OPERATION TECHNICAL MANUAL - MILL 5D - 10D
3
1 - Introduction
Congratulations! You have just purchased an excellent grain chopper JF 5D-10D, easy to operate
andmaintain.
Besidesgrainchopper,thismachinecanbeconfiguredtoworkasforagechopper.
Wethankyouforchoiceofamachinereallysuitabletoyourneeds,whichismadebyacompanythat
continuouslysearchesfortheimprovementofitsproducts.
This Manual supplies the instructions for correct operation, preventive maintenance and
informationonhowtocontacttheTechnicalServiceifnecessary.Beforeoperatethemachineforthe
firsttime,readthesafetyinstructionsandallotherinstructionsinthismanual.
In case of any doubt, please contact with any of our Authorized Dealers or with our Post Sale
Department;Wearegoingtobeverygladinhelpingyouonwhateveryouneed.
PostSaleDepartment
Phone ..................................................................................................... (0xx19) 3863-9658
(0xx19) 3863-9642
e-mail ...................................................................................... [e-mail]
Website ............................................................................................... www.jfmaquinas.com
The images displayed in this manual are only for illustrative purposes. Thus to facilitate your
viewing,theimages showcutawayor thesafetyshielding removedfordisplaying itmoreclearly.Do
notoperatethemachineunderanycircumstanceswithouttheserespectiveprotectiveshields.
English

1-Introduction 03
2-Safetyinstructions 06
2.1-Whenreadingtheinstructionsmanual 06
2.2-Whenoperatingthemachine 06
2.3-Whenmakingmaintenanceinthemachine 07
2.4-Transportontruck 07
3-Machinepresentation 08
3.1-Componentsidentification 08
3.2-Operation 09
3.3-Technicalspecifications 10
4-Assemblingprioroperation 12
4.1-Assemblyofthedetachedparts 12
4.2-Assemblingthemachineonthesuport 14
4.3-Assemblingthemotoronthesupport 15
4.4-Cyclone(optionalitem) 16
4.5-Machinelevellingandpositioning 17
5-Adjustsofoperation 18
5.1-TooperatetheJF5D-10Dasgrainchopper 18
5.2-TooperatetheJF5D-10Dinforagechoppermode 20
5.3-Machineworkspeedadjustments 21
6-Stepbystepoperation 22
6.1-Operatingthemachineingrainchoppermode 22
6.2-Operatingthemachineinforagechoppermode 23
7-Maintenanceinstructions 24
7.1-Greaselubricatingpoints 24
7.2-Chopperknivessharpening 25
7.3-Gapadjustmentsbetweenknifeandcounterknife 26
7.4-Counterknifereplacement 27
7.5-Changeofgrinderhammers 28
7.6-Pulleyalignment 30
7.7-Beltstensionadjustmentandreplacements 31
7.8-Machinepreservation 32
8-Detacheditemsthatcomealongwiththemachine 33
9-Troubleshooting 34
10-TechnicalAssistance 35
10.1-Machineserialnumber 35
10.2-Warrantyterm 36
10.3-TechnicalDeliveryvoucher 37
Contents
4
Note:
JF Máquinas Agrícolas Ltda., goal is the constant update and improvement of its
products.keepingitselftherightofinstrucingchangeswithoutpreviousadvice.

5
OPERATION TECHNICAL MANUAL - MILL 5D - 10D
2- Safety Recommendations
2.1- While Reading the Manual
Warning Labels
Seating and Torques
Protectors, Closures and Fairings
ObservetherecommendationsofyourTractor'sManual,forasafeandefficientoperation.
Obs.: You must obey and never discard these labels. In case of repainting, you ought to replace
themwithoriginalitemsasstatedinItem8.
Note:
Itmeansthatadetailwillbepresentedanditmayconcernsoperationorsecurity.
Note:
The machine features several labels containing warnings and/or technical guidance
thatconcernsecurity.
Note:
Whenseatingthe screwspresentedinthismanual,usetorques andkeyspresent inthe
tableofItem AdditionalInformation.
Attention:
It means that your life or parts of your body may be in danger. You must pay
attentiontothissign!
Attention:
YoumustneveroperatetheHarvesterwithoutProtectors,ClosuresandFairings.
1
2.2- When operating the machine
1- The JF 5D - 10D is designed exclusively to
desintegrategrainsandchopforage.
2- When supply the machine, never introduct the hands
intothefeedingchute(1).
3-Inordertoobtainthemaximumefficiencyandqualityof
chopped or designed material, maintain a constant and
uniformfeeding.
4- To more security fasten the machine on a even and
rigidsurface.
English

6
5-Never usethe machineto choptree branchsor another
rigidmaterial.
6- Never attempt to adjust or repair components with the
machinerunning.
7- Do not leave the machine in a place that can be
operatedbychildrenornotqualifypeople.
1
8- The cover belt is not included with the machine when it leaves the factory without a motor
coupled,but itsuse isMANDATORY assafety NR12 (Item12.38. Dangerareas of themachineries
andequipmentsmusthavesafetysystems,characterizedbyfixedcovers,mobilecoversandsafety
devices interconnected to ensure health protection and physical integrity of workers) and NR31
(Item 31.12.12 the rural employer or similar are responsible to maintain the security systems in
perfect condition and operation, which the total or partial withdrawal or neutralization of these
systemswhichendangerthephysicalintegrityofworkersconsideredseriousandimminentrisk).
2.3- When making maintenance in the machine
1-Machinemustbeturnedoffforanytypeofmaintenance.
2-Observethespecificationandamountoflubricanttobeusedonthemachine
2.4- Transport on truck
Whenever you have to transport the machine for longer distances, when there is need for using
publicroads,thetransportmustbedoneontruckortrailler.
Tomoresafety,themachinemustbefixedwithropeonthetruck.

7
OPERATION TECHNICAL MANUAL - MILL 5D - 10D
3- Machine presentation
3.1- Parts identification
1-Grainhopper
2-Feedingnozzle
3-Protectionscreen
4-Upperproductoutput(forage)
5-Deflector(forage)
6-Foragecounterknife
7- Inferior product outlet (desintegrated
grains)
8- Flow adjusting plate to desintegrated
product
9-Foragechopperknifes(2units)
10-Grinderhammers(20units)
11-Machinebase
1
64
5
11
9
10
2
8
7
3
English

8
3.2- Operation
The JF 5D - 10D Mill machine is a simple, strong and
versatile machine, designed to help you on daily animal
feed.
Themachineofferstwooperationtypes:
A-Cerealsmill:corn,sorghum,soybeanetc.
For this function, use the grain chopper (1), lower outlet
(2)andoneof4sives(3).Thecerealsmillingisperformed
byhammers(4),thatrotateinhighspeed.
B- Plants chopper for forage such as corn, grass
(elephantgrass,napieretc)andsugarcane.
For this usage, to use the feeding nozzle (5), upper outlet
(6) and sealing rubber (7). The gring action occurs by the
knives(8)andcounterknife(9).
1
5
9
6
2
8
4
Sieves kit that come along with the machine
(see sieve chart on page 19)
7
3

9
OPERATION TECHNICAL MANUAL - MILL 5D - 10D
3.3- Technical specifications
Models
JF 5D
JF 10D
Drive
Electric motor
Electric motor
Power
7,5 until 10,0 cv
5,5 until 7,5 Kw
10,0 until 15,0 cv
7,5 until 11,0 Kw
Work speed
4.200 until 4.400 rpm
3.800 until 4.000 rpm
Cutting knifes
2 units
2 units
Grinder hammers
20 units
20 units
Pulley diameter which follow the machine
(50 Hz motor)
138 mm
155 mm
Pulley diameter which follow the machine
(60 Hz motor)
115 mm
130 mm
approximated weight
115 kg
130 kg
Dimensions (see pictures next page)
A1 (height without cyclone)
1.380 mm
1.427 mm
A2 (height with cyclone)
1.763 mm
1.763 mm
C1 (lengh without cyclone)
802 mm
912 mm
C2 (lengh with cyclone)
1.858 mm
1.995 mm
L (width with or without cyclone)
1.346 mm
1.374 mm
Note: Electric base heigh = 56 mm
English

10
A1
C1
L
L
A2
C2
Frontal view without cyclone Right hand side view without cyclone
Frontal view with cyclone Right hand side view with cyclone

11
OPERATION TECHNICAL MANUAL - MILL 5D - 10D
4- Assembling prior operation
4.1- Assembly of the detached parts
Thepartsfollowingmentionedaredelivereddisassembled.Assembleitaccordingnextstep:
Feedingnozzle(1)
Assemble the feeding nozzle (1) according the picture
aside,fasteningitwiththreebolts(1a).
Grainhopper(2)
Install the grain chopper (2) into feeding nozzle (1) and
pushittofitcorrectly,accordingthepictureaside.
Protectionscreen(3)
Hangthescreen(3)onchute(1)accordingpictureaside.
Flowcontrolplatetodesintegratedproduct(4)
Installtheplate(4)accordingpictureasideandpushitfully.
11a
3
1
2
4
English

12
Rack(5)
Itenswhichfollowtherack
5a-Lockingpin
5b-Tighteninglever
5c-Boltsandnutstofasteningthelever(5b)
5d-Pulleywith2grooves
5e-Machinedrivingchain
5f-Enginefasteningelements
5g-Fasteningelementsoftheslidingrails(5h)
5h-Slidingrails
5i-Machinefasteningelements
See instructions on next page to install the rack (5).
ATTENTION: Items 5d and 5e only accompany the machines that leaves the factory with
the motor.
5i
5h 5g
5f
5e
5a 5b 5c 5d
5

13
OPERATION TECHNICAL MANUAL - MILL 5D - 10D
Rackassembling(5)
a) Assemble both of sliding rails (5) with the bolts +
washers+nuts(5g),justasillustratedaside.
b) Insert the locking pin (5a) in the hole (5j) according
illustrated.
c)Assemblethetighteninglever(5b)accordingillustrated
aside,fasteningitwiththeboltandnuts(5c).
d)Pulley(5e)andbelts(5f)willbedescribedfollowing.
5c
5a
5j
5h
5g 5b
4.2- Assembling the machine on the support
Install the machine on the other side of the support (5) according image aside and fasten it with the
supportfeet,usingthebolts+washers+nuts(5i).
5
5i
4.3- Assembling the motor on the support
IMPORTANT: Check the necessary power of the JF 5D or
JF 10D on the page 10. There you can find the ideal
working speed to each machine model, and the motor
pulleydiameter(5d)andthemachine(6).
Procedure:
a) Assemble the pulley (5d) which follow the machine,
fasteningitwiththekey.
IMPORTANT:Seeonpage21aboutdifferentspeedsetup
accordingpulleydiameters.
6
7
55d
English

14
5d
5h
5f
b)Installthemotorcentralizedontherails(5h)andfasten
it with the four bolts + washers + nuts (5f), according
pictureaside.
c) Make the alignment between the motor pulleys (5d)
andthemachine(6),accordinginstructionsonpage30.
d) Install both of the belts (7) according illustrated and
adjustthetighteningaccordinginstructionsonpage31.
ATTENTION: Items 5d and 7 only accompany the
machinesthatleavesthefactorywiththemotor.
a) Attach the first part of the belt cover (1) as figure
beside.
b)Placethepulley(2)ofthemachine.
WARNING: The cover belt is not included
with the machine when it leaves the
factory without a motor coupled.
You can purchase the standard
safeguardsprovidedbyJF.
The use of the equipment without the
required cover belt or guards is
prohibited, according to the page 7
indications.
4.4- Cyclone assembly (optional item)
Ifyouprefertoinstallthecycloneassemble,installitaccordinginstructionsbelow:
1
2

15
OPERATION TECHNICAL MANUAL - MILL 5D - 10D
c)Placethepulley(3)oftheengine.
d)Placeandalignthebelts.
e)Attachthe cover of the fanhousing (4) and the cyclone
fan(5).
f)Placethefanhousing(6)andfixthemachine.
g)Fixthesecondpartofthebeltcover.
3
4
5
6
7
English

16
h) Fit the curve of the cyclone (8) and place the cyclone
(9). 8
9
4.5- Machine levelling and positioning
The machine must be installed on even, leveled as
rigidgroundtoagoodperformance.
To end the job, fit the four dumper rubbers (9) under the
support(5),onthepointsindicatedonpicture.
5
9
5
9

17
OPERATION TECHNICAL MANUAL - MILL 5D - 10D
5- Operation adjustments
5.1- To operate the JF5D - 10D as grain chopper
a)Loosenlatch(1)andraisethecover(2).
b)Removethecountercover(3).
c)Select oneof thesieves (4, 5,6 or7), accordingdesired
product chips size and install it under the impeller
accordingpictureaside.
NOTE. See dimensions and application of sieves on table
onthenext.
d)Removethecountercover(3).
e)Closecover(2),risingandtightenlatch (1).
f)Pushtheplate(8)completelyin.
2
1
3
4
8
Sieves kit that come along with the machine
(see sieve chart on page 19)
56712
4
English

18
g) Regulate the amount of grains (flow) that leave the
choppertowardstheimpeller.
To do it, loosen the wing nut (9) and push the doser (10)
upward on downward, according desired. Then, retighten
thenut(9). 9
10
11
Note:
The grain flow must be adjusted according the
applied motor power, sieve holes diameter
andproducttype.
h) Install a bag or other recipient to collect the material
whichflowoutfromtheinferioroutlet(11).
Sieve chart - JF 2D on grain desintegrator configuration
56712
4
Sieve Holes Diameter
Usage
4 10mm Broken corn- gross
5 5mm
6 3mm
7 0,8mm Cornmeal, wheatmeal and rye meal
12 Lowersealing See itsusage on the nextpage
Broken corn, sorghum and subproducts

19
OPERATION TECHNICAL MANUAL - MILL 5D - 10D
5.2- Para usar o JF 5D - 10D como forrageira
a)Loosenlatch(1)andraisethecover(2).
b)Removethecountercover(3).
c) Install lower sealing (12) under mill rotor, according
picturebelow.
IMPORTANT: Maintain bent plate (3) out, leaving upper
outletopen.
d)Closecover(2),risingandtightenlatch(1).
e)Adjusttheheightanddistanceoftheforagejet.
f) To do it, loosen the wing nut (4) and push the deflector
(5) upward on downward, according desired. Then,
retightennuts(4).
As more raised is the deflector, more distant will be throw
theforageandviceversa.
2
1
3
12
4
5
English

20
Diameterof
motor'spulley X RPMMotor
Diameterof the
pulley machine =
RPMMachine
Diameterof the
pulley machine X RPMMachine
Diameterof
motor'spulley =
RPMMotor
Diameterof
motor'spulley X RPMMotor
RPMMachine =
Diameterof the
pulley machine
Diameterof the
pulley machine X RPMMachine
RPMMotor =
Diameterof
motor'spulley
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
5.3- Machine work speed adjustment
See on page 10 the speed ratio to operate the JF 2D. To have diferent speeds in this zone. Its
necessarychangethepulleyscombination,thatis,usediferentsdiameters.
The formulas below will hep you to discover which diameter is better to each pulley, according the
desiredspeed.
Exampleofformulaaplication
Machinepulleydiameter=90mm
Motorpulleydiameter=?(thismeasurewillbecalculated)
Speeddesiredtothemachine=4.100rpm
Motor’sspeed=3.500rpm(thisvalueisanexample,becauseitdependsonthepower)
2ndFormula:?*=90mmx4.100rpm
3.500rpm
*Inthisexample,thepulleyassembledonthemotorshaftshouldbeadiameteror 105mm.
