JBL C508GTi MkII User manual

For more than 60 years, JBL has been delivering products
embodying the technology developed in the professional
arena – equipping leading recording studios and movie
theaters, as well as live-music reinforcement in venues
ranging from dance clubs to Woodstock. We continue
to transform this expertise into products that provide the
impact and excitement of a live performance. The JBL®
experience is for enthusiasts who won’t settle for anything
less than “live” at home or on the go.
JBL GTi component systems originate in a decades-long
passion for studio accuracy and concert impact. Their
design demonstrates the technical acumen required to
sculpt sound with grace for car cabin acoustics. Here are
several of the key technologies that help GTi deliver an
incredible listening experience.
SYMMETRICAL FIELD
GEOMETRY™
SFG technology determines the precise shape of the
magnetic field in and around the magnetic gap. This
provides identical motor force both above and below the
gap. The benefit is low distortion, even at high excursion.
PURE-TITANIUM-DOME
TWEETERS
The JBL pure-titanium dome is suspended in a high-loss
rubber surround that is designed to damp dome
resonances. The benefit is smooth response, free
from fatigue, even at high-output levels.
EDGE-WOUND ALUMINUM
VOICE COILS
Using this 2" ribbon-shaped wire allows JBL engineers to
precisely specify the number of windings in the magnetic
gap. The benefits are distortion-free extension of high
frequencies and increased power handling.
FOURTH-ORDER LINKWITZ-
REILY ACOUSTIC PASSIVE
CROSSOVERS
Steep slopes minimize interaction between drivers. The
benefit is uniform system response in a variety of vehicle
mounting locations.
C608GTi MKII
6-1/2" (160mm) 2-Way Component System
•Power handling: 150W RMS, 600W peak
•Frequency response: 50Hz – 21kHz
•System impedance: 4 ohms
•Sensitivity: 89dB
•Voice-coil diameter: woofer – 2" (50mm)
edge-wound; tweeter –1" (25mm)
•Mounting depth: woofer – 2-11/16"
(68mm); tweeter – 1-1/8" (29mm)
•Overall diameter: woofer – 6-1/4"
(159mm); tweeter – 2-1/16" (53mm)
•Cutout diameter: woofer – 5-1/8"
(131mm); tweeter – 1-3/4" (45mm)
•Crossover dimensions (L x W x H):
6" x 4-1/2" x 1-3/4"
(153mm x 115mm x 45mm)
C508GTiMKII
5-1/4" (130mm) 2-Way Component System
•Power handling: 125W RMS, 500W peak
•Frequency response: 58Hz – 21kHz
•Sensitivity: 88dB
•System impedance: 4 ohms
•Voice-coil diameter: woofer – 2" (50mm)
edge-wound; tweeter – 1" (25mm)
•Mounting depth: woofer – 2-3/8"
(61mm); tweeter – 1-1/8" (29mm)
•Overall diameter: woofer – 5-1/4"
(133mm); tweeter – 2-1/16" (53mm)
•Cutout diameter: woofer – 4-5/8"
(118mm); tweeter – 1-3/4" (45mm)
•Crossover dimensions (L x W x H):
6" x 4-1/2" x 1-3/4"
(153mm x 115mm x 45mm)
Features, specifications and appearance are subject to
change without notice.
