JK Audio QuickTap User manual

QuickTap
Telephone Handset Tap
Users Guide
Telephone Interface Products
JK Audio

Connections
Install QuickTap between the handset and the
telephone base of your existing telephone.
1. Unplug the handset cord from your
telephonebase.
2. Using the black handset jumper cord that
we have provided, connect the telephone
jackofQuickTaptothehandsetjackonyour
telephonebase.
3. Plug your handset cord, and handset, into
thehandsetjackonQuickTap.
Connect your audio equipment to the line output
jack on QuickTap.
23
Operating
The Output Jack provides a mix of both sides of
the conversation. In other words, whatever you
send down the phone line will come back on this
jack mixed with the audio from the other side of
the call.
Two adapter cables are supplied with QuickTap.
One cable has 1/8" mono connectors on each end.
This cable can be used to connect QuickTap to the
line input on some powered speakers. The
second cord has a 1/8" stereo plug on one end
and an RCA mono plug on the other end. The
RCA plug is wired to the tip or left channel of the
stereo plug. The ring or right channel is not
connected. Use this cable to connect QuickTap to
powered speakers or amplifiers equipped with
RCA jacks.
QuickTap
Audio Equipment or
Powered Speakers
Telephone
Handset
Telephone Base
Phone Line

Connections
Install QuickTap between the handset and the
telephone base of your existing telephone.
1. Unplug the handset cord from your
telephonebase.
2. Using the black handset jumper cord that
we have provided, connect the telephone
jackofQuickTaptothehandsetjackonyour
telephonebase.
3. Plug your handset cord, and handset, into
thehandsetjackonQuickTap.
Connect your audio equipment to the line output
jack on QuickTap.
23
Operating
The Output Jack provides a mix of both sides of
the conversation. In other words, whatever you
send down the phone line will come back on this
jack mixed with the audio from the other side of
the call.
Two adapter cables are supplied with QuickTap.
One cable has 1/8" mono connectors on each end.
This cable can be used to connect QuickTap to the
line input on some powered speakers. The
second cord has a 1/8" stereo plug on one end
and an RCA mono plug on the other end. The
RCA plug is wired to the tip or left channel of the
stereo plug. The ring or right channel is not
connected. Use this cable to connect QuickTap to
powered speakers or amplifiers equipped with
RCA jacks.
QuickTap
Audio Equipment or
Powered Speakers
Telephone
Handset
Telephone Base
Phone Line

FCCRegistration
Your new JK Audio product has been registered with the
Federal Communications Commission (FCC). This product
complieswith thestandardsin Part68 ofthe FCC rules. The
FCCrequiresustoprovidethefollowinginformation:
1. Connection and use with the nationwide
telephonenetwork
The FCC requires that you connect this telephone
equipmenttothenationaltelephonenetworkthrough
aFCCregisteredtelephone.
This equipment may not be used with Party Line
ServiceorCoinTelephoneLines.
2. Informationforthetelephonecompany
Upon request from your local telephone company,
youarerequiredtoprovidethefollowinginformation:
a) The "line" to which you will connect the telephone
equipment(thatis,yourtelephonenumber),and
b) The telephone equipment's FCC registration
number. This can be found on the bottom of your
telephoneequipment.
3. RepairInstructions
If it is determined that your telephone equipment is
malfunctioning, the FCC requires that it not be used
Specifications
Line Output: Connector 1/8" Mono Jack
OutputImpedance 600ohms
Level 100mVRMS
Isolation 1500VRMS
HandsetandTelephoneconnectors:
Modular4pin/4wirehandsetjacks
Compatibility Note: Not all telephones are built
alike so we cannot guarantee QuickTap will work
with any handset design out there. We designed
QuickTaptoworkwithmostpopulartelephones.
QuickTap is not for use with cellular phones or
telephones that have a keypad built into the
handset.
54

FCCRegistration
Your new JK Audio product has been registered with the
Federal Communications Commission (FCC). This product
complieswith thestandards in Part68 ofthe FCC rules. The
FCCrequiresustoprovidethefollowinginformation:
1. Connection and use with the nationwide
telephonenetwork
The FCC requires that you connect this telephone
equipmenttothenationaltelephonenetworkthrough
aFCCregisteredtelephone.
This equipment may not be used with Party Line
ServiceorCoinTelephoneLines.
2. Informationforthetelephonecompany
Upon request from your local telephone company,
youarerequiredtoprovidethefollowinginformation:
a) The "line" to which you will connect the telephone
equipment(thatis,yourtelephonenumber),and
b) The telephone equipment's FCC registration
number. This can be found on the bottom of your
telephoneequipment.
3. RepairInstructions
If it is determined that your telephone equipment is
malfunctioning, the FCC requires that it not be used
Specifications
Line Output: Connector 1/8" Mono Jack
OutputImpedance 600ohms
Level 100mVRMS
Isolation 1500VRMS
HandsetandTelephoneconnectors:
Modular4pin/4wirehandsetjacks
Compatibility Note: Not all telephones are built
alike so we cannot guarantee QuickTap will work
with any handset design out there. We designed
QuickTaptoworkwithmostpopulartelephones.
QuickTap is not for use with cellular phones or
telephones that have a keypad built into the
handset.
54 Downloaded from www.Manualslib.com manuals search engine

FCC Registration (continued)
permission to connect this telephone equipment to their
telephone must first be obtained.
FCC Registration (continued)
and that it be unplugged from the modular outlet until the
problem has been corrected.
Repairs to this telephone equipment can only be
madebythemanufactureroritsauthorizedagentsor
by others who may be authorized by the FCC. For
repair procedures, follow the instructions outlined
underthewarrantysectionofthemanual.
4. Rightsofthetelephonecompany
If telephone equipment is causing harm to the
network, the telephone company may temporarily
discontinue your telephone service. If possible,
they'll notify you before they interrupt service. If
advanced notice isn't practical, you'll be notified as
soon as possible. You'll be given the opportunity to
correct the problem, and you'll be informed of your
righttofileacomplaintwiththeFCC.
Your telephone company may make changes in its
facilities, equipment, operations or procedures that
could affect the proper functioning of your JK Audio
product. If such changes are planned, you'll be
notified.
If this telephone equipment is to be used with a
telephone that is leased or owned by another party,
76

FCC Registration (continued)
permission to connect this telephone equipment to their
telephone must first be obtained.
FCC Registration (continued)
and that it be unplugged from the modular outlet until the
problem has been corrected.
Repairs to this telephone equipment can only be
madebythemanufactureroritsauthorizedagentsor
by others who may be authorized by the FCC. For
repair procedures, follow the instructions outlined
underthewarrantysectionofthemanual.
4. Rightsofthetelephonecompany
If telephone equipment is causing harm to the
network, the telephone company may temporarily
discontinue your telephone service. If possible,
they'll notify you before they interrupt service. If
advanced notice isn't practical, you'll be notified as
soon as possible. You'll be given the opportunity to
correct the problem, and you'll be informed of your
righttofileacomplaintwiththeFCC.
Your telephone company may make changes in its
facilities, equipment, operations or procedures that
could affect the proper functioning of your JK Audio
product. If such changes are planned, you'll be
notified.
If this telephone equipment is to be used with a
telephone that is leased or owned by another party,
76 Downloaded from www.Manualslib.com manuals search engine

Warranty
The model QuickTap is covered by a 2 year
warranty to be free from defective workmanship
and materials. In the event that the QuickTap
needs repair, you must call us to get an
authorization, and then carefully pack and ship it
to us. You will pay for shipping to us and we will
pay for return back to you, UPS ground. No free
repairs will be made if the defect was caused by
misuse, weather conditions, or other cause,
except for defective workmanship or materials.
THERE ARE NO EXPRESS OR IMPLIED
WARRANTIES WHICH EXTEND BEYOND THE
WARRANTY HERE MADE.
2/00
JK Audio Inc.
2701 N. 45th Road, Sandwich, IL 60548 [phone]
