JBL BASSPRO User manual

Service Manual
BASSPRO
SpecificationBassPro™
Subwoofer type 165mm
Enclosure type Band-pass Box
Power handling RMS 100W
Freq. response 20-100Hz
RCA Input Yes
High Level Input Yes
Remote Level Control
Input
Yes (option)
Variable Electronic
Crossover
70Hz – 100Hz

NO. Part number Description Remark
-431-000-00753 Packing material - EPE
-406-000-00929 owner's manual
-405-000-00285 warranty card
-402-000-01592 Gift Box
-400-000-03792 Master Carton
-371-000-00330 Screw ASS'Y
-283-000-00135 unweaven bag
1 + 4 241-060-00541 Wooden Cabinet port tube inside Not for sale
2 + 3 301-ABS-00352 Baffle ASS'Y equals ABS side and logo inclued
5325-ABS-00420 Foot Bracket - left
6325-ABS-00421 Foot Bracket - right
7352-HM0520D596 SCREW FOOT
806-T4455097 SCREW FOOT
916PF11BZW-AW02 Woofer
10 166-AL035081 cable wire
11 011-AA08-00268 AMP ASS'Y

REFERENCE DESCRIPTION PART NO.
-AMP ASS'Y Complete 011-AA08-00268
- PCB ASS'Y Complete 051-AA00-00534
R5,6,7,8 Resistor100Ω2W ±5% 20mm 110-20101j20
R10 Variable Resistor R0901N-JMD1-B20K 115-v203b101
R12 Variable Resistor R0901G-2KDQ-B20K 115-v203b202
L2 Inductor 100UH 1/2W 120-12101k3
L1 Inductor Ferrite 5uH 15A CR630*5R0KUM 122-14050k4160
C16 Electrolytic Cap. 3300U 25V ±20% 135-4338m25
F1 Fuse 20A 32V ATC UL/CSA 154-k020a800
F1 Fuse Holder F30240100P 155-9f30240
JK1 JACK 2PIN RCB-202HAG 174-0rcb202ha
JK3 DC JACK TE1-12J 174-5te112j
M104 M/JACK D/S 6P4C 174-9mjd0604
CH1,2,3,4 Wire connector 2PIN pitch=3.96mm 175-1d02v01
JK2 Wire connector 4PIN pitch=4.2mm 175-9h04v01
SW40 PUSH SW SSP752209-25JJ1 180-p752209
U1 I.C. NJRC NJM4558L 190-06m4558l
IC301 I.C. NS LM13700 190-14m13700n
IC101,21 I.C. TDA7377 190-16a73770
PWR LED RED 3mm FOR STANDBY 195-10204hd
D1 Diode 1N5402 197-101n5402
R01,25,32,40 Resistor 1K 1/6W ±5% CF 110-16102j26
R11,3,20,44,102,305,7,12 Resistor 10K 1/6W ±5% CF 110-16103j26
R45 Resistor 1M 1/6W ±5% CF 110-16105j26
R311 Resistor 150Ω1/6W ±5% CF 110-16151j26
R304,9 Resistor 15K 1/6W ±5% CF 110-16153j26
R42,310 Resistor 150K 1/6W ±5% CF 110-16154j26
R14 Resistor 220K 1/6W ±5% CF 110-16224j26
R16 Resistor 27K 1/6W ±5% CF 110-16273j26
R46 Resistor 2.7M 1/6W ±5% CF 110-16275j26
R306 Resistor 30K 1/6W ±5% CF 110-16303j26
R26 Resistor 3.3K 1/6W ±5% CF 110-16332j26
R21 Resistor 33K 1/6W ±5% CF 110-16333j26
R15 Resistor 39K 1/6W ±5% CF 110-16393j26
R31 Resistor 4.7K 1/6W ±5% CF 110-16472j26
R33 Resistor 47K 1/6W ±5% CF 110-16473j26
BASS PRO AMP
PCB ASS'Y

REFERENCE DESCRIPTION PART NO.
R43 ,34 Resistor 470K 1/6W ±5% CF 110-16474j26
R302,3 Resistor 510Ω1/6W ±5% CF 110-16511j26
R0 Resistor 51K 1/6W ±5% CF 110-16513j26
R47 Resistor 510K 1/6W ±5% CF 110-16514j26
R23 Resistor 680Ω1/6W ±5% CF 110-16681j26
R1,2 Resistor 6.8K 1/6W ±5% CF 110-16682j26
R30,301 Resistor 8.2K 1/6W ±5% CF 110-16822j26
R3,4 Resistor 91K 1/6W ±5% CF 110-16913j26
R22 Resistor 1.1K 1/6W ±1% MF 116-161101f26
C2,01,02,42,3 Disc Cap. 1000P 50V ±10% 130-2b102k503
C15,7,26,8,107,25,306,7 Disc Cap. 0.1U 50V +80/-20% 130-2f104z503
C29,30 Mylar Cap. 0.01U 50V ±5% 132-103j503
C6,7,25 Mylar Cap. 0.1U 50V ±5% 132-104j503
C5,21,2,3,4,40,303 Electrolytic Cap. 1U 50V ±20% 135-3105m50
C1,8,13,109,301 Electrolytic Cap. 10U 50V ±20% 135-3106m50
C14 Electrolytic Cap. 1000U 16V ±20% 135-3108m16
C27 Electrolytic Cap. 220U 16V ±20% 135-3227m16
C304 Electrolytic Cap. 4.7U 50V ±20% 135-3475m50
C41,102,23 Electrolytic Cap. 47U 50V ±20% 135-3476m50
Q31,40,301 Transistor 2SC1815GR 192-027c1815gr
Q32,41,2 Transistor 2SA1015GR 192-028a1015gr
D2,4,40,1,2 Diode 1N4148 197-131n4148
D5,D6 Zener Diode 5.1V 1/2W 52mm TAP 199-15000515
D3 Zener Diode 6.2V 1/2W 199-15000625
- SPEAKER WIRE #1015 400mm 162-a040d001
- Remote Control complete 015-AA00-00110
- RC WIRE 5M BLK 162-a5000001
NA PCB ASS'Y 051-0000-00288
- Res 2K 1/6W ±5% CF 26mm TAP 110-16202j26
- Res VR701 20K RD902-20-15K-A24 115-h203a203
- JACK 623 6P4C 3U 174-96236p4c
NA 3*8 b type screw 352-AM03008D040
NA 3*10 b type screw 352-BM0310D064
NA top cover 303-FE-00111
NA bottom cover 323-AL-00101
- volume knob 311-ABS-00237
REMOTE CONTROL
