MANUAL FOR INSTALLATION, USE AND
MAINTENANCE
CARINO 67
CARINO 77
Congratulations!
You have chosen an appliance of the Jidé range and we would like to thank you for it. We
are convinced that it will bring you warmth and comfort. In order to derive the greatest
benefit from your fireplace, we greatly stress the importance of following the instructions
and recommendations given in this notice.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
2
TABLE OF CONTENTS
INTRODUCTION ...................................................................................................................................... 3
General............................................................................................................................................................ 3
Important ........................................................................................................................................................ 4
CE label –Categories –Types - Performances .................................................................................................... 5
USER NOTICE .......................................................................................................................................... 7
Working and use .............................................................................................................................................. 7
1. Description of the remote control..................................................................................................................................... 7
2. Setting of remote control's parameters ............................................................................................................................ 8
3. Setup of the remote control with the insert ..................................................................................................................... 9
4. Starting the device........................................................................................................................................................... 10
5. Turning off the device ..................................................................................................................................................... 11
6. Setting of the pace .......................................................................................................................................................... 11
7. Security or automatic stop .............................................................................................................................................. 14
8. Convection ventilation .................................................................................................................................................... 14
9. Maintenance ................................................................................................................................................................... 14
10. Malfunction................................................................................................................................................................. 16
INSTALLATION MANUAL ....................................................................................................................... 17
Important ...................................................................................................................................................... 17
Site preparation ............................................................................................................................................. 18
Installation and connection of the insert......................................................................................................... 26
Checks and first lighting.................................................................................................................................. 29
Installation and fitting of accessories and options ........................................................................................... 31
Interventions on components......................................................................................................................... 34
Maintenance.................................................................................................................................................. 39
Technical documents...................................................................................................................................... 41
PRODUCT FICHE –EU 2015/1186........................................................................................................... 44
WARRANTY .......................................................................................................................................... 45
Warranty agreement...................................................................................................................................... 45
Warranty card................................................................................................................................................ 46

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
3
INTRODUCTION
General
To obtain optimum operation of your fireplace in complete safety, we recommend having it
installed by a specialist who will do the work professionally. The installer has the
responsibility to explain the use of the device to the user and to give them this manual.
The responsibility of Jidé relates to the supply of the appliance. The installation is the
responsibility of the owner who must have it done according to the requirements of this
notice, and in accordance with the applicable regulations and standards of the different
countries governing the installation, insulation and connection of closed gas-burning
fireplaces, in new and old constructions, as well as smoke flues. The appliance may not be
modified as it could present a real danger and will invalidate the warranty.
A list of our dealers-installers is available on our site www.jide.be/en.
Before using your fireplace for the first time and in order to guarantee its good usage and
operation over time, we suggest you carefully read these instructions for use in order to
familiarise yourself with its various functions and characteristics.
Before starting your first fire, please ensure that no material required for the installation is
in the fireplace. There is a paint spray for eventual retouching. Attention: before using the
Carino, make sure to get the spray out and to keep it away with a minimum distance of
2 m.
The paint has not been cured and will consequently harden when used for the first time,
causing the release of smoke and odours. We advise you to make a very strong fire during at
least 1 hour and then ventilate the room well.
The Carino range comprises the following models:
CARINO 67
CARINO 77

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
4
Important
Carino gas inserts are closed-hearth connected with a concentric duct. This concentric duct is made
of two pipes, the outside one brings the combustion air and the inside one expel the combustion
products. There is no direct contact between the heating chamber and the room where the carino
is placed.
-This insert can never be used without its door, with damaged components or without
connection to a concentric pipe giving to the outside of the building.
-This insert works with natural gas, propane or butane. It is forbidden to use any other kind of
combustible.
-Combustion settings are settled in factory and are sealed. Any handling on the setting pieces
is forbidden and will lead to cancellation of the warranty. For every questions concerning this,
please contact your installer or the manufacturer.
-Internal decoration kit is made of small pieces of vermiculite and of 7 ceramic logs. The
placement of this kit is explained in this manual and must be carefully respected in order to
avoid any operating problem.
-It is strictly forbidden to use other decorations than the ones supplied with the device, under
penalty of dysfunction of the insert and cancellation of the warranty.
-It is strictly forbidden to introduce foreign object inside the device.
-The appliance in function has some burning areas (door, glass, cadre, pipes …). Do not touch
these areas during working and just after extinction of the device, in order to avoid any serious
injury. Hold children, elderly and disabled persons off to avoid contact with the appliance. If
necessary, provide a protection around the fireplace.
-It is strictly forbidden to make the insert work without convection ventilation.
-Keep the remote control out of reach of children.
-It is also forbidden to place objects in a beam of 80 cm in front of the fireplace.
-This device owns two internal thermal securities. If the fireplace has not worked for a long time
and the system is very cold, the first lightning up might be unsuccessful. Two or three tries will
be necessary to succeed. Beyond three tries, contact your installer.
-In order to keep a sufficient signal quality between the two components, do not keep the
remote control at more than 5 meters of the insert without obstacle.
-Read mindfully and entirely the manual before any use.
-When the device is not used during a long period of time, close the gas inlet valve.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
5
CE label –Categories –Types - Performances
The Carino range is certified under the European directive 2009/142EC, resumed in norm EN613.
Every device is settled and tested in factory according to technical specifications written on the
descriptive plates below. Every insert has a proper descriptive plate mentioning the serial number
of the device and the type of gas it requires.
An aluminium label must be pasted on the electronical deck of the insert, a sheet label is to be
pasted on page 45 of this manual or on the invoice.
It also mentions the type of installation, categories authorised for each country and performances
of the device according to the type of gas.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
6

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
7
USER NOTICE
Working and use
The insert is working with a RF remote control which turns on and off the device, settles manually
the flames level and set thermostatic or programming mode. You can also turn off one burner with
this remote control and work with only one.
For a good working of the remote control, you must keep a distance of maximum 5 meters from the
insert without any obstacle. If you use thermostatic or programming mode, keep the remote control
in an appropriate place in order to get the desired temperature. If the remote is too close of the
device, it will start pilot mode too quickly, if the remote is too far it will react too late.
The insert also has a convection air ventilation system which propels warm air in the room by the
top of the glass of by pipes connected to the fireplace.
The speed of the fans is adjustable with a speed controller. The fans start and stop automatically
thanks to a temperature sensor (airstat) placed in the convection body.
Caution: the insert can never be used without ventilation!
If there is a problem with the remote control, it is possible to turn on and off the appliance manually,
thanks to control elements places on the bloc valve.
1. Description of the remote control
1 pile 9V
1
2
3
4
5
1. Screen
2. Setting
3. Start-Stop
4. High flame –High setting
5. Low flame –Low setting
6.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
8
2. Setting of remote control's parameters
2.1 Time setting
Time can be set when the battery is connected to the remote control or by pushing simultaneously
on high flame button and low flame button.
On screen, the time display blinks. Push on high flame button to settle hours and on low flame
button to settle minutes. Then, push on start/stop button or wait until the display stops blinking.
2.2 Pattern for set point temperatures
To use your appliance in thermostatic or programming mode, it is necessary to configure set point
temperatures. They are among 2:
-A "day" temperature, represented on display by:
-A "night" temperature represented on display by:
Units (Celsius-24h/Farenheit-12h)
Room temperature
Temperature mode
(day-night)
Program
Working mode
Signal control
Battery state
Hour
2nd burner active
Hout
Minute

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
9
To settle day temperature, push twice on SET button of the remote control.
« TEMP » mode and appear on display. Push at length on SET button until temperature flashes
on display. Then, push on high flame or low flame button to settle the desired temperature.
Attention: Do not settle day temperature above 30° C. It could lead to overheating of the room
and huge consumption of gas.
To settle nigh temperature, push four times on SET button of the remote control when it is in
« MAN » mode or twice when it is in « TEMP + » mode.
« TEMP » mode and appear on display. Push at length on SET button until temperature flashes
on display. Then, push on high flame or low flame button to settle the desired temperature.
3. Setup of the remote control with the insert
When you receive the fireplace, the remote control is already linked with the device. If it is not linked
or if the remote control has been replaced, you have to do a setup and create a proper
communication code between the insert and the remote control. This operation has to be done only
once and is not necessary after replacing the battery of the remote control or of the receptor.
2x
« MAN » 4x
« TEMP+ » 2x

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
10
4. Starting the device
Note: The first firing must be done by the installer. Respect the important notes mentioned in
chapter "IMPORTANT" at the beginning of this manual.
-Check the manual button of the valve is on position « ON »
-On the remote control, push simultaneously on start/stop and high flame button. A beep
comes from the receptor.
1. Push on « RESET » button on the receptor of the
insert until 2 beeps are heard (a short and then a
longer one).
Release the « RESET » button
2. Push on «low flame» button on the remote control
within the 20 seconds. Two small beeps sound, they
confirm the setup. If one long beep is heard after
20 seconds, it means the setup has failed.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
11
-A sequence of beeps (1beep per second) confirms the sequence of staring the pilot.
-Once the pilot is turned on, the main vain opens to its maximum level and burners light.
Note: during the first firing, after a long period of no working or when the weather is really cold,
you may need several try to start the fire. If it does not start after three tries, contact the installer.
5. Turning off the device
Push on start/stop button on the remote control. You hear a beep from the receptor. The burners
and the pilot are turned off.
6. Setting of the pace
6.1 Manual mode
When the starting sequence has been done (point 4), the insert is at its maximal working.
To go from maximum to minimum working, push twice on low flame on the remote control. "LO"
appears on top left of the display and a beep comes from the receptor.
To go from minimum to maximum working, push twice on high flame on the remote control. "Hi"
appears on top left of the display and a beep comes from the receptor.
To go to sleep mode (the pilot only remains on), push on low flame on the remote control until the
burners are turned off.
2x
2x

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
12
« ECO » mode
In case of manual working, it is possible to only work with the front burner and, therefore, reduce
the gas consumption of approximately 43 % while keeping a high flame. To do so, push
simultaneously on "SET" and low flame button.
To start again the back burner, push simultaneously on "SET" and high flame button (AUX appears
on the remote control display).
6.2 Thermostatic mode
In this working mode, the remote control acts as the thermostat. According to the room
temperature detected, it handles automatically the working of the insert to reach the setpoints
temperatures.
Before using this mode, you must settle the setpoints temperatures wished. To do so, go to
point 2.2. Note that the device must be in sleeping mode to start thermostatic mode (pilot on,
burners off). To put the device in sleeping mode, go to point 6.1.
To work on day temperature, push twice on SET button of the remote control. "TEMP" mode and
appear on display.
To work on night temperature, push 4 times on SET button of the remote control. "TEMP" mode and
appear on display.
2x
4x

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
13
To get back on manual mode, push 5 times on SET button when the device is on day mode, 3 times
when it is on night mode. By pushing on high flame or low flame button, the device get automatically
back on manual mode.
6.3 Programming mode
In this working mode, it is possible to settle two operating ranges per day. The remote control also
acts as the thermostat and handles the working of the insert according to set points temperature
and desired schedules. Before using this mode, you must settle set points temperature and set the
clock. To do so, go back to point 2. Note that the device must be in sleeping mode to start
programming mode (pilot on, burners off). To put the device in sleeping mode, go to point 6.1.
To set the operating ranges, push 5 times on SET button of the remote control. "TIMER" mode and
P1 or P2 appear on display.
Push then on SET button until the clock blinks and appears. Set starting hour of day temperature
function by means of high flame button for hours and low flames button for minutes.
Note: schedule can be set by ranges of 10 minutes. Day starts at 00:00 and end at 23:50.
Push once on SET button of the remote control. The hour of night function blinks and appears.
Set starting hour of night temperature function by means of high flame button for hours and low
flames button for minutes.
Push once on SET button of the remote control, P2 and appear and the hour of the 2nd starting
range of day function blinks. Repeat these actions to set day and night hours.
Push once on SET. Display gets back to its initial position. "TIMER" mode is activated and the current
mode (P1 or P2, or ) appear on display.
To get back on manual mode, push once on SET button or on high flame or low flame button.
5x

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
14
7. Security or automatic stop
The insert can stop working automatically and for security in three different cases:
-Pilot security: when the flame of the pilot lights up, it heats a thermocouple of security. If this
one is not heated anymore, the device will turn off automatically (see malfunction tables at
the end of the manual).
-Temperature security: in order to avoid overheating of electric components, the receptor is
fitted with a sensor which will stop the device if the temperature in the box reaches 60° C (see
malfunction tables at the end of the manual).
-Low battery in the receptor turns the device in security mode. Replace the battery.
8. Convection ventilation
This insert is fitted with two integrated fans which spread the warm convection air in the room from
the top of the door or from warm air ducts previously installed. The start and stop of the fans is done
automatically by a thermal switch (airstat). The speed setting is done by the speed controller
supplied with the device.
Attention:
-The device can NOT work without ventilation. It is necessary to cool down the fireplace, its
electrical components and its trim. In case of malfunction, contact your installer.
-Do not use another speed controller than the one supplied with the insert.
9. Maintenance
9.1 Regular maintenance
-Outside cleaning of the glass
When the glass is dirty on the outside, it is important to clean it by means of a cleaning product for
glass or of vinegared water.
Every biting products are to ban at risk of deteriorating the front painting or the ceramic protection.
Use a soft cloth. If the glass has dirt stuck on it, use a razor blade or a scraper for glass-ceramic.
Note: If a dirt is not previously removed before starting a fire, it could became permanent (cooked
in the ceramic)!
-External cleaning of the fireplace
Dust the accessible zones around the fireplace by means of a dry soft cloth and a feather duster,
mainly on top of the insert.
Note: when the device is not used for a long time, dust settles on the heating chamber. During the
first firing, an odour can appear due to the cooking of these residues.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
15
-Inside cleaning of the glass
Note: thanks to the clean combustion of the insert, this action has to be done only rarely and can
be done by the installer during the manual maintenance. Do this cleaning only if the glass has
obvious dirt.
To open the door, remove the 6 screws by means of a key or a Phillips socket PH2.
Note: the door is self-supporting on the top of the heating chamber. Nevertheless, remove the
screws carefully because the airtight seal can have a spring effect.
Once the screws are removed, raise the door by placing one hand under the glass and the other on
the side. Place the door carefully and stably in a safe place. Do not place the door on its face without
covering (blanket, foam …).
Clean the glass by means of a cleaning product for glass or of vinegared water. Use a soft cloth.
Note: Avoid every biting product that could spoil the painting, the screen print and the ceramic of
the glass.
Replace the glass by placing the upper part on the top of the heating chamber.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
16
Set the door my means of hexagonal screws and a key or a Phillips socket PH2.
Note: place the 6 screws in the threads before tightening in order to avoid to pressurise the seal
and to have difficulty placing the next screws.
9.2 Annual maintenance
For a good working of the device and for security, it is essential to do an annual maintenance on the
insert. This must be done by an installer or a certified heating installer.
10. Malfunction
For every operating problem of the insert, see page 41 at the end of the manual.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
17
INSTALLATION MANUAL
It is important to check the fireplace upon receipt and to ensure the absence of any damage during
transport.
Important
Carino gas inserts are closed-hearth connected with a concentric duct. This concentric duct is made
of two pipes, the outside one brings the combustion air and the inside one expel the combustion
products. There is no direct contact between the heating chamber and the room where the carino
is placed.
-This insert can never be used without its door, with damaged components or without
connection to a concentric pipe giving to the outside of the building.
-This insert works with natural gas, propane or butane. It is forbidden to use any other kind of
combustible.
-Combustion settings are settled in factory and are sealed. Any handling on the setting pieces
is forbidden and will lead to cancellation of the warranty. For every questions concerning this,
please contact your installer or the manufacturer.
-Internal decoration kit is made of small pieces of vermiculite and of 7 ceramic logs. The
placement of this kit is explained in this manual and must be carefully respected in order to
avoid any problem of operating.
It is strictly forbidden to use other decorations than the one supplied with the device, under
penalty of dysfunction of the insert and cancellation of the warranty.
-It is strictly forbidden to introduce foreign object inside the device.
-The appliance in function has some burning areas (door, glass, cadre, pipes …). Do not touch
these areas during working and just after extinction of the device, in order to avoid any serious
injury. Hold children, elderly and disabled persons off to avoid contact with the appliance. If
necessary, provide a protection around the fireplace.
-It is strictly forbidden to make the insert work without convection ventilation.
-Keep the remote control out of reach of children.
-It is also forbidden to place objects in a beam of 80 cm in front of the fireplace.
-This device owns two internal thermal securities. If the fireplace has not worked for a long time
and the system is very cold, the first lightning up might be unsuccessful. Two or three tries will
be necessary to succeed. Beyond three tries, contact your installer.
-In order to keep a sufficient signal quality between the two components, do not keep the
remote control at more than 5 meters of the insert without obstacle.
-Read mindfully and entirely the manual before any use.
-When the device is not used during a long period of time, close the gas inlet valve.
-Before installation, check that local distribution conditions (type of gas and pressure) match
with the settings of the device.
-Respect inlet pressures of the insert (G20/20mbar, G25/20-25mbar) and use connection
flexibles certified (see standards in force).

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
18
-It is mandatory to install a block valve on gas inlet, close to the device and easily accessible.
-This device must be installed according to standard in force. It is asked to comply with local
legislations for the installation of type C devices:
oConnection of the device must be done by a certified installer. Main standards to respect
are NBND51/003 and NBN61002 for Belgium, NFD 35-377 or DTU P45-204. If no
standards is specified, refer to NBN 61002 standard.
oIf connection is done to an existing chimney which was previously used by a device using
another combustible than gas, it is mandatory to sweep, clean and inspect the duct. The
duct and its connection must be clean and sealed.
-Concentric pipes and connection pieces used must be EONTOP METALOTERM US100 or
JEREMIAS (Detandt-Simon) TWIN K-100. For flexibles, use ducts in stainless steel. You can buy
EONTOP connections by Jidé (rue des Meuneries 11, 4650 Herve, Belgium) or directly by
EONTOP (Oude Veerseweg 23, 4332 SH Middelburg, The Netherlands) and JEREMIAS
connections by Detandt-Simon (Rue d'Herchies 37, 7011 Ghlin, Belgium).
-Chimney settings authorised are only those mentioned in this manual.
-Read mindfully and entirely the manual before any use.
Site preparation
Dimensions of the recess and aeration around the fireplace
The recess, i.e. the volume around the fireplace, has to contain the
appliance while providing an additional space of at least 5 mm (on the left
and right sides, and above the fireplace) in order to accommodate
expansion. Place the decorating frame and ensure a good airflow between
the insert and the housing (see plan in attachment at the end of the
manual). There must be no masonry against the fireplace.
Attention! The back offset of the concentric elbow is 3,5 cm.
Insulation of the fireplace
The materials used must be non-inflammable. Provide high-temperature insulation around the
fireplace to protect certain materials. In this case we advise protecting the back, sides and top of the
appliance. If no insulation has been provided, it is recommended keeping a distance of 5 cm from
inflammable materials around the corner and 10 cm from the outlet nozzle, and to ventilate the
recess.
Your installer can advise you regarding the protection to be provided.
3,5 cm

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
19
Fireplace base
We recommend placing the appliance on a solid flat surface with sufficient strength to support the
weight of the fireplace and the chimney flue.
Radiation from the fireplace
The fireplace emits heat by radiation through the window and by air convection. It is thus essential
to provide non-inflammable materials in the distribution zone. It is also forbidden to place objects
in a beam of 80 cm in front of the device.
Inlets
-Gas
The gas inlet must be done by a certified installer and according to standards in force.
Pipe diameter must be sufficient to grant nominal working pressure of the insert at the inlet
(G20/20mbar, G25/20-25mbar). It is mandatory to install a block valve on gas inlet, close to the
device and easily accessible.
Clean the pipe previously (traces of filings …) before connecting to the fireplace. This connection is
done with a flexible of minimum 500 mm length in order to allow the electronic drawer to go out of
the device. Connection can be done on the right or left side or in the centre of the fireplace (back or
below). Choose your connection and cut the previously drilled junction of the convection chamber.
-Electricity
Provide a power supply for convection ventilation in the recess or near the insert (230 VAC).
Preparation of the chimney duct
The insert is a type C (sealed) device and must be connected with a concentric pipe whose terminal
go to the outside of the building.
Rigid conduits and connection are from EONTOP brand, model US10 or
JEREMIAS (Detandt-Simon) TWIN K-100. No other brand or model can
be used.
Note: see also included mounting instructions !
In case of flexible connection, use stainless steel.
The insert connection is supplied for 100/150 mm connections.
Connector is removable from the inside and allows to insert the device
in the recess ant to connect by the inside.

Jidé s.a. –Rue des Meuneries 11 –B-4650 HERVE (Belgique) –Tél. [phone] –Fax [phone] –www.jide.be - [e-mail]
CARINO (EN) February 2020
20
Chimney setting
1. Wall outlet (type C11)
1.1 Minimal setting
1.2 Maximal setting (Attention: only authorised for G20 and G25 !!)
Note: Remove the baffle for this setting!
A
B
C
D
A = Elbow 45°
B = G20/G25 1 m min length
C = Elbow 90°
D = End USDHC13
A
B
C
D
E
A = Elbow 45°
B = 1.5 m min length
C = Elbow 90°
D = 3 m max length
E = End USDHC13
