Jigabot Jigabot EX User manual

Quick-Start Guide
What’s In the Box?
Jigabot EX
Confi dential & proprietary. Copyright 2021 Jigabot LLC, all rights reserved. [email protected] www.Jigabot.com Ph. 801-995-3680
Confi dential & proprietary. Copyright 2021 Jigabot LLC, all rights reserved. [email protected] www.Jigabot.com Ph. 801-995-3680
Jigabot EX robot
DOTs (two shown)
USB Wall Charger
Ballhead Mount
Carrying Case
Micro USB Charging Cable
DOTdriver
Power Supply
Your Jigabot EX comes with the following items (and may
include more depending upon the accessories or Kit you
purchased):
1. Jigabot EX robot, including
• Power Supply (plugs into wall & Jigabot EX)
• Tripod adapter (1/4-20” to 3/8-16”)
2. DOTdriver & 4 DOTs, including
• USB wall charger
• Micro USB charging cable
3. Ballhead Mount
4. Carrying Case
Tripod
Adapter
for using
the Jigabot
with 1/4-
20” tripods

Quick-Start Guide
Do a Quick Test
Jigabot EX
Confi dential & proprietary. Copyright 2021 Jigabot LLC, all rights reserved. [email protected] www.Jigabot.com Ph. 801-995-3680
Once you unpack your Jigabot EX, do a quick test to see how simple it is.
Set up as follows:
1. Attach the Jigabot EX to a Tripod
2. Plug in the power supply, and press IN the power button
3. Tighthly plug in a set of DOTs to the DOTdriver, and hold the power
button IN for 3 seconds
Stand 6 feet in front of the Jigabot EX, and move the dots slowly from side to
side. Congratulations, you’re tracking!
Plug in power supply
NOTE: it takes about 45
seconds to boot up
before you can track
Attach tripod here
Press power ON
(this is the back of the
Jigabot EX)
Plug in a set of DOTs
(press very fi rmly)
STEP 2
STEP 3
STEP 1
NOTE: You only need to use the included Tripod
Adapter if you are using a consumer tripod. A Jigabot
tripod (or kit accessory) uses a professional standard
stud which is 3/8-16” and fi ts into the Jigabot EX
directly without an adapter.
Press and hold power button
(for 3 seconds)
NOTE: to power OFF, press and hold
the same button for 3 seconds

Quick-Start Guide
Mount an iPad
Jigabot EX
Confi dential & proprietary. Copyright 2021 Jigabot LLC, all rights reserved. [email protected] www.Jigabot.com Ph. 801-995-3680
Once you verify how to track with your Jigabot EX, you can attach an iPad as
follows:
First power OFF your Jigabot and DOTdriver, then set up as follows:
1. Attach the Ballhead mount to the Jigabot EX
2. Attach the iPad Mount to the Ballhead mount
3. Attach the iPad to the iPad Mount Accessory
Again power ON, then stand 6 feet in front of the Jigabot EX and move the
DOTs slowly from side to side. Congratulations, you’re tracking with an iPad!
STEP 1
STEP 2 STEP 3
Attach the Ballhead Mount
(screw in fi rmly)
Attach the iPad Mount to
the Ballhead Mount
(screw in fi rmly)
Second rest your iPad
on the iPad Mount
(bottom of iPad into the
base channel)
First extend up the
iPad Mount
(just above the height
of your iPad)
Third, place top of
iPad in top channel
(push top of mount
down to hold iPad
fi rmly in position)
