Jensen ISO-MAX DB-2RM-WP User manual

Jensen ISO•MAX
®
Jensen ISO•MAX
®
USERGUIDE
DB-2RM-WP Wall Direct Box DB-2RM-WP Wall Direct Box
FEATURES
ISO-MAX® DB-2RM-WP User Guide - Part No. R870 1215 00 • © Copyright 2014 all
rights reserved. Specifications and appearance are subject to change without notice.
Jensen is a division of Radial Engineering Ltd.
ISO-MAX DB-2RM-WP SPECIFICATIONS
1. LEVEL:Let’s youadjustthe volumelevelof yoursourcedevice.
2. MONO: Mixes the left and right inputs together and outputs a
mono signal to the PA system.
3. LIFT: Disconnects the audio ground of both channel outputs to
eliminate hum and buzz created by ground loops.
4. 3.5MMINPUT:Stereo mini-phonejack letsyou connect mobile
devices such as laptop computers, MP3 players or tablets.
Plugging in here will deactivate the RCA connectors.
5. RCA INPUT: A stereo pair of RCA inputs lets you connect a
wide range of consumer electronics such as CD/DVD players
and digital players/recorders.
6. STEELENCLOSURECOVER: Protectsthe audio circuit from
electro-magnetic and radio interference.
7. HEAVY DUTY FRAME:The PCB and cover mount to a ridgid
14-guage steel L-frame that’s powder-coated for long life.
8. OUTPUTTERMINALS:Balanced leftandright mic-leveloutput
connections are made via two screw-down terminals.
9. TIE-WRAP HOLD-DOWNS: Slots cut in the steel frame for
tie-wraps (included) help secure the cable and provide strain
relief for the connectors.
Frequency response.........................................20Hz to 18kHz +/- .5dB
Total harmonic distortion ..................................0.01% THD 20Hz to 20kHz
Stereo input ......................................................Unbalanced high-Z -10dB
Input connections..............................................RCA and 3.5mm TRS
Stereo output ....................................................AES standard balanced 600-Ohm,
mic-level, pin-2 hot
Output connection.............................................Screw terminals
Input level..........................................................Variable from infinity
Power requirement............................................None, completely passive
Mounting...........................................................Fits single gang electrical junction box
4
7
2
3
5
1
8 8
9
6
To meet the requirements of California Proposition 65, it is our responsibility to inform you of the following:
WARNING:ThisproductcontainschemicalsknowntotheStateofCaliforniatocausecancer,
birth defects or other reproductive harm.
Please take proper care when handling and consult local government regulations before discarding.
jensen-transformers.com
JENSEN TRANSFORMERS 3 YEAR
TRANSFERABLE LIMITED WARRANTY
Jensen-transformers(“Jensen”)warrants thisproducttobe freefromdefectsin materialandworkmanship
andwillremedyany suchdefectsfreeofchargeaccording tothetermsofthiswarranty.Jensenwillrepair
or replace (at its option) any defective component(s) of this product (excluding finish and wear and tear
on components under normal use) for a period of three (3) years from the original date of purchase. In
theeventthataparticularproductisnolongeravailable,Jensenreserves the right to replace the product
with a similar product of equal or greater value. In the unlikely event that a defect is uncovered, please
call 818-374-5857 to obtain a RA number (Return Authorization number) before the 3 year warranty
periodexpires.Theproductmustbe returned prepaid in the originalshippingcontainer(orequivalent)to
Jensen or to an authorized repair center and you must assume the risk of loss or damage. Acopy of the
originalinvoiceshowing date of purchase and thedealernamemustaccompanyanyrequest for work to
beperformedunderthis limitedandtransferablewarranty.Thiswarrantyshall notapplyiftheproducthas
been damaged due to abuse, misuse, misapplication, accident or as a result of service or modification
by any other than an authorized repair center.
THERE ARE NO EXPRESSED WARRANTIES OTHER THAN THOSE ON THE FACE HEREOF
AND DESCRIBED ABOVE. NO WARRANTIES WHETHER EXPRESSED OR IMPLIED, INCLUDING
BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE SHALL EXTEND BEYOND THE RESPECTIVE WARRANTY PERIOD
DESCRIBED ABOVE OFTHREE YEARS. JENSEN SHALLNOT BE RESPONSIBLE OR LIABLE FOR
ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSARISING FROM THE USE
OFTHISPRODUCT. THISWARRANTYGIVESYOUSPECIFICLEGALRIGHTS,ANDYOUMAYALSO
HAVE OTHER RIGHTS, WHICH MAY VARYDEPENDING ON WHERE YOU LIVEAND WHERE THE
PRODUCT WAS PURCHASED.
Jensen Transformers
9304 Deering Avenue, Chatsworth, CA91311
Phone: [phone] • Fax: [phone]
www.jensen-transformers.com
DB-2RM-WP
WALL MOUNT DIRECT BOX

Thank you for purchasing the Jensen DB-2RM-WP stereo direct box. This
innovative direct box is designed to fit a standard single-gang electrical wall
plate and provides the A/V integrator with an elegant means of connecting
a stereo audio source such as a laptop computer, CD player or tablet to a
professional audio system. Although the DB-2RM-WP is designed to be
plug & play easy to use, please take a minute to read this short manual. It
will give you insight on how to best use the DB-2RM-WP direct box and get
the most out of it.
INSTALLATION
The DB-2RM-WP fits a standard single gang electrical wall plate and should
be installed in accordance with the electrical codes in your region. It is the
responsibility of the installing contractor to comply with electrical codes
and regulations with regards to installing and terminating. The DB-2RM-
WP is classified as a low voltage device and should never be installed in
the same electrical junction box alongside high-voltage class-1 electrical
powerdevices. Pleaseconsult yourlocal electrical authoritybefore installing.
The DB-2RM-WP is completely passive and no power source is required.
Signal connections are made using standard twisted pair audio cable. This
usually comes in a shielded format with two insulated conductors 18AWG to
26AWG and a ground conductor often called the drain wire. The cable itself
should comply with all electrical codes as regulated in your area.
Shielded twisted pair audio cable with drain wire.
GROUND (DRAIN)
WHITE OR RED (+)
FOIL SHIELD
BLACK (-)
Run two twisted pair cables from the PAmixer/amplifier to the location where
the DB-2RM-WP is to be installed. Mark one of the cables with tape or magic
marker.This willhelp toindicateone cableas theleftchannel. Pullabout 20cm
(8”) of cable through the electrical junction box to allow easy manipulation
while installing. Strip back the cable insulation by 1cm (½”) and tin the bare
wire ends with solder to prevent corrosion.
Next, remove the protective metal cover from the DB-2RM-WP using a
Phillips screwdriver and locate the audio output terminals on either side
labelled ‘LEFT’ and ‘RIGHT’. The output terminals are balanced and have
three screw-down connections, one labelled negative (-); another labelled
ground (G); and a third labelled positive (+).
Left output Right output
CONNECTIONS
Starting with the left channel terminal, push the BLACK wire into the negative
connection and screw down tight using a small slotted screwdriver. Insert the
other color wire (sometimes white or red) into the positive connection and screw
it down tight. The drain wire or shield is inserted into the ground connection and
tightened. Repeat for the right channel.
Tie-wrap
inserted into
hold down slots
Theincluded tie-wrapsare usedwith hold-down slots cut intothe frameto secure
the twisted pair cable and provide strain relief. Once secure, replace the cover
and fit into the electrical junction box.
You will need to terminate the cables at the mixer/amplifier using the same
polarity. The following diagrams show balanced terminations for standard XLR
and ¼” TRS phone connectors.
SHIELD/DRAIN
RING (-)
TIP (+)
SLEEVE (G)
SHIELD/DRAIN
123
-G + XLR and ¼” TRS Balanced terminations
The output is mic level and therefore should be connected to a microphone preamp
input.At themixer/amplifier,connectthe leftandrightcablesfrom theDB-2RM-WPto
twomicinputson thePAmixer/amplifiersystem.If thereisonlyonemicinput available
or if the PAsystem operates in mono, you can connect the left channel and set the
DB-2RM-WP to mono mode by depressing the MONO switch on the front panel.
USING THE DIRECT BOX
Before connecting a device to the DB-
2RM-WP, turn the audio level control fully
counter-clockwise to the off position. This
will help avoid loud transients that can
damage more sensitive components like
tweeters and startle your audience.
TheDB-2RM-WP features stereoRCAand3.5mm TRSinputjacks toconnect
anunbalanced audiosource. TheRCAjack allowsconsumer electronicslike
CD/DVD players to connect to the PA system while the 3.5mm jack works
well with mobile devices like smart phones and tablets.
After connecting your device, start playback and slowly turn up the level
control on the DB-2RM-WP to a comfortable listening volume. Be aware
your device may also have its own volume control that you may need to
adjust. It is very difficult to overload the DB-2RM-WP, however it is possible
to overload the input on the mixer/amplifier. If you hear distortion, turn the
level control down or adjust the volume on your device.
USING THE GROUND LIFT
Sometimes when connecting your device to the PAsystem via the DB-2RM-
WPdirect box,youmay encounternoise likehum andbuzzcaused byground
loops.If youencounternoise afterconnecting, depresstheground LIFTswitch
on the front panel. This disconnects the signal ground between the source
device and the PAsystem eliminating ground loop noise. The LIFT switch is
recessedto preventtampering. Usea smallscrewdriver toaccess theswitch.
USING THE MONO SUM
The MONO switch on the front panel sums the left and right inputs together.
When this switch is fully depressed, the DB-2RM-WP will output the same
mono signal at both screw terminal outputs. This can be used to connect a
stereo device like a CD/DVD player to a mono only sound system or when
only one input at the mixer is available. The MONO switch is recessed to
prevent tampering. Use a small screwdriver to access the switch.
