JL Audio Stealthbox SB-F-TRKCTR/10W3 User manual

Sheet SKU#011113 Revision 9/4/01
SB-F-TRKCTR/10W3, JL AUDIO, Inc 1999 • Page 1
SB-F-TRKCTR/10W3 Stealthbox™
Fits Full-Size Ford Pickup Trucks Equipped
with a Center Console
Installation Guide:
This Stealthbox is a product which requires professional installation skills and tools. Please read this
installation guide thoroughly before beginning the project. It will guide you step by step through the
installation. Several of the steps in this process may require two people to accomplish.
It is absolutely vital that the enclosure be properly mounted to the vehicle according to these instruc-
tions. Failure to mount the enclosure properly presents two problems: 1) The sub-bass performance
will suffer due to the movement of the enclosure caused by the force exerted by the woofer and 2) A
loose enclosure presents a serious safety hazard in the event of a collision or sudden deceleration.
STEP 1: Remove the rubber pad & cup holder from the factory center console.
STEP 2: Remove the four nuts holding the console to
the floor. There are two in the front edge and two in the
back edge of the console..
Cup holder size may differ depending on vehicle
year.

Sheet SKU#011113 Revision 9/4/01
SB-F-TRKCTR/10W3, JL AUDIO, Inc 1999 • Page 2
STEP 3: Remove the console from the vehicle.
STEP 4: Cut the carpet between each set of mounting
studs in the vehicle. The Stealthbox should sit directly on
the metal floor of the vehicle.
STEP 5: Remove the six screws holding the outer shell of the console to the storage unit. There are two
screws in the cup holder and two in each side near the bottom of the unit. Remove the outer shell.
STEP 6: Place the outer shell over the Stealthbox. Bolt the shell to the Stealthbox using the six factory
screws.
IMPORTANT: Only screw into the predrilled holes in the Stealthbox, do not drill new holes!

Sheet SKU#011113 Revision 9/4/01
P.O. Box 839004, Miramar, Florida 33083-9004 Voice: [phone] Fax: [phone]
SB-F-TRKCTR/10W3, JL AUDIO, Inc 1999 • Page 3
This completes the installation.
Specifications:
Enclosure Type: Acoustic Suspension (Sealed)
Driver Type: JL AUDIO 10W3-D6 Subwoofer
Cont. Power Handling: 250 Watts
Nominal Impedance: 3Ω
STEP 7: Run speaker wire to the mounting location of the
Stealthbox. Trim to length and attach to the Stealthbox.
STEP 8: Test the operation of the enclosure.
STEP 9: Place the Stealthbox in the vehicle. The brackets on the
bottom of the Stealthbox should fit over the studs in the floor of the
vehicle.
STEP 10: Using the nuts removed in Step 2, bolt the Stealthbox
into place. This step will require an open end wrench. Tighten
securely.
