very slowly – and quietly. At
high listening levels (and the higher operating
temperatures this creates within any amplifier), the
sensing circuitry causes the fan to turn faster,
producing increased cooling. As a result, the fan is
never turning faster than necessary, and most of the
noise that is generated is masked by the program
being listened to.
Comprehensive and Isolated Circuit Protection
The S7150 amplifier employs a sophisticated protective
circuit (one for each channel) that senses many possible
fault conditions, such as shorted loudspeaker wires or
excess power demand, and turns the affected
channel(s) and their blue front panel indicators off
until the fault condition is removed, at which time
normal operation is automatically restored. While
protection of this sort is not uncommon in today’s
well-designed amplifiers, a remarkable feature of the
Synthesis S7150’s protective circuits is that they are
optically-coupled to the signal circuit; there is no direct
electrical connection between the signal path and the
protective circuitry.
As a result, there can be no coloration of the
music, no interaction between protection and
amplification, until certain thresholds are
exceeded, at which point the channel(s) turn
off completely.
9
2.0
INTRODUCTION
AND FEATURES
2.0
INTRODUCTION
AND FEATURES

10
3.0
OPERATION AND
CONTROLS 3.0
OPERATION AND
CONTROLS
3.1 S7150
1. Power Switch
Pushing this button is all that is required to turn on the
S7150 if it is not part of a Synthesis system and the
Manual On/Auto On switch (rear panel) is in the
Manual On position. If the amplifier is used as part of
a JBL Synthesis System, and the Manual On/Auto
On switch is in the Auto On position, the amplifier
will turn on when the surround processor is activated.
The front panel pushbutton power switch is left in the
ON (in) position.
2. Standby Indicator (red)
This indicator, immediately above the front panel power
switch, will glow red when the amplifier is in the
"standby" mode, whether operating as part of a
Synthesis system or not. When the S7150 is in the
"operate" mode, this light will shut off and the blue
"operate" mode indicators will light..
3. Power Indicators (blue)
These indicators will light up when the power amplifier
is in the "operate" mode. Each monitors the operation
of one channel, and will extinguish if that channel’s
protective circuit is activated.
4. Input Jacks (Ch.1 thru Ch.7) (see page 11)
Seven of the output signals from the Synthesis digital
processor and equalizer are connected to the seven input
jacks. We suggest the channels be assigned as follows:
5. Speaker Terminals (see page 11)
Connect the speakers to these terminals, following the
normal convention; wire the "+" side of the speaker to
the red terminal, and the "-" side to the black terminal.
Wire the speakers with the proper polarity; reversing
any speaker’s connections will not damage either the
speaker or the amplifier, but will result in poor low
frequency performance and imprecise imaging.
NOTE: The minimum load impedance that this amplifier
can handle safely is two ohms per channel. Using lower
impedance loads can damage the unit and will void
your warranty!
Wire Run Length Rec. Ga.
Up to 20' 16
Up to 50' 14
Up to 100' 12
Wire Run Length Minimum Gage
Ch. 1 Right Rear (Processor) Ch. 5 Left Front (Equalizer)
Ch. 2 Right Side (Equalizer) Ch. 6 Left Side (Equalizer)
Ch. 3 Right Front (Equalizer) Ch. 7 Left Rear (Processor)
Ch. 4 Center (Equalizer)

S7150
WARNING:
serial number
ATTENTION:
VOIR LE CAHIER D'
INSTRUCTION
15A
120V
50/60Hz
1800W
Ch. 1 Output Ch. 2 Output Ch. 3 Output Ch. 4 Output Ch. 5 Output Ch. 6 Output Ch. 7 Output
ON
OFF
MANUAL
ON
AUTO
ON
IN
OUT
SPKR-1 SPKR-2
Ch. 1
Input
Ch. 2
Input
Ch. 3
Input
Ch. 4
Input
Ch. 5
Input
Ch. 6
Input
Ch. 7
Input
AVIS: RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
~


DESIGNED, ENGINEERED AND MANUFACTURED
IN THE UNITED STATES OF AMERICA
S7150 POWER AMPLIFIER JBL SYNTHESIS
NORTHRIDGE, CA TRIGGERS
+
-+
-+
-+ -
+
-
+
-
+
-
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture
HAZARDOUS ENERGY, MAKE PROPER SPEAKER CONNECTIONS; SEE OWNERS MANUAL BEFORE USING.
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED PERSONNEL
11
6. Circuit Breaker/Main Power Switch
The main power switch, located on the rear panel of the
S7150, is also a circuit breaker. Putting this switch in
the ON position allows the amplifier to enter the
"standby" and "operate" modes as controlled by the
front panel POWER switch and Manual On/Auto On
switches. Should the amplifier be asked to produce
more power than its design allows for a prolonged
period, or should the S7150 draw an amount of current
from the AC power source that could damage internal
components, the handle of this switch will move to a
center position. Reduce the audio level and wait a
minute for the circuit breaker to reset, then move it to
the OFF, then the ON position. If the handle returns to
the center ("tripped") position, service is required;
contact your JBL Synthesis dealer.
The S7150 was designed to operate reliably under
virtually all conditions. Even momentary short
circuiting of the output (speaker) connections will not
ordinarily damage the output circuitry (although this
will activate internal protective circuitry and cause one
or more of the front-panel blue LED indicators to
extinguish until the circuit resets.)
There are no user-serviceable parts in the S7150; there
are no fuses accessible from outside the unit.
Internal fuses have been incorporated in the S7150 to
protect it from short circuits and other faults, but these
should only be replaced by a qualified technician. In
case of one or more inoperative channels, call your
dealer to make service arrangements.
7. Auto On/ Manual On Switch
Put this switch in the Auto On position if the amplifier
is being used as part of a JBL Synthesis System. When
used in this way, the S7150 will automatically turn on
when the power switch is depressed and the surround
processor is activated. For other installations, or
should individual control of each component be
desired, put this switch in the Manual On position.
The amplifier will then be controlled solely by the front
panel switch.
3.0
OPERATION AND
CONTROLS
S7150

8. IN/OUT DIN Jacks
If you are using the amplifier as part of a JBL Synthesis
System, it is necessary to use these jacks to interconnect
to other system components, so that control signals
(power on/off and music/cinema mode switching) can
be transmitted from one unit to the next, starting at the
surround processor, through the equalizer and amplifiers,
and ending at the speakers. Follow the connection
diagrams on the following pages corresponding to the
appropriate Synthesis system for detailed information
regarding these connections. Make connections to
these jacks only as shown in the diagrams. If these
jacks are used in any other manner, e.g., to control
electric screens, the unit can be damaged and the
warranty will be void. For specific electrical information on
these jacks, contact JBL Synthesis Customer Service at
(800) 336-4JBL.
Do not plug anything into these jacks if you
are not using the S7150 with a JBL Synthesis
System.
9. Speaker Mode Control Connectors
The front left and front right speakers are switched
between Music and Cinema modes by signals present
at both the DIN connectors (as described in the previous
paragraph) AND the 2-conductor connectors shown at (9).
The installer may find it preferable to use 2-conductor
wire (18 gage recommended) rather than long multi-
conductor DIN cables for the mode-switching connection
between the S7150 and these two speakers. Adapters
supplied with the S7150 are used at the speaker end of
the wire to allow connection to the speakers' DIN input
connectors. Proper polarity must be observed as shown
in the wiring diagrams; reverse the connections at one
end of the wire if the speaker(s) do not switch modes
(from horn (Cinema) to tweeter (Music)).
Note that 5-conductor DIN cables MUST be used
between all other components to allow correct power
and mode switching and that the same warning as in
(8) applies here; do not attempt to use these jacks to
control anything other than the mode-switching function
of Synthesis speakers, as this may damage the S7150
and will void the warranty.
10. AC Inlet
Your S7150 is shipped with an IEC-type removable
power cord that mates with the AC inlet on the rear
panel. To ensure proper operation, use the supplied
power cord. This amplifier is NOT a multi-voltage
unit; using a power cord with a different connection to
the AC wall receptacle will void the warranty.
12
3.0
OPERATION AND
CONTROLS 3.0
OPERATION AND
CONTROLS

General Information
A Synthesis Two or Three installation incorporates a total
of two power amplifiers; one S7150 and one S800. All
seven channels on the S7150 are to be used for driving
the left, center, right, both side, and both rear speakers.
Use the simplified connection diagrams on the following
pages to help you understand how to connect the S7150
amplifier to a JBL Synthesis System. These diagrams are
intended to show the signal flow through the system. For
more detail in making these connections, please refer to
the JBL Synthesis Certified Dealer Installation Manual.
Connect DIN and audio cables between system components,
as shown on the following pages. Make sure that on all
power amplifiers the power switches are in the depressed
(ON) position and that the Auto On/ Manual On switches
are in the Auto On position. Operated in this mode, all of
the components will turn on with one touch of the power
button on the surround processor's remote control.
4.0
INTERCONNECTIONS IN
SYNTHESIS SYSTEMS
13
4.0
CONNECTING YOUR
SYNTHESIS SYSTEM

14
Power VCR DVD V-Disc TV Aux CD Tuner Tape Rec/ Zone 2 Effect 2-Channel Mute
JBL SDP-3
COPYRIGHT 1999
SDP-3 Digital Surround Processor/Controller
SDP-3
SDEC-2500A
S800
S7150
SDEC-2500A
S800
Top
#1
#2
#3
#4
4.1 Synthesis Two & Three
Suggested Rack Mounting Order
4.0
CONNECTING YOUR
SYNTHESIS SYSTEM

SDP-3
SDEC-2500A
WARNING – Toreduce the risk of
fire or electric shock, do not expose
this appliance to rain or moisture.
Do not remove cover. No user
serviceable parts inside. Refer
servicing to qualified service personnel.
SDEC-2500A
Digital Equalizer Controller
JBL, INC. Northridge CA
Made in USA
R-AMB L-AMB R-SUB L-SUB C R L R-IN L-IN SUB-IN C-IN
ANALOG INPUT
S/P DIF DIGITAL INPUT
R-AMB-IN L-AMB-IN
THX®CONNECTOR
OUTPUT
MANUAL
ON
RS-232
DIN IN DIN OUT
AUTO
ON
AUTO
MODE
CINEMA
MODE
CINEMA
MODE
AUTO
MODE
AUTO
ON
MANUAL
ON
(Use "Cinema Mode" position only 
when there are no music mode 
speakers in the system.)
CONTROL JACK SIGNALS
24
1
5
3
PIN 1 Ground
PIN 2 Ground
PIN 3 +5vdc when Power is on
PIN 4 Not Used
PIN 5 +5vdc in Cinema mode
1)To ensure proper operation, connect the system control lines 
 exactly as indicated.

2)If any of the control lines become disconnected while the 
 system is on, turn off all Synthesis components before 
 reconnecting control lines. This will reset all operation.
SPEAKER CONTROL JACK
2
1
PIN 1 Ground
PIN 2 +5vdc in Cinema mode
NOTES
AUDIO
EXPANSION PORTS
L
R
L
R
ABC
L
R
L
R
L
R
SUBWOOFER
TAPE TUNER CD AUX TV V-DISC DVD VCR
AUDIO
INPUT
TRIGGERS
GND
S
PGMPWR
IR IN
TRIGGERS
PGM GND PWR
R
C
R
LISTEDAUDIO
EQUIPMENT
7D77
E172268
MAIN OUTPUTS
REAR
ZONE 2 RECORD 1 RECORD 2 SIDE CENTER FRONT
12
3
S/PDIF INTPUTS
1
3
2
45
S/PDIF OUT
RISKOF ELECTRIC SHOCK
DONOT OPEN
RISQUEDE CHOC
ELECTRIQUE
NEPAS OUVRIR
CAUTION
ATTENTION
RS 232
100-240V 50-60 Hz, 35W
SDP-3
JBL Synthesis, INC. 
ASSEMBLED IN U.S.A.
OUTPUT
MONITOR
S-VIDEO VIDEO
S7150 Manual
On
Auto
On
TO SPEAKERS
WARNING:
serial number
ATTENTION:
VOIR LE CAHIER D'
INSTRUCTION
15A
120V
50/60Hz
1800W
Ch. 1 Output Ch. 2 Output Ch. 3 Output Ch. 4 Output Ch. 5 Output Ch. 6 Output Ch. 7 Output
ON
OFF
MANUAL
ON
AUTO
ON
IN
OUT
SPKR-1 SPKR-2
Ch. 1
Input
Ch. 2
Input
Ch. 3
Input
Ch. 4
Input
Ch. 5
Input
Ch. 6
Input
Ch. 7
Input
AVI S: RISQUE DE CHOC ELECTRIQUE NE PASOUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
