jcb 4CX User manual

OPERATOR'S MANUAL
BACKHOE LOADER
4CX Wastemaster Eco, 5CX Wastemaster Eco
EN - 9831/8300 ISSUE 2 - 06/2018
THIS MANUAL SHOULD ALWAYS STAY WITH THE MACHINE

OPERATOR'S
MANUAL
BACKHOE LOADER
4CX Wastemaster Eco,
5CX Wastemaster Eco
EN - 9831/8300 - ISSUE 2 - 06/2018
This manual contains original instructions, verified by
the manufacturer (or their authorized representative).
Copyright 2018 © JCB SERVICE
All rights reserved. No part of this publication may
be reproduced, stored in a retrieval system, or
transmitted in any form or by any other means,
electronic, mechanical, photocopying or otherwise,
without prior permission from JCB SERVICE.
www.jcb.com
Foreword
The Operator's Manual
You and others can be killed or seriously injured
if you operate or maintain the machine without
first studying the Operator's Manual. You must
understand and follow the instructions in the
Operator's Manual. If you do not understand
anything, ask your employer or JCB dealer to
explain it.
Do not operate the machine without an Operator's
Manual, or if there is anything on the machine you
do not understand.
Treat the Operator's Manual as part of the machine.
Keep it clean and in good condition. Replace the
Operator's Manual immediately if it is lost, damaged
or becomes unreadable.
Machine Delivery and Installation
Even if you have operated this type of equipment
before, it is very important that your new machines
operations and functions are explained to you by
a JCB Dealer Representative following delivery of
your new machine.
Following the installation you will know how to gain
maximum productivity and performance from your
new product.
Please contact your local JCB dealer if the
Installation Form (included in this manual) has not
yet been completed with you.
Your local JCB Dealer is
Find manuals at https://best-manuals.com

9831/8300-2
Notes:
Find manuals at https://best-manuals.com

Table of Contents
i 9831/8300-2 i
Contents Page No.
Acronyms Glossary ........................................................................................................................................ ix
Introduction
About this Manual
Model and Serial Number ..................................................................................................................... 1
Using the Manual .................................................................................................................................. 1
Left-Hand Side, Right-Hand Side ......................................................................................................... 1
Cross References ................................................................................................................................. 2
Location of Manual ............................................................................................................................... 2
Safety
Safety - Yours and Others .................................................................................................................... 3
Safety Warnings .................................................................................................................................... 3
General Safety ...................................................................................................................................... 4
Clothing and Personal Protective Equipment (PPE) ............................................................................ 5
About the Product
Introduction
General .................................................................................................................................................. 7
Name and Address of the Manufacturer .............................................................................................. 7
Product Compliance .............................................................................................................................. 7
Description
General .................................................................................................................................................. 8
Intended Use ......................................................................................................................................... 8
Log Moving/Object Handling ................................................................................................................. 8
Optional Equipment and Attachments .................................................................................................. 8
Danger Zone ......................................................................................................................................... 8
Main Component Locations .................................................................................................................. 9
Product and Component Identification
Machine ............................................................................................................................................... 10
Engine ................................................................................................................................................. 10
Axle(s) ................................................................................................................................................. 11
Gearbox ............................................................................................................................................... 12
Operator Protective Structure ............................................................................................................. 14
Safety Labels
General ................................................................................................................................................ 16
Safety Label Identification ................................................................................................................... 17
Operator Station
Component Locations ......................................................................................................................... 22
Interior Switches
Ignition Switch ..................................................................................................................................... 24
Multi-Purpose Switch .......................................................................................................................... 24
Cab Interior Light ................................................................................................................................ 25
Console Switches
General ................................................................................................................................................ 26
Road Lights ......................................................................................................................................... 26
Rear Fog Lights .................................................................................................................................. 26
Hazard Warning Lights ....................................................................................................................... 26
Front Work Lights ............................................................................................................................... 27
Rear Work Lights ................................................................................................................................ 27
Four Wheel Drive Selector ................................................................................................................. 27
Find manuals at https://best-manuals.com

Table of Contents
ii 9831/8300-2 ii
Smooth Ride System (SRS) ............................................................................................................... 27
Smooth Ride System with Hose Burst Check Valve .......................................................................... 27
Beacon ................................................................................................................................................ 27
Air-Conditioning ................................................................................................................................... 27
Window Heater ................................................................................................................................... 28
Lifting Warning System ....................................................................................................................... 28
Loader Quickhitch ............................................................................................................................... 28
High Exhaust System Temperature (HEST) ....................................................................................... 28
Kingpost Clamp ................................................................................................................................... 28
Rear Window Wiper ............................................................................................................................ 28
Bi-Directional and Hammer Mode Selector ........................................................................................ 29
Hydraulic Flow Control ....................................................................................................................... 29
Return To Dig Enable ......................................................................................................................... 29
Handheld Hydraulic Tool Circuits ........................................................................................................ 29
Hammer ............................................................................................................................................... 29
Auto Drive ........................................................................................................................................... 29
Drinks Machine ................................................................................................................................... 30
Excavator/Loader Control Selector ..................................................................................................... 30
Operation
Introduction
General ................................................................................................................................................ 31
Operating Safety
General ................................................................................................................................................ 32
Worksite Safety ................................................................................................................................... 34
Risk Assessment ................................................................................................................................ 35
Walk-Around Inspection
General ................................................................................................................................................ 37
Entering and Leaving the Operator Station
General ................................................................................................................................................ 38
Emergency Exit ................................................................................................................................... 38
Doors
Operator Door ..................................................................................................................................... 41
Windows
Side Window ....................................................................................................................................... 42
Rear Window ...................................................................................................................................... 42
Battery Isolator
General ................................................................................................................................................ 44
Before Starting the Engine
General ................................................................................................................................................ 45
Operator Seat
General ................................................................................................................................................ 47
Suspension Seat ................................................................................................................................. 47
Seat Belt
General ................................................................................................................................................ 51
Inertia Reel Seat Belt ......................................................................................................................... 51
Mirrors
General ................................................................................................................................................ 53
Starting the Engine
General ................................................................................................................................................ 54
Warming Up ........................................................................................................................................ 55
Find manuals at https://best-manuals.com

Table of Contents
iii 9831/8300-2 iii
Immobiliser .......................................................................................................................................... 55
Stopping and Parking
General ................................................................................................................................................ 59
Preparing for Travel
General ................................................................................................................................................ 61
Preparing for Road Travel .................................................................................................................. 62
Preparing for Worksite Travel ............................................................................................................. 65
Skiphook .............................................................................................................................................. 66
Beacon ................................................................................................................................................ 67
Safety Equipment
Boom Lock .......................................................................................................................................... 69
Slew Lock ........................................................................................................................................... 70
Drive Controls
Steering Wheel ................................................................................................................................... 72
Steering Column ................................................................................................................................. 72
Accelerator Pedal ................................................................................................................................ 72
Hand Throttle Control ......................................................................................................................... 73
Service Brake Pedal ........................................................................................................................... 74
Park Brake .......................................................................................................................................... 74
Transmission Drive Lever ................................................................................................................... 74
Gear Lever .......................................................................................................................................... 77
Transmission Kickdown Switch ........................................................................................................... 77
Transmission Dump Switch ................................................................................................................ 78
Steer Mode Control ............................................................................................................................ 78
Transmission Mode ............................................................................................................................. 80
Instruments
Instrument Panel ................................................................................................................................. 82
Speedometer ....................................................................................................................................... 95
Getting the Machine Moving
General ................................................................................................................................................ 96
Slopes
General ................................................................................................................................................ 98
Driving on Slopes ............................................................................................................................... 98
Driving the Machine
Steer Modes ........................................................................................................................................ 99
Limited Slip Differential (LSD) ............................................................................................................ 99
TorqueLock .......................................................................................................................................... 99
Operating Levers/Pedals
General .............................................................................................................................................. 101
Control Layouts ................................................................................................................................. 101
Loader Controls ................................................................................................................................ 101
Excavator End Controls .................................................................................................................... 105
Stabiliser Controls ............................................................................................................................. 109
Auxiliary Circuit Controls ................................................................................................................... 111
Lifting and Loading
General .............................................................................................................................................. 114
Lifting (Object Handling) Kit .............................................................................................................. 114
Load Charts ...................................................................................................................................... 115
Lifting Warning System ..................................................................................................................... 119
Working with the Loader
General .............................................................................................................................................. 121
Find manuals at https://best-manuals.com

Table of Contents
iv 9831/8300-2 iv
Filling the Shovel .............................................................................................................................. 122
Loading a Truck ................................................................................................................................ 123
Working with the Excavator End
General .............................................................................................................................................. 124
Preparing to Use the Excavator End ................................................................................................ 124
Lifting With the Excavator End ......................................................................................................... 125
Digging .............................................................................................................................................. 126
Changing the Bucket Linkage .......................................................................................................... 127
Extending Dipper .............................................................................................................................. 130
Compaction ....................................................................................................................................... 131
Dipper Auxiliary ................................................................................................................................. 134
Working with the Skiphook
General .............................................................................................................................................. 137
Working with the Wastemaster Shovel
General .............................................................................................................................................. 139
Heating, Ventilating and Air-Conditioning (HVAC)
Air-Conditioning Controls .................................................................................................................. 141
Cab Heater Controls ......................................................................................................................... 142
Face Level Fan ................................................................................................................................. 142
Extreme Cold Climate Heater
General .............................................................................................................................................. 143
Power Sockets
Auxiliary Power Socket ..................................................................................................................... 150
Radio
General .............................................................................................................................................. 151
Cab Options
Drinks Machine ................................................................................................................................. 152
Fire Extinguisher
General .............................................................................................................................................. 153
Moving a Disabled Machine
Getting the Machine Unstuck ........................................................................................................... 154
Jump-Starting the Engine ................................................................................................................. 154
Retrieval ............................................................................................................................................ 155
Loader Arm (Emergency Operation) ................................................................................................ 157
Excavator End (Emergency Operation) ............................................................................................ 158
Lifting the Machine
General .............................................................................................................................................. 160
Transporting the Machine
General .............................................................................................................................................. 164
Loading the Machine onto the Transporting Vehicle/Trailer ............................................................. 164
Operating Environment
General .............................................................................................................................................. 166
Operating in Low Temperatures ....................................................................................................... 166
Operating in High Temperatures ....................................................................................................... 166
Refuelling
General .............................................................................................................................................. 168
Low Fuel Levels ................................................................................................................................ 168
Filling the Tank .................................................................................................................................. 168
Attachments
Working with Attachments
Introduction ........................................................................................................................................ 171
Find manuals at https://best-manuals.com

Table of Contents
v 9831/8300-2 v
Attachments for your Machine .......................................................................................................... 171
Connecting/Disconnecting Hydraulic Hoses ..................................................................................... 172
Direct-Mounted Attachments
General .............................................................................................................................................. 176
Tool Carrier
General .............................................................................................................................................. 177
Quickhitch
General .............................................................................................................................................. 180
Loader Quickhitch ............................................................................................................................. 180
Loader Quickhitch Carriage .............................................................................................................. 182
Excavator End Quickhitch ................................................................................................................. 183
Auxiliary Circuits
General .............................................................................................................................................. 196
Handheld Hydraulic Tool Circuits ...................................................................................................... 196
Bi-directional Circuits ........................................................................................................................ 197
Shovels
Shovel Forks ..................................................................................................................................... 202
Street Pads ....................................................................................................................................... 204
Side-Shift Carriage
General .............................................................................................................................................. 205
Hose Reel
General .............................................................................................................................................. 207
Work Platforms
General .............................................................................................................................................. 209
Hydraulic Thumb
General .............................................................................................................................................. 210
Hammer
General .............................................................................................................................................. 211
Preservation and Storage
Cleaning
General .............................................................................................................................................. 215
Preparation ........................................................................................................................................ 216
Checking For Damage
General .............................................................................................................................................. 217
Storage
General .............................................................................................................................................. 218
Put into Storage ................................................................................................................................ 218
During Storage .................................................................................................................................. 219
Take out of Storage .......................................................................................................................... 219
Security
General .............................................................................................................................................. 220
JCB Plantguard ................................................................................................................................. 220
Construction Equipment Security and Registration Scheme (CESAR) ............................................ 220
LiveLink ............................................................................................................................................. 220
Maintenance
Introduction
General .............................................................................................................................................. 221
Owner/Operator Support ................................................................................................................... 221
Service/Maintenance Agreements .................................................................................................... 222
Initial Service and Inspection ............................................................................................................ 222
Find manuals at https://best-manuals.com

Table of Contents
vi 9831/8300-2 vi
Obtaining Spare Parts ...................................................................................................................... 222
Maintenance Safety
General .............................................................................................................................................. 223
Fluids and Lubricants ....................................................................................................................... 224
Maintenance Schedules
General .............................................................................................................................................. 228
How to Use the Maintenance Schedules ......................................................................................... 228
Maintenance Intervals ....................................................................................................................... 228
Pre-start Cold Checks, Service Points and Fluid Levels .................................................................. 229
Functional Tests and Final Inspection .............................................................................................. 232
Maintenance Positions
General .............................................................................................................................................. 235
Maintenance Position - Loader Arm Lowered .................................................................................. 235
Maintenance Position - Loader Arm Raised ..................................................................................... 235
Service Points
General .............................................................................................................................................. 238
Access Apertures
General .............................................................................................................................................. 240
Engine Compartment Cover ............................................................................................................. 240
Fuel Filter Cover ............................................................................................................................... 241
Front Grille ........................................................................................................................................ 242
Tools
General .............................................................................................................................................. 243
Toolbox .............................................................................................................................................. 243
Lubrication
General .............................................................................................................................................. 244
Preparation ........................................................................................................................................ 244
Attachments
General ............................................................................................................................................. 245
Body and Framework
General ............................................................................................................................................. 248
Kingpost ............................................................................................................................................ 250
Telescopic Steps ............................................................................................................................... 250
Loader Arm
General ............................................................................................................................................. 252
Wastemaster Shovel ......................................................................................................................... 252
Skiphook ........................................................................................................................................... 253
Excavator End
Lubricate ............................................................................................................................................ 255
Wear Pads ........................................................................................................................................ 255
Extending Dipper .............................................................................................................................. 256
Stabilisers
Wear Pads ........................................................................................................................................ 258
Operator Station
General ............................................................................................................................................. 262
Operator Protective Structure ........................................................................................................... 262
Seat ................................................................................................................................................... 263
Seat Belt ........................................................................................................................................... 263
Controls ............................................................................................................................................. 264
Engine
General ............................................................................................................................................. 265
Find manuals at https://best-manuals.com

Table of Contents
vii 9831/8300-2 vii
Oil ...................................................................................................................................................... 265
Drive Belt .......................................................................................................................................... 269
Air Filter
General ............................................................................................................................................. 270
Fuel System
General ............................................................................................................................................. 272
Fuel Filter .......................................................................................................................................... 272
Engine Fuel Filter ............................................................................................................................. 273
Water Separator ............................................................................................................................... 274
Cooling System
General ............................................................................................................................................. 275
Coolant .............................................................................................................................................. 275
Cooling Pack .................................................................................................................................... 276
Brakes
Park Brake ........................................................................................................................................ 277
Service Brake ................................................................................................................................... 278
Gearbox
Oil ...................................................................................................................................................... 280
Steering System
General ............................................................................................................................................. 282
Axles
General ............................................................................................................................................. 283
Driveshafts
General ............................................................................................................................................. 285
Wheels
General ............................................................................................................................................. 286
Tyres
General ............................................................................................................................................. 288
Hydraulic System
General ............................................................................................................................................. 290
Services ............................................................................................................................................ 291
Oil ...................................................................................................................................................... 291
Cylinders / Rams .............................................................................................................................. 292
Electrical System
General ............................................................................................................................................. 293
Battery ............................................................................................................................................... 294
Battery Isolator ................................................................................................................................. 295
Fuses ................................................................................................................................................ 296
Relays ............................................................................................................................................... 299
Window Washer
Check (Level) .................................................................................................................................... 303
Technical Data
Static Dimensions
Dimensions ........................................................................................................................................ 305
Weights ............................................................................................................................................. 307
Visibility Diagrams ............................................................................................................................. 308
Performance Dimensions
Loader Arm Dimensions and Performance ...................................................................................... 312
Excavator End Dimensions and Performance .................................................................................. 314
Excavator End Quickhitch Dimensions and Performance ................................................................ 316
Driving Performance ......................................................................................................................... 316
Find manuals at https://best-manuals.com

Table of Contents
viii 9831/8300-2 viii
Attachment Dimensions
General .............................................................................................................................................. 317
Safe Working Loads ......................................................................................................................... 317
Excavator Bucket .............................................................................................................................. 318
Loader Shovels ................................................................................................................................. 320
Hydraulic Thumb ............................................................................................................................... 322
Noise Emissions
General .............................................................................................................................................. 323
Noise Data ........................................................................................................................................ 323
Vibration Emissions
General .............................................................................................................................................. 324
Vibration Data ................................................................................................................................... 325
Fluids, Lubricants and Capacities
General .............................................................................................................................................. 326
Fuel ................................................................................................................................................... 327
Diesel Exhaust Fluid (DEF) .............................................................................................................. 330
Coolant .............................................................................................................................................. 332
Torque Values
General .............................................................................................................................................. 334
Electrical System
General .............................................................................................................................................. 335
Bulbs ................................................................................................................................................. 335
Fuses ................................................................................................................................................. 335
Relays ............................................................................................................................................... 340
Engine
Exhaust After Treatment (EAT) ......................................................................................................... 344
Hydraulic System
General .............................................................................................................................................. 348
Hydraulic Hose Burst Pressures ....................................................................................................... 348
Wheels and Tyres
Tyre Sizes and Pressures ................................................................................................................ 350
Declaration of Conformity
General .............................................................................................................................................. 352
Data ................................................................................................................................................... 352
Warranty Information
Service Record Sheet ....................................................................................................................... 354

Table of Contents
ix 9831/8300-2 ix
Acronyms Glossary
2WD Two Wheel Drive
2WS Two Wheel Steer
4WD Four Wheel Drive
4WS Four Wheel Steer
ARV Auxiliary Relief Valve
AWS All Wheel Steer
CESAR Construction Equipment Security and Registration
DCU Dosing Control Unit
DEF Diesel Exhaust Fluid
ECU Electronic Control Unit
EHTMA European Hydraulic Tool Manufacturers Association
ESOS Engine Shut-Off Solenoid
FEAD Front End Accessory Drive
FOPS Falling Object Protective Structure
GPS Global Positioning System
HBCV Hose Burst Check Valve
HEST High Exhaust System Temperature
HP High Pressure
HVAC Heating Ventilation Air Conditioning
ISO International Organization for Standardization
LCD Liquid Crystal Display
LED Light Emitting Diode
LP Low Pressure
LSD Limited Slip Differential
MIL Malfunction Indicator Lamp
MP Medium Pressure
MRV Main Relief Valve
NOx Nitrogen Oxide
PIN Product Identification Number
PPE Personal Protective Equipment
PWM Pulse Width Modulation
RMS Root Mean Square
ROPS Roll-Over Protective Structure
RPM Revolutions Per Minute
SAE Society of Automotive Engineers
SCR Selective Catalytic Reduction
SRS Smooth Ride System
SWL Safe Working Load
VGT Variable Geometry Turbocharger
km/h kilometers per hour
mph miles per hour

Notes:
x 9831/8300-2 x

Introduction
About this Manual
1 9831/8300-2 1
Introduction
About this Manual
Model and Serial Number
This manual provides information for the following model(s) in the JCB machine range:
Model From: To:
2000000 2017872
2254521 2274521
2442701 2451000
4CX Wastemaster Eco
2509500
2000000 2017872
2254521 2274521
2442701 2451000
5CX Wastemaster Eco
2509500
Using the Manual
This operator's manual is arranged to give you a good understanding of the machine and its safe operation.
It also contains maintenance and technical data.
Read this manual from the front to the back before you use the machine for the first time, even if you have used
machines of a similar/same type before as the technical specification, systems and controls of the machine
may have changed. Particular attention must be given to all the safety aspects of operating and maintaining
the machine.
If there is anything you are not sure about, ask your JCB dealer or employer. Do not guess, you or others could
be killed or seriously injured.
The general and specific warnings in this section are repeated throughout the manual. Read all the safety
statements regularly, so you do not forget them. Remember that the best operators are the safest operators.
The illustrations in this manual are for guidance only. Where the machines are different, the text and or the
illustration will specify.
The manufacturer's policy is one of continuous improvement. The right to change the specification of the
machine without notice is reserved. No responsibility will be accepted for discrepancies which may occur
between specifications of the machine and the descriptions contained in this manual.
All of the optional equipment included in this manual may not be available in all territories
Left-Hand Side, Right-Hand Side
In this manual, 'left' and 'right' mean your left and right when you are seated correctly in the machine.
This is so whether you are facing the loader (front) or the backhoe (rear).
Figure 1.
B
A
B
A
B
A
A
B
ALeft BRight

Introduction
About this Manual
2 9831/8300-2 2
Cross References
In this manual, cross references are made by presenting the subject title in blue (electronic copy only). The
number of the page upon which the subject begins is indicated within the brackets. For example: Refer to:
Cross References (Page 2).
Location of Manual
The manual is located in the case attached to the back of the seat. The manual should always be returned
to its case after use.
Figure 2.
A
B
AManual location BSeat

Introduction
Safety
3 9831/8300-2 3
Safety
Safety - Yours and Others
All machinery can be hazardous. When a machine is correctly operated and maintained, it is a safe machine
to work with. When it is carelessly operated or poorly maintained it can become a danger to you (the operator)
and others.
In this manual and on the machine you will find warning messages, you must read and understand them. They
inform you of potential hazards and how to avoid them. If you do not fully understand the warning messages,
ask your employer or JCB dealer to explain them.
Safety is not just a matter of responding to the warnings. All the time you are working on or with the machine
you must be thinking of what hazards there might be and how to avoid them.
Do not work with the machine until you are sure that you can control it.
Do not start any work until you are sure that you and those around you will be safe.
If you are not sure of anything, about the machine or the work, ask someone who knows. Do not assume
anything.
Remember:
• Be careful
• Be alert
• Be safe.
Safety Warnings
In this manual there are safety notices. Each notice starts with a signal word. The signal word meanings are
given below.
The signal word 'DANGER' indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
The signal word 'WARNING' indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
The signal word 'CAUTION' indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
The signal word 'Notice' indicates a hazardous situation which, if not avoided, could result in machine damage.
The safety alert system symbol (shown) also helps to identify important safety messages in this manual. When
you see this symbol your safety is involved, carefully read the message that follows.
Figure 3. The safety alert system symbol

Introduction
Safety
4 9831/8300-2 4
General Safety
Training
To operate the machine safely you must know the machine and have the skill to use it. You must abide by
all relevant laws, health and safety regulations that apply to the country you are operating in. The operator's
manual instructs you on the machine, its controls and its safe operation; it is not a training manual. Ensure that
you receive the correct training before operating any machinery. Failing to do so will result in incorrect operation
of the machine and you will be putting yourself and others at risk. In some markets, and for work on certain
jobsites, you may be required to have been trained and assessed in accordance with an operator competence
scheme. Make sure that you and your machine comply with relevant local laws and jobsite requirements – it
is your responsibility.
Care and Alertness
All the time you are working with or on the machine, take care and stay alert. Always be careful. Always be
alert for hazards.
Clothing
You can be injured if you do not wear the correct clothing. Loose clothing can get caught in the machinery.
Keep cuffs fastened. Do not wear a necktie or scarf. Keep long hair restrained. Remove rings, watches and
personal jewellery.
Alcohol and Drugs
It is extremely dangerous to operate machinery when under the influence of alcohol or drugs. Do not consume
alcoholic drinks or take drugs before or while operating the machine or attachments. Be aware of medicines
which can cause drowsiness.
Feeling Unwell
Do not attempt to operate the machine if you are feeling unwell. By doing so you could be a danger to yourself
and those you work with.
Mobile Phones
Switch off your mobile phone before entering an area with a potentially explosive atmosphere. Sparks in such
an area could cause an explosion or fire resulting in death or serious injury.
Switch off and do not use your mobile phone when refuelling the machine.
Lifting Equipment
You can be injured if you use incorrect or faulty lifting equipment. You must identify the weight of the item to
be lifted then choose lifting equipment that is strong enough and suitable for the job. Make sure that lifting
equipment is in good condition and complies with all local regulations.
Raised Equipment
Never walk or work under raised equipment unless it is supported by a mechanical device. Equipment which
is supported only by a hydraulic device can drop and injure you if the hydraulic system fails or if the control
is operated (even with the engine stopped).
Make sure that no-one goes near the machine while you install or remove the mechanical device.
Raised Machine
Never position yourself or any part of your body under a raised machine which is not correctly supported. If the
machine moves unexpectedly you could become trapped and suffer serious injury or be killed.
Lightning
Lightning can kill you. Do not use the machine if there is lightning in your area.
Machine Modifications
This machine is manufactured in compliance with prevailing legislative requirements. It must not be altered in
any way which could affect or invalidate its compliance. For advice consult your JCB dealer.

Introduction
Safety
5 9831/8300-2 5
Clothing and Personal Protective Equipment (PPE)
Do not wear loose clothing or jewellery that can get caught on controls or moving parts. Wear protective clothing
and personal safety equipment issued or called for by the job conditions, local regulations or as specified by
your employer.

Notes:
6 9831/8300-2 6

About the Product
Introduction
7 9831/8300-2 7
About the Product
Introduction
General
Before you start using the machine, you must know how the machine operates. Use this part of the manual
to identify each control lever, switch, gauge, button and pedal. Do not guess, if there is anything you do not
understand, ask your JCB dealer.
Name and Address of the Manufacturer
JCB Excavators Limited, Lakeside Works, Rocester, Uttoxeter, United Kingdom, ST145JP
Product Compliance
Your JCB product was designed to comply with the laws and regulations applicable at the time of its manufacture
for the market in which it was first sold. In many markets, laws and regulations exist that require the owner to
maintain the product at a level of compliance relevant to the product when first produced. Even in the absence
of defined requirements for the product owner, JCB recommend that the product compliance be maintained
to ensure safety of the operator and exposed persons and to ensure the correct environmental performance.
Your product must not be altered in any way which could affect or invalidate any of these requirements. For
advice consult your JCB dealer.
For its compliance as a new product, your JCB and some of its components may bear approval numbers
and marking's, and may have been supplied with a Declaration/Certificate of Conformity. These marking's and
documents are relevant only for the country/region in which the product was first sold to the extent that the
laws and regulations required them.
Re-sales and import/export of products across territories with different laws and regulations can cause new
requirements to become relevant for which the product was not originally designed or specified. In some cases,
pre owned products irrespective of their age are considered new for the purposes of compliance and may be
required to meet the latest requirements which could present an insurmountable barrier to their sale/use.
Despite the presence of any compliance related marking's on the product and components, you should not
assume that compliance in a new market will be possible. In many cases it is the person responsible for import
of a pre owned product into a market that becomes responsible for compliance and who is also considered
the manufacturer.
JCB may be unable to support any product compliance related enquiry for a product which has been moved out
of the legislative country/region where it was first sold, and in particular where a product specification change
or additional certification would have been required in order for the product to be in compliance.
