JBL on stage micro II User manual

iPhone/iPod not included IiPhone/iPod non inclus
jblOn stage®' m iero II speaker dock for iPhone/iPod
OWorks
with
iPhone
User Guide
English 3-9
Deutsch 10-16
Franc;ais 17-23
Espano!... 24-30
Italiano 31-37
Nederlands 38-44
-~ ~
Korean ~ 2.45-51
Norsk 52-58
Dansk 59-65
Japanese 66-72
~ Y:. Simplified Chinese 73-79
Suomi 80-86
Svenska 87-93
PYCCKIIIVI 94-100
Portugues 101-1 07

Important Safety Instructions
Please read the following precautions before use:
FCC regulations I
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves
or other apparatus (including
amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. Apolarized plug
has two blades
with one wider than the other. Agrounding-type plug
has two blades and athird grounding prong.The wide
blade
or the third prong is provided for your safety. If the
provided plug does
not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched, particularly at plugs, convenience receptacles
and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket (I
or table specified by the manufacturer or
sold with the apparatus. When acart is used, _
use caution when moving the cart/apparatus
combination to avoid injuryfrom tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing
is required when the apparatus has been
damaged in any way, such
as power supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus
has been exposed
to rain or moisture, does not operate normally, or has
been dropped.
15. Do not expose this apparatus to dripping or splashing
and ensure
that no objects filled with liquids, such as
vases, are placed on theapparatus.
16. To completely disconnect this apparatus from the
AC Mains, disconnect the powersupply cord plug from
the
AC receptacle.
17. The mains plug of the power suppiy cord shall remain
readily operable.
18. Do not expose batteries to excessive heat such as
sunshine, fire or the like.
AThe lightning flash
with arrowhead symbol,
within
an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous
voltage"within the product's enclosure that
may be of sufficient magnitude to constitute arisk of
electric shock to persons.
AThe exclamation
point within an equilateral
triangle
is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the product.
WARNING: To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or moisture.
3
FCC Information For Users
This device complies with Part 15 of the FCC Rules. Operation is
subject to the follOWing two conditions: (1 )This device may not cause
harmful interference;
and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Radio and Television Interference
This equipment has been tested and found to comply with the limits
for a
Class Bdigital device, pursuantto Part 15 ofthe FCC Rules. These
limits are designed
to provide reasonable protection against harmful
interference in aresidential installation.This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance
with the instructions, may cause harmful
interference
to radio communications. However, there is no guarantee
that interference will not occur in aparticular installation.
If this
equipment does cause interference
to radio or television reception,
which can be determined
by turning theequipment off and then on,
the user
is encouraged to try to correct the interference by one or
more
of the follOWing measures:
•Increase the separation between theequipment and receiver.
•Connect the equipment
to adifferentoutlet so that the equipment
and receiver are on different branch circuits.
•Consult the dealer or an experienced radiolTV technician for help.
Changes or modifications
not expressly approved by JBL could void
the user's authority
to operate the equipment.
IC Statement and Warning
This
Class Bdigital apparatus complies with Canadian ICES-003. Cet
appareil numerique de
la cia sse Best conforme a la norme NMB-003
du Canada
Important Note for All Electronic Products:
Before inserting or unplugging audio cables from the source
deVice's headphones or line-level
output jacks, it is good
practice
to turn off the device first.This will prolong the life of
your unit, help protectyour device from static electricity and
prevent potential damage.

jbl on stage micro II easy setup guide
~
~
~
,mi.
o
~
~
Step 1. Carefully unpack your speaker
system and identifyall its components.
JBL On Stage Micro II, power supply,
remote and adapter.
Step
2. Move the battery door to the
unlocked position
to open the battery
compartment.
D
Step 4. Connect the power adapter into
thejack labeled"6V
DC In"on the rear
of the JBL On Stage Micro II and plug
the power adapter into awall outlet or
power strip.
G@E)C:::>@~
"" T ;
~
Step 3. Place 4AAA batteries in the
battery compartment.
*auxiliary audio
cables
not included
~
UD
or
o
~
~
Step 5. Place the appropriate iPhone/iPod adapter onto JBL On Stage Micro II.
Place your iPhoneliPod on the docking connector or connect a3.5mm (1/8") stereo
audio cable
to thejack labeled "Audio In"on the rear of the JBL On Stage Micro II.
Connect the audio cable to the audio source.
Step
6. Press the Power button on
the back
of the JBL On Stage Micro II.
Agreen LED will light when the JBL
On Stage Micro II system is on.
Step
7. Adjust the volume using (+) to
increase and (-) to decrease. Press both
to mutethe JBL On Stage Micro II. Press
either button to unmute.
Synching and transferring files with your computer
Make sure your iPhone/iPod is securely docked into the JBL On Stage Micro II. Connect a USB cable (not included) into the USB jack on the back of the unit, connect other end of the USB cable directly to your
computer's
USB port. Make sure your iPhone/iPod and iTunes are updated to the latest software version.
4

troubleshooting your jbl on stage micro II
1. The JBL On Stage Micro II is designed with abattery conservation mode (BCM) to extend the battery life, utilizing computer optimized equalization (COE). To select this
mode the system must first be turned"Off':
To enter the BCM option, the user then turns the unit"On"while holding the volume (-) button.The green and Red LEDs will
cycle
to show activation of the battery conservation mode. To exit this mode, the user must power the unit"Off"and back "On".
-
[
2. The JBL On Stage Micro II has a built in energy conservation mode (ECM). If no audio signal is detected for 10 minutes, the LED will turn off and the unit will be placed in
standby. Once
an audio signal is detected the system will return to normal operation and the LED will illuminate.
3. The On Stage Micro II LED will display various colors and modes depending on the state of the unit. Please see below for LED light indicator table
I
Green, Constant
Green, Flashing
Red, Constant
OSMII is"On"
OSMII
is muted
"Low"Battery
Red, Flashing
Green &
Red, Flashing for 3Cycles
No LED
OSMII muted and "low" battery state
Indicates selection
of Battery EQ mode
In Standby Mode or no power to unit
Volume Down
iPhone/iPod Play/Pause'
iPhone/iPod Previous/Rewind
*Hold
for"rewind"
iPhone/iPod Scroll Up
iPhone/iPod Menu
UBL
(~) ~))D
>11 ~
(1« »1)
(- -)
MENU f-J
Volume Up
Mute/Unmute'
iPhone/iPod Next/Fast Forward
*Hold for"fast forward"
iPhone/iPod Scroll Down
iPhone/iPod Select/Enter
'iPod touch and iPhone menu navigation may require the user
to manually put the iPhone/iPod in music mode.
5

troubleshooting your jbl on stage micro II
Technical Specifications
Frequency Response:
70Hz -20kHz
Power Consumption:
lOW Maximum
Power Input:
6V/l.SA
JBL On Stage Micro II Transducer:
(2) 1" Full range per channel
Dimensions:
Diameter -6"(lSOmm)
Height -1-3/4"(38mm)
System Weight:
0.67 Ib (0.30kg)
Battery:
OSMII Size -AAA (4 pes.)
Type -Alkaline, NiMh
Remote Control
Size - CR202S (1 pc)
Type -Lithium
DO NOT MIX BATTERYTYPES.
DO NOT MIX CHARGED AND PARTIALLY
CHARGED BATTERIES.
BATTERIES WILL NOT RECHARGE WHILE IN
JBL ON STAGE MICRO II.
CAUTION: RISK OF EXPLOSION OF BAT-
TERY IF REPLACED WITH AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
No sound from the JBL
On Stage Micro II speaker
system
No power
to the system or power
supply
is not inserted correctly
The volume may be set
too low
Issue with auxiliary audio source
Issue
with iPhone/iPod source
Low or drained batteries
Ensure thatthe power supply is connected to alive power
source and properlyconnected
to the JBL On Stage Micro II.
Note: When the JBL On Stage Micro lIis powered, agreen
power
LED on the top of the system will illuminate.
Touch
the volume"Up" (+) button to increase system
volume level. Note:
See the Easy Setup guides for an
overview of volume and other system functions.
Make sure
an auxiliary cable is properly connected to
a known reliable source. Test the audio source with
headphones.Turn up the volume of the source.
Make sure
that the iPhone/iPod is properly docked. Make
sure iPhone/iPod
is not paused; press the Play button on
the iPhone/iPod or remote control.Try connecting your
iPhone/iPod from it's heaphone jack.
Replace the batteries.The green
power LED will change
to red when batteries need to be replaced.
If you have any questions or need further assistance, please visit www.jbl.com.
These specifications are subject
to change without notice. 6

I
No sound, no LED INo audio signal has been received for
10 minutes and the system is in energy
conservation mode
No sound,
no LED (running from batteries) IThe power supply may still be connected to
the "6V DC In"jack
Distortion (static, crackling or hissing sounds) IAudio source or source material maybe the
problem
Volume level may be
too high
EQ setting may be too high
Make sure iPhone/iPod
is not paused; press the Play button on the
iPhone/iPod or remote control. Make sure audio signal is supplied
through docked iPhone/iPod or"Audio In"jack; increase volume of
source if needed.
When battery operation
is desired, place 4fresh AAA batteries in the
battery
compartment and disconnect the power supply from the JBL
On Stage Micro II.
Test the JBL On Stage Micro II with another source. Note: Does the
distortion occur with specific songs? If so, check the recording or record
the source again.
Check the volume
of the source. Note: Some devices will distort the
output signal if the source's volume is set to maximum.
Check the
EQ setting on your iPhone/iPod or source device. Note: It is
recommended that you set the source device EQ to "Flat"or"Off:'
Loud hum or buzzing noise
Input cable is not plugged in properly
Cable may be bad
Ground
loop (an unsuitable connection)
7
Check the input cable connection.
Replace the cable
with a3.5mm (1/8") stereo audio cable.
Turn
the JBL On Stage Micro II off and connect it to another wall outlet.

Maximum volume is reduced
Sound comes from only one side/channel
The system has been placed in battery
conservation mode
iPhone/iPod
or auxiliary cable is not seated
properly
Turn the system
"0ff" and then back "0
n
/: This will reset the system to
the normal equalization mode. Adjust "_" and "+" volume buttons as
desired.
Make sure
that the iPhone/iPod is seated all the way into the docking
station. Make sure
that the auxiliary cable is seated all the way into the
"Audio In"jack.Try resetting the iPhone/iPod.
Note:
If you are using a3.5mm auxiliary extension cable, make sure it is
astereo cable.
Speaker system experiences radio-frequency I
Input cable may be picking up interference
interference or picks
up aradio-station trans-
mission
8
Purchase aferrite core and wrap the excess cable around it. Aferrite
core can be purchased at your local electronics store.

JBL and Odyssey are trademarks of Harman International Industries, Incorporated, registered in the United States and/or other countries.
The trademark
On Stage is used with permission of OSA International, Inc.
iPhone, iPod, iTunes and iPod touch are trademarks
of Apple Inc., registered in the U.S. and other countries. iPhone/iPod not included."Made for iPod" means that an electronic accessory has been
designed
to connect specifically to iPod and has been certified by the developer to meet Apple performance standards. "Works with iPhone" means than an electronic accessory has been designed
to connect specifically to iPhone and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety
and regulatory standards.
Features, specifications and appearance are subject
to change without notice.
H Harman International
Harman Consumer Group, Inc,
8500 Balboa Boulevard, Northridge, CA 91329 USA
1.5 16.255.4525 (USA only)
www.jbl.com
©2010 Harman International Industries, Incorporated. All rights reserved.
Part Number: 950-0282-001 rev. C
9
I

JBL and Odyssey are trademarks of Harman International Industries, Incorporated, registered in the United States and/or other countries.
The trademark On Stage
is used with permission of OSA International, Inc.
iPhone,
iPod, iTunes and iPod touch are trademarks of Apple Inc., registered in the u.s. and other countries. iPhone/iPod not included."Made for iPod" means that an electronic accessory has been
designed
to connect specifically to iPod and has been certified by the developer to meet Apple performance standards. "Works with iPhone" means than an electronic accessory has been designed
to connect specifically to iPhone and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety
and regulatory standards.
Features, specifications and appearance are subject
to change without notice.
JBL et Odyssey sont des marques commerciale de Harman International Industries, Incorporated, deposee aux Etats-Unis et/ou dans d'autres pays.
La marque commerciale On Stage est utilisee avec I'autorisation d'OSA International, Inc.
iPhone, iPod, iTunes et
Ipod touch sont des marques deposees Apple Inc., deposee aux Etats-Unis et dans d'autres pays. iPhone/iPod non inclus.« Made for iPod »signifie que Ie dispositif
electronique aete specialement
con~u pour se connecter al'iPod etqu'il est certitie par Ie developpeur comme conforme aux normes de performance Apple.« Works with iPhone» signifie que Ie
dispositifelectronique aete specialement con~u pour se connecter al'iPhone et qu'il est certitie par Ie developpeur comme conforme aux normes de performance Apple. Apple n'est pas responsable
du fonctionnement de
ce dispositifou de sa conformite avec les normes de securite ou reglementaires.
Les fonctionnalites, les specifications et I'aspect du produit peuvent etre modifies sans preavis.
HHarman International
Harman ConsumerGroup, Inc.
8500 Balboa Boulevard, Northridge, CA 91329 USA
1.516.255.4525 (USA only)
www.jbl.com
©2010 Harman International Industries, Incorporated. Ali rights reserved. Tous droits reserves.
Part Number: 950-0282-001 rev. (

Harman Multimedia 1-year limited warranty
This is an importantdocument. Attach your bill of sale to this card and keep it in asafe place.
Your bill
of sale is yourwarranty
The Harman Multimedia warranty remainsin effectfor
ONE YEAR from thedate of thefirst
consumer purchase.
WHO IS PROTECTED BY THIS WARRANTY
The Harman Multimedia warranty protectsthe original
ownerand all subsequentowners provided
that theHarman Multimedia product was purchased from an authorized dealer:
A
copyof theoriginal dated bill of sale must be presentedwhenever warrantyservice is required.
WHAT
IS COVERED BY THIS WARRANT Y
Except
as specified below,the Harman Multimedia warrantycovers all defects in material and
workmanship. The followingare
NOT covered: Damage caused byaccident, misuse, abuse, product
modification, or neglect;damageoccurring during shipment; damagefrom failure to follow instructions
contained in thesetup guide; damageresulting from the performance
of repairs bysomeone not authorized
byHarman Multimedia; damagecaused byinstallation
of parts that do not conform to Harman
specifications; units used for
other than homeand office use; anyclaims based on misrepresentations
bythe seller; products sold on
an "as-is" or final sale basis; or the cost of installing, removing, or
re-installing the unit. Harman Multimedia's liability is limited to therepair or replacement,at our option,
of anydefectiveproductand shall not include incidental or consequentialdamages. Harman Mu.ltimedia
reserves theright
to replace adiscontinued model with acomparablemodel. Any replacementunits or
parts may be newor rebuilt.
IF PURCHASED OUTSIDE OF THE UNITED STATES
If the productwas purchased outside ofthe United States, please contactyourlocal authorized
Harman Multimedia Distributor for details on warranty service.
Do
not return products to the Harman Multimedia Distributor without authorization. They will be
returned unopened.
You are responsible for transportingyour productfor repair or replacement.
IF PURCHASED IN THE UNITED STATES
You are responsible for transporting your product for repair or replacement. Harman Multimedia
will pay reasonable return charges for delivery
to any location in the United States if the repair or
replacement is covered underthis warranty
TO OBTAIN WARRANTY SERVICE IN THE UNITED STATES
Ifyou require warranty service for JBL products call 516-255-4525 for information and RMA number.
If you require warranty service for harman/kardon products call 516-255-4545 for information and RMA number.
Correspondence
with Harman Multimedia should beaddressed to Harman Multimedia
Customer Service. 8500 Balboa Blvd., Northridge, California 91329.0utside theUnited States,
please contactyour local distributor
or dealer:
This warranty gives you specific legal rights.
You mayalso have other rights that va ry from state
to state. Some states do not allowtheexclusion or limitation of incidental or consequentialdamages
or limitations on
how long an implied warranty lasts, so theabovemay not apply to you.
harman multimedia
8500 Balboa Blvd. Northridge, Ca 91329
Document Number: 950-0084-002 Description: Warranty Information Card

Garantie Iimitee Harman Multimedia
Les produits Harman Multimedia enumeres plus bas sont garantis pendant la periode stipulee a compter de la date de I'achat original.
Produits
Multimedia 1annee
QUI
EST PROTEGE PAR CETTE GARANTIE
Votre garantieHarman
Multimedia protege Ie proprietaire original du produit Harman Multimedia pourvu que Ie produit ait ete achete
sur
Ie territoire canadien d'un marchand agree et dument autorise par Harman Multimedia avendre de tels produits au moment de
I'achat original
ou qui aurait ete achete par du personnel militaire dans un point de vente en territoire militaire autorise. Le service sur
garantieest
disponible seulementdans Ie pays ou aeu lieu I'achatoriginal. Pour obtenir de I'information sur la garantiehors du territoire
canadien, nous vous prions de
communiqueI' avec votre marchand local ou encore avec Ie distributeur national. Le service sur garantie
est disponible aussi
longtemps que la preuve d'achat originale est presentee lorsque du service sur garantie est demande. Nous vous
recommandons
de joindre et attachera la presente garantie une copie de votre facture et de ranger Ie tout dans un endroit sur.
QU'EST-CE QUI EST PROTEGE
Votregarantie Harman Multimedia vous protege contre tout defaut de fabrication et de main d'oeuvreaI'exception descauses suivantes
:
(1) les dommages causes par un accident,un usagederaisonnable ou negligent (y compris I'absenced'entretien necessaire et dit raison-
nable);
(2) les dommages survenus durant I'expedition (Ies reclamations doivent etre achemineesau transporteur); (3) les dommages a
au la deterioration de tout accessoire au surface decorative; (4) les dommages decoulant du defaut de suivre les instructions contenues
dans
Ie manuel du proprietaire; (5) les dommages resultant du fonctionnement suite ades reparations faites par du personnel autre que
celui d'un atelier de reparation agree Harman Multimedia; (6) de tout appareil Harman Multimedia dont Ie numero de serie sera it efface,
altere
ou enleve; (7) d'appareils utilises pour un usage autre que domestique. Cette garantie ne couvre que les defaillances detectees
dans
Ie produit lui-meme etelle ne couvre pas les COlns d'installation ou d'enlevement sur uneinstallation fixe, Ie montage normal et les
ajustements, des reclamations basees sur une
information trompeuse de la part du marchand ou de variantes de rendement decoulant
de circonstances reliees aI'installation telle la qualite de la source sonore ou I'alimentation secteur.
REMARQUE : La reparation de notre produit doit etre accomplie par un marchand ou un centre de service agree. Une reparation non
autorisee annulera la garantie et elle est faite au risque du consommateur.
COMMENT
OBTENIR DU SERVICE SUR GARANTIE
Si votre produit Harman Multimedia requiert du service, nous vous prions de retourner Ie produit avotre marchand au Canada. Si ceci
n'est pas possible et
que vous vivez hors du Canada, rendez-vous sur notre site web au www.harman-multimedia.com ou appelezau
516-255-4545
pour obtenir la localisation de I'atelier de reparation sur garantie la plus pres de chez vous ou ecrivez aHarman Multi-
media 8500 Balboa Blvd., Northridge, California 91329 USA (il I'attention du Service a la clientele).Vous devrez presenter votre preuve
d'achat originale au representant
de I'atelier de reparation sur garantie pour etablir la date d'achat.
QUI
PAlE POUR QUOI
Harman
Multimedia defraiera taus les couts de main d'oeuvre et de materiel pour toute reparation faite pendant la duree de la protec-
tion offerte par cette garantie. Si les reparations necessaires ne sont pas couvertes par cette garantie ou si I'appareil est verine et il
s'avere qu'il ne requiert aucune reparation, les couts
de I'examen vous seront alors factures.
Le proprietaire doit payer tout frais d'expedition decoulant de I'envoi du produit Harman Multimedia a un atelier de reparation agree
Harman
Multimedia situe au Canada. Nous debourserons des frais de port raisonnables pour Ie retourvel's toute destination au Canada
si les reparations sont sujettes a la protection offerte par la garantie. Assurez-vous de bien conserver Ie materiel d'emballage d'origine
sinon une charge
additionnelle vous sera facturee pour Ie nouvel emballage.
INFORMATION
Si vous avez des questions concernant I'installation ou Ie fonctionnement de cet appareil. nous vous prions d'appeler Ie service a la
clientele au 516-255-4545 ou encore de nous envoyer un cOlmiel a[email protected] ou ecrivez-nous aHarman Multimedia
8500 Balboa Blvd., Northridge, California 91329 USA (a I'attention du Service a la clientele).
LIMITATION
SUR LES GARANTIES IMPLICITES
LES GARANTIES IMPLICITES SUR LA QUA LITE MARCHANDE ET L'APTITUDE A UN EMPLOI PARTICULIER SONT L1MITEES
ENTEMPS A LA DUREE DE LA PRESENTE GARANTIE SAUF EN CAS D'AVIS CONTRAIRE DECOULANT D'UNE LEGISLATION
PROVINCIALE OU LOCALE.
EXCLUSION DE CERTAINS DOMMAGES
LA RESPONSABILITE DE HARMAN MULTIMEDIA SE LIMITE A LA REPARATION OU AU REM PLACEMENT, A NOTRE DISCRE-
TION, DE TOUT PRODUIT DECLARE DEFECTUEUX ET NE DEVRAIT COMPRENDRE EN AUCUNS CAS DE DOMMAGES DE
NATURE INCIDENTE OU CONSEQUENTE DE TOUTES NATURES.
CERTAINES PROVINCES NE PERMETTENT AUCUNES LIMITATIONS SUR LA DUREE DE LA GARANTIE IMPLlCITE ET/OU NE
PERMETTENT PAS D'EXCLUSIONS CONCERNANT LES DOMMAGES INCIDENTS OU CONSEQUENTS, LES LIMITATIONS ENU-
MERtES PLUS HAUT PEUVENT DONC NE PAS S'APPLIQUER A VOUS.
Cette garantie vous octroie des droits legaux specifiques et vous pourriez aussi beneficier d'autres droits variant d'une province aune
autre.
Nous vous remercions en
toute sincerite pour I'expression de cette marque de connance envers les produits de la marque Harman
Multimedia.Cet appareil aete assemble avec d'infimes precautions par des artisans
tirant profit d'une formation tres poussee.1I devrait
vous procurer de nombreuses annees de rendement musical de grande qualite.
harman
multimedia
8500 Balboa Blvd., Northridge, CA 91329 USA
www.harman-multimedia.com
Document Number: 950-0084-002 Description: Warranty Information Card
