JBL ATX SUB 100 User manual

ATX 100 SUB
Service manual
Am
p
lifier : SUB 100
21 August 2002

SUB 100 Amp
material No
material description
quantity
12314j70d
Ferrite Core J70
1
132104kb70
mylar capacitor 0.1u 275v
+
10%
1
150e8604106
transformer EI-86 230v/50Hz TT0869803320 1
152v602026
power cable SP-021A 6FT VDE
1
154v12506t0
fuse TSD 1.25a 25.v vde
1
155520020
fuse bracket R3-11
1
16210082007
wire red awg18 80mm#1015
1
16250652002
wire 650mm
1
16311009
plastic binding wire trasparent 100mm
2
16311509
nylon binding wire transparent 150mm
1
176wjcel
closed edge terminal CE-1
1
180prf1003s
power sw rock PF-103-bb2-OHA
1
1932m1813
piezo sheet TO-220 18*13mm
2
600b8401200
wood screw 4*12
4
602c8401610
mechanic screw M4*16 type "+"
4
602f8301200
mechanic screw M3*12 type "+"
1
602p8300800
mechanic screw M3*8 type "+"
6
606p8301000
B type self screw 3*10: type "+" black
5
607p8300800
B type self screw 3*8: type "+" black
8
610gm4b
M4 nut
4
640rp110w
aluminum plate
1
644a110w
copper foil 65L*50W
1
650ih125
IC holder
1
650sub240
PCB bracket L TYPE t=1.6mm S.P.C.C
2
653hs110w
heat sink 117.5*71.5*25 anodization silver
1
700kb800
plastic rotary switch 46077-w soft P.V.C
2
700ac800
power cable knob 4K-4 NO-BB
1
700rc110w
rear housing
2
723a110w
EVA gasket width 200*12*2.0mm
2
723b110w
EVA gasket length 276*12*2.0mm
2
723c110w
EVA gasket width 200*12*1.0t
2
723d110w
EVA gasket length 276*12*1.0t
2
725a125
rubber gasket 25*21*4t
4
860a135
sticker " made in China"
1

PART NO. DESCRIPTION
QTY
REFERENCE
197 50 73 Complete AMP 230V 110W 1
2101OTLX110W PCB ASS'Y AMP 1
3101ATLX110W AI PCB ASS'Y 1
4104tlx11000 PCB 1
511012472j52 RESISTOR 4.7K 1/2W ±5% CF 2R201,2
611014560j26 RESISTOR 56 1/4W ±5% CF 1R117
711016101j26 RESISTOR 100 1/6W ±5% CF 1R120
811016102j26 RESISTOR 1K 1/6W ±5% CF 6R124,66,213,4,5,54
911016103j26 RESISTOR 10K 1/6W ±5% CF 17 R133,4,209,16,7,20,1,5
,6,8,32,5,48,60,212,22,40
10 11016104j26 RESISTOR 100K 1/6W ±5% CF 4R163,4,231,66
11 11016105j26 RESISTOR 1M 1/6W ±5% CF 2R143,259
12 11016123j26 RESISTOR 12K 1/6W ±5% CF 3R135,9,65
13 11016124j26 RESISTOR 120K 1/6W ±5% CF 1R233
14 11016151j26 RESISTOR 150 1/6W ±5% CF 1R253
15 11016152j26 RESISTOR 1.5K 1/6W ±5% CF 7R103,23,36,7,41,2,53
16 11016153j26 RESISTOR 15K 1/6W ±5% CF 5R118,45,52,4,234
17 11016154j26 RESISTOR 150K 1/6W ±5% CF 6R131,203,4,5,6,52
18 11016181j26 RESISTOR 180 1/6W ±5% CF 2R111,4
19 11016183j26 RESISTOR 18K 1/6W ±5% CF 2R227,62
20 11016205j26 RESISTOR 2.0M 1/6W ±5% CF 1R257
21 11016223j26 RESISTOR 22K 1/6W ±5% CF 9
R128,9,55,6,8,
60,238,47,55
22 11016273j26 RESISTOR 27K 1/6W ±5% CF 2R223,37
23 11016332j26 RESISTOR 3.3K 1/6W ±5% CF 3R106,7,44
24 11016392j26 RESISTOR 3.9K 1/6W ±5% CF 2R105,8
25 11016393j26 RESISTOR 39K 1/6W ±5% CF 1R126
26 11016470j26 RESISTOR 47 1/6W ±5% CF 4R112,3,5,6
27 11016471j26 RESISTOR 470 1/6W ±5% CF 3R140,61,2
28 11016472j26 RESISTOR 4.7K 1/6W ±5% CF 10
R110,25,30,47,
50,7,9,200,7,58
29 11016473j26 RESISTOR 47K 1/6W ±5% CF 5R101,219,49,50,1
30 11016512j26 RESISTOR 5.1K 1/6W ±5% CF 2R210,1
31 11016513j26 RESISTOR 51K 1/6W ±5% CF 1R224
32 11016563j26 RESISTOR 56K 1/6W ±5% CF 1R104
SUB 100 PART LIST

33 11016681j26 RESISTOR 680 1/6W ±5% CF 2R148,51
34 11016682j26 RESISTOR 6.8K 1/6W ±5% CF 3R109,229,30
35 1302b101k503 DISC CAPACITOR 100P 50V ±10% 3C104,39,40
36 1302b102k503 DISC CAPACITOR 1000P 50V ±10% 2C116,41
37 1302b221k503 DISC CAPACITOR 220P 50V ±10% 12
C204,5,7,8,10,1
,2,4,20,30,200,49
38 1302f104z503 DISC CAPACITOR 0.1U 50V +80/-20% 13
C108,13,5,9,37,8,
232,42,4,5,6,52,4
39 1303f473m503 DISC CAPACITOR 0.047U 50V ±20% 1C106
40 130sl470k503 DISC CAPACITOR 47P 50V +350/-1000 1C229
41 132103j503 MYLAY CAPACITOR 0.01U 50V ±5% 2C223,4
42 132104j503 MYLAY CAPACITOR 0.1U 50V ±5% 4C107,218,21,2
43 132223ja03 MYLAY CAPACITOR 0.022uF 100V ±
5%
9
C123,4,5,6,7,8,31,2,215
44 132473j503 MYLAY CAPACITOR 0.047U 50V ±5% 2C216,7
45 1353105m50 ELECTROLYTIC CAP 1U 50V ±20% 3C105,12,228
46 1353106m50 ELECTROLYTIC CAP 10U 50V ±
20%
10
C201,2,6,13,9,
31,41,3,51,3
47 1353107m16 ELECTROLYTIC CAP 100uF 16V ±
20%
5C109,10,7,20,234
48 1353107m50 ELECTROLYTIC CAP 100U 50V ±
20%
2C135,6
49 1353226m50 ELECTROLYTIC CAP 22U 50V ±20% 3C114,8,225
50 1353227m10 ELECTROLYTIC CAP 220U 10V ±20% 2C129,30
51 1353227m16 ELECTROLYTIC CAP 220U 16V ±
20%
1C111
52 1353336m16 ELECTROLYTIC CAP 33U 16V ±20% 1C233
53 1353476m25 ELECTROLYTIC CAP 47U 25V ±
20%
1C103
54 192027c1815gr TRANSISTOR 2SC1815GR 10
Q102,11,2,3,8,
23,6,201,6,7
55 192027c2235y TRANSISTOR 2SC2235Y 1Q121
56 192028a1015gr TRANSISTOR 2SA1015GR 4Q114,6,22,7
57 192028a965y TRANSISTOR 2SA965Y 1Q125
58 1921672n5551 TRANSISTOR 2N5551 2Q103,9
59 1921682n5401 TRANSISTOR
2N5401 AI-PNP 350V 500mA
2Q104,10
60 197131n4148 1N4148 19
D101,3,5,8,13,4,201,
2,3,4,5,6,7,8,11,2,4,5,
61 19915000335 3.3V 1/2W 2D102,213
62 19915000625 6.2V 1/2W 2D106,7
63 19915001605 16V 1/2W 1D109
64 101OTLX110WA PCB ASS'Y 1
65 101ATLX110WA AI ASS'Y 1

66 104tlx1100a PCB 1
67 11016103j26 RESISTOR 10K 1/6W ±5% CF 9R301,2,3,4,8,9,14,40,4
68 11016223j26 RESISTOR 22K 1/6W ±5% CF 2R310,2
69 11016273j26 RESISTOR 27K 1/6W ±5% CF 1R341
70 11016333j26 RESISTOR 33K 1/6W ±5% CF 1R305
71 11016472j26 RESISTOR 4.7K 1/6W ±5% CF 2R342,3
72 11016474j26 RESISTOR 470K 1/6W ±5% CF 1R307
73 11016751j26 RESISTOR 750 1/6W ±5% CF 2R311,3
74 11016755j26 RESISTOR 7.5M 1/6W ±5% CF 1R306
75 1302f104z503 DISC CAPACITOR 0.1U 50V +80/-20% 2C305,6
76 132103j503 MYLAY CAPACITOR 0.01U 50V ±5% 2C302,3
77 1353226m50 ELECTROLYTIC CAP 22U 50V ±20% 2C301,40
78 1353476m25 ELECTROLYTIC CAP 47U 25V ±20% 1C304
79 192027c1815gr TRANSISTOR 2SC1815GR 2Q301,2
80 197131n4148 1N4148 2D301,2
81 1759f40hr2 40PIN PITCH=2.54mm HR2*40 0.13 P301
82 19016tl074cn I.C. TL074CN ST 1U301
83 11010821jk1 RESISTOR 820 1W ±5% 1R132
84 110122r2j15 RESISTOR 2.2 1/2W ±5% 1R127
85 113500r1j10 CEMENT RESISTOR 0.1 5W 2R121,2
86 11403302m0 SEMI-FIXED RESISTOR 3K 0.3W ±20% 1R138
87 115h203b208 VARIABLE RESISTOR B20K 1VR202
88 115h503a104 VARIABLE RESISTOR D16 50K/1 A 1VR201
89 1354478m35 ELECTROLYTIC CAP 4700U 35V ±20% 2C121,2
90 1354478m50 ELECTROLYTIC CAP 4700U 50V ±20% 2C133,4
91 171udhss124d RELAY 5A 24V UDH-SS124D 1RY101
92 1740300390g JACK 1JK202
93 1742psz406g1 JACK S-8071 1JK203
94 1742psz406g2 SPK JK 4PIN S-8072 1JK203
95 180tms7210v SWITCH SLIDE 6PIN MS7210V 1SW201
96 19006m4558d I.C. OPA 4558D 2U101,203
97 19016tl074cn I.C. TL074CN ST 2U201,2
98 192011d669a TRANSISTOR 2SD669A 1Q106
99 192012b649a TRANSISTOR 2SB649A 1Q105
100 192021c1815gr TRANSISTOR 2SC1815GR 2Q101,15
101 192021tip35c TRANSISTOR TIP35C 1Q107

102 192022tip36c TRANSISTOR TIP36C 1Q108
103 192161tip41c TRANSISTOR TIP41C NPN SGS 1Q124
104 192162tip42c TRANSISTOR TIP42C PNP SGS 1Q120
105 192201d882y TRANSISTOR KSD882Y 1Q117
106 192202b772y TRANSISTOR KSB772Y 1Q119
107 19700kbl405 4A 500V KBL405 2D110,5
108 197101n4002 1N4002 1D104
109 197101n5402 1N5402 2D111,2
110 197131n4148 1N4148 1D115
111 150e8604106 TRANSFORMER TT0869803320 1
112 152v602026 LINE CORD SP-021A 6FT VDE 1
113 154v12506t0 FUSE TSD 1.25A 250V VDE 1
114 155520020 FUSE HOLDER R3-11 1
115 180prf1003s POWER SW ROCK RF-1003-BB2-OHA 1
