JK J46472 Quick start guide

Operation and Installation Guide
Please carefully read all information within this guide
prior to use of the solar charging screen.
JK Solar
Charging
Screen

II JK Solar Charging Screen: Installation and Operation Guide
Step-by-step user instructions 1
Box contents 1
Folding the solar screen away 1
Internal installation 2
Device charging 2
External installation 3
Leisure battery charging 3
Warranty 4
Technical information 4
Purchase information 5
Contents

1JK Solar Charging Screen: Installation and Operation Guide
6 x suction cups
The screen folds up into its own carry case for easy storage under a seat or in a cupboard.
The carry handles mean you can take it with you wherever you need power.
Solar charging screenInside the box
Charging dock
(inside zip panel)
Crocodile clips 12v power socket
01.
04.
02.
05.
03.
06.
For instructions on installation and connecting the Solar Screen to your devices
and vehicle / leisure battery please see the following pages.
JK SOLAR CHARGING SCREEN
STEP-BY-STEP USER
INSTRUCTIONS
Box contents
Folding the solar screen away

2JK Solar Charging Screen: Installation and Operation Guide
Slide the base of the solar panel
(cells facing up) to the base of
the windscreen.
To secure the suction cup push
the handle down and to release
pull handle up.
Once the suction
cups are in place, you
can simply hook the
eyelets at the top of
the solar panel over
them.
Due to the solar
panels design, it
is not necessary
to have a perfect
fit across the
windscreen.
Suction cups can be
pre-placed then the
solar panel can be
hooked into place or…
…you can place the suction cup in the eyelet
before placing on the windscreen for a
more accurate fit.
Internal installation (ideal if you are not in the vicinity of the vehicle)
01.
04.03.
02.
There are two USB B
charging slots.
One USB C charging slot and a DC charging port, which is used for the
Battery charger (see opposite).
Device charging
01. 02.
JK SOLAR CHARGING SCREEN
STEP-BY-STEP USER
INSTRUCTIONS

3JK Solar Charging Screen: Installation and Operation Guide
Unfold the solar screen lengthways
across the windscreen.
Once the top section is in place,
unfold the rest of the screen and
attach the bottom suction cups,
angling them outwards to prevent
wind moving the solar panel.
When all the suction
cups are in place, you
are ready to start using
the solar screen.
We would recommend
you take the cable
inside your vehicle and
close the door to keep
your devices safe.
Fold the top third of the
solar screen up the
windscreen.
Fasten the suction cups and hook them
into the eyelets.
External installation (ideal if you are staying in the vicinity of the vehicle)
01.
04. 05.
03.02.
Connect either the crocodile
clips or the 12v charger into
the DC charging port on the
charging dock.
The crocodile clips can
be connected to either
the main vehicle battery
or leisure battery.
Black clip to negative,
red clip to positive.
The 12v charger can be used
with any compatible device.
(Please check your compatibility)
The screen will charge all 12 volt batteries pulling at a maximum of 2 amps to protect your battery.
The unit is ideal for trickle charging, however a 75 amp/hour battery will charge from flat to full in 37 hours.
Leisure / vehicle battery charging
01. 02.
03.

4JK Solar Charging Screen: Installation and Operation Guide
TECHNICAL INFORMATION
Warranty
This product is covered by a limited warranty of 12 months from the date of purchase
against manufacturing faults and defects.
This excludes malfunctions that are a result of improper installation,
use or modification.
In the event of a fault please contact:
Just Kampers Customer Services on 01256 86 22 88
Model: JK Solar Charging Screen
JK Part number: J46472
OEM Part number: OEM PART NUMBER JKSOLSC
Dimensions (packed): 300 mm x 370 mm x 60 mm
Dimensions (unfolded): 1,582 mm x 890 mm x 5 mm
Power output: 120 wh
Charging ports
USB B: x2
USB C: x1
DC: x1
Product weight: 3.5 kg
Inspection/certification:

5JK Solar Charging Screen: Installation and Operation Guide
Purchase information
NB. Please note your warranty runs from date of purchase and NOT date of installation.
DATE OF PURCHASE:
ORDER NUMBER:
We hope you enjoy your Just Kampers product.
To see our full range please visit justkampers.com
If you wish to finally dispose of this product, please ask your local recycling centre
or specialist dealer for information on how to do this in accordance with the
appliance disposal regulations in your area.

w: justkampers.com | e: [e-mail] | t: 01256 862 288
Just Kampers Unit 1, Stapeley Manor, Long Lane, Odiham, Hampshire, UK RG29 1JE
