Jinbo JLV-12240K Installation instructions

( LED Power Supply, LED driver, Switching Power Supply)
Thank you for using our power supply, please read the below information carefully before
using this power supply!
SPECIFICATION & USER'S GUIDE
1 / 5

Features:
JLV-12240K JLV-24240K
DC voltage 12V 24V
Voltage tolerance ±1% ±1%
Rated current 20A 10A
Current range 0~20A 0~10A
Rated power 240W 240W
Ripple&noise 150mvp-p 180mvp-p
DC voltage
ADJ.range ±10% ±10%
Voltage range
frequency
AC current
Efficiency 84% 85%
Inrush current
Leakage current
Working
temp,humidity
Storagetemp,
humidity
Withstand vibration
Withstand voltage
Isolated resistance
Safety standard
EMC standard
Others Dimension
PICTURE MODEL: JLV-12240K
199*98*50mm (L*W*H)
Note
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and
25℃of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire
terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
Safety & EMC refer to UL1012
refer to EN55022, CLASS B
Safety
overload
Rated output power 115%~135% start over load protection
protection type: hiccup mode, auto-recovery after fault condition is
removed
Environment
-10℃~+60℃,20%~90%RH
-20℃~+85℃,10%~95%RH non-condensing
10~500HZ,2G 10min/1cycle,period for 60 minutes, each axes
Protection
4.5A/115VAC, 2.5A/230VAC
Output
Input
Cold start current 25A/115VAC, 40A/230VAC
<2.5mA/240VAC
1. Designed for 100% full loading
2. Universal AC input; Smooth-start
3. High transfer efficiency
4. Over-load, short-circuit protection
5. Compact size
6. 100% full-load burn-in tested
Model
90~132VAC/170~264VAC(selected by switch), 235~373VDC
47~63HZ
2 / 5

1) Over-load / over-current / short circuit protection
2) Able to work under 100% full loading continuously
3)
4) Input electric current suger resisting ( 5 seconds under 300VAC input )
II．Product Features
Comply with international power consumption standard of stand by status
I．About this LED power supply (LED driver, switching power supply)
This LED power supply is mainly consisted of five parts:
1) Electromagnetic Interference network
2) Rectifier filter
3) Built-in Pulse Width Modulation unit
4) Switch for energy transform
5) Low ESR Pulse Width Modulation output devices
Our high efficiency LED power supply provides you stable power output with stable current, 100% burn-in tested, and interference of
fluctuation from input current which is benefit for the life span of LED appliances.
3 / 5

5)
6)
7)
8)
1) The input voltage must fall into 170~250VAC (some models are able to work
2)
3)
4) NO wood or flammable surface mounting, keep min. 5CM for power supplies each other
5) Keep away from inflammable or explosive environments
Waterproof types:
AC Input: yellow/green lead is for grounding, rest leads are for electricity
DC Ouput: Red (brown) possitive +, black (blue) negative -
Non-waterproof types:
1) The power supply will be automatically protected and enter the abnormal state of
2) For models have multi-outlets, never connect all loading with single outlet,
please keep balanced loading. If connecting with only single outlet is
necessary, please connect all positive output leads together to provide
electricity fully, also negative leads.
3) Please be well noticed that too long connecting leads will cause to line loss. So please
4) Input/output lead’s surface listed its diameter and industrial standard, please choose
proper extension leads accordingly. In view of the line loss, the longer extension, the
stronger leads is needed.
5) This power supply can be connected with plugs, but please make it well connected
and insulated.
LED POWER SUPPLY Trouble-shooting Tips
There is a protection circuit in the Power Supply that will cut off (trip) the power whenever an short circuit or overload condition occurs,
please make sure correct connection of positive and negative terminals(+, -) before power on.
1. Power Supply does not work:
1) Check the input power voltage.
2) Check power on/off status.
IV. Wire Connection
Make sure wires are well connected, most of our models have multi-outlets, we recommmend the following loading order: negative –
positive- negative- positive- negative….etc. Please always keep balanced loading.
Cautions for Connecting Leads and Loading
intermittent connection if the load power exceeds the maximal rated output power
avoid too long extension with ouput leads.
Compact size and easy installation
Waterproof types are suitable for outdoor use, waterproof rate: IP67
III．Installation and working environments
Always keep good ventilation as below indicated
(normally 5~20% exceeds).
under 100~250VAC input) 50/60HZ
Do not overload, also avoid free of load while a power supply is powered on, keep proper loading
Choose 105℃electrolytic capacitor,suitable for tough work condition
High working efficiency, energy saving
The installation and wire connection of this power supply should be conducted by qualified
technicians!
4 / 5

V
．Workin
g
environment:
Outdoor types: -25℃~+45℃, Relative Humidity: 100%
Indoor type: -25℃~+45℃, Relative Humidity: under 90%
Storage environment: -25℃~+80℃, Relative Humidity: under 95%
3) Check if there’s short-circuit on output line.
4) Check if wrong positive and negative terminal connection.
5) Check if the output indication light is lighting (for the models which have this function).
6) Check if the fuse well connected (for the non-sealed models ).
2. Over-heated of the Power Supply:
1) Keep good ventilation.
2) Check the loading status, avoid over loading.
3. Unsteady power output:
1) Check if there's over-loading or improper output extension leads connected.
2) Check if there's strong interference in the working environment.
3) Check if there's magnetic field around the working environment.
4. LED light works dark (weak light, LED not bright enough)
1) Please check if the output voltage is good for your requiremnt(5V/12V/24V...etc.).
2) Choose proper wires in aspects of wire's diameter and voltage capacity.
3) Check if there's over-load or too long extension leads been used.
5 / 5
