Jenn-Air JER8500AAA Installation instructions

mmmIENN.AIR Gourmet Edition
Use and Care
Electric Range
with
Self-Cleaning Oven
fTABLEOFCONTENTS
IMPORTANTSAFETYINSTRUCTIONS.......... 2-4 • LevelingLegs ............................ 16
RANGEFEATURES............................. 5 ABOUTCLEANING ......................... 17-21
CLOCK,TIMER, OVENCONTROL .............. 6-7 •Self-CleanOven Feature ............... 17-18
•CleaningChart ........................ 19-21
ABOUTYOUR COOKTOP ...................... 8-9
•HowTo OperateSurfaceUnit ............... 8 ABOUTCOOKING .......................... 22-27
•Cooktop .................................. 9•Surface Cooking ...................... 22-23
-Coil Elements ............................. 9Se/ectingheat settings ................... 22
Suggestedheatsettingguide ............. 22
•DripBowls ................................ 9Canninginformation ..................... 22
About cookware ......................... 23
ABOUTYOUR OVEN ....................... 10-13 •Aluminum FoilUsage ..................... 24
• HowTo Set OvenToBakeOr Roast ........ 10
•Automatic Oven Timer Control ............. 11 • Baking&Roasting ..................... 24-27
Preheating ............................. 24
•HowTo Set OvenTo Broil ................. 12 Rackpositions .......................... 24
•Oven Characteristics ..................... 13 Bakingtips ............................. 25
•Control Lock-OutFeature ................. 13 Roastingtips ........................... 25
Commonbakingprob/emchart ............ 26
ABOUTYOUR RANGE ...................... 14-16 •Broiling .................................. 27
•Oven Door ............................... 14
•DoorLockLever .......................... 14 ABOUTSERVICE ........................... 28-32
•Oven Vent ................................ 14 •TroubleshootingChart ................. 28-30
•Oven Ught ............................... 15 •Oven TemperatureAdjustment ............ 31
•HowToReceiveService .................. 32
•Oven Racks .............................. 15
•StorageDrawer ........................... 16 WARRANTY .................................. 32
INSTALLER Pleaseleave ModelNumber:
thismanualwiththisappliance. SerialNumber:
"-- CONSUMER Tosaveyou DateofPurchase: J
time,energyandmoney,read
andkeepthismanualforfuture Modelandserialnumbersareonthe ratingplate.See page5 forlocation.
Pleasekeepyoursaes receiptand/oryourcancelledcheckasproofof
reference, purchaseShouldwarrantyservicebe needed.
FOR CUSTOMERASSISTANCE CALL 1-800-688-1100 8111 P366-60
(12-97-00)

IMPORTANTSAFETYINSTRUCTIONS
Thank You forpurchasingour cooking IMPORTANT INSTRUCTIONS
appliance.Tohelpyouobtainthemaximumincooking Readandfollow all instructionsbefore usingthis
satisfaction,weofferthesesuggestions: appliancetopreventthe potentialriskoffire,electric
shock,personalinjuryordamagetotheapplianceasa
[]E_=Readthismanualbeforeusingtheappliance, resultofimproperusageoftheappliance.Useappliance
onlyfor itsintendedpurposeas describedinthismanual.
IE_Reviewallsafetyandcautioninstructions.Toensure properand safe operation:Appliancemust
beproperlyinstalledandgroundedbyaqualified
ET' ReviewtheTroubleshootingCharton technician.
pages29to 31 if servicebecomesnecessary.
[]ET'Includethe modelandserialnumbersofyour I _ _) ACAUSEINJURIEsWARNINGToPERSONS.
appliancewhen requestingservice.
•Proofofpurchasesuchassalesreceipt • ALL RANGES CANTIP AND
will be neededfor warrantyservice.V
lET'Youcancontact usat: ___)•INSTALLANTI-TIPDEVICES
Maytag AppliancesSales Company PACKEDWITH RANGE.
Attn: CAIR Center i
P.O. Box2370
Cleveland,TN 37320-2370 •FOLLOWALL INSTALLATION
1-8oo-688-11oo INSTRUCTIONS.
In our continuingeffortto improvethequalityand
performanceofourcookingappliances,it maybeWARNING: Toreduceriskoftippingoftheappliance
necessaryto makechangestotheappliancewithoutfromabnormalusageor by excessiveloadingoftheoven
revisingthismanual, door,theappliancemustbesecuredby a properly
installedanti-tipdevice.
Tocheckifdeviceisproperlyinstalled,removestorage
drawerand lookunderneathrangetomakesureoneof
therear levelinglegsisproperlyengagedin the bracket
slot.Theanti-tipdevicesecurestherearlevelinglegto
thefloorwhenproperlyengaged.Youshouldcheckthis
anytimetherangehas beenmoved.
INCASE OFFIRE :;
Turn offapplianceand ventilatinghoodto avoidspreading
theflame. Extinguishflamethenturn on hoodto remove
smokeand odor.
• Cooktop: Smotherfire or flame in a _,
pan witha lidor cookiesheet. ,,_
3=%
NEVERpick up or movea
flamingpan.
•Oven:Smotherfireor flame by closingthe ovendoor.
Donotusewaterongreasefires.Usebakingsoda,adry
chemicalor foam-typeextinguishertosmotherfireor
flame.

GENERALINSTRUCTIONS COOKTOP
WARNING:NEVERuseappliance '_'_'_%ililil_ NEVERleavesurface units .,t_,_ _i_
door, or drawer,ifequipped, as a ,f _,_ , _. unattendedespecially when using _ '_iI}_ _ _
step stool or seat as this may result i _ high heat settings. An unattendedi_i o_i_ _ _
inpossibletippingofthe appliance, _,,[_ i_i_, Ill
damageto the appliance,and '_! boilover couldcausesmokingand a H_ F!4• Jii_
seriousinjuries,greasyspillovercan cause a fire. 'i_,=.I _,_!i5,
...._=._,.. _!i!i_ __._.._,__ _. •
Ifappliance isinstalledneara window,proper This applianceis equippedwith differentsize surface
precautionsshouldbetakento preventcurtainsfrom elements.Selectpans havingflat bottomslargeenoughto
blowingover surfaceelements. ,._,_'_"_'=_%_o coverelement.Properrelationshipof pantoelementwill
NEVERuseappliancetowarm or _i!',i_,1_ improvecookingefficiency.
heatthe room. Failureto followthis . j, _==_
instructioncan leadtopossible .___, Ifpan is smallerthan element,a _!i_
burns,injury,fire, or damage tothe =_ portionof the elementwill be _i "_"
appliance, exposedto directcontactand -
_'_ couldigniteclothingor potholder.
NEVERwearloose-fittingor #i_ ,_,
hanginggarmentswhileusingthe _i.'r'_m_L ............
appliance.Clothingcould catch _iL__,__"_,_I , III_L_, Onlycertaintypesof glass,glass/ceramic,ceramic,
utensilhandlesor igniteandcause _i_.__ earthenware,or other glazedutensilsare suitablefor
burnsif garmentcomesin contact _ cooktoporovenservicewithoutbreakingdueto the
with hot heatingelements._=_ sudden changein temperature.Follow utensil
manufacturer'sinstructionswhen usingglass.
Toensure properoperationandto avoid damageto the
applianceor possible injury,do notadjust,service,repair Turn pan handletoward center of _._._
or replaceanypartof theapplianceunlessspecifically cooktop,not outintothe room or _'_I_
recommendedinthismanual.Referallotherservicingtoa over anothersurface element.This _ _--1_ _
qualifiedtechnician, reducesthe riskof burns, ignitionof !_i
flammablematerials,or spillageif__
NEVERstoreor usegasolineor other combustibleor pan isaccidently bumpedor
flammablematerialsinthe oven,nearsurface unitsor in reachedbysmall children. _'
thevicinityof this applianceas fumescould create afire Topreventdamageto removableheating elements,do not
hazardor anexplosion, immerse,soakor clean in a dishwasheror self-clean
Topreventgreasefires, donot let cookinggreaseor other oven.A damagedelementcould short resultingin a fire or
flammablematerialsaccumulatein or nearthe appliance, shockhazard.
Useonly dry potholders.Moistor Makesuredripbowlsare in placeas absenceof these
_o_,_. bowls duringcookingcoulddamagewiringorparts.
damppotholdersonhot surfaces ._|_....... _i_.__
mayresult ina steamburn. Do not_'_1:___
let potholdertouchhotheating '___ OVEN
elements.Donotusea towelor
otherbulkyclothwhichcouldeasily _,,=""..... ' Usecarewhenopeningdoor.Lethot
touchhotheatingelementsand _' airorsteamescapebeforeremoving
ignite, or replacingfood.
Alwaysturnoffallcontrolswhencookingiscompleted. Forproperovenoperationand
NEVERheatunopenedcontainersonthesurfaceunitor performance,donotblockorobstruct
intheoven.Pressurebuild-upinthecontainermaycauseovenventduct.
containertoburstresultinginburns,injuryordamageto
theappliance. Alwaysplaceovenracksindesiredlocationswhileovenis
cool.If rackmustbemovedwhileovenishot,donotlet
NEVERusealuminumfoiltolinedripbowls,ortocover potholdercontacthotheatingelementinoven.
anovenrackorovenbottom.Misusecouldresultinriskof
electricshock,fire,or damagetotheappliance.Usefoil
onlyasdirectedinthismanual.

0 IMP()RTANTSAFETYINSTRUCTIONS
SELF-CLEANINGOVEN
Cleanonlypartslistedinthismanual.Do not cleandoor CAUTION:NEVERstore itemsof _==.-..=,,,_==.._.=_,,_.,_..........
gasket.The gasketis essentialfora goodseal. Care interestto childrenJncabinets.,_= _%=
shouldbe taken notto rub,damage,ormovethe gasket, abovean applianceor on backguard ,_i_1=_ _iii
._ _
of a range.Childrenclimbingoni _ _
Donotuseovencleaners.No,,S_%=.appliance,dooror drawertoreach ___J
commercialovencleaner or oven _"_'1_'____'_"1 itemscoulddamagethe appliance
linerprotectivecoatingofany kind
shouldbe used in or aroundany ,!11_ I_ orbeburnedor seriouslyinjured.
_. -_, i _
partoftheoven. _i_._l_?._! Childrenmustbetaughtthattheapplianceand utensils in
'_,_ _:,oronitcan behot.Let hot utensilscool ina safeplace,
Beforeself-cleaningtheoven, '°_'_"°_"_..... outofreachofsmallchildren.Childrenshouldbetaught
removebroilerpan,ovenracksandotherutensilsto that anapplianceisnotatoy.Childrenshouldnotbe
preventexcessivesmoking,discolorationof the oven allowedtoplaywithcontrolsorotherpartsoftheunit.
racksorpossibledamagetoutensils.
Wipeupexcessivespillovers,especiallygreasyspills,
beforetheclean cycletopreventexcessivesmokingorHEATINGELEMENTS
flare-ups. NEVERtouch surfaceor oven
It isnormalfor thecooktoptobecomehot duringa clean heatingelements,areas near
cycle.Therefore,avoidtouchingor liftingthe cooktop elementsor interiorsurfacesof
duringa cleancycle, oven. _= .....
Heatingelementsmay behot even
though they are darkin color.Areas
.:nearsurfaceelementsand interior
VENTILATING HOODS ' surfacesof anovenmay becomehot enoughtocause
burns.Duringand afteruse,do not touchorlet clothing
Cleanrangehoodand filtersfrequentlyto preventgrease or otherflammablematerialscontactheatingelements,
orother flammablematerialsfromaccumulatingon hood areasnear elements,or interiorsurfaces ofoven until
orfilterand to avoid greasefires.they have hadsufficienttime to cool.
Turnthefan offwhen fiamb_ingfoods (suchas Cherry Otherpotentiallyhotsurfacesinclude:Cooktop,areas
Jubilee)underthehood.Thefan, ifoperating,mayspread facingthe cooktop,oven vent opening,surfaces nearthe
theflame,vent opening,ovendoor, areasaroundthe door, and oven
window.
DEEPFATFRYERS IMPORTANT SAFETY NOTICE & WARNING
Useextremecautionwhenmovingthegrease kettleor
disposingof hot grease.Allowgreaseto cool before TheCaliforniaSafe DrinkingWater andToxicEnforcement
attemptingto movepan. Actof 1986(Proposition65) requiresthe Governorof
Californiato publisha listofsubstancesknownto the
Stateof Californiato causecanceror reproductiveharm,
CHILDSAFETY and requiresbusinessestowarncustomersof potential
exposurestosuch substances.
NEVERleavechildrenaloneor
unsupervisedin area where Usersof this applianceare herebywarnedthat when the
applianceisin useor isstillhot.oven is engagedin the self-clean cycle,there maybe
somelowlevelexposureto some ofthe listedsubstances,
NEVERallow childrento sit or stand includingcarbonmonoxide. Exposuretothese substances
onanypartof the applianceas they can beminimizedby properlyventingtheoven to the
could beinjuredor burned, outdoorsduring the self-cleancycle by openinga window
and/ordoor in the roomwherethe appliance islocated.

ELECTRONICCONTROL (pages6 and 7)
OVE_r(page 15) (page8)
BACKGUARD SURFACECONTROLS(page8)
SURFACE
(page8) VENT(page 14)
(page9) (notshown)
(pages 12and 27)
(page 14)
COOKTOP(page (self-cleanoven -pages 17and 18)
"RACKSUPPORTS
OVENRACKS
ANTI-TIP BRACKET (page 15)
(page 16)
LEVELING LEG BAKE ELEMENT
(pages2 and 16) (pages 1O,25and 26)
RATINGPLATEOVENDOOR
(page 14) OVENWINDOW
STORAGEDRAWER(page 16) DOORGASKET

CLOCK,TIMER,OVENCONTROL
Pressth,s,a Pressor,ress
tocancelalland holdthese
operations pads to enter
exceptthe time,oven
TIMER.The temperatureor
timeof daywill [_ _.[ _ 1[_ I toselectHI or
reappearin the LO broil.
display.
ABOUT THE FUNCTIONPADS HOW TO SET CLOCK
• Functionpads arethe BAKE,BROIL,CLEAN, 1. PressCLOCKpad.
TIMER,CLOCK,COOKTIME, STOPTIME, and tt
CANCELpads.Abeepwillsound whenthese pads 2. Pressor pressand hold [C_K ]
are pressed.•or •pad until correct [ (_ _ then
•No beepwill soundwhen the • or • padis pressed,time ofday appearsin
• Allfunctionpads exceptthe CANCEL _ display.
padfeaturean indicatorlight. I_l Displaywill flashwhen poweris suppliedto unit.
WhentheBAKEor BROILpad is
pressed,the indicatorlightwill PressCLOCKpad.Torecall time of daywhen another
turnonto let youknowthat the _ functionisdisplayed.
ovenis setfor this operation. _ _- / Clock timecannotbechangedif ovenis setfor timed
Indicatorlightson CLEAN,TIMER, bake or delayedcleanoperation.Canceltheoperation
CLOCK,COOKTIMEandSTOPTIMEpadswill beforesettingthe clock.
flash when thepad is pressed.These indicatorlights Iftimer is in use,pressCLOCKpad onceto recall the
will stop flashingbut will remainlit oncethe function timeofday or twice toresetthe time of day.
starts.
• Ifan indicatorlightona functionpad islit and you set
asecondoperation: CLOCKDISPLAY DISABLE PEATURE
Eitherthe controlwill notacceptthe operationor Ifyou preferthat thetime of day isnotdisplayed:
- The indicatorlight onthefirstpad will "dim"slightly 1.Pressand hold both
andthe indicatorlightonthe padyoujust pressed CLOCKand CANCEL L 'J
will be"fullon."This letsyouknowthat you have padsfor 3 seconds,and
set the controlfor two operations. When clockdisplayis
Forexample: Ifyou setthe oven _"DIM" disabled,pressCLOCK padto recalltime of dayfor 4
to bakeat 350°Fand thenseta[_/ seconds. Displaywill then blank.
timingoperation,the indicatorlight
onthe BAKE padwill"dim"and Ifa powerfailureoccurswhenthe clock hasbeen
the indicatorlightonthe TIMERpad will be "full on." disabled,the display remainsblankand will notflash
whenpoweris restored.
The displaywillshowtheoperation _"R_'FUL,,L
for the pad withthe "fullon" indicator Repeatstep 1to reactivateclock feature.
LzJ
light. Pressthefunctionpad withthe
"dim"indicatorlightto recallthat
operation.

CLOCK,TIMER,OVENCONTR()L
HOW TO SET TIMER .... "END 'OFTIMED COOK"BEEPS
1.PressTIMERpad._ _ You havea choice ofthree"end ofcooking"reminder
2. Pressor pressand hold ['_1 then _ beepsfor the AutomaticOven lqmerfeature.
• or• pad untilcorrect •Option1:Four beepsthen onebeepevery30seconds
time appearsin display, for the next 5 minutes or until CANCELpad is
Thetimerfeaturedoes not operatethe oven. pressed,(Defaultoption,)
Thetimer canbesetfrom 1 minute[0:01]upto 9 hours °Option 2: Fourbeeps.Therearenoother beeps.
and 50minutes [9:50]. • Option3: Fourbeepsthenone beepeveryminutefor
Thetimerwill start automatically.The TIMER indicatoron thenext 12hours or until CANCELpadis pressed.
theTIMERpadwill lightwheneverthe timer isin use. One
longbeepand"End"willbebrieflydisplayedto signalthe How to select the desiredoption:
end ofthe timeroperation. 1.Pressand hold both _
Tocanceltimer: Pressand holdTIMER pad for 3 COOKTIME andCLOCK
seconds. Timeofdaywill reappearin the display,padsfor3 seconds,and
•A singlebeepwillsound.
12 HOURENERGY SAVERFEATURE •Displaywillshowcurrent
,option.
The 12 HourEnergySaverfeature automaticallyturns off 2. Press• or• padto _f"_
the oven if it was accidentlyleft on for 12 hours.To selectthe option number
deactivatethisfeatureso the oven will NOT turnoff you wish.The currenttime
automaticallyat theendof 12hours: ofdaywill reappearin the
1.Pressand hold CLOCKpad _ displayafter 4 seconds.
for3 seconds. N
2, Press• or•pad until 8:88 i_K I then
appearsinthedisplay.
Currenttime ofdaywill
reappearin the displayafter
4 seconds.
Repeatsteps1and 2 to reactivatethe 12HourEnergy
Saverfeature. 12:00will appearindisplay to indicatethe
EnergySaverfeatureisrestored,

0 ABOUTYOURCOOKTOP
I c. I
rUTION_,
Before cooking... Other tips...
• Always place a pan on the surfaceunitbefore you • To eliminate the hazard of reaching over hot surface
turn it on.To prevent damage torange, neverelements donot install cabinet storagedirectly
operate surface unit without a pan in place, above a unit.
•NEVER use the cooktop as a storage area for food If storage is provided, limit it to items that are
orcookware, infrequently used and can be safely stored in an
• Be sure you know which knob controls which surface areasubjected to heat.
unit.Makesure you turned on thecorrect surface
unit. Temperatures may be unsafe for items such as
During cooking.., volatile liquids, cleaners oraerosol sprays.
• Begin cookingon a higher heat settingthen reduce
to alowersetting to completetheoperation. Never • Aerosol-type spray cans are EXPLOSIVE or highly
useahighheat setting for extendedcooking,flammablewhenexposedto heat.Avoid their useor
•NEVER allow a pan to boil dry. This could damagestorage near an appliance.
the pan and the appliance. • NEVER leaveany items, especially plastic items,
•NEVER touch cooktopuntil ithas cooled. Expect unattended onthecooktop. The hotair from the vent
some parts of thecooktop,especially aroundthemay igniteflammable items,meltor soften plastics,
surfaceunits,to becomewarm or hotduring or increasepressurein closedcontainers causing
cooking.Use potholdersto protect hands, them to burst.
After cooking... • NEVER allow aluminum foil, meat probesor any
• Be sure surface element isoff after cooking,other metal object, otherthan a utensil on a surface
•Cleanup greasy spillsassoon aspossible, element, to contact heatingelements.
SURFACE UNIT SURFACE INDICATOR UGHT
HOW TO OPERATE
1.Place pan on surface unit. off A SURFACEindicator lightlocated on the backguard will
2. Push inand turn knob to desired Low_High turn on whenever a surface unit is turned on.Light will
setting. 1/Ill \_.turn off when surface unit is turned off.
•Each knob is identified by _28 7"_,__/_'",_o, '_
international symbols located • •
beloweach knob. 37
• Knob can be turnedin either 4• 5 • 6 • ,.' • ,. /
direction. ire
•Knob can be seton any number _ w
Re_r Fr_l
or between any numbers. 10-.=-- INTERNATIONAL
3. After cooking, turn knob to OFF then Front SYMBOLS SURFACE
remove pan. INDICATOR
LIGHT

ABOtlTYOURCOOKTOP
COOKTOPTo raise the cooktop:
1.Whencool,graspthefrontedgeofthecooktop.
Freestandingrangeswitha coilelementcooktopwillfeature 2.Gentlylift upuntilthetwosupportrods,at thefrontof
a lift-upcooktop, thecooktop, snapintoplace.
The cooktopdoes not liftuponthesemodels:
•Smoothopcooktop __ j,___
• Slide-inor drop-inrange
To preventstainingor discolorationof cooktop:
• Cleancooktopafter each use.-, SUPPORTROD
• Wipeacidor sugarstainsas soonas theyoccuras _ }\
thesestainsmay discoloror etchthe porcelain. Y
To lowerthe cooktop:
1. Holdthefrontedgeofthecooktopandcarefullypush
backoneachsupportrodtoreleasethenotched
support.
2.Thengentlylowerthetopintoplace.The supportrods
willslideintotherangeframe.
COIL ELEMENTS DRIPBOWLS:
• Whenan elementisturnedon,itwill cycle on andoff • Besure drip bowlis properly
to maintainthe heatsetting, installedand in place.
• Coil surfaceelementsareself-cleaning.• Dripbowlwillnot"rock" when
• Do notimmerseelementsin water, installedproperly.Notchabove
openingonbowlshouldbe f_f__
centeredoverscrewthat secures
Toremoveelement: _receptacleto thecooktop.
tWhencoo,.ra,see,ement l(-. / •Absenceofthesebow,sdur,ngook,ng
2. Carefullypulloutand _ maysubjectwiringor componentpartsunderneath
awayfrom receptacle. _ __ _ thecooktoptodamage.
/| • Topreventriskof electricshock orfire, never linedrip
To replaceelement: bowlswithaluminumfoil.
1. Insertterminalsonthe element_ Yourrangewillbeequippedwitheitherchromeplatedor
intoreceptacle. _porcelaincoatedsteeldripbowls.
2.Gentlyliftup onouteredgeof•Chromedripbowlswillturnblue orgoldovertimeor
elementwhileinsertingterminals
intoreceptacle. TERMINALS ifoverheated.Thistype of discolorationis normaland
permanent.Itwill notaffectcookingperformance.
3. Gentlypressdownon outer edgeof elementuntil •To protectthe chrome orporcelainfinish:
elementsitslevel ondrip bowl. • Avoid usinghigh settingsfor long periods oftime.
• Reduceto a lowersettingonce food begins
cooking.
• Do not useoversizedcookware.Pan shouldnot
extendmorethan 1 inchfrom the element.
• Cleanbowls aftereach use.

ABOUTYOUROVEN
HOWTO SET OVENTO BAKE OR ROAST
1. PressBAKEpad. INDICAToRBAKE--_
•BAKEindicatoron theBAKE padwill light. LIGHT
• 000 will light indisplay.
2. Pressor pressand hold• or • padto selectoven
temperature.
• 350° will lightwhen eitherpad ispressed.
• Oventemperaturecan besetfrom 170°to 550°.
3.Therewill bea 4 seconddelay beforethe oventurns
on. Whenthe oven turnson:
• OVENON indicatorwill light.
• PREHEATindicatorwill light.
• The preselectedtemperaturewill remain in display.
gDOVENON
I PREHEAT
LOOK
4. Allow8 to 15minutesfor the ovento preheat.
• A singlebeepwill indicatethatthe ovenhas
preheated.
• The OVEN ONindicatorwill remainlit.
• The PREHEATindicatorwillturn off.
5. Placefood in the oven. NOTE:The oventemperaturecan bechangedat
anytime.Ifthe temperatureischanged,the
PREHEATindicatorwillturnbackonuntilthenew
temperatureisreached.A beepwillsignalthatthe
newtemperaturehas beenreached.
6. Checkcookingprogressattheminimumcooking NOTE:Seepages24, 25, and26 foradditional
time.Cooklongerifneeded, informationonbakingandroasting.
7. PressCANCELpadand removefoodfrom the oven.
•The BAKE indicatoronthe BAKE padwill turn off.
• The OVENON indicatorwillturn off.NOTE: If you forget to turn offthe oven, it will
• Time of day will reappear in display,automaticallyturn off at the end of 12 hours.If
you wishto deactivatethis energysaving feature,
see page7.

AUTOMATICOVEN _-- =_ -TIMER CONTEIOI- Theclockmustbefunctioningandsetat thecorrecttime
ofdayforthisfeaturetooperateproperly.
TheAutomaticOvenTimerControlisusedtoturnthe
ovenonandoffat a presettimeofday.Thisfeaturecan
•Highlyperishablefoodssuchas dairyproducts, beusedforeitherovencookingor self-cleaning.
pork,poultry,seafoodor stuffingare not •Immediatestart: Oventurnsonimmediatelyand
recommendedfora delayedcookingoperation, automaticallyturnoffat a presettime.
•Bakingisnotrecommendedbecausepreheatingis • Delayedstart:Delaysthe startofcookingor cleaning
required, andautomaticallyturnsoffat a presettime.
Cooktimecanonlybesetfor upto11hoursand59
HOW TO SET TIMED COOKOPERATION minutes(11:59).
1.PressCOOKTIME pad. B
• COOKTIME indicatoronthe COOKTIME padwill
flash. [_
• 0:00 will light indisplay, then
2. Pressor pressand hold • orV padto enter cooking
time.
3. PressBAKEpad.
• BAKEindicatoronBAKEpadwilllight. _'1
B
• 000will lightin display.[ B_E ] then
4.Pressor pressand hold• orVpadto enter oven
temperature,
NOTE:Beepswill sound and 000will flash in display
ifthe BAKE padis not pressedwithin4 seconds.
5. IFYOU WISH TO DELAYTHE START OF
COOKING(ifnot,skipto#6):
a. PressSTOPTIME pad.
• STOPTIME indicatoron STOPTIME padwill _
flash. [ "(_ / then then
b.Pressor pressand hold• orvpad to entertime
of dayyouwishovento turn off.
c. PressCLOCKpad.
• Timeofdaywill reappearin display.
6. Whenthe oventurnson,the OVENON indicatorwill _ NOTE:It isnot necessarytoseta starttime.
light.The oventemperaturewill appear inthe display. [_'_ Controlwilldeterminewhen toturnthe oven
PresstheCOOKTIME padto recallthe remaining onbasedonthe cooktime youset.
cooktime.
7. Ovenwill automaticallyturn off. Four beepswill sound NOTE:See page7 ifyou wishto changethe end of
and "End"will light indisplay.A beepwill sound every cookingreminderbeeps.
30secondsfor the next5 minutes,
8. PressCANCELpadand beepswill stop. Remove
food fromoven.

ABOUTYOUROVEN
HOW TO SET OVEN TO BROIL
1.PressBROILpad. BROIL_ _
•BROILindicatoronthe BROILpadwill light. INDICATOR_ _ I
LIG.TI,"''J
• 000 willlight indisplay.
2.Pressthe • pad to selectHI (high)broilor the •pad Ht--,,-
to selectLO (low)broil.
• SelectHI broilfor normalbroiling.
• Select LObroilfor lowtemperature broilingof L0
longercookingfoodssuchas poultry.
I OVEN0i_
PREHEA-
LOOK
3. There will bean 8 seconddelay beforethe oventurns
on.Whenthe oventurns on:
• TheOVENON indicatorwill light.
4.Foroptimumbrowning,preheatbroilelementfor 3 to NOTE: Expectbroiltimes to increaseand
4 minutesbeforeaddingfood. browningto be slightlylighterif appliance is
installedona 208 volt circuit.
5. Placefood in the oven.Leaveoven door openedto NOTE:See page27for broiling instructionsand
thebroilstop position (openedabout4-inches). broilingchart,
6.Turn meatonceabout halfway through cooking.
7. PressCANCELpad. Removefood and broilerpan
fromtheoven.
•The OVENON indicatorwillturn off.
• TheBROIL indicatoron the BROILpad will turn off.
• Timeofdaywill reappearin display.

ABOUTYOUROVEN
• Besureall packingmaterialisremovedfromoven •PreparedFoodWarning:Followfoodmanufacturer's
beforeturning on. instructions.If a plasticfrozen food containerand/or
• Donot useoven for storingfoodorcookware, itscover distorts,warps,or isotherwisedamaged
duringcooking,immediatelydiscardthe food and its
• Manyaerosol-typespraycansare EXPLOSIVE container.The foodcouldbe contaminated.
whenexposedto heatand may behighly flammable.
Avoidtheir useor storagenearthe oven. •Followthe manufacturer'sdirectionswhen using
• Allowsteamand hot airto escapebeforereaching ovencookingbags.
intoovento check, add,or removefood. , , ,, ,_
GENERAL INFORMATION,_, = , OVENCHARACTERISTICS '
•Donotlockovendoorduringa cookingoperation, Becauseeachovenhasitsownbakingcharacteristicsdo
- IfthedoorislockedtheLOCK notexpectyournewovento performexactlylikeyour
indicatorwill lightandthe previousoven.Allowa period ofadjustment.
operationwill be canceled.
Unlockthedoor then resetthe OVENCONTROLLOCK-OUTFEATURE
operation. ....
TheControlLock-Outfeaturepreventsthe ovenfrom
- Ifoventemperatureisabove400°F,theinternalbeingturnedon.
lockingmechanismwillengageandthedoorcannot
be unlockeduntilthe oven hascooled. To activate:
• Boththe bakeand broilelementscycleonand offto 1.Pressand hold both
maintainthe oventemperaturefor baking.Onlythe broil STOPTIMEand L,,_ / and
elementturns on for broiling. CANCELpadsfor3
• If youpressBAKEor BROILpadand do notset an seconds.
oventemperatureorbroilsettingwithin30 seconds,the 2."OFF"willappearindisplaywhenthisfeatureis
programwillautomaticallycancel.Thetimeofdaywill activated.
reappearinthedisplay.• Onlytheclockandtimerfunctionswilloperate
•Tochangeoventemperatureor broilsettingduringwhenControlLock-Outfeatureisactivated.
cooking:RepeatstepItodeactivate.
- If temperatureisdisplayed,press
• or• padto selectthe new H
temperature.
- If anotherfunctionis displayed,press
BAKEor BROILpad thenpress
• or• pad to selectnewtemperature.

ABOUTYOURRANGE
• • _ _1 _ _ _ i .... ,i ¸ /!
OVEN DOOR : ' :iR LOCK LEVER : :
Thedoorlock lever is usedto lockthe ovendoorduringa
self-cleanoperation.To lockdoor, movethe leverto the
right.Thisisthe lockedpositionfor thecleancycle.
• WARNING:NEVERplaceexcessiveweight onor
standonanopenoven door.ThiscouldcausetheDo not movethe lock leverto the rightor lockedposition
whenbaking.If the door isaccidentlylocked:
rangeto tipover,breakthe door,or injurethe user.
• NEVERplacefingersbetweenhingeandfrontoven • The cookingoperationwillbe canceled.
frame.Hingearmsarespringmounted.If °Ifoventemperatureisabove400°F,thedoorwillnot
accidentlyhit,thehingewillslamshutagainstovenunlockuntiltheovenhascooled.
frameandcouldinjureyourfingers.• Allowoventocoolthenunlockandopendoor.(Placea
fan infrontofoventospeedcooling.)
When baking,be sureovendooriscompletelyclosed.
_VENT
Bakingresultswillbe affectedifdooris not closed., ....
NOTE:Whenrangeis new,the oven door may feel
"spongy"when youclosethedoor.Thisis normaland will
becomeless "spongy"withuse.[[
Toremovelift-offoven door: Whenovenisinuse,thearea neartheovenvent
1. Whencool,openovendoortothebroilstoppositionopeningmayfeel warmor hottothetouch.
(openedabout4-inches). Theovenventislocatedat theRIGHT
2. Graspdoor ateach side. REARelement.
3.Liftup evenlyuntildoorclears hingearms. Do notuse • Besuredrip bowlfor theright rear
doorhandleto lift door. elementhasa hole in the center to
allowproper ovenventing. OVENVENT
•Donotcover thisdrip bowlwith OPENING
aluminumfoil as thiswill blockproper
OVENFRAME ovenventingandmayaffectbakingresults.
OVENVENTLOCATION
DOOR HINGE
Toplaceoven dooronoven:
1.Graspdoorateachside. LEVER
2.Alignslotsin doorwithhingearmsonrange,
3. Slidedoordownontohingearmsuntildoorisseatedon
hinges.Thenpushdownontopcornersofdoorto
completelyseatdooronhinges.
Doorisnotcompletelyseatedif onesideis higherorif
doorappearsto becrooked.
Donotattempttoopenorclosedoororoperateovenuntil
doorisproperlyreplaced.

ABq)UTYOURRAN(IE
OVEN LIGHT OV_ RACKS
CAUTION 1
f
Disconnect
powertorangebytripping
circuit
LDonotattempttochangetherackpositionwhenthe
breakeror removingfusebeforereplacinglight ovenishot.
bulb.
•Besurebulbiscoolbeforetouchingorreplacing The ovenrackisdesignedwitha safetylock-stopposition.
bulb. Thispreventstherackfromaccidentlycomingcompletely
•Usea drypotholdertopreventpossibleharmto outoftheovenwhenpullingtherackouttoaddor remove
handswhenreplacingbulb. food.
•Donottouchhotbulbwitha dampclothasthis Toremoveovenrack:
maycausethe bulbto break. 1. Whenrack iscool, pullrackstraightoutuntilitstops at
thelock-stopposition.
To turnon the oven light: PushinNOTE: If itisnecessaryto change rackpositionwhen
rockerswitchlocatedonthebackguard, rackishot,usepotholderstoprotecthands.
2.Tiltthefrontendoftherackup.
3.Continuepullingrackoutofoven.
Toreplaceoven lightbulb:
1. Disconnectpowertorange. _,_= / RACK
2.Hold bulbcoverinplacethen slidewireretaineroff [_ \. ._ _.'J'_SUPPORT
cover.NOTE: Bulbcoverwillfall ifnot heldin place _ _ °" _
whileremovingwireretainer._\// I [_
3. Removebulbcover. ]1_,_\\\\/ I I.] 11
4. Removelightbulband replacewith a4OwattapplianCebulb.II__
\\ __ J_
5, Replacebulbcoverandsecurewithwireretainer.
6, Reconnectpowertorange.Resetclock, Toreplaceoven rack:
BULBCOVER 1. Placerackontheracksupportsinoven.
2,Tiltthefrontendoftherackupslightly,
3. Sliderackbackuntilitclearsthelock-stopposition,
4.Lowerfrontofrackandsliderackstraightback into
oven.
(5. IMPORTANT:Pullrackoutto the lock-stoppositionto
besure rackiscorrectlyreplaced.
WIRE 6.If properlyinstalled,rack will not comeout ofoven
RETAINER unlessthe frontedgeisliftedup.
7. Push rack backinto oven and closeoven door.

(DABOUTYOURRAN(iE
=' LEVELING LEGS =
STORAGE DRAWER : ..... :
I&°'°"°"t j
Donot storeplastic, paper products, foodor flammable WARNING: The anti-tip bracket providedwiththis
materials inthis drawer. The drawer may become too rangemust secure oneof the rear leveringlegs to
warmfortheseitemswhen theoven is inuse. thefloor.Thisbracket prevents therangefrom
accidentlytipping.
The storage drawer at the bottomof the range is safe and
convenient for storing metalandglass cookware.
The storage drawer can be removed to clean underthei[?_'__ri_
range._,
To remove storage drawer: _u _ _
2.Lift up front of drawer.
3. Pull out to the second stop position.
4.Grasp sides and lift drawer up and out. _ _ANTI-TIPBRACKET
LEVELINGLEG
The installer should level the range when it isinstalled. If
the range is not level, turn the leveling legs, located at
each corner of the range, until range is level. Placelevel
.. on an oven rack to determine ifrange is level.
Cooking resultscan be affected if the range was not
To replace storage drawer: properly leveledduring installation.
1. Fittherollers located at the endsofthedrawer glides
intotherailson therange.
2. Lift up frontof drawer and gently pushin tofirststop
position,
3.Liftdrawer up again andpush untildrawer is closed.

ABOUTCLEANING
HOWtoSEt i
OVEN FORA SELF,CLaN CYCLE
F
1. Movedoorlocklevertolockedposition.
2.PressSELF-CLEANpad.
• CLEANindicatoronthe CLEANpadwillflash.
• 3:00willlightin display.B
• Ifdooris notlocked,"dr" willappearin display.
Lockdoor. _'_
3. Press• or • padto selectcleantime. then
• You canselectfrom2 upto4 hours.
•Ovenwillautomaticallyclean for 3 hours.Or,
• Select2 hoursfor lightsoil.
•Select4 hoursfor heavysoil.
4. IFYOU WISHTO DELAYTHE STARTOF
CLEANING(if not,skip to #5):
a. PressSTOPTIME pad.
b. Press• pad to selectthe time ofday youwishthe _
ovento turnoff. ["_ / then
• PressCLOCKpad andtime of daywill reappear
in display.
• PressSTOPTIME padto recallthe time youset.
5. Whenthe oventurns on:
• The OVENON indicatorwill light.
• LOCKindicatorwilllight whenovenheatsto400°.
• Internallock will engage.Doorcannotbeunlocked
and openedwhen LOCK indicatorislit. _,LIGHTTURNSONWHEN
OVENREACHES400°E
6.Aboutone hourafter the cleancycle ends,the LOCK
indicatorwillturn off. Theoven door canbe unlocked
andopened.
TOCANCELCLEANCYCLE:
1.PressCANCELpad.
2. If LOCKindicatoris NOT lit,unlock and openoven ,, WHENLIGHTTURNS
door.OFF,UNLOCKAND
IfLOCKindicatoris lit,allow ovento cool aboutone OPENDOOR.
hourthenunlock and openovendoor.

(D ABOUTCLEANING
•Itisnormalforpartsofthe oventobecomehot
duringa self-cleancycle.
• Avoidtouchingdoor,windoworovenventarea
duringa self-cleancycle.
•Topreventdamagetoovendoor,do notattempt
tounlockthedoorwhenthe LOCKindicatoris
displayed.
•Itisnormalforexcessiveflare-upsandsmokingto
occurduringcleaningiftheovenisheavilysoiled.
BEFORESELF-CLEANCYCLE DURINGSELF-CLEANCYCLE AFTERSELF-CLEANCYCLE
•Removepans,broilerpan,and •Asovenheats,the LOCKindicator •The LOCKindicatorwillturnoff
ovenracks,willlightinthedisplay.Atthis aboutonehouraftercleancycle
•NOTE:Racksmaydiscolorand point,thedoorcannotbe ends.The doorcan beunlocked
unlockedandopened, andopened.Usecareasoven
notslideeasilyafter cleaning,may still behot.
• Cleanovenframeand door frame. •To preventdamageto door orlock
Theseareasare not exposedto lever,donot forcedoor open •A gray powderyashmayremain
whenthe LOCKindicatoris onthe oven bottomor walls.This
cleaningtemperatures;soil may
bakeon during clean cycle, displayed, is normal.Usea damp clothto
removeash.
• Topreventdamage,do not clean =Somesmokeand odormay be
gasketlocatedon ovendoor. detectedthe firstfew times the •Ifsoil remains,the cleancycle
Gasketsealsin heatduring theoveniscleaned.This isnormal maynot havebeen long enough.
cleancycle, andwill lessenintime. • Cleanaroundoven vent openingif
• Topreventexcessivesmoke, • Smokemay occurifoven is there is a depositfromthe fumes
flare-ups,or flaming,wipe up heavilysoiledor if broiler panwas ventedduringcleaning.
excessgrease orspilloversfrom leftin oven.
ovenbottom. • A whitediscolorationmayappear
• As ovenheats,youmay hear aftercleaningif acid soils (milk,
• Porcelainisacid resistant,not soundsof metalpartsexpanding tomato, lemon,etc.) were not
acid proofand may discolorduring and contracting.This is normal wiped up beforethe clean cycle.
thecleancycle.To preventor and will not damageoven.Porcelainenamelis acidresistant
reducediscoloration,wipe up not acidproof.This discoloration
sugaror acid spills(lemon,milk, isnormaland will notaffectthe
barbecuesauce,cheese), performanceof the cleancycle.
_1"rumoffovenlightbeforecleaningasthe light
mayburnoutduringa cleancycle.
Cleanoven reguladyratherthan allowingsoilto
build-up.
_]Do notuseoven cleanersin,on, or aroundany
partof the range astheywilldamagethe finishor
parts.

ABOUTCLEANING
•Besureapplianceisoffand all partsare coolbeforehandling or
cleaning.Thisisto avoid damageand possibleburns.
• Ifa partis removed,besure itis correctlyreplaced.
•Topreventstainingor discoloration,clean applianceafter each use.
CLEANING CHART
PROCEDURES
Broilerpan and • Soapand water Never cover insertwith aluminumfoil as this prevents the fat from
insert •Plasticorsoap drainingto pan below.
filledscouringpad 1. Removefromovenafteruse.Coolthenpouroffgrease.
•Dishwasher 2.Placesoapyclothoverinsertandpan;letsoaktoloosensoil,
3. Wash in warm soapywater. Use soapfilledscouringpad to remove
stubbornsoil.
4. Broilerpanand insert can becleaned in thedishwasher.
Controlknobs •Soapandwater Foreaseof cleaning,turn off knoband removeby pullingforward.
•Mildliquidsprays 1.Wash,rinse, anddry. Do not useabrasive cleaningagentsas they may
• Glass cleaners scratchthe finish and removethe markings.
2.Turn oneach elementto besure knobshave beencorrectly replaced.
Drip bowls, Do notcover drip bowls with aluminumfoil.
chrome • Soapand water Bowlscanpermanentlydiscolorovertime,ifexposedtoexcessiveheat,or if
• Plasticscouring soil is allowedto bake on. The discolorationwill not affect the cooking
pads performance.
• Mildabrasive 1. Aftereach use,wash, rinseand dry.
cleaners 2. If heavilysoiled,gentlyscrub with plasticscouringpad. If soilisallowed
• FlitzMetalPolish to burn on,it may be impossibleto remove.
3. A non-abrasivemetal polishsuchas Flitzmay be usedto help remove
blue/goldheat stains. Flitz isavailable in many automotivesupply and
hardwarestores.These stainsare caused byoverheating,andnormally
occurovera periodoftime.Theyareusuallypermanent.Followpackage
directions.
Dripbowls, • Soapandwater Porcelainmaydiscoloror crazeovertime,ifoverheated,orifsoilisallowed
)orcelain •Mildabrasive tobakeon.This isnormaland willnot affect cookingperformance.
cleaners 1. When cool, wash after each use, rinse and dry to prevent staining or
•Plasticscouring discoloration.
pads 2.To clean heavy soil, soak in hot sudsy water,then use mild abrasive
• Dishwasher cleaner and plasticscouringpad.
Elements, 1. Elementsare self-cleaning.Soilwillburnoffas elementsare used.
ovenand coil2. Donotsprayovencleaneron elements,electricalhookuporconnection.
3. Donotimmersecoil-typesurfaceelementsinwater.
Enamel,painted•Soapandwater NOTE:Usedrytowelorclothtowipeupspills,especiallyacid(milk,lemon
• Backguard •Mildliquidcleaner juice,fruit,mustard,tomatosauce)orsugaryspills.Surfacemaydiscoloror
•Ovendoor • Glasscleaner dullifsoilisnotimmediatelyremoved.Thisisespeciallyimportantforwhite
•Sidepanels surfaces.
•Storagedrawer 1.Whencool,washwithwarm soapywater,rinseanddry.Neverwipea
orlowerpanel warmor hotsurfacewitha dampclothasthismaydamagethesurface
andmaycausea steamburn.
2. Forstubbornsoil,usemildlyabrasivecleaningagentssuchas baking
sodapasteorBonAmi.
3. Donotuseabrasive,causticorharshcleaningagentssuchassteelwool
padsorovencleaners.Theseproductswillscratchorpermanentlydam-
agethe surface.

ABOUTCLEANING
PARTS CLEANINGAGENTS CLEANING PRocEDURES
Glass •Soapandwater To preventstainingof the oven window,avoidusingexcessive
•Ovenwindow •Glasscleaner amountsofwaterwhichmayseepunderorbehindglass.
•Pasteof baking 1.Wash withsoap and water. Removestubborn soil with pasteof baking
soda andwater soda andwater.Rinsewith clear waterand dry.
2. Do not use abrasive materials such as scouring pads, steel wool or
powderedcleaningagents.They will damageglass.
Metalfinishes •Soapandwater 1. Washwithsoapand water ora glasscleaner and a softcloth.
suchasbrushed•Glasscleaner 2.To preventscratchingor dullingofthefinish,do notuse mildlyabrasive,
aluminum,or •Plasticor non- abrasive,or harshcleaners,orcausticcleanerssuchas ovencleaners.
chromeabrasive parlor 3.Tocleanbrushedaluminum:Useonlysoapandwaterorasoftclothand
• Backguard sponge glasscleanerto preventscratchingor dullingof thefinish.
• Cooktop 4.To clean brushedchromecooktopor door:
• Ovendoor •Usea pasteof bakingsodaand waterand a soft cloth.
• Storagedoor •Rubwith thegrainto preventscratching,dulling or streakingof the
•Trimparts finish.
• Usea soft clothand mineraloil to restorelusteror to removefinger-
printsor smudges.
• Cleanwith an automotivechrome cleaneror polisher.
Oven interior Porcelainenamel isacid resistant,not acidproof.Therefore,when cool,
wipe upsugaryor acidspills (milk,fruit,tomato, etc.)as they occur.See
pages17-18for self-cleanoven.
Oven racks• Soap andwater 1. Cleanwith soapy water.
• Plasticscouring 2. Removestubbornsoilwithcleansingpowderorsoap-filledscouringpad.
pad Rinseand dry.
• Cleansingpowders Rackswillpermanentlydiscolorandmaynotslidesmoothlyif leftintheoven
• Soap-filled during aself-cleanoperation. If thisoccurs, wipethe rack and embossed
scouringpad rack supports with a small amount of vegetable oil to restore ease of
movement,then wipe off excessoil.
Plasticfinishes • Soapand water NOTE: To prevent staining or discoloration, wipe up fat, grease or acid
•Door handles •Non-abrasive (tomato,lemon, vinegar,milk,fruitjuice, marinade) immediatelywith a dry
• Backguardtrim plasticpad or papertowel or cloth.
• Knobs sponge 1.When cool,clean with soapand water,rinse,and dry.
• End caps •Glasscleaner 2. Use a glasscleanerand a softcloth.
NOTE: Never use oven cleaners, abrasive or caustic liquid or powdered
cleansers on plastic finishes. These cleaning agents willscratch or mar
finish.
Porcelain enamel•Soapand water Porcelainenamelisglassfusedonmetalandmaycrackorchipwithmisuse.
•Cooktoponcoil •Pasteof baking It is acid resistant,not acid proof. All spillovers, especially acid or sugar
elements soda andwater spillovers,shouldbewipedup immediatelywithadrycloth.Thisisespecially
• Trimon •Non-abrasive important around the vent opening for smoothtop cooktop. Surface may
smoothtop plasticpad or discoloror dull if soilis not removed.
cooktop sponge1.When cool,washwith soapy water,rinseand dry.
•Backguard 2. Neverwipe off awarmor hotsurfacewith adamp cloth.Thismay cause
crackingand chipping,
3. Neveruseovencleaners,abrasiveorcausticcleaningagentsonexterior
finishof range.
