JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
NO: JK/J.JK-B2A8S20P.01
Ver: V1.1
JK Smart BMS
JK-B1A8S20P/JK-B2A8S20P
User Manual
Translated by Energiepanda.com from JK’s original Chinese version
1 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
1 Overview
Li-ion battery intelligent BMS is a management system tailored for large-capacity series Li-ion battery
pack, with functions of voltage acquisition, high-current active balancing, over-charge, over-discharge,
over-current and over-temperature protection, coulomb meter, Bluetooth communication, GPS remote,
etc. It can be applied to Li-ion, lithium iron phosphate (LiFePO4), LTO and other battery types.
JK BMS relies on the energy transfer type active balancing technology with independent intellectual
property rights, which can achieve a maximum continuous 2A balancing current.
The high-current active balancing technology can maximize battery consistency, improve battery
range and slow down battery aging.
JK BMS has smart Android and IOS APPs. APP can be connected to the BMS via Bluetooth to check
the working status of the battery, modify the working parameters of the board, control the charging
and discharging switches, etc. JK BMS is small in size, simple to operate and full-featured, and can be
widely used in small sightseeing vehicles, mobility scooters, shared cars, high-power energy storage,
base stations, backup power, solar power plants, etc.
2 Main technical specifications
2.1 The main technical specifications of JK-B2A8S20P are shown in Table 1.
Table 1 JK-B1A8S20P/JK-B2A8S20P specifications
Technical Specifications
Model
B1A8S-20P/B2A8S-20P
Li-ion battery strings 3~8
LiFePO4 battery strings 4~8
LTO battery strings Not support
Balancing Mode Active Balancing
Balancing Current 1A(JK-B1A8S20P)/2A(JK-B2A8S20P)
The Main Circuit
Resistance
0.3mΩ
Continuous Discharge
Current 200A
2 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
Maximum Discharge
Current 350A
Overcurrent Protection
(Adjustable)
10~200 A
Other Interfaces RS485(customized)/CAN(customize
d)/ Heating(customized)/ LCD
display
Port Type Common Port
Single Cell Voltage
Range 1~5 V
Voltage Acquisition
Accuracy ±5 mV
Overcharge Protection
Voltage 1.2~4.35 V Adjustable
Overcharge Release
Voltage 1.2~4.35 V Adjustable
Overcurrent Release
Time 2~120S Adjustable
Over-discharge
Protection Voltage 1.2~4.35 V Adjustable
Over-discharge
Recovery Voltage 1.2~4.35 V Adjustable
Temperature Detection
Ports 3
Temperature Protection Yes
Short Circuit Protection Yes
Coulometer Yes
Bluetooth Support android phone / iPhone
Gps ports Support
2.2 Environmental conditions of use
3 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
a) Operating Temperature Range：-20℃～70℃；
b) Power requirements：10~40V。
c) Power consumption: 25mA@40V in balanced state, 20mA@40V in unbalanced state
3Connector and interface decription
3.1 Connectors, LED light location description
Figure 1 - JK-B1A8S20P/JK-B2A8S20P Connector
4 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
3.2 Connectors and LED definition description
Table 2 Connectors, LED Definition
Connector
Pin Number
JK-B2A8S20P
Name
Definition
P1
1
B
-
Negative battery terminal
2
B1
P
ositive pole of #1 cell
3
B2
Positive
pole of #2 cell
4
B3
Positive
pole of #3 cell
5
B4
Positive
pole of #4 cell
6
B5
Positive
pole of #5 cell
7
B6
Positive
pole of #6 cell
8
B7
Positive
pole of #7 cell
9
B8
Positive
pole of #8 cell
10
B+
BMS power
supply
P2
Heating port
P3
Display connector
P4
External GPS module connector
P5
RS485/CAN connector(Choose
one of two)
P6
1
T1A
The first temperature sensor A pin
2
T
1B
The first temperature sensor
B pin
3
T2A
The second temperature sensor A pin
4
T2B
The second temperature sensor
B pin
D1
Bluetooth connection indicator. The indicator light is always on when the Bluetooth is
connected to the BMS, and the indicator light flashes when the connection is disconnected.
C
-
Connect to external load or negative pole of charger
B
-
Connect the negative pole of the battery
5 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
3.3 Product appearance
Figure 2JK-B1A8S20P/JK-B2A8S20P Appearance
6 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
3.4 Product size
The dimensions of JK-B2A8S20P is 153 mm x 126 mm x 17.6 mm.
Figure 3 B2A8S20P Size
3.5 Weight
The weight of JK-B1A8S20P/JK-B2A8S20P BMS is 349g.
7 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
4Installation method and precautions
4.1 Open box inspection and precautions are as follows.
a) The boxes and BMS should be handled lightly and not inverted as much as possible.
b) Before opening the box, pay attention to whether the packaging is intact, such as whether
there are signs of impact, whether there is damage, etc.；
4.2 Wiring Diagram
The wiring of 4S and 8S is shown in Figure 4 and Figure 5.
Figure 4 4S battery wiring diagram
8 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
Figure 5 8S battery wiring diagram
9 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
4.3 APP installation
The QR code shown in Figure 6 can be scanned to obtain the mobile app that accompanies
the product.
Figure 6 QR code for APP download
5Instructions for use
5.1 Preparation and inspection before use
Before turning on the power supply, please make sure again that the cable connection is correct,
that the power supply provided to the battery management system is within the required range,
that the device is properly placed, that the circuit board is short-circuited, and so on, that the
power supply of the battery management system can only be connected after making sure that it
is correct, otherwise it may cause serious consequences such as abnormal work or even burning
down.
5.2 BMS power up
After confirming the above operation is correct, you can power on the BMS, which has no
power-on control switch and is designed for charging and activation mode (charger voltage is
5V higher than the battery voltage).
The BMS has no power-on control switch and is designed for charging activation mode
10 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
(charger voltage is 5V higher than the battery voltage), i.e., after the battery assembly is
completed, the charger needs to be connected to make the BMS power on and work.
5.3 APP APP operation instructions
5.3.1 Connect to BMS and set password
a) Connect to BMS
Firstly, turn on the Bluetooth on your phone, then open the app as shown in Figure
7. Click the icon on the top left corner to scan the device, wait until the scanning is
finished, then click the name of the device you need to connect, such as "JK-
B2A8S20P". When you connect for the first time, the APP will prompt you to
input the password, the default password of the device is "1234" (the password of
the setting parameter is "123456").
The APP will automatically record the password after the device is connected, so
you don't need to enter the password for the next connection, and the device will be
connected automatically after the APP is opened.
The password input interface is shown in Figure 8.
Figure 7 Scan Device Figure 8 Enter Password
11 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
b) Change passwords and device name
Click the "pen" icon on the right side of the device list to change the device name
and password.
Note that the device name only supports English or numbers.
The interface for changing the password is shown in Figure 9. To change the
device password, you must first enter the old password, and only if the current
password is correct then you can set the new password. After entering the new
password twice, click 'OK' to finish
Figure 9 Change the device name Figure 10 Change the password
12 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
5.3.2 Battery status view
The real-time status screen is shown in Figure 11.
Figure 11 Real-time status screen
Zone 1 in the figure is the comprehensive information column of the battery. The parameters of
each parameter are explained as follows.
a) Runtime
The total runtime from when the BMS was first powered on until now.
b) Charge
It’s the status of BMS charging MOS. When "On" is displayed, it means the current
BMS charging MOS is on and the battery is allowed to be charged; when "Off" is
displayed, it means the current BMS charging MOS is off and the battery is not allowed
to be charged。
13 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
c) Discharge
It’s the status of the BMS discharge MOS. When "On" is displayed, it means the BMS
discharge MOS is on and the battery is allowed to discharge; when "Off" is displayed, it
means the BMS discharge MOS is off and the battery is not allowed to discharge.
d) Balance
It indicates the state of BMS Balance switch. When "On" is displayed, the BMS will balance the
battery automatically when the balance trigger condition is reached; when "Off" is displayed, it means
the balance is off and the BMS will not balance the battery.
e) Voltage
The voltage displays the total voltage of the battery in real time, and the total voltage is the sum
of all individual cell voltages.
f) Current
The current shows the total battery current in real time. When the battery is charging, the current is
positive, and when the battery is discharging, the current is negative.
g) Battery Power
Indicates the real-time power of the battery output or input, and its value is the current battery voltage
multiplied by the current.
h) Remain Battery
Percentage of remaining battery capacity
i) Battery Capacity
It’s the actual battery capacity calculated by the BMS. (This value is updated only after the
battery has done a complete discharge and charge cycle).
j) Remain Capacity
It represents the current remaining capacity of the battery. Unit: AH
k) Cycle Capacity
Cycle capacity indicates the cumulative discharge capacity of the battery, unit: AH.
l) Cycle Count
It indicates the number of times the current battery has been charged.
m) Ave. Cell Volt
It indicates the current single cell average voltage of the battery. Unit: V.
n) Cell Volt. Diff
It indicates the difference between the highest cell voltage and the lowest cell voltage of the
current whole battery. Unit: V
o) Balance Curr.
14 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
When the BMS turns on the balancing function and the balancing condition is reached, the balancing
current display area shows the balancing current in real time, unit: A.
When the balancing is in progress, the real-time status of the single unit voltage display area, blue
represents the discharged battery, red represents the battery being charged. The negative balance current
indicates that the battery is discharging, at this time blue flashes, and the positive balance current
indicates that the battery is charging, at this time red flashes.
JK BMS adopts active balancing technology. The principle of balancing is to take power from the high
voltage cell, store it in the BMS, and then discharge it to the low voltage cell.。
p) MOS Temp
Display the temperature of MOS in °C.
q) Battery T1
“NA” is displayed if temperature sensor 1 is not installed. If the temperature sensor 1 is installed, it is
displayed in real time in °C.
r) Battery T2
“NA” is displayed if temperature sensor 2 is not installed. If the temperature sensor 2 is installed, it is
displayed in real time in °C.
Zone 2 in the figure shows the cell voltage area. The voltage data of each cell in the pack is
displayed in real time, where red indicates the cell with the lowest voltage and blue indicates the
cell with the highest voltage.
Zone 3 of the diagram is to display the resistances of balancing wires. The balance wire resistance
is the balance line resistance obtained from the BMS self-test, the value is only a preliminary
calculation, the purpose is to prevent the wrong connection or poor contact, when the balance
wire resistance exceeds a certain value, the display will be yellow, then can not open the balance.
15 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
Parameter Setting
The parameter setting page is shown in Figure 12.
Figure 12 Parameter setting page display
If you need to modify the working parameters of the BMS, you must first click the "Authorize
Settings" button and enter the parameter setting password to verify the parameter setting authority.
The factory default password for parameter setting is "123456". You can only modify the
parameters of the BMS after entering the password correctly. The parameter setting password and
the device Bluetooth connection password are independent of each other.
The parameters of the BMS can be modified in the parameter setting page, and the definitions of
each parameter are as follows.
16 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
a) Li-ion buttion
Click this button to change all the working parameters of BMS to Li-ion parameters, and the
default values of Li-ion battery parameters are shown in the Appendix.
b) LiFePO4 button
Click this button to modify all working parameters of BMS to LiFePO4 battery parameters,
the default values of LiFePO4 battery parameters are shown in the appendix.
c) LTO button
Click this button can change all the working parameters of BMS to LTO parameters. The
default values of LTO battery are shown in the Appendix.
d) Cell Count
Cell count indicates the number of cells in the current battery pack, please set the value accurately
before use, otherwise the BMS will not work properly.
e) Battery Capacity(Ah)
This value is the design capacity of the battery.
f) Balance Trig. Volt.(V)
With the balancing function enabled, when the maximum voltage difference of the cell pack
exceeds this value and the current cell voltage exceeds the balancing start voltage, the BMS
starts balancing the cell until the differential voltage is lower than this value or the cell voltage
is lower than the balancing start voltage. For example, if you set the balancing trigger voltage
difference to 0.01V, balancing will start when the cell pack voltage difference is greater than
0.01V and end when it is lower than 0.01V.
(It is recommended to set the balancing trigger differential to 0.005V for cells above 50AH and
0.01V for cells below 50AH).
g) Calibrating Volt.(V)
The voltage calibration function can be used to calibrate the accuracy of the BMS voltage collection.
When you find an error between the collected voltage and the actual voltage of the battery, you can use
the voltage calibration function to calibrate the BMS.
To calibrate, fill in the current manually measured battery voltage, and then click the 'Set' button next to
Voltage Calibration to complete the calibration.
h) Calibrating Curr.(A)
17 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
The current calibration function can be used to calibrate the accuracy of the BMS current
collection.
When you find an error between the total current collected by the BMS and the actual current
of the battery, you can use the current calibration function to calibrate the BMS.
To calibrate, fill in the current measured battery current, and then click the 'Set' button next to
Current Calibration to complete the calibration.
i) Cell UVP(V), Cell UVPR(V)
The “Cell UVP(V)” is cell under-voltage protection which refers to the cut-off voltage of the cell.
Whenever the voltage of any cell in the battery pack is lower than this value, the 'cell under-voltage
alarm' is generated, and the BMS turns off the discharge MOS at the same time, so the battery cannot
be discharged and can only be charged. After the alarm is generated, only when all the cell voltage
value exceeds the value of “Cell UVPR(V)” which means cell under-voltage protection recovery,
BMS will release the 'cell under-voltage alarm' and turn on the discharge MOS.
j) Cell OVP(V), Cell OVPR(V)
"Cell OVP(V)" is cell over-voltage protection. As long as the voltage of any cell exceeds this value,
the "Battery Over-voltage Alarm" will be generated and the BMS will turn off the charging MOS at
the same time, so the battery cannot be charged, but only discharged. After the alarm is generated,
only when the voltage of all cells is below the "Cell OVPR(V)" value, the BMS will release the
"Battery Over-voltage Alarm" and turn on the charging MOS.
k) Power Off Vol.(V)
The “Power Off Vol.(V)” indicates the minimum voltage at which the BMS will operate and the BMS
will shut down when the highest voltage of the cell in the battery pack falls below this value. This value
must be lower than the "cell under-voltage protection".
l) Max Charge Curr.(A), Charge OCP Delay(S), Charge OCPR Time(S)
When charging the battery pack, the current exceeds the "MAX Charge Curr.(A)" and the duration
exceeds the "Charge OCP Delay(S)" time, the BMS generates a "charge over-current alarm" and turns
off the charging MOS. After the time of "Charge OCPR Time(S)", the BMS will release the charge
over-current alarm and turn on the charging MOS again.
Example: Set the "Max Charge Curr.(A)" to 10A, "Charge OCP Delay(S)" to 10 seconds, and "Charge
OCPR Time(S)" to 50 seconds. If the charging current exceeds 10A for 10 seconds in a row during
charging, the BMS will generate a 'charging over-current alarm' and turn off the charging MOS at the
same time. 50 seconds after the alarm is generated, the 'charging over-current alarm' will be released
and the BMS will turn on the charging MOS again.
18 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
m) Max Discharge Curr.(A), Discharge OCP Delay(S), Discharge OCPR Time(S)
When discharging the battery pack, the current exceeds the "Max Discharge Curr.(A)" and the duration
exceeds the "Discharge OCP Delay(S)" time, the BMS generates the "discharge over-current alarm" and
turns off the discharge MOS at the same time. After the time of "Discharge OCPR Time(S)", BMS will
release the "Discharge Over-current Alarm" and turn on the Discharge MOS again.
Example: Set the " Max Discharge Curr.(A)" to 100A, " Discharge OCP Delay(S) " to 10 seconds, and "
Discharge OCPR Time(S)" to 50 seconds. If the discharge current exceeds 100A for 10 seconds, the
BMS will generate the 'discharge over-current alarm' and turn off the discharge MOS. 50 seconds after
the alarm is generated, the 'discharge over-current alarm' will be released and the BMS will turn on the
discharge MOS again.
n) SCP Delay(us), SCPR Time(S)
When short-circuit protection occurs, the short-circuit protection is released after the time set by “SCPR
Time(S)”..
o) Start Balance Vol.(V)
The Start Balance Vol.(V) is used to control the voltage phase of balancing. Balancing will be triggered
only when the cell voltage exceeds this value and the maximum voltage difference between the cells
exceeds the balancing trigger voltage difference.
p) Max Balance Cur.(A)
The balancing current indicates the continuous current of discharging the high-voltage cell and charging
the low-voltage cell during the energy transfer. The Max Balance Cur.(A) indicates the maximum
current in the energy transfer process, and the maximum balancing current should not exceed 0.1C.
For example: The balancing current for 20AH battery should not exceed 20*0.1=2A.
q) Charge OTP(℃), Charge OTPR(℃)
When the battery temperature exceeds the " Charge OTP(℃)" value during charging, the BMS
generates the "Charge Over Temperature Protection" alarm and turns off the charging MOS. When the
temperature falls below the " Charge OTPR(℃)", the BMS release the "Charge Over Temperature
Protection" alarm and turns on the charging MOS again.
r) Charge UTP(℃), Charge UTPR(℃)
When the battery temperature is lower than the "Charge UTP(℃)" value during charging, the BMS
generates the "charge low temperature protection" alarm and turns off the charging MOS. When the
temperature is higher than " UTPR(℃)", BMS will release the 'charge low temperature protection' alarm
and turn on the charging MOS.
19 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.

JK Smart BMS JK-B1A8S20P/JK-B2A8S20P User Manual
s) MOS OTP(℃), MOS OTPR(℃)
When the MOS temperature exceeds the "MOS OTP(℃)" value, the BMS generates the "MOS
over-temperature" alarm and turns off the charging and discharging MOS, so the battery cannot
be charged or discharged. After the MOS temperature is lower than the " MOS OTPR(℃)" value,
the BMS will release the "MOS over-temperature" alarm and turn on the charging and
discharging MOS at the same time (the MOS over-temperature protection value is 75℃and the
MOS over-temperature recovery value is 65℃, these two values are the factory default values
and cannot be changed).
Attention.
Any parameter modification, please refer to the manual, inappropriate parameters may make the
BMS not work normally, or even burn the BMS. After any parameter modification, you need to
click the "Set" button to finish sending the parameter, and the protection board will make a "tick"
sound when it receives the parameter successfully.
BMS control page
The BMS control page is shown in Figure 13. The BMS control allows you to switch on/off and
restore factory settings for the charging function, discharging function, and balancing function of
the BMS.
20 /22
Energiepanda.com, providing you with quality accessories for DIY batteries.
