JL Audio 6W3v3-4 User manual

6W3v3-4 / 6W3v3-8
Subwoofers
owner’s manual
Congratulations on your purchase of a JL Audio subwoofer component. Your JL Audio subwoofer is a
precision loudspeaker which has been engineered to produce the highest quality sub-bass performance
in your vehicle. Authorized JL Audio dealers have extensive technical information for many different
applications of your new speaker. They also have the knowledge, skills and tools to build a high-quality
enclosure that will maximize the performance of your speaker. We highly recommend that you have your
enclosure built by an authorized JL Audio dealer.
Inside you will find specifications and two recommended enclosures for your speaker; one is a sealed
enclosure, the other is a ported design. Both types of enclosures will give you excellent sound quality and
low-frequency extension. The sealed enclosure is a better choice if space is extremely tight, but the ported
enclosure will produce 3dB more output at the same power if you have the extra space to work with.

A
C
D
B
E
SUBWOOFER 6W3v3-4 6W3v3-8
Free Air Resonance (Fs): 41.80 Hz 44.05 Hz
Electrical “Q” (Qes): 0.533 0.666
Mechanical “Q” (Qms): 11.027 10.291
Total Speaker “Q” (Qts): 0.508 0.625
Equivalent Compliance (Vas): 0.181 ft³
5.13 litres
0.178 ft³
5.04 litres
One-way, Linear Excursion (Xmax)*: 0.35 in.
8.89 mm
0.35 in.
8.89 mm
Efficiency (1W/1m)**: 80.49 dB 80.13 dB
Effective Piston Area (Sd): 17.36 in²
0.0112 m²
17.36 in²
0.0112 m²
DC Resistance (Re): 3.476 ohm 7.917 ohm
Nominal Impedance: 4 ohm 8 ohm
Power Handling (continuous): 150W 150W
* Xmax specifications are derived via one-way voice coil overhang
method with no correction factors applied.
** Efficiency (1W/1m) is not an accurate indicator of a subwoofer’s
output capability and should not be used as a comparison to other
subwoofers to determine which one is “louder” !
6W3v3 SUBWOOFER PHYSICAL
SPECIFICATIONS
Nominal Diameter: 6.5 in.
165 mm
Overall Diameter (A): 6.85 in.
174 mm
Mounting Hole Diameter (B): 5.5 in.
140 mm
Bolt Hole Circle (C): 6.125 in.
156 mm
Magnet Diameter (D): 4.25 in.
108 mm
Mounting Depth (E): 4.25 in.
108 mm
Net Weight: 6.1 lbs
2.8 kgs
Driver Displacement: 0.02 ft³
0.57 litres
JL AUDIO 6W3v3-4 / 6W3v3-8

JL AUDIO 6W3v3-4/6W3v3-82

SUBWOOFER RECOMMENDED SEALED ENCLOSURES
Volume
(net int.)
External Dimensions
(Width x Height x Depth)
F3
(Hz)
Fc
(Hz) Qtc
6W3v3-4 0.15 ft³
4.2 litres
9 in. x 9 in. x 6.750 in.
229 mm x 229 mm x 171 mm 34 60.06 0.729
6W3v3-8 0.15 ft³
4.2 litres
9 in. x 9 in. x 6.750 in.
229 mm x 229 mm x 171 mm 35 64.10 0.894
All specifications are subject to change without notice.
SUBWOOFER RECOMMENDED PORTED ENCLOSURES
Volume
(net int.)
External Dimensions
(Width x Height x Depth)
SlotPortSpecs
Slot Area x Slot Length
Rec. Slot Port Int. Dims.
(Slot Width x Slot Height x Slot Length)
F3
(Hz)
Tuneto:
(Hz)
6W3v3-4 0.25 ft³
7.1 litres
14 in. x 9.75 in. x 5.25 in.
356 mm x 248 mm x 133 mm
2.125 in² x 12.25 in.
14 cm² x 311 mm
4.25 in. x 0.5 in. x 12.25 in.
108 mm x 13 mm x 311 mm 36.6 38
6W3v3-8 0.25 ft³
7.1 litres
14 in. x 9.75 in. x 5.25 in.
356 mm x 248 mm x 133 mm
2.125 in² x 12.25 in.
14 cm² x 311 mm
4.25 in. x 0.5 in. x 12.25 in.
108 mm x 13 mm x 311 mm 36.6 38
!! CAUTION !!
Prolonged exposure to sound pressure levels in excess of 100dB can cause
permanent hearing loss. This high-performance speaker can exceed this level.
Please exercise restraint in its operation in order to preserve your ability to enjoy
its fidelity.
When installing a subwoofer in your vehicle, it is extremely important to secure
the enclosure firmly. We recommend bolting the enclosure through the metal
of the floorpan or the frame of the vehicle with large diameter washers for
reinforcement. If an enclosure is not firmly attached, it can become a projectile
in a collision. This is particularly important in a hatchback, station wagon, sports
utility vehicle, or van.
     external
1/2" (13mm) thick

than 1/2" (13mm)

All enclosure volumes listed are net internal volumes!

        
      

  two    
double   
two times the
recommended port(s).
        
bi-amplified system  

passive crossover (coil)

JL AUDIO 6W3v3-4/6W3v3-8 3

MEDIUM GRAY (MINIMUM):
From a reliability standpoint, this zone
represents a very comfortable operating
power range for each driver. This level
of power will not stress the woofer but
will not extract all of its performance
potential, either.
Use of less than the minimum power
level will not damage the woofer, but may
result in unsatisfactory performance.
LIGHT GRAY (OPTIMUM):
This zone represents the best
compromise between long-term
reliability, high-output and low-distortion
performance. This power level is lower
thanthewoofer’scontinuouspowerrating
(as published in its specifications), but
you will still be taking advantage of the
woofer’s, low-distortion performance
range without undue risk of failure.
DARK GRAY (MAXIMUM):
Slightly more SPL will be gained by
pushing the power into this zone, but
typically not more than 2dB,compared to
the light gray zone.The subwoofer driver
is designed to operate safely up to this
power range, but not beyond. Operate
with caution.
BLACK (WARRANTY VOID):
We do not recommend operating
woofers at this level of power. In this
zone, there is a very high probability that
the driver will fail due to excessive heat
and/or mechanical stress.
Subwoofer drivers operated
at these levels of power are NOT
covered under warranty.
MINIMUM OPTIMUM MAXIMUM
LEGEND:
WARRANTY VOID
6W3v3
50W 100W 200W 400W25W

a period of one (1) year
           
     
  
             

This warranty is not transferable and applies only to the original
purchaserof theproductfromanauthorizedJLAUDIOdealer. Warrantyis
voidedifthefactory-appliedproductserialnumberisremovedordefaced.









If you need service on your JL AUDIO product:


    
           

        
           
           
              

RECOMMENDED CONTINUOUS (RMS) POWER RANGE FOR ONE SUBWOOFER DRIVER:
