JETWAY MM91 Series User manual

MM91 Series User Manual
NO. G03-MM9100-F
Rev: 1.0
Release date: Sep 20, 2019
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are subject
to change at any time without notice, and should not be construed as a commitment by manufacturer.

ii
ENVIRONMENTAL SAFETY INSTRUCTION ...........................................................................iii
ENVIRONMENTAL PROTECTION ANNOUCEMENT ..............................................................iii
USER’S NOTICE .......................................................................................................................iv
MANUAL REVISION INFORMATION........................................................................................iv
ITEM CHECKLIST .....................................................................................................................iv
CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD
1-1 SPECIFICATION .........................................................................................................1
1-2 LAYOUT DIAGRAM ....................................................................................................2
CHAPTER 2 HARDWARE INSTALLATION
2-1 JUMPER SETTING .....................................................................................................6
2-2 CONNECTORS AND HEADERS ................................................................................10
2-2-1 REAR I/O BACK PANEL CONNECTORS.....................................................10
2-2-2 MOTHERBOARD INTERNAL CONNECTORS .............................................11
2-2-3 HEADER PIN DEFINITION ...........................................................................14
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERNING SETUP ..................................................................................................19
3-2 BIOS MENU SCREEN ................................................................................................20
3-3 FUNCTION KEYS .......................................................................................................20
3-4 GETTING HELP ..........................................................................................................20
3-5 MENU BARS ...............................................................................................................21
3-6 MAIN MENU ................................................................................................................21
3-7 ADVANCED MENU .....................................................................................................22
3-8 CHIPSET MENU .........................................................................................................30
3-9 SECURITY MENU.......................................................................................................32
3-10 BOOT MENU...............................................................................................................33
3-11 SAVE & EXIT MENU ...................................................................................................34
TABLE OF CONTENT

iii
Environmental Safety Instruction
Avoid the dusty, humidity and temperature extremes. Do not place the product in
any area where it may become wet.
0 to 40 centigrade is the suitable temperature. (The figure comes from the request
of the main chipset)
Generally speaking, dramatic changes in temperature may lead to contact
malfunction and crackles due to constant thermal expansion and contraction from
the welding spots’ that connect components and PCB. Computer should go
through an adaptive phase before it boots when it is moved from a cold
environment to a warmer one to avoid condensation phenomenon. These water
drops attached on PCB or the surface of the components can bring about
phenomena as minor as computer instability resulted from corrosion and oxidation
from components and PCB or as major as short circuit that can burn the
components. Suggest starting the computer until the temperature goes up.
The increasing temperature of the capacitor may decrease the life of computer.
Using the close case may decrease the life of other device because the higher
temperature in the inner of the case.
Attention to the heat sink when you over-clocking. The higher temperature may
decrease the life of the device and burned the capacitor.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.

iv
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED
OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN
PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIES AND WE
DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME
WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE REGISTERED
TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE USED ONLY FOR
IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
1.0 First Edition Sep 20, 2019
Item Checklist
Motherboard
Cable(s)
I/O Back panel shield

1
Chapter 1
Introduction of the Motherboard
1-1 Specification
Spec
Description
Design
m-ATX form factor; PCB size: 24.4 x24.4 cm
Chipset
Intel®H110 Express Chipset
CPU Socket
Supports Intel®Core™ i7, Core™ i5, Core™ i3 series,
Pentium®processor in LAG1151 Package (Max. 65W)
* for detailed CPU support information please visit our website
Memory Slots
2*DDR4 RAM module slot
Supporting 2* 2133MHz DDR4 RAM Module, expandable
to 32 GB (Maximum)
Support dual-channel function
Expansion Slots
1 * PCI-Express x16 slot (PCIE1)
1 * PCI-Express x4 slot (PCIE3)
2 * PCI slot (PCI1/2)
1 * Full-size Mini-PCIE USB signal only (MPE)
Storage
3 * SATAIII 6Gb/s port (SATA1/2/3)
1* M.2 Socket 3 connector (Socket 3, M-key, support type
2242/2260/2280/22110 SATA SSD)
LAN Chip
Integrated with 1* I211-AT + 1* I219-V GbE Intel LAN chip
Support Fast Ethernet LAN function of providing
10/100/1000Mbps Ethernet data transfer rate
Audio Chip
Realtek ALC662-VD 6-channel Audio Codec integrated
Audio driver and utility included
BIOS
AMI 64MBit Flash ROM
Multi I/O
Rear Panel I/O:
2* Serial port connector(COM1/2, COM1 supports
RS232/422/485 function )
2* USB 2.0 port connector
1* HDMI port connector
1* DVI-D port connector
1* VGA port connector
2* RJ-45 LAN port connector
4* USB 3.0 port connector
1*3-jack audio connector (Line-in, Line-out, MIC)
Internal I/O Connectors & Headers:
1 *24-pin main power connector
1 *8-pin 12V power connector
1* Front panel audio header
1* SPDIF-out header
2* LAN Status indicator header(LAN1_LED/LAN2_LED)
8* COM port header (COM3/4/5/6/7/8/9/10)
1* GPIO header

2
1* Front panel header
1* Speaker header+ 1* POWER LED header
1* Vertical type connector USB 2.0 port
1* 9-pin front panel USB 2.0 header for 2* expansion USB
2.0 port
1* PS/2 KB & MS header
1* SMBUS header
3* FAN header
1-2 Layout Diagram
Rear IO Diagram
* Note: Many PCs now include XHCI USB controllers which allow for the support of
USB 3.0 and higher USB speeds. This inclusion of XHCI controllers has lessened the
need for EHCI USB controllers within platforms. However, legacy operating systems
(OS) may not natively recognize XHCI controllers. You might need to pre-install XHCI
driver while desiring to install a non-XHCI OS (ex.Windows* 7) on Intel platforms
which do not include EHCI controllers. Please contact your representative for more
details.
Serial Port
(COM2)
USB 2.0 Ports
HDMI Port
VGA Port
DVI-D Port
RJ-45 LAN Ports
USB 3.0 Ports
Line-IN
Line-OUT
MIC-IN
Serial Port
(COM1)

3
Motherboard Internal Diagram
*Note: SIM card slot only work when compatible SIM card installed & 3G LAN card installed in MPE
Mini-PCIE slot.
ATX 12V
Power Connector
Serial Ports
(COM1/COM2)
USB 2.0 Ports
over HDMI Port
VGA Port
over DVI-D Port
RJ-45 LAN Ports
Over USB 3.0 Ports
Audio
Connectors
LGA 1151
CPU Socket
PCI Express 2.0 x 16 Slot (PCIE1)
Intel H110 Chipset
SATAIII Ports
(SATA1/2/3)
ATX Power
Connector
SMBUS Header
PS2KBMS Header
SYSFAN2 Header
GPIO Header
Serial Port Headers
(COM8/7/6/5/4/3)
Serial Port Headers
(COM10/9)
SPK-LED
USB 2.0 Headers
USB2.0 Vertical
Connector
CPUFAN Header
SYSFAN1 Header
DDR4
DIMM Slot x 2
PCI Express 2.0 x 4 Slot
(PCIE3)
HDMI_SPDIF
Header
PCI Slots
(PCI12)
M.2 Socket 3 Connector
(MH1/2/3/4) *
Full-size
Mini-PCIE Slot
USB only(MPE)
*
*SIM Card Slot
Front Panel Header
(JW_FP)
Front Panel
Audio Header
LAN1 over LAN2_LED
Header

4
Motherboard Jumper Position
Jumper
Jumper
Name
Description
JPCOM1
COM1 Port Pin9 Function Select
4-pin Block
JPCOM2
COM2 Port Pin9 Function Select
4-pin Block
JPCOM3
COM3 Header Pin9 Function Select
4-pin Block
JPCOM4
COM4 Header Pin9 Function Select
4-pin Block
JPCOM5
COM5 Header Pin9 Function Select
4-pin Block
JPCOM6
COM6 Header Pin9 Function Select
4-pin Block
JATX_AT
Pin (1-2): ATX Mode
Pin (2-3): AT Mode
3-pin Block
COPEN
Pin (1-2) OPEN: Normal
Pin (1-2) SHORT: Case Open
2-pin Block
JBAT
Pin (1-2): Clear CMOS RAM Function Setting
Pin (3-4): DFDS Override
4-pin Block
JP1
Mini PCI-E Slot (MPE)VCC3.3V/3.3VSB Select
3-pin Block
JATX_AT
JBAT
JPCOM5
JPCOM6
JPCOM3
JPCOM4
JPCOM2
JPCOM1
JP1
COPEN

5
Connectors
Connector
Name
ATXPWR
ATX Main Power Connector
ATX12V
ATX 12V Power Connector
COM1_2
Serial Port COM Connector X2
USB1
USB 2.0 Port Connector X2
USB20_V
USB 2.0 Vertical Port Connector X1
HDMI
HDMI Port Connector
CRT_DVI
Top: VGA Port Connector
Bottom: DVI-D Port Connector
UL1/UL2
Top:RJ-45 LAN Connector X2
Middle & Bottom: USB 3.0 Port Connector X4
AUDIO
Top: Line-in Connector
Middle: Line-out Connector
Bottom: MIC Connector
SATA1/2/3
SATAIII Connector X3
Headers
Header
Name
Description
FP_AUDIO
Front Panel Audio Header
9-pin Block
SPDIF
HDMI_SPDIF Out Header
2-pin Block
LAN1_LED/ LAN2_LED
LANLED Activity Header
2-pin Block
COM 3/4/5/6/7/8/9/10
Serial Port Header
9-pin Block
GPIO_CON
GPIO Header
10-pin Block
JW_FP
PWR LED/ HD LED/ Power Button
/Reset
9-pin Block
SPK_LED
Power LED & Speaker Header
7-pin Block
FP_USB1
USB 2.0 Header
9-pin Block
PS2KBMS
PS/2 Keyboard & Mouse Header
6-pin Block
SMBUS
SMBUS Header
5-pin Block
SYSFAN1/SYSFAN2/CPUFAN
FAN Header
4-pin Block

6
Chapter 2
Hardware Installation
2-1 Jumper Setting
JPCOM1 (4-pin): COM1 Port Pin9 Function Select
JPCOM1→COM1 Port
4-6 Closed:
RI= 12V
6
4
2
3-4 Closed:
RI= 5V
2-4 Closed:
RI=RS232
3
1
5
1
3
5
2
4
6
1
3
5
2
4
6
JPCOM2 (4-pin): COM2 Port Pin9 Function Select
JPCOM2→COM2 Port
4-6 Closed:
RI= 12V
6
4
2
3-4 Closed:
RI= 5V
2-4 Closed:
RI=RS232
3
1
5
1
3
5
2
4
6
1
3
5
2
4
6
JPCOM3 (4-pin): COM3 Header Pin9 Function Select
JPCOM3→COM3 Header
4-6 Closed:
RI= 12V
6
4
2
3-4 Closed:
RI= 5V
2-4 Closed:
RI=RS232
3
1
5
1
3
5
2
4
6
1
3
5
2
4
6

7
JPCOM4 (4-pin): COM4 Header Pin9 Function Select
JPCOM4→COM4 Header
4-6 Closed:
RI= 12V
6
4
2
3-4 Closed:
RI= 5V
2-4 Closed:
RI=RS232
3
1
5
1
3
5
2
4
6
1
3
5
2
4
6
JPCOM5 (4-pin): COM5 Header Pin9 Function Select
JPCOM5→COM5 Header
4-6 Closed:
RI= 12V
6
4
2
3-4 Closed:
RI= 5V
2-4 Closed:
RI=RS232
3
1
5
1
3
5
2
4
6
1
3
5
2
4
6
JPCOM6 (4-pin): COM6 Header Pin9 Function Select
JPCOM6→COM6 Header
4-6 Closed:
RI= 12V
6
4
2
3-4 Closed:
RI= 5V
2-4 Closed:
RI=RS232
3
1
5
1
3
5
2
4
6
1
3
5
2
4
6

8
JATX_AT(3-pin): ATX Mode/AT Mode Select*
JATX_AT(3-pin) → ATX/AT Mode Select
Pin 1
2
Pin 1
2
3
3
1-2 Open: ATX Mode Selected(Default)
;
2-3 Closed: AT Mode Selected
.
*ATX Mode Selected: Press power button to power on after power input ready;
AT Mode Selected: Directly power on as power input ready.
COPEN (2-pin): Case Open Message Display Select
Pin(1-2) of COPEN → Case Open
Pin 1
2
Pin 1
2
1-2 Open: Normal (Default)
;
1-2 Closed: Case Open Funcion Selected
.
Use needs to enter BIOS and enable ‘Case Open Detect’function. In this case if you
case is removed, next time when you restart your computer a message will be
displayed onscreen to inform you of this.

9
Pin(1-2)of JBAT (4-pin): Clear CMOS RAM Function Settings
Pin(1-2) of JBAT → Clear CMOS
Pin 1
4
2
Pin 1
2
4
3
3
1-2 Open: Normal(Default)
;
1-2 Closed: Clear CMOS RAM Settings
.
Pin(3-4)of JBAT (4-pin): DFDS Override
Pin(3-4) of JBAT → DFDS Override
Pin 1
3
2
Pin 1
2
4
4
3
3-4 Open: Normal (Default)
;
3-4 Closed: DFDS Override
.
JP1 (3-pin): Mini PCI-E USB only (MPE) Slot VCC 3.3V/3 VSB Select
2-3 Closed: MINI PCI-E Slot VCC = 3VSB
JP1→Mini-PCIE Slot VCC Select
1-2 Closed: MINI PCI-E Slot VCC= 3.3V
3
1
1
3

10
2-2 Connectors and Headers
2-2-1 Rear I/O Back Panel Connectors
*Refer to Page-2.
Icon
Name
Function
Serial Port
Mainly for user to connect external MODEM or
other devices that supports
Serial Communications Interface.
*Note: COM1 supports RS232/422/485 function.
HDMI Port
To connect display device that support HDMI
specification.
(Max. resolution Support: 3840*2160@24Hz)
DVI-D Port
To connect display device that support DVI
specification.
(Max. resolution Support:1920*1200@60Hz)
VGA Port
VGA connector is the 15-pin D-subminiature
female connector; it is for the display devices,
such as the CRT monitor, LCD monitor and so on.
(Max. resolution Support:1920*1200@60Hz)
USB 2.0 Port
To connect USB keyboard, mouse or other
devices compatible with USB 2.0 specification.
USB 3.0 Port
To connect USB keyboard, mouse or other
devices compatible with USB 3.0 specification.
USB 3.0 ports supports up to 5Gbps data transfer
rate.
RJ-45 LAN Port
This connector is standard RJ-45 LAN jack for
Network connection.
Audio Connectors
BLUE: Line-in Connector
GREEN:Line-out Connector
PINK : MIC Connector
COM1 (9-pin Block): RS232/422/485 Port
COM1 port can function as RS232/422/485 port. In normal settings COM1 functions
as RS232 port. With compatible COM cable COM1 can function as RS422 or RS 485
port. User also needs to go to BIOS to set ‘Transmission Mode Select’ for COM1 at
first, before using specialized cable to connect different pins of this port.
For RS422 Mode
RS422TX-(B)
RS422TX+(A)
RS422RX+(A)
RS422RX-(B)
(B)
For RS485 Mode
RS485 D-(B)
RS485 D+(A)

11
2-2-2 Motherboard Internal Connectors
(1) ATXPWR (24-pin block): Main Power Connector
ATX Power Supply connector: This is a new defined 24-pins connector that usually
comes with ATX case. The ATX Power Supply allows using soft power on momentary
switch that connect from the front panel switch to 2-pins Power On jumper pole on the
motherboard. When the power switch on the back of the ATX power supply turned
on, the full power will not come into the system board until the front panel switch is
momentarily pressed. Press this switch again will turn off the power to the system
board.
** We recommend that you use an ATX 12V Specification 2.0-compliant power supply
unit (PSU) with a minimum of 350W power rating. This type has 24-pin and 4-pin
power plugs.
** If you intend to use a PSU with 20-pin and 4-pin power plugs, make sure that the 20-
pin power plug can provide at least 15A on +12V and the power supply unit has a
minimum power rating of 350W. The system may become unstable or may not boot
up if the power is inadequate.
** If you are using a 20-pin power plug, please refer to Figure1 for power supply
connection. Power plug form power supply and power connectors from motherboard
both adopt key design to avoid mistake installation. You can insert the power plug into
the connector with ease only in the right direction. If the direction is wrong it is hard to
fit in and if you make the connection by force if is possible.
PIN
ROW1
ROW2
1
+3.3V
+3.3V
2
+3.3V
-12V
3
GND
GND
4
+5V
Soft Power on
5
GND
GND
6
+5V
GND
7
GND
GND
8
Power OK
-5V
9
+5V Stand by
+5V
10
+12V
+5V
11
+12V
+5V
12
+3.3V
GND
24-pin Main Power Connector
Figure1：20-pin power plug Figure 2：24-pin power plug

12
(2) ATX12V (8-pin block): 12V Power Connector
This is a new defined 8-pin connector that usually comes with ATX Power Supply that
supports extra 12V voltage to maintain system power consumption. Without this
connector might cause system unstable because the power supply can not provide
sufficient current for system.
Pin1
4
Pin
Definition
No.
Definition
1
GND
5
+12V
2
GND
6
+12V
3
GND
7
+12V
4
GND
8
+12V
(3) SATA1/2/3: SATAIII Port Connector
These connectors are high-speed SATAIII ports that support 6 GB/s transfer rate.
Pin No.
Definition
1
GND
2
TXP
3
TXN
4
GND
5
RXN
6
RXP
7
GND

13
(4) M2: M2 Socket 3 Connector
This M2 Socket 3 connector support compatible type 2242/2260/2280/22110 SATA
SSD module.
M.2 Socket 3 Connector
M.2 Module Installation Guide
1. Prepare compatible M.2 SATA or M.2 SSD card. Deferent type of cards has different
length. Find corresponding nut location for further installation.
2. Remove the screw post and nut fixed at
location MH4 by default (Skip step 2 & 3
and go straight to Step 4 if you are going
to use the default nut).
3. Lock the screw post into the location
corresponding to the length of the
module.
4. Align and insert corresponding M.2
module, as the photo shows.
5. Tighten up the screw to secure the
module into the M.2 connector. Mare
sure not overtighten the screw to avoid
possible damage to the module.

14
2-2-3 Header Pin Definition
FP_AUDIO (9-pin): Line-Out, MIC-In Header
This header is connected to Front Panel Line-out, MIC connector with cable.
Pin 1
MIC2-L
LINE OUT-L
MIC2-R
LINE OUT-R
SENSE
GND
LINE_OUT_JD
MIC_JD
DETECT
2
SPDIF (2-pin): HDMI-SPDIF Out header
Pin1
SPDIF_OUT
GND
LAN1_LED/ LAN2_LED (2-pin): LANLED Header
Pin1
LED+
LED-

15
HDD LED+
VCC
HDD LED-
GND
RST SW
PWR LED+
+
PWR LED-
2
Pin 1
PWRBTN
GND
COM10/9/8/76/5/4/3 (9-pin): Serial Port Header
DCD
Pin1
Pin6
SIN
SOUT
DTR
GND
DSR
RTS
CTS
RI
GPIO_CON (10-pin): GPIO Header
9
GPIO81
GND
GPIO83
GPIO85
GPIO87
GPIO80
GPIO82
2
Pin 1
10
VCC
GPIO84
GPIO86
JW_FP (9-pin): Front Panel Header

16
SPK_LED (7-pin): PWR LED Header & Speaker Header
SPEAK+
NC
NC
SPEAK-
PWR LED-
Pin 1
2
PWR LED+
VSB_LED
FP_USB1(9-pin): USB 2.0 Port Headers
Pin 1
VCC
-DATA
GND
+DATA
VCC
NC
C
-DATA
GND
+DATA
PS2KBMS (6-pin): PS/2 Keyboard & Mouse Header
GND
KB_CLK
KB_DATA
Pin1
MS_DATA
VCC
MS_CLK
