JBL Synthesis S800 User manual

SYNTHESIS
S800
POWER
AMPLIFIER
USER’S
MANUAL

TABLE
OF
CONTENTS
SECTION ______________________________________________________PAGE
1.0 Precautions _______________________________________________________4
1.1 Important Safeguards for Audio Products ______________________________4-7
2.0 Introduction and Features of the S800 _________________________________8-9
3.0 Operation and Controls______________________________________________10
3.1 S800 _________________________________________________________10-12
4.0 Connecting Your Synthesis System ____________________________________13
4.1 JBL Synthesis One – Suggested Rack Mounting Order _____________________14
4.2 JBL Synthesis One – Control Wiring Diagram ____________________________15
4.3 JBL Synthesis One – Interconnection Diagram ___________________________16
4.4 JBL Synthesis Two & Three – Suggested Rack Mounting Order ______________17
4.5 JBL Synthesis Two & Three – Control Wiring Diagram _____________________18
4.6 JBL Synthesis Two & Three – Interconnection Diagram_____________________19
5.0 Installing the S800 _________________________________________________20
6.0 Troubleshooting ___________________________________________________21
7.0 Specifications _____________________________________________________22
8.0 Synthesis Limited Warranty __________________________________________23
JBL Synthesis S800 Power Amplifier
User's Manual
©2000 JBL
JBL and Synthesis are registered trademarks of JBL Incorporated.
All Rights Reserved
JBL Synthesis
8500 Balboa Boulevard, Northridge, CA 91329
250 Crossways Park Drive, Woodbury, NY 11797
800-336-4JBL
Printed on Recycled Paper
Part Number: S800OM6/00
A Harman International Company
3

1.1 Important Safeguards
For Audio Products
PLEASE READ CAREFULLY ALL THE
FOLLOWING IMPORTANT SAFEGUARDS
THAT ARE APPLICABLE TO YOUR EQUIPMENT
1. Read instructions – All the safety and operating
instructions should be read before the product is
operated.
2. Retain instructions – The safety and operating
instructions should be retained for future reference.
3. Heed Warnings – All warnings on the product
and in the operating instructions should be
adhered to.
4. Follow Instructions – All operating and use
instructions should be followed.
5. Water and Moisture – The product should not
be used near water – for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, and the like.
6. Carts and Stands – The product should be used
only if a cart or stand is recommended by the
manufacturer.
6a. A product and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination
to overturn.
7. Wall or Ceiling Mounting – The product should
be mounted on a wall or ceiling only when and as
recommended by the manufacturer.
8. Ventilation – The product should be situated so
that its location or position does not interfere with
its proper ventilation. For example, the product
should not be situated on a bed, sofa, rug, or
similar surface that may block the ventilation
openings; or, placed in a built-in installation,
such as a bookcase or cabinet that may impede
the flow of air through the ventilation openings.
9. Heat – The product should be situated away from
heat sources such as radiators, heat registers,
stoves, or other products that produce heat. If placed
near an amplifier, check with the manufacturer for
applicability.
10. Power Sources – The product should be
con-nected to a power supply only of the type
described in the operating instructions or as
marked on the product.
11. Grounding or Polarization – Precautions
should be taken so that the grounding or polarization
means of a product is not defeated.
12. Power-Cord Protection – Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords
at plugs, convenience receptacles, and the point
where they exit from the product.
13. Cleaning – The product should be cleaned only
as recommended by the manufacturer.
14. Power Lines – An outdoor antenna should be
located away from power lines.
15. Nonuse Periods – The power cord of the product
should be unplugged from the outlet when left
unused for a long period of time.
16. Object and Liquid Entry – Care should be taken
so that the objects do not fall and liquids are not
spilled into the enclosure through the openings.
The lighting flash with arrowhead
symbol, within an equilateral trian-
gle, is intended to alert the user to
the presence of uninsulated ”dan-
gerous voltage” within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and mainte-
nance (servicing) instructions in
the literature accompanying the unit..
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT
TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS (POLAR-
IZED) PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUT-
LET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT
BLADE EXPOSURE.
ATTENTION: POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS
UTILISER AVEC UN PROLONGATEUR. UNE PRISE DE COURANT OUUNE
AUTRE SORTIE DE COURANT SAUF SI LES LAMES PEUVENT ETRE
INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.
4
1.0
PRECAUTIONS 1.0
PRECAUTIONS

1.0
5
PRECAUTIONS
17. Outdoor Antenna Grounding – If an outside
antenna is connected to the receiver, be sure
the antenna system is grounded so as to
provide some protection against voltage
surges and built-up static charges. Article
810 of the National Electrical Code,
ANSI/NFPA 70, provides information with
regard to proper grounding of the mast
and supporting structure, grounding of the
lead-in wire to an antenna-discharge unit,
size of grounding conductors, location of
antenna-discharge unit, connection to
grounding electrodes, and requirements for
the grounding electrode (See Figure 1).
18. Damage Requiring Service – The product
should be serviced by qualified service per-
sonnel when:
a. The power supply or the plug has been
damaged; or
b. Objects have fallen on, or liquid has
been spilled into, the product; or
c. The product has been exposed to rain; or
d. The product does not appear to operate
normally or exhibits a marked change
in performance; or
e. The product has been dropped, or
the enclosure damaged.
19. Servicing – The user should not attempt to
service the product beyond that described
in the operating instructions. All other
servicing should be referred to qualified
service personnel.
Note to CATV system installer:
This reminder is provided to call the CATV
system installer’s attention to Article 820-22
of the NEC that provides guidelines for proper
grounding and, in particular, specifies that
the cable ground shall be connected to the
grounding system of the building, as close
to the point of cable entry as practical.
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
Figure-1
Example of Antenna Grounding
as per National Electrical Code

Français
Instructions de Sûreté Importantes
Gardex ces instructions pour réference future.
Observez toutes les instructions et tous les avertissements marqués sur l’appareil.
Branchez uniguements sur un réseau de tension indiquée. Consultez le manuel
d’instruction du fabriquant pour les spécifications de courant. N’oubliez pas que
différentes tensions peuvent nécessiter l’utilisation de cables et/ou de fiches
deconnexion différents.
N’installez pas l’appareil en un compartiment non-aéré ou directement au-dessus
d’équipements générateurs de chaleur, tels qu’amplificateurs de courants, etc. Ne
dépassez pas la température ambiante maximale de fonctionnement indiquée
dans les spécifications du produit.
Des fentes et ouvertures sont prévues dans le boîtier pour l’aération; Pour assur-
er le bon fonctionnement et pour prévenir l’échauffement, ces ouvertures ne
doivent pas être couvertes ou bloquées. N’insérez pas d’objets dans les fentes
d’aération. Empêchez tout liquide de se répandre sur l’appareil.
Ce produit est muni d’une fiche à trois fils pour la mise à terreee. Ceci est une
mesure de sécurité et ne doit pas être contrariée.
Ne connectez jamais d’amplificateurs audio directement aux connecteurs de l’appareil.
Pour empêcher les chocs électriques et le danger d’incendie, évitez d’exposer
l’appareil à la pluie ou à l’humidté, et ne le mettez pas en marche en un endroit
où il serait exposé aux éclaboussures d’eau.
N’essayez pas de faire fonctionner l’appareil s’il est tombé à terre, a été endom-
mangé, exposé à un liquide, ou si vous observez des différences nettes dans son
fonctionnement, indiquant la nécessité de réparations.
Cet appareil ne doit être ouvert que par un personnel de service qualifié. En enl-
evant les couvercles vous vous exposez àdes tensions électriques dangereuses.
Ce triangle, sur votre appaeil vous avertit de la présence de ten-
sion dangereuse, non-isolée à l’intérieur du boîtier…une tension
suffisante pour représenter un danger d’electrocution.
Ce triangle sur sur votre appareil vous invite de suivre d’impor-
tantes instructions d’utillisation et d’entretien dans la documen-
tation livrée avec le produit.
Español
Instrucciones importantes de sequirdad
Guarde esta instrucciones para uso posterior.
Utilice siempre el voltaje correcto. Diríjase a las instrucciones de operación del
fabricante para obtener las especificaciones de potencia. Esté al tanto de que
voltajes de operación distintos requieren el uso de cable y/o enchufes distintos.
No instale esta unidad en un estante sin vntilación, ni tampoco directamente
encima de equipose que generen calor tales como amplificadores de potencia.
Fíjese en las temperaturas ambientales máximas de operación que se mencionan
en las especificaciones del producto.
Las aperturas y ranuras del chasis sirven para proveer la ventilación necesaria para
operar la unidad con sequridad y para prevenir sobrecalentamiento, y por lo tanto
no pueden ser obstruidas o cubiertas. No introcuzca objetos de ningún tip a través
de las ranuras de ventilación, y nunca deje caer ningún líquido sobre la unidad.
Este producto está equipado con un enchufe de 3 clavijas con conexión a ierra.
Este es un elemento de seguridad que no debe ser eliminado.
Nunca conecte ningùn tipo de salida de amplificadores de sonido directamente a
los conectores de la unidad.
Para prevenir descargas eléctricas o incendios, mantenga la unidad alejada de la
lluvia, humedad o cualquier lugar en el que pueda entrar en contacto con ague.
No trate de hacer funcionar la unidad si se ha caído, está dañada, ha entrado en
contacto con lítuidos, o si nota cualquir cambio brusco en su funcionamiento
que indique la necesidad de hacerle un servicio de mantenimiento.
Esta unidad deberá ser abierta únicamente por personal calificado. Si usted quita
las coberturas se expondrá a voltajes peligrosos.
Este triángulo que apaece en su componente le advierte sobre la
existencia dentro del chasis de voltajes peligrosos sin ais-
lantes…voltajes que son lo suficientemente grandes como para
causar electrocución.
Este triángulo que aparece en su componente lo alerta sobre las
instrucciones de operación y mantenimiento importantes que
están en los materiales de lectura que se incluyen.
Italiano
Importanti norme di sicurezza
Conservare le presenti norme per l’utilizzo futuro.
Osservare tutte le istruzioni e le avvertenze apposte sull’unita.
Utilizzare esclusivamente con la tensione di rete corretta. Consultare le istruzioni
operative fornite dal fabbricante per i dati riguardanti la tensione e l’assorbimento
di corrente. Potrebbe essere necessario l’uso di cavi di rete e/o di spine diverse a
seconda della tensione utilizzata.
Non installare l’unità in uno scaffale privo di ventilazione oppure direttamente sopra
una fonte di calore, come, ad esempio, un amplificatore. Non superare la temper-
atura ambientale massima di funzionamento riportata nei dati tecnici del prodotto.
Le fessure e le altre aperture nella scatola servono alla ventilazione. Per un fun-
zionamento affidabile, e per evitare un eventuale surriscaldamento, queste aper-
ture non vanno ostruite o coperte in nessun modo. Evitare in tutti i casi di inserire
oggetti di qualsiasi genere attraverso le fessure di ventilazione. Non versare mai
del liquido di nessun tipo sull’unità.
QUesto pordotto viene fornito con una spina a 3 fili con massa. Tale dispositivo
di sicurezza non va leiminato.
Evitare sempre di collegare le uscite dell’amplificatore auio direttamente ai con-
nettori dell’unità.
Per prevenire il pericolo di folgorazione e di incendio non esporre l’unità alla
pioggia o ad un’umidtà eccessiva; evitare di adoperare l’unità dove potrebbe
entrare in contatto con acqua.
Evitare di adoperare l’unità se la stessa è stata urtata violentemente, se ha subito
un danno, se è stata esposta ad un liquido o in caso di un evidente cambiamento
dell prestazioni che indichi la necessità di un intervento di assistenza tecnica.
Ogni intervnto sull’unità va esqguito esclusivamente da personale qualificato. La
rimozione della copertura comporta l’esposizione al pericolo di folgorazione.
ll present triangolo impresso sul componente avverte della pre-
senza di tensioni pericolose non isolate all’interno della copertu-
ra…tali tensioni rappresentano un pericolo di folgorazione
ll presente triangolo imprsso sul componente avverte l’utente
della presenza nella documentazione allegata di importanti
istruzioni relative al funzionament ed alla manutenzione.
Deutsch
Wichtige Sicherheitsanweisungen
Heben Sie sich diese Sicherheitsanweisungen auch für später auf.
Befolgen Sie alle auf der Vorrichtung stehenden Anweisungen und Warnungen.
Immer nur mit der richtigen Spannung verwenden! Die Gebrauchsanweisungen
des Herstellers informieren Sie über die elektrischen Anforderungen. Vergessen
Sie nicht daß bei vershiedenen Betrievsspannungen ggf. auch verschiedene
Leitungskabel und/oder Verbindungsstacker zu verwenden sind.
Stellen Sie die Vorrightung nicht in ein unbelüftetes Getell oder unmittelbar über
wärmeerzeugende Geräte wie z.B. Tonverstärker. Halten Sie die in den Produkt-
spezifikationen angegebene maximale Umgebungstemperatur bei Betrieb ein.
Schlitze und Öffnungen im GehUause dienen der Belüfung; um verläßlichen
Betrieb sicherzustellen und Überheizen zu vermeiden dürfen diese Öffnungen
nich verstopft oder abgedeckt werden. Stecken Sie nie irgend einen Gegenstand
durch die Belüftungsschlitze. Vergießen Sie keine Flüssigkeiten auf den Apparat.
Dieses Produkt is mit einem 3-drahtigen Erdungsstecher ausgerüstet. Diese
Sicherheitsmaßnahme darf nicht unwirksam gemacht werden.
Schließen Sie nie Tonverstärker unmittelbar an einen Anschluß des Apparates an.
Um elektrischen Schlag oder Feuer zu vermeiden, setaen Sie den Apparat weder Regen
noch Feuchtigkeit aus und betreiben Sie ihn nicht dort wo Wasser eindringen könnte.
Versuchen Sie nicht den Apparat zu betreiben falls er fallen gelassen, beschädigt,
oder Flüssigkeiten ausgesetzt wurde, oder falls sich seine Arbeitsweise derart
ändert daß daraus ein Bedarf nach Raparatur zu schließen ist.
Dieser Apparat sollte nur von qualifizierten Fachleuten geöffnet
werden. Das Abnehmen von Abdeckungen setzt Sie
gefährlichen Spannungen aus.
Dieses Dreick auf ihrem Apparat warnt Sie voe nicht-isolierter,
gefährlicher Spannung im Gehäuse…stark genug um eine
Berührungsgefahr darzustellen.
Diese Dreick auf ihram Apparat bedeutet daß wichtige Betriebsund
Wartungsanweisungen in der mitgelieferten Dokumentation zu
finden sind.
6

7
Dansk
Vigtig information om sikkerhed
Gem denne vejledning til senere brug.
Følg all anvisninger og advaresler på apparatet.
Apparatet skal altid tilslttes den korrekte spænding. Der henvises til brugsanvis-
ningen, der indeholder specifikationer for strømforsyning. Der gøres opmærk-
som på, at ved varierende driftsspændinger kan det blive nødvendigt at bruge
andre lednings- og/eller stiktyper.
Apparated må ikke monteres i et kabinet uden ventilation eller lige over andet
udstyr, der udvikler varme, f.eks. forstærkere. Den maksimale omgivelsestemper-
atur ved drift, der står opført i specifikationerne, skal overholdes.
Der er ventilationsåbninger i kainettet. For at sikre apparatets drift og hindre
overophidning må disse åbninger ikke blokeres elle tildækkes. Stik aldrig noget
ind igennem ventilationsåbningerne, og pas på aldrig at spilde nogen form for
væske på apparatet.
Dette apparat er forsynet med et stik med jordforbindelse. Denne sikkerheds-
foranstaltning må aldrig omgås.
Udgangsstik fra audioforstærkere må aldrig sættes direkte i apparartet.
Apparatet må ikke udsættes for regn eller fugt og må ikke bruges i nærheden af
vand for at undgå risiko for elektrisk stød og brand.
Apparatet må aldrig bruges, hvis det er blevet stødt, beskadiget eller vadt, eller
hvis ændringer i ydelsen typer på, at det trænger til eftersyn.
Fette apparat må kun åbnes af fagfolk, Hvis dækslet tages af, udsættes man for
livsfarlig højspænding.
Denne mærkat på komponenten advarer om uisoleret, farlig
spænding i apparatet… høj nok til at give elektrisk stød.
Denne mærkat på komponenten advarer om vigtig driftsog
vedligeholdsinformation i den tilhørende litteratur.
Suomi
Tärkeitä varten
Säilytä nämä ohjeet tulevaa käyttoöä varten.
Seuraa kaikkia yksikköön merkittyjä ohjeita ja varoituksia.
Käytä aina oikeaa verkkojännitettä. Tehovaatimukset selviävät valmista-
jan käyttöohjjeista. Huomaa, että eri käyttöjännitteet saattavat vaatia
toisenlaisen verkkojohdon ja/tai- pistokkeen käytön.
Älä asenna yksikköä telineeseen jossa ei ole tuulet usta, tai välittömästi
lämpöä tuottavien laitteiden, esim. tehovahvistimien, yläpuolelle.
Ympäristön Iämpötila käytössä ei saa ylittää twotespesifikaation mak-
similämpötilaa.
Kotelo on varustettu tuuletusreiillä ja -aukiooa. Luotettavan toiminnan
varmistamisksi ja ylilämiseksi näitä aukkoja ei saa sulkea tai peittää.
Mitään esineitä ei saa työntää tuuletusaukkoihin. Mitään nestritä ei saa
kaataa yksikköön.
Tuote on varustettu 3-jjohtimisella maadoitetulla verkkipistokkeella.
Tämä on turvallisuustoiminne eikä sitä saa poistaa.
Älä kytke audiotehovahvistimen lähtöjä suoraan mihinkään yksikön liit-
timeen.
Sähköiskun ja palovaaran välttämiseksi yksikkö ei saa olla sateessa tai
kosteassa, eikä sitä saa käyttää märässä ympäristössa.
Älä käytä yksikköä jos se on pudonnut, vaurioitunut, kostunut, tai jos
sen suorituskkyky on huomattavasti muuttunut, maikä vaatii huoltoa.
Yksikön saa avata vain laitteeseen perehtynyt huoltohenkilö. Kansien
poisto altistaa sinut vaarallisille jännittelille.
Tämä kolmio, joka esiintyy homponentissasi, varoittaa
siua eristämättömän vaarallisen jännitteen esiintymisestä
yksikön sisällä. Tämä jännite saattaa olla riittävä korkea
aiheuttamaan sähköiskuvaaran.
Tämä koimio, joka esiintyy komponentissasi, kertoo sin-
ulle, että tässä tuotedokumentoinnissa esiintyy tärkeitä
käyttö-ja ylläpite-ohjeita.
Norsk
Viktig informasjon om sikkerhet
Ta vare pådenne veiledningen for senere bruk.
Følg alle anvisningene og advarslene som er angitt på apparatet.
Apparatet skal alltid anvendes med korrekt spenning.
Produktbeskrivelsen inneholder spesifikasjoner for strømkraav. Vær oppmerksom
på at det ved ulike driftsspenninger kan være nødvendig å bruke en annen led-
ningog/eller støpseltype.
Apparatet skai ikke monteres i skap uten ventilasjon, eller direkte over varmepro-
duserende utstyr, som for eksempel kraftforsterkere. Den maksimale romtempera-
turen som står oppgitt i produktbeskrivelsen, skal overholdes.
Apparatet er utstyrt med ventilasjonsåpninger. For at apparatet skal være pålitelig
i bruk og ikke overopphetes, må disse åpningene ikke blikkeres eller tildekkes.
Stikk aldri noe inn i ventilasjonsåpningene, og pass på at det aldri søles noen
form for væske på apparatet.
Dette apparatet er utstyrt med et jordet støpsel. Dette er en sikkerhetsforanstalt-
ning som ikke må forandres.
Utgangsplugger fra audioforsterkere skai aldri koples direkte til apparatet.
Unngå brannfare og elektrisk støt ved å sørge for at apparatet ikke utsettes for
regn eller fuktighet og ikke anvendes i næheten an vann.
Apparatet skal ikke brukes hvis det har blitt utsatt for støt, er skadet eller blitt vått,
eller hvis endringer i ytelsen tyder på at det trenger service.
Dette apparatet skal kun åpnes av fagfolk. Hvis dekselet fjernes, utsettes man for
livsfarlig høyspenning.
Komponenten er merket med denne trekanten, som er en
advarsel om at det finnes uisolert, farlig spenning inne i kabi-
nettet…høy nok til å utgjøre en fare for elektrisk støt.
Komponenten er merket med denne trkanten, som betyr at den
tilhørende litteraturen inneholder viktige opplysninger om drift
og vedikehold.
Svenska
Viktiga säkerhetsföreskrifter
Spara dess föreskrifter för framtida bruk.
Följ alla anvisningar och varningar som anges på engeten.
Använd alltid rätt nätspänning. Se tillverkarens bruksanvisningar för informa-
tion om effektkrav. Märkväl, att andra matningsspänningar eventuellt kräver att
en annan typs nätsladd och/eller kontakt anänds.
Installera inte enheten i ett oventilerat stativ, eller direkt ovanför utrustningar
som avger värme, t ex effektförstärkare. Se till att omgivningens temperatur
vid drift inte överskrider det angivna värdet i produktspecifikationen.
Behållaren är försedd med hål och öppningar för ventilering. För att garantera
tillförlitlig funktion och förhindra överhettning får dessa oppningar inte block-
eras eller täckas. Inga föremål får skuffas in genom ventilationshålen. Inga
vätskor får spillas på enheten.
Produkten är försedd med en jordad 3-trådskontakt. Detta ä en säkerhetsfunk-
tion som inte får tas ur bruk.
Anslut aldrig audioeffektförstärkarutgångar direkt till någon av enhetens
kontakter.
För att undvika elstöt eller brandfara får eenheten inte utsättas för reegn eller
fukt, eller användas på ställen där den blir våt.
Använd inte enheten om den far fallit i golbet, skadats, blivit våt, eller om dess
prestanda förändrats märkbart, vilket kräver service.
Enheten får öppnas endast av behörig servicepersonal. Farliga spänningar blir
tillgängliga när locken tas bort.
Denna triangel, som visas på din komponent, varnar dig om
en oisolerad farlig spänning inne i engeten. Denna spänning
är eventuellt så hög att fara för elstöt föreligger.
Denna triangel, som visas på din komponent, anger att viktiga
bruksanvisningar och servideanvisningar ingår i dokumenta-
tionen i fråga.

Introduction
Congratulations on your purchase of this JBL
Synthesis S800 power amplifier! You have purchased a
product that embodies the best of what JBL has learned
about the emotional power of audio reproduction in over
fifty years of preeminence in the field. This amplifier
has been designed and crafted to provide the user with
a high level of sonic performance; special attention has
been paid to minimize the number of components in the
audio signal path, resulting in extremely low distortion,
excellent transient response, and wide dynamic range.
Synthesis products set new benchmarks in audio
technology, and, when used as part of a complete JBL
Synthesis System, will bring the ambience and
acoustics of some of the world’s greatest concert halls
and theaters into your home.
To obtain the best performance from this amplifier,
please be sure to completely read this user’s manual and
use the S800 only in accordance with its instructions.
Features
The JBL Synthesis S800 power amplifier features the
following:
THX ®Ultra Specifications
This amplifier meets or exceeds the stringent specifications set
by the Lucasfilm THX Audio division in their specifications for
"Ultra"-class certification, including power handling, total
harmonic distortion, frequency response, signal to noise
ratio, slew rate, and crosstalk. When incorporated into a
complete THX system, you will hear in your home what the
director and sound engineer heard in the recording studio.
Multi-Channel Operation
The S800, a two channel amplifier that can also be
operated in bridged-mode as an extraordinarily
powerful single-channel amplifier (typically when used
to drive a subwoofer), has been designed to integrate
well into the world of multi-channel audio. When
coupled with the five channels available in the S650A,
or the seven channels of the S7150, they are a solid
foundation on which to build a high-performance home
cinema system that will astound the listener with its
power and realism.
High Power Capability
The S800 provides a truly satisfying 200 watts per
channel of clean audio (<0.03% THD) into eight ohm
loads, and 800 watts when operated in bridged-mode
into an eight ohm load, making it ideal for powering
subwoofers and surround speakers, which are frequently
less efficient than front speakers. Because of their power
capabilities, all Synthesis amplifiers have an extremely
wide dynamic range, an element critical to realistic home
cinema. Sound pressure levels equal to those present at
original performances are easily recreated in even the
largest of home listening environments.
Auto Turn-On and Power Sequencing Circuitry
When used in a JBL Synthesis System, the S800 can
be turned on automatically whenever the surround
processor is activated. No longer do you have to get out
of that chair to turn on the various pieces of equipment
in your entertainment system; just one touch on the
remote control of the surround processor, and you’re
a few seconds away from a truly impressive audio
presentation!
Modern amplifiers produce more power per channel
(and frequently have more channels) than those of the
traditional two-channel stereo era. Due to the high
current demands of power amplifiers at the instant of
turn-on, the S800, S650A, and S7150 amplifiers and
the SDEC digital equalizer are equipped with power
sequencing circuits which turn on each unit in sequence,
avoiding the large instantaneous current demand (and
possible house circuit breaker tripping) that would occur
should they all turn on at the same instant.
8
2.0
INTRODUCTION
AND FEATURES
2.0
INTRODUCTION
AND FEATURES

Quiet Cooling
The S800 utilizes a fan to cool the amplifier channels,
ensuring long-term reliability. To reduce fan noise to an
absolute minimum, a thermal sensing and control
circuit has been incorporated in the Synthesis S800
that senses increases in temperature within the amplifier
and powers a fan at a speed proportional to that
temperature increase. When the S800 is "loafing", the
fan turns very slowly – and quietly. At high listening
levels (and the higher operating temperatures this
creates within any amplifier), the sensing circuitry
causes the fan to turn faster, producing increased
cooling. As a result, the fan is never turning faster than
necessary, and most of the noise that is generated is
masked by the program being listened to.
Comprehensive and Isolated Circuit Protection
The S800 amplifier employs a sophisticated protective
circuit (one for each channel) that senses many
possible fault conditions, such as shorted loudspeaker
wires or excess power demand, and turns the affected
channel(s) and their blue front panel indicators off until
the fault condition is removed, at which time normal
operation is automatically restored. While protection of
this sort is not uncommon in today’s well-designed
amplifiers, a remarkable feature of the Synthesis S800’s
protective circuits is that they are optically-coupled to
the signal circuit; there is no direct electrical connection
between the signal path and the protective circuitry.
As a result, there can be no coloration of the
music, no interaction between protection and
amplification, until certain thresholds are
exceeded, at which point the channel(s) turn
off completely.
9
2.0
INTRODUCTION
AND FEATURES
2.0
INTRODUCTION
AND FEATURES

10
S800
3.0
OPERATION AND
CONTROLS 3.0
OPERATION AND
CONTROLS
3.1 S800
1. Power Switch
Pushing this button is all that is required to turn on the
S800 if it is not part of a Synthesis system and the
Manual On/Auto On switch (rear panel) is in the
Manual On position. If the amplifier is used as part of
a JBL Synthesis System, and the Manual On/Auto
On switch is in the Auto On position, the amplifier
will turn on when the surround processor is activated.
The front panel pushbutton power switch is left in the
ON (in) position..
2. Standby Indicator (red)
This indicator, immediately above the front panel power
switch, will glow red when the amplifier is in the
"standby" mode, whether operating as part of a
Synthesis system or not. When the S800 is in the
"operate" mode, this light will shut off and the blue
"operate" mode indicators will light.
3. Power Indicators (blue)
These indicators will light up when the power amplifier
is in the "operate" mode. Each monitors the operation
of one channel, and will extinguish if that channel’s
protective circuit is activated.
4. Input Jacks (Ch.1 and Ch.2) (see page 11)
If you are using the S800 as a stereo power amplifier,
connect the signal output(s) from the system equalizer
or surround processor to these jacks and set the
Stereo/Mono switch to the Stereo position. If you
are using the S800 in the bridged mode, connect the
subwoofer signal output from the equalizer to the Ch.1
jack only, and put the Stereo/Mono switch in the
Mono position.
5. Stereo/Mono Switch
See paragraph 4 above
6. Speaker Terminals (see page 11)
Connect the speakers to these terminals, following the
normal convention; wire the "+" side of the speaker to the
red terminal, and the "-" side to the black terminal. The
terminals for Channel 1 are on the left; those for Channel
2 on the right side as you face the rear panel. Use all four
terminals when using the amplifier in the stereo mode of
operation. Wire the speakers with the proper polarity;
reversing any speaker’s connections will not damage
either the speaker or the amplifier, but will result in poor
low frequency performance and imprecise imaging.
In mono mode, connect the speaker to the center red
terminals only; no connection is made to the

20A 120VAC/60Hz 2400 W
S800
10A
120V
50/60Hz
1200W
ON
OFF
MANUAL
ON AUTO
ON
IN
OUT
Ch. 2 Output
Ch. 1
BRIDGED
Input
Ch. 2
Input
ATTENTION: VOIR LE CAHIER D'
INSTRUCTION
WARNING: HAZARDOUS ENERGY, MAKE PROPER SPEAKER CONNECTIONS; SEE OWNERS MANUAL BEFORE USING.
serial number
STEREOMONO
BRIDGED
Ch. 1 Output
BRIDGED
+-
+- +
-
DESIGNED, ENGINEERED AND MANUFACTURED
IN THE UNITED STATES OF AMERICA
S800 POWER AMPLIFIER JBL SYNTHESIS
NORTHRIDGE, CA TRIGGERS
AVIS: RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
~
No user serviceable parts inside. Refer
servicing to qualified personnel.
WARNING; To reduce the risk of fire or
electric shock, do not expose
this appliance to rain or moisture
11
black terminals. Wire the "+" terminal of the speaker
to the left red terminal, and the "-" terminal of the
speaker to the right red terminal.
In bridged mode, speakers connect only to the
"hot" (red) amplifier output connectors, and
neither can be connected to ground under any
circumstances, as damage to the S800 will
result.
NOTE: The minimum load impedance that this
amplifier can handle safely is two ohms per channel in
stereo operation, and four ohms in mono. Using lower
impedance loads can damage the unit and will void
your warranty!
Use the following chart as a guide to the appropriate
gage of wire to use for different amplifier-speaker
distances:
7. Circuit Breaker/Main Power Switch
The main power switch, located on the rear panel of the
S800, is also a circuit breaker. Putting this switch in
the ON position allows the amplifier to enter the "standby"
and "operate" modes as controlled by the front panel
POWER switch and Manual On/Auto On switches.
Should the amplifier be asked to produce more power
t
han its design allows for a prolonged period, or should
the S800 draw an amount of current from the AC power
source that could damage internal components, the
handle of this switch will move to a center position.
Reduce the audio level and wait a minute for the circuit
breaker to reset, then move it to the OFF, then the ON
position. If the handle returns to the center ("tripped")
position, service is required; contact your JBL
Synthesis dealer.
The S800 was designed to operate reliably under virtu-
ally all conditions. Even momentary short circuiting of
the output (speaker) connections will not ordinarily
damage the output circuitry (although this will activate
internal protective circuitry and cause one or more of
the front-panel blue LED indicators to extinguish until
the circuit resets.)
There are no user-serviceable parts in the S800; there
are no fuses accessible from outside the unit.
Internal fuses have been incorporated in the S800 to
protect it from short circuits and other faults, but these
should only be replaced by a qualified technician. In
case of one or more inoperative channels, call your
dealer to make service arrangements
3.0
OPERATION AND
CONTROLS
Wire Run Length Rec. Ga.
Up to 20' 16
Up to 50' 14
Up to 100' 12
Wire Run Length Minimum Gage
S800

8. Auto On/ Manual On Switch
Put this switch in the Auto On position if the amplifier
is being used as part of a JBL Synthesis System. When
used in this way, the S800 will automatically turn on
when the power switch is depressed and the surround
processor is activated. For other installations, or
should individual control of each component be
desired, put this switch in the Manual On position.
The amplifier will then be controlled solely by the front
panel switch.
9. IN/OUT Din Jacks
If you are using the amplifier as part of a JBL Synthesis
System, it is necessary to use these jacks to interconnect
to other system components, so that control signals
(power on/off and music/cinema mode switching) can
be transmitted from one unit to the next, starting at the
surround processor, through the equalizer and amplifiers,
and ending at the speakers. Follow the connection
diagrams on the following pages corresponding to the
appropriate Synthesis system for detailed information
regarding these connections. Make connections to
these jacks only as shown in the diagrams. If these
jacks are used in any other manner, e.g., to control
electric screens, the unit can be damaged and the
warranty will be void. For specific electrical information
on these jacks, contact JBL Synthesis Customer
Service at (800) 336-4JBL.
Do not plug anything into these jacks if you are
not using the S800 with a JBL Synthesis System.
10. AC Inlet
Your S800 is shipped with an IEC-type removable
power cord that mates with the AC inlet on the rear
panel. To ensure proper operation, use the supplied
power cord. This amplifier is NOT a multi-voltage
unit; using a power cord with a different connection to
the AC wall receptacle will void the warranty.
12
3.0
OPERATION AND
CONTROLS 3.0
OPERATION AND
CONTROLS

General information
A Synthesis One installation incorporates a total of four
power amplifiers; two S800's and two S650A's. Eight of
the ten channels on the S650A's are to be used for
driving the HI frequency and LO frequency inputs on the
left, center, and right speakers, as well as the two side
ambient speakers. Please refer to the connection chart on
the following page; you will find that there are two spare
output channels on the S650A. If desired, these channels
can be connected to the rear outputs on the surround
processor for additional rear ambient speakers. They can
also be used to drive additional speakers in other areas.
The S800's are operated in bridged mode; each drives
one subwoofer. Verify that the subwoofers are connected
ONLY to the red terminals of the amp.
In bridged mode, speakers connect only to the
"hot" (red) amplifier output connectors, and
neither can be connected to ground under any
circumstances, as damage to the S800 will result.
A Synthesis Two or Three installation incorporates a total
of two power amplifiers, one S800 and one S7150 or one
S650A. All channels on the S650 or S7150 are to be used
for driving the left, center, right, and ambient speakers, with
the S800 running in stereo mode to drive the subwoofers.
Use the simplified connection diagrams on the following
pages to help you understand how to connect the S800
amplifier to a JBL Synthesis System. These diagrams are
intended to show the signal flow through the system. For
more detail in making these connections, please refer to
the JBL Synthesis Certified Dealer Installation Manual.
Connect DIN and audio cables between system
components, as shown on the following pages. Make
sure that on all power amplifiers the power switches are
in the depressed (ON) position and that the Auto On/
Manual On switches are in the Auto On position.
Operated in this mode, all of the components will turn on
with one touch of the power button on the surround
processor's remote control.
4.0
INTERCONNECTIONS IN
SYNTHESIS SYSTEMS
13
4.0
CONNECTING YOUR
SYNTHESIS SYSTEM

14
S650A
S650A
Pow e r VC DVD V- TV Aux CD Tu ne Tape Rec/Zone Effe 2- Mut
JBL SDP-3
COPYRIGHT 1999
SDP-3 Digital Su rround
POWER
RF TIMING
LOCK ADVANCE
RETARD
NORMAL
OPTICAL
COAX
INPUT SELECT
AC-3
®
/RF DEMODULATOR
SDP-RFD
SDEC-1000A
SDP-3
S800
S800
S800
S800
Top
#1
#2
#3
#4
#5
#6
#7
4.1 Synthesis One
Suggested Rack Mounting Order
4.0
CONNECTING YOUR
SYNTHESIS SYSTEM

WARNING – Toreduce the risk of
fire or electric shock, do not expose
this appliance to rain or moisture.
Do not remove cover. No user
serviceable parts inside. Refer
servicing to qualified service personnel.
THX®ISA REGISTERED
TRADEMARKOF
LUCASFILM,LTD.
SDEC-1000A
Digital Equalizer Controller
JBL Inc., Northridge CA
Made in USA
R-AMB L-AMB R-SUB L-SUB C-HI R-HI L-HI R-IN L-IN SUB-IN C-IN
ANALOG INPUT
R-AMB-IN L-AMB-IN
THX®CONNECTOR
OUTPUT
MANUAL
ON
RS-232
DIN IN DIN OUT
AUTO
ON
AUTO
MODE
CINEMA
MODE
POWER RF IN S/PDIF INPUTS
9V~, 1A,
50-60Hz
AC-3
®
COAXS/PDIF OPTICAL
USE SYNTHESIS
MSA AC ADAPTER
PWR CTL
INPUT LOOP
THRU
PWR CTL
OUTPUT
SDP-RFD AC-3
®
/RF
DEMODULATOR
SDP-RFD
SDP-3
R-LO L-LO
C-LO
SDEC-1000A
AMB IN
S/P DIF DIGITAL INPUT
C/SUB IN
L/R IN
AUDIO
EXPANSION PORTS
L
R
L
R
ABC
L
R
L
R
L
R
SUBWOOFER
TAPE TUNER CD AUX TV V-DISC DVD VCR
AUDIO
INPUT
TRIGGERS
GND
S
PGMPWR
IR IN
TRIGGERS
PGM GND PWR
R
C
R
LISTEDAUDIO
EQUIPMENT
7D77
E172268
MAIN OUTPUTS
REAR
ZONE 2 RECORD 1 RECORD 2 SIDE CENTER FRONT
123
S/PDIF INTPUTS
1
3
2
45
S/PDIF OUT
RISKOF ELECTRIC SHOCK
DONOT OPEN
RISQUEDE CHOC
ELECTRIQUE
NEPAS OUVRIR
CAUTION
ATTENTION
RS 232
100-240V 50-60 Hz, 35W
SDP-3
JBL Synthesis, INC.
ASSEMBLED IN U.S.A.
OUTPUT
MONITOR
S-VIDEO VIDEO
TO SPEAKERS
CINEMA
MODE AUTO MODE AUTO ON MANUAL ON
(Use "Cinema Mode" position only
when there are no music mode
speakers in the system.)
CONTROL JACK SIGNALS
241
5
3
PIN 1 Ground
PIN 2 Ground
PIN 3 +5vdc when Power is on
PIN 4 Not Used
PIN 5 +5vdc in Cinema mode
1)To ensure proper operation, connect the system control lines
exactly as indicated.
2)If any of the control lines become disconnected while the
system is on, turn off all Synthesis components before
reconnecting control lines. This will reset all operation.
NOTES
Manual
On Auto On
S650A
IN
SPKR 1
SPKR 2
OUT
CAUTION
RISK OF ELECTRONIC SHOCK
DO NOT OPEN
AVIS: RISQUE DE CHOC
ELECTRIQUE-NE PAS OUVRIR
S650A Power Amplifier
JBL, INC.
Northridge, CA
Designed and Assembled in the USA Serial No.
Ch. 1
Ch. 1
Ch. 2 Ch. 3 Ch. 4 Ch. 5
+
-
Ch. 2
+
-
Ch. 3
+
-
Ch. 4
+
-
Ch. 5
+
-
Manual
On Auto On
CAUTION: SPEAKER IMPEDANCE ATTENTION: IMPEDANCE DE HAUT - PARLEURS 4 Min
TRIGGERS
Manual
On Auto On
S650A
IN
SPKR 1
SPKR 2
OUT
CAUTION
RISK OF ELECTRONIC SHOCK
DO NOT OPEN
AVIS: RISQUE DE CHOC
ELECTRIQUE-NE PAS OUVRIR
S650A Power Amplifier
JBL, INC.
Northridge, CA
Designed and Assembled in the USA Serial No.
Ch. 1
Ch. 1
Ch. 2 Ch. 3 Ch. 4 Ch. 5
+
-
