JBL Control Control 26CT User manual

JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
JBL CONTROL 26CT REV E
PACKAGE WIRING DIAGRAM
05-03
Technical Manual
JBL CONTROL 26CT
SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance: 16 ohms
• Power Capacity: 140W Continuous Program
• Frequency Range: 75 Hz to 20 kHz
• Sensitivity: 89 dB, 1 Watt @ 1 Meter
• Crossover Frequency: 4 kHz
SYSTEM COMPONENTS:
• Cabinet:
• Grille: 389-00029-01
• Woofer, Tweeter 152mm (6in.)
Transducer: 124-16000-00
• DC Resistance: 12.8 ohms
• Taps 60W, 30W, 15W and 7.5W at 70V
60W, 30W, and 15W at 100V
SYSTEM COMPONENTS: (cont’d)
• Crossover Network: 129-20048-00
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test: 12.0V*Input, 75 Hz to 20 kHz
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions: 210mm x 252mm Dia.
(8.3 x 9.9 in. Dia.)
• Shipping Weight: 24 lbs. (10.88 kg.) (in Pairs)
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
Warranty 59660
Owners Manual
CEILING SPKRMAN
Ceiling Rails (4)
888-00062-00
C-Bracket (2)
888-00061-02 SCHEMATIC 129-20048-00
Network
129-20048-00
Woofer, Tweeter
124-16000-00
RED
BLK
BLK
WHT
Woofer
Tweeter
RED
BLK
RED
NOTE:
All Models with Line Transformers are Tested at the Lowest Power Position
(3.7W/70V for the 24CT, and 7.5W/70V for Both the 26CT and 19CST Models),
with a Reversed Transformer in the Same Power Position Between the
Speaker and the Amplifier.
SW YEL
GRN
BLK
*
ORG
VIO
BLU
WHT
WHT
BLK
INPUT
L1
0.445mH
C1
2.0µF
PCT
RXE065
T1
562-00036-00

JBL CONTROL 26CT
JBL CONTROL 26CT
COMPONENT EXPLODEDVIEW
Seismic Bracket
Assembly
396-00006-00
396-00007-00
Can
885-00047-00
Grille
389-00029-01
Woofer, Tweeter
With Horn
124-16000-00
Transformer Switch
Assembly
562-00036-00
Baffle
Not for Sale
Input Connector
424-00092-00
Switch Cover
923-00019-01
Mounting Tab (4)
885-00050-00
Crossover Network
129-20048-00
