JinJiaTai Technology S1 User manual

User Manual for Sports Watch
Thanks for using our product. Before using this watch, please read the following
instructions first:
1. Warning: Please consult your doctor before starting a new exercise. The smart watch
has no medicinal use anyway, though it can monitor your real-time heart rate
dynamically. Remember to consult your doctor before starting any exercise and dieting
program.
2. Device requirement: This watch supports Android 4.3, IOS7.0, and Bluetooth 4.0
or above.
3. Charging:

Before using the watch, please charge it with a 5V500mA USB device to ensure that
it is full of electricity.
  
To charge the watch, remove its main unit from your wrist and place it on the USB
charging base (5V500MA), Keep the main unit on the charging base at least 2 hours. To

ensure good contact during charging, the metal contact should be free of contamination,
oxidation, and impurities. During charging, a symbol will be displayed on the screen to
indicate the charging progress. If you keep the watch idle for a long time, please
recharge it at least once every 3 months.
Ⅰ. Connect the watch to the APPon your phone
1. Power on: 
Long press the bottom of the watch screen for 3 seconds, and the watch will be
powered on and a pairing code will be displayed on the screen to identify the watch.
Power off
Long press the button on the time interface for 3 seconds to enter the secondary
menus, and browse through these menus to switch to the Power Off option. Long
press this option to enter the Power Off interface. On this interface, switch from ON
to OFF and the numbers 5, 4, 3, 2, 1 will be displayed on the screen. After the
number 1 is displayed, the watch will be powered off.
Reset
Among the secondary menus, select the Reset icon and long press it to enter the Reset
interface. On this interface, switch from Off to On, and the system will be reset and the

time and data of the watch will be reset to the factory settings.
2. Install the app
Scan the QR code on the packing box with your phone, or search for "smart watch" on
Google Play, App store, or Myapp store and download it.
3. Connect the watch: Keep your watch close to your phone, and start and enter the smart
watch APP. According to the APP connection wizard, find the bluetooth watch (the
bluetooth name is "Smart Watch") and finish pairing. Then, click Next to finish
connection.
Connect to Apple devices: For the IOS of Apple devices, a bluetooth pairing request will
be displayed after you successfully connect to the App for the first time. To receive such

notifications as incoming calls, short messages, QQ, and Wechat from the IOS on your
watch, click Pair. Otherwise, you will unable to receive such notifications.
4. Delete the watch: To delete the watch after connecting it to your phone, open the
APP and choose Setting > My Watch. If you have registered an account and logged in
to the account to bind your watch, you need to unbind it by opening the App and
choose Setting > Device Management.
Delete the watch on an Apple device: After deleting the watch according to the steps
above, choose System > Bluetooth on your phone after being prompted to do so. Then,
press the exclamation mark after the device name and select Neglect the Device on the
popup dialog box. By doing so, you remove the ANCS connection of the watch and you
will no longer receive any notification from Apple.

Note: When connecting the watch to the APP for the first time, be sure allow the
APP to obtain the related permissions. If you forbid the APP to obtain your phone's
permissions, some functions between the watch and phone may be disabled.
ⅡFunction Interface of the Watch
Function area on the main interface
1. Time mode:
After you successfully pair your watch with the APP for the first time, the watch will
synchronize its time and date with your phone.
2. Step-counting mode


The watch is in step-counting mode by default when powered on. With the watch on
your wrist, if you walk and swing your arms, the watch will record your motion data
which you can view immediately.
3. Riding mode:

On the bicycle interface, if you long press the button for 3 seconds, you will enter the
riding mode. In this mode, the watch will record your riding time and the calories you
have burned. If you ride, the watch will display the time and the calories you have
burned. If you do not ride, the watch will not record the time. In the riding mode, the
watch consumes more power and thus its battery life will be shortened.
To exit the riding mode, long press the button for 3 seconds in the riding mode.
4. Heart rate detection: On the heart rate detection interface, if you long press the button,
you can use the heart rate detection function to detect your real-time heart rate
dynamically. In the heart rate detection mode, the watch's battery life will be shortened.


To exit the heart rate detection mode, long press the button for 3 seconds in the heart rate
detection mode.
4.1 Please put on your watch on your wrist, 2cm from the inside of your ulnaradius joint.
4.2 When measuring your heart rate, keep the heart rate sensor clung to your skin and in
good contact. Otherwise, the light of the sensor may leak and the measurement data may
be incorrect.
Do not look directly at the green light of the sensor, which may cause discomfort to your
eyes.
4.3 Though this watch can detect your real-time heart rate dynamically, you are still
recommended to keep still during heart rate detection. Otherwise, it may take a longer
time to measure the heart rate or you may get incorrect data. After the watch has
measured the data, you can do exercise again and view the dynamic data.
4.4 If great difference exists between measurements, please have a rest and make another
measurement. If you make 5 successive measurements and take their average value, you
will get a correct result.

4.5 This watch measures your heart rate dynamically. Thus, it gives different heart rate
values when you are in different states (talking, eating, and drinking). The real heart rate
value depends on the actual situation.
4.6 After connecting your watch to the APP, you can set the maximum heart rate warning
value and synchronize it to your watch. Then, when the heart rate value on your watch
reaches the maximum heart rate value, your watch will vibrate to give a prompt and at
the same time, the heart rate value will flash, telling you to stop intensive exercise.
4.7 If you are not clear of your maximum or minimum heart rate, please consult your
doctor before taking exercise.
4.8 Before making a measurement, ensure that there is no contamination at the bottom of
the heart rate sensor. Such factors as skin color, thick hair, tattoo, and scar may affect the
detection result.
4.9 This heart rate detector works according to the PPG measurement principle.
Therefore, its precision may vary with the physiological factors (blood circulation, blood
pressure, skin conditions, blood vessel location and density) which affect light
absorption and reflection. When the measured heart rate value is very great or very small,
the measurement value may be incorrect and you need to make another measurement.
4.10 Long-time measurement may cause the watch to get hot. If this makes you
uncomfortable, you can take the watch off your wrist and wear it again after it has cooled
down.
4.11. You are recommended to make measurement when it is warm because cold weather
may affect the measurement result.

Function menu: In the time mode, long press the button for 3 seconds to enter the
interface for secondary menus. This interface provides the following buttons: Back,
Sleeping, Remote-control music, Remote-control photo, Find your phone, Vibration
on/off, Power off, and Reset.
1. Back
This button allows you to return to the main interface by long pressing it for 3 seconds.
2. Sleeping
This button allows you to enter the interface for sleeping setting by long pressing it for 3
seconds. The interface provides two buttons for you to switch on or off the sleeping
mode. After finish setting, a symbol will be displayed in time mode to indicate the
sleeping mode. In the sleeping mode, the watch does not count your steps.
3. Remote-control music

This button allows you to enter the music play interface where you can control the music
player of your phone to play/pause music, play the previous and next song. (Support
only the playing of the music in the system). To return to the previous page, long press
the Back button.
4. Remote-control photo and video
  
This button allows you to enter the interface for remote control photo or video, where
you can enable the APP to start the built-in camera of the system to take photos by long
pressing this button.
If you have selected remote-control video, the watch will start to take videos after you
press this button for the first time and stop to take videos after you press this button
again. If you long press this button, you exit the photo mode.
5. Find your phone
This button allows you to active the function to find your phone by long pressing it for 3
seconds. If you press this button, you will hear a ring tone (if the volume of ring tone is

on) which help you to find your phone. Phone vibration is not supported. Long press this
button, and you will exit this function.
6. Vibration on/off
This button allows you to enter the interface for switching on or off vibration by long
pressing this button. By default, vibration is ON. When vibration is in OFF state, the
watch does not vibrate no matter what notification is received.
7. Palming screen-on
If you enable this function, the screen of the watch will light up automatically when you
raise you wrist to help you view the time.
Ⅲ. APPfunctions and settings
1. Main interface

The main interface displays the data about step counting, distance, and calories you have
burned. The buttons on the upper right corner of this interface allow you to synchronize
and share history data. By clicking the heart-shaped icon in the center, you can perform a
heart rate test. The APP will measure and record your current heart rate data. Once the
detection at the APP end is finished, the heart rate detection will stop automatically.
By clicking the Setting icon on the upper right corner, you can set the heart rate warning
(vibration) switch and the heart rate warning threshold. Then, after you synchronize this

setting to the watch, the watch will vibrate and the heart rate value measured will flash
when the maximum heart rate is reached.
2. Trend
After synchronizing the history data, you can view the exercise record of each day, each
month and each year on the daily records. You can also view the data about step counting,
distance, calories you have burned, and the goal you have achieved.
After synchronizing the history data, you can also view the data about your sleeping
quality and the related history records.
3. Outdoor exercise

Enable the GPS on your phone, enable the network connection, and open the map built
in the APP, and you can record your movement and share it to social platforms.
4. Multi-exercise mode
1) Rope skipping: Click this icon and START to start rope skipping and FINISH to stop rope skipping, then the watch will
record the number of rope skippings
2) Jumping jack: Click this icon and START to start jumping jack and FINISH to stop jumping jack, then the watch will
record the number of jumping jacks
3) Sit up: Click this icon and START to start sit up and FINISH to stop sit up, then the watch will record the number of sit ups
4) Treadmill: Click this icon and START to start treadmill exercise and FINISH to stop treadmill exercise, then the watch will
record the distance you have covered
When the multi-exercise mode is on, the watch will display the corresponding
exercise icons. To exit this mode, exit the APPor long press the Multi-exercise mode
button.

5. Interface for function setting
5.1 Personal information:
After enter the APP, you are recommended to set your personal information first by
choosing Setting > Personal Information. The personal information you can set
includes nickname, head portrait, gender, date of birth, height, weight, step pitch, and
unit (metric/imperial). After finish settings, you can synchronize your personal
information to your watch.
If this is the first time for you to use this APP, you are recommended to register an
account with your email address and log in to the account. Also, you can have a try
without a login. If you have registered an account but forget the password, you can click
Forget Password, and the system will send a mail to your register email for you to reset

your password.
5.2 Exercise goal:
This function allows you to set your exercise goal.
5.3 Phone anti-lost: This function allows you to set anti-lost for your phone. By
default, this function is disabled (grey). If you enable this function, your watch will
vibrate to give a prompt when your phone or watch is beyond the bluetooth connection
distance.

5.4 Music remote control: This function allows you to control (to play, pause, play
the previous song, play the next song) the music on the phone via your watch.(The
music player attached with the system is supported)
5.5. Remote-control photo: This function allows you to switch on or off the photo
function of the APP.
5.6 Call notification: If you enable this function, you will receive a notification when
a call from one contact in the default system address book is coming. You will receive no
notification, however, when a call from one contact in the third-party address book is
coming.
5.7 SMS notification: If you enable this function, you will receive a notification
when a system SMS is received and you can view the SMS. You will receive no
notification, however, when an SMS from a third-party application is received.
5.8 QQ notification: If you are using an Android device and enable this function for
the first time, the system will prompt you to enable access notification permission to
allow your watch to read all system notifications and to check this APP. You are
recommended to check access notification permission for only one APP. If you check
access notification permission for multiple APPs, you may receive no notification.
5.9 WeChat notification: If you enable this function, you can receive WeChat
notifications and view the content of the notifications. This applies to other notifications.
Notification from foreign social applications: This watch supports the notifications from
such foreign social applications as Facebook, Twitter, Line, SKYPE, and WhatApp and
displays the content of such notifications
When a notification is received, the watch will display the icon of the corresponding

social application. You can click this icon to view the message or long press this icon to
exit.
For an Apple system, all notifications are uniformly pushed by the notification
center.
5.10. Alarm clock notification: This function allows you to set an alarm clock for 4
periods, and set an on-off, snooze time, and alarm cycle for each alarm clock. After
finishing setting, click Synchronize to Device to bring your setting into effect. This
function supports offline notification.

5.11. Long-time sitting notification: This function allows you to set an on-off,
notification interval, notification time segment, and notification period.
5.12. My watch: This function allows you to search for or add a watch.
5.13. Find watch: Click Start to find the watch you have bound it to your phone. If the
watch is found, it will vibrate to prompt you.
5.14. Device management: This function allows you to manage, uninstall, and rename
the watch you have bound.
5.15. Clear data: This function allows you to clear the data on your watch and the APP.
5.16. Sleeping preference:
You can set the sleeping switch manually on the watch or set the sleeping starting time
on the APP. The APP allows you to set a sleeping switch for three time segments. The
watch will automatically get into sleeping state at the beginning of the time segment set
and automatically stop sleeping at the end of the time segment set. The watch does not

count your steps when it is in sleeping mode. You can view your sleeping time in the
history record of the APP.
5.17 User manual: This function allows you to view the help information about the use
of the watch
5.18 Device update: This function allows you to update the watch software.
5.19 About: This function allows you to view the APP version.
Ⅳ. System compatibility
1. This watch supports nearly 200 mainstream mobile phone models, including iphone
and Android
Supported iphones: iPhone4s/5/5C/5S/6/6 PLUS/6S/6S PLUS
Supported Android phones: Xiaomi: MI4, MI 3, NOTE LTE, HM NOTE 2, HM
NOTE1S, 4C, HM 2A
HUAWEI: MT7, H60, P7
MEIZU: M1 NOTE, MX4, MX4 PRO, MX5, M2 NOTE
SAMSUNG: S4, S5, S6, NOTE2, NOTE3, NOTE4, NOTE5, A7
OPPO: R7
VIVO: X5 PRO, X5S
LG: NEXUS 5, D885
ONEPLUS: A0001
2. Supported languages for the APP: English, Japanese, simplified Chinese, traditional
Chinese, French, German, Russian, and Romanian
3. Supported languages for watch information: Japanese, Danish, Korean, Portuguese,
Estonian, German, Spanish, Bulgarian, Russian, Czech, Greek, Swedish, Italian, Polish,
