Jiyue Technology Air1 User manual
Product diagram
LED indicator
Packing list
Air1 true wireless headset host
Air1 real wireless headset charging box
Micro 5pin charging cable
Spare large and small earcaps
an instruction manual
Led charge indication
Multitouch area
Microphone port
harging contact
USB Electricity Input
Charging thimble
Charging thimble
Product specification
Product model: Air1
True wireless version: V5.1
Battery specification: earphone 3.7v ; Charging bin 3.7v
Supported mode: HFP/HSP/ A2DP/AVRCP
Sensitivity: 105dB ±3dB S.P.L at 1KHz
Signal distance: 10 m (in an ideal environment without any large obstacles)
Playing time: about 2.5 hours
Talk time: approximately 3 hours
Standby time: about 80 hours
Charging time: charge the charging warehouse for about 1.5 hours,
and charge the headset for about 1 hour
Charging times for the headset: about 3 times
Functional instructions
1.Boot
Take the headset out of the charging bin and start it automatically or long press the left and right
multi-function button of the headset for 3 seconds.
2. Shut down
Put the earphone into the charging chamber and turn it off automatically. Long press the left
and right earphone multifunction keys for 7 seconds to turn it off
3. Boot back
When the pairing is successful, the bluetooth headset will first enter the state of reconnect
when the second time is started and automatically reconnect the connected phone.
4. Play/pause
In standby state, click the left or right earphone multifunction button to play music directly,
while click the left or right earphone multifunction button to pause playing.
5. Switch songs
Press the left earphone muti_function button for 2 seconds to play music, and then press the
right earphone muti_function button for 2 seconds to play music.
6. Volume up and down
Double-click the left earphone multifunction button to increase the volume step by step, and
double-click the right earphone multifunction button to decrease the volume step by step
7. Answer incoming calls
When the phone calls, click on the multi-function key around earphones can answer the phone,
earphones with voice noise reduction function, make the call more clear.
8. Call hang up
When talking on the mobile phone, you can hang up the phone by clicking the left or right
earphone multifunction button.
9. Call relection
When the phone calls, long press the left and right earphone multifunction button for 2
seconds to reject the call.
1. Redial
When you are on standby or playing music, you can make the last call in your phone record by
three clicks of the left earphone multifunction button.
11. Start voice assistant
Three clicks on the right earphone multifunction button can activate apple's Siri or Google
voice assistant for voice control of the phone operation.
12. Low battery alert
When the battery of bluetooth headset is low, play the warning sound of low battery at an
interval of 30 seconds until the headset is low battery and turns off.
pairing method
1. Take out from the charging warehouse or press the left and right earphone multifunction button
for 3 seconds to start up the headset until the red and blue lights flicker alternately, enter the state of
search and pairing for the ear, enter the state of automatic pairing for the ear. After the pairing is
successful, the red and blue lights of the main ear (right ear) continue to flicker alternately, while
the blue lights of the secondary ear slowly flash, and play the prompt sound of successful pairing
for the ear.
2. 2. Start the bluetooth function of mobile phone or other devices. If it is an android phone or
device, please click the "search bluetooth device" option. When the model of the bluetooth headset
is found, click to enter pairing; After the pairing is successful, the main (right) ear will send out a
signal that the connection is successful, and the indicator lights of the left and right earphones will
turn to blue light and enter the standby state of connection. After the pairing is successful, the main
ear will be the right channel, and the secondary ear will be the left channel.
3. The two earphones can also be paired with the mobile phone independently. The lamp operation
method can be operated according to the operation method in step 2 above.
Charging operation
1. Plug one end of the Micro USB charging cable into the USB port of the charging warehouse and
plug one end of the charger to charge the charging warehouse. The will display the latest power.
2. Charge the earphone: put the earphone into the charging bin to charge it automatically. The lamp
earphone indicator is red when charging, and it will be off after being fully charged. The lamp of
the charging cabin will display the remaining power. When the headset is fully charged, the lamp of
the charging cabin will go out.
Precautions
1. Please charge in a safe environment. When charging the charging warehouse, please separate the
charging warehouse from the USB charging cable as soon as possible after the charging indicator is
off, so as to avoid damage to the charging warehouse caused by the long time of charging.
2. When the music is playing, please adjust the music to the appropriate volume to avoid long-term
damage to the hearing under the condition of high volume.
3. Try to avoid using the earphone where there is interference source, otherwise it may affect the
earphone signal.
4. Try to avoid using the earphone in a corrosive environment, so as not to affect the function of the
earphone.
Tips: when you use this bluetooth headset to listen to music or talk, please pay attention to
adjust the volume, so as not to affect your listening too much!
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer
could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
