JDS Labs ELEMENT II User manual

OPERATING INSTRUCTIONS | AMP+DACS
ELEMENT II
SUPPORT
ONLINE BY PHONE BY MAIL
314-252-0936
9:30AM-6PM CST,
MONDAY THROUGH FRIDAY
CONT[email protected]
JDSLABS.COM/SUPPORT
909 N BLUFF RD
COLLINSVILLE, IL 62234
UNITED STATES

JDSLABS.COM 2JDSLABS.COM 3
SECTION 1
QUICK SETUP
STEP 01
Connect AC power adapter to rear power jack
(16VAC), then connect to wall outlet
STEP 02
Connect USB cable between your computer and
the USB jack
SECTION 2
CONFIGURATION
Connectivity
Element II accepts two methods of audio input: Digital input via USB, or Analog input via RCA
jacks. Connecting an RCA cable mechanically bypasses the integrated DAC, so that the
amplier only plays audio from your external source.
Maximum RCA Analog Input Level (High Gain): 2.2 VRMS (+9 dBu)
Maximum RCA Analog Input Level (Low Gain): 9.9 VRMS (+22 dBu)
STEP 03
Connect headphones to the front
headphone output jack
STEP 04
A short press of the Power/Mode button turns
Element on, indicated by lighting beneath the
volume knob.
A long press of the Power/Mode button will
toggle between headphone or RCA Output.
Please see Connectivity and Computer Setup for
additional help.
STEP 05
Slowly raise the volume knob to an
appropriate listening level.
See listening tips on page 5
Setting Gain
Press the gain button to toggle between low or high gain amplication. Always use the lowest
gain necessary.
Switch to high gain only when you’re unable to achieve desired listening volume at low gain.

JDSLABS.COM 4JDSLABS.COM 5
HEADPHONE OUTPUT MODE RCA OUTPUT MODE
RCA INPUTS DISCONNECTED
HEADPHONE OUTPUT MODE RCA OUTPUT MODE
RCA INPUTS CONNECTED
USB
INPUT DAC
HEADPHONE
AMPLIFIER
AUDIO TO
HEADPHONES
RCA JACKS
(LINE-OUTPUT)
SPEAKERS
MUTE
RCA JACKS
(LINE-INPUT)
EXTERNAL
AUDIO
NOT USED RCA JACKS
(LINE-INPUT)
EXTERNAL
AUDIO
NOT USED
USB
INPUT DAC
HEADPHONE
AMPLIFIER
HEADPHONES
MUTE
RCA JACKS
(LINE-OUTPUT)
AUDIO TO
SPEAKERS
DAC
USB
INPUT
NOT USED
EXTERNAL
AUDIO
HEADPHONE
AMPLIFIER
HEADPHONES
MUTE
RCA JACKS
(LINE-OUTPUT)
AUDIO TO
SPEAKERS
RCA JACKS
(LINE-INPUT)
HEADPHONE
AMPLIFIER
AUDIO TO
HEADPHONES
RCA JACKS
(LINE-OUTPUT)
SPEAKERS
MUTE
DAC
USB
INPUT
NOT USED
EXTERNAL
AUDIO
RCA JACKS
(LINE-INPUT)
For maximum signal delity, set the DAC
to 24 or 32-bit audio and adjust digital
volume slightly below 100% at your
computer. Only control volume from the
amplier.
Element II can amplify headphones to
dangerously loud audio. Listen
safely to conserve your hearing:
www.hearingloss.org
Set sampling rate to the highest integer
multiple of your music collection. For
example, use 176.4kHz for a collection
of 44.1k or 88.2k or 176.4kHz les. Use
192kHz for a collection of 48k or 96k or
192k audio les.
Alternatively, you may install the
optional XMOS drivers in Win10 for
exclusive WASAPI mode.
Element II uses a high current
power supply and runs warm to the touch.
Avoid covering the top and sides.
Element II can be safely powered on 24/7.
For maximum relay lifespan, cycle power at
least once per month.
Do not lift the amplier by knob, or turn
knob beyond its limits.
Use gentle force when inserting or
removing cables.
To ensure an optimal noise oor,
always position headphone ampliers as
far away as possible from wireless devices.
Element II Connectivity
Element II provides headphone output and RCA Preamp Outputs. Press the Power/Mode
button for at least 1 second to toggle between these modes. Only one mode is active at a time.
Volume is adjustable in either mode.
Listening Tips
Operating Care

JDSLABS.COM 6JDSLABS.COM 7
Element II requires no drivers in Windows 10, Mac OS, Linux, and modern version of iOS and
Android. You may download drivers for Win7/8 from jdslabs.com/drivers. These drivers may
optionally be installed in Win10 for WASAPI support. Be sure to select your new DAC as the
default playback device:
Windows 7/8/10
Right click the volume icon in your taskbar and
choose Sound --> Playback. Click the XMOS
or JDS Labs audio device, then choose “Set
Default”. For best experience, also congure
Properties:
• Enhancements: Check “Disable all
enhancements”
• Advanced: See Listening Tips
Mac OS X
Ensure JDS Labs audio device is selected from
Audio Devices.
Troubleshooting
Amplier does not turn on
Cause: Missing or loose power adapter connection.
Solution: Firmly connect AC adapter to 16VAC power jack.
Internal LED ashes, then turns o
Cause: Wrong power adapter detected.
Solution: Please see Power Adapters section below.
No sound in one channel
Cause: Bad cable, or incorrect computer settings.
Solution: Check balance settings; try another headphone or RCA cable. Some Mac OS X systems
will pan audio to the Left channel upon initial connection of a DAC. User must restore balance
to center.
Power Adapters
ATTENTION: Incorrect power adapters can result in capacitor
explosion hazards and device damage. Only use the power adapter
included with your Element:
Type: AC-to-AC Transformer Output Voltage: 16 VAC
Current: Minimum 1000mA Connector: 2.1x55.mm (ID x OD)
SECTION 3
SETUP
Computer Setup
No USB device or “Failed to Play Audio”
Cause: USB Device is not initialized.
Solution: Turn Element II o, then back on to reset the USB device.
No sound from headphones
Cause: Wrong mode, or incorrect connectivity, or incorrect setup
Solution: Please see Connectivity page to toggle between Headphone or RCA Output. Check
cabling.

JDSLABS.COM 8
Application for Council Directives 2004/108/EC, 2006/95/EC, 2002/95/
EC.Conformity declared for EN55022:2011, EN611000-3-2, EN61000-3-
3, EN55024-2
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
